CKD AF3000 Large Main Line Filter (P/S/M/X, 16 to 256 m3/min)

CKD AF3000 Large Main Line Filter (P/S/M/X, 16 to 256 m3/min)

CKD AF3000 series large main line filter for compressor outlets, 16 to 256 m3/min (ANR) with JIS 10K flanged connection, also built in outdoor specification (option O).

Key features

  • Four element types: P pre-filter (3 um), S oil removal (0.3 um), M high-performance oil mist (0.01 um), X activated carbon
  • Flow classes 16 to 256 m3/min (ANR) with 1 to 16 elements; flanges 2B to 8B (JIS 10K)
  • Differential pressure gauge GA5102-S11 and drain discharger 5100-4C-MG standard (not on X type)
  • Outdoor specification by option O; options H/K/L/L1/X1/Y2 not multiplied
  • Made-to-order product; consult CKD for delivery

Specifications

Fluid Compressed air
Operating pressure 0.07 to 1.0 MPa
Proof pressure 1.5 MPa
Ambient temperature 5 to 60 C (X type 5 to 30 C)
Connection JIS 10K flange 2B-8B
Body material SS400
Source CKD Korea catalog CC-1276K, p. 96-97
AF3016P-50-O Element: P pre-filter 3 um | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032P-80-O Element: P pre-filter 3 um | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048P-100-O Element: P pre-filter 3 um | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064P-100-O Element: P pre-filter 3 um | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080P-150-O Element: P pre-filter 3 um | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096P-150-O Element: P pre-filter 3 um | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128P-150-O Element: P pre-filter 3 um | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160P-200-O Element: P pre-filter 3 um | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192P-200-O Element: P pre-filter 3 um | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256P-200-O Element: P pre-filter 3 um | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3016S-50-O Element: S oil removal 0.3 um | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032S-80-O Element: S oil removal 0.3 um | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048S-100-O Element: S oil removal 0.3 um | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064S-100-O Element: S oil removal 0.3 um | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080S-150-O Element: S oil removal 0.3 um | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096S-150-O Element: S oil removal 0.3 um | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128S-150-O Element: S oil removal 0.3 um | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160S-200-O Element: S oil removal 0.3 um | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192S-200-O Element: S oil removal 0.3 um | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256S-200-O Element: S oil removal 0.3 um | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3016M-50-O Element: M oil mist 0.01 um | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032M-80-O Element: M oil mist 0.01 um | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048M-100-O Element: M oil mist 0.01 um | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064M-100-O Element: M oil mist 0.01 um | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080M-150-O Element: M oil mist 0.01 um | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096M-150-O Element: M oil mist 0.01 um | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128M-150-O Element: M oil mist 0.01 um | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160M-200-O Element: M oil mist 0.01 um | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192M-200-O Element: M oil mist 0.01 um | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256M-200-O Element: M oil mist 0.01 um | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3016X-50-O Element: X activated carbon | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032X-80-O Element: X activated carbon | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048X-100-O Element: X activated carbon | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064X-100-O Element: X activated carbon | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080X-150-O Element: X activated carbon | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096X-150-O Element: X activated carbon | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128X-150-O Element: X activated carbon | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160X-200-O Element: X activated carbon | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192X-200-O Element: X activated carbon | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256X-200-O Element: X activated carbon | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
Air FiltersCKD
40 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD AF3000 Large Main Line Filter (P/S/M/X, 16 to 256 m3/min)

Brand CKD·Air Filters

Available part numbers (40)

AF3016P-50-O, AF3032P-80-O, AF3048P-100-O, AF3064P-100-O, AF3080P-150-O, AF3096P-150-O, AF3128P-150-O, AF3160P-200-O, AF3192P-200-O, AF3256P-200-O + 30 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AF3016P-50-OElement: P pre-filter 3 um | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032P-80-OElement: P pre-filter 3 um | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048P-100-OElement: P pre-filter 3 um | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064P-100-OElement: P pre-filter 3 um | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080P-150-OElement: P pre-filter 3 um | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096P-150-OElement: P pre-filter 3 um | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128P-150-OElement: P pre-filter 3 um | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160P-200-OElement: P pre-filter 3 um | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192P-200-OElement: P pre-filter 3 um | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256P-200-OElement: P pre-filter 3 um | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3016S-50-OElement: S oil removal 0.3 um | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032S-80-OElement: S oil removal 0.3 um | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048S-100-OElement: S oil removal 0.3 um | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064S-100-OElement: S oil removal 0.3 um | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080S-150-OElement: S oil removal 0.3 um | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096S-150-OElement: S oil removal 0.3 um | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128S-150-OElement: S oil removal 0.3 um | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160S-200-OElement: S oil removal 0.3 um | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192S-200-OElement: S oil removal 0.3 um | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256S-200-OElement: S oil removal 0.3 um | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3016M-50-OElement: M oil mist 0.01 um | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032M-80-OElement: M oil mist 0.01 um | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048M-100-OElement: M oil mist 0.01 um | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064M-100-OElement: M oil mist 0.01 um | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080M-150-OElement: M oil mist 0.01 um | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096M-150-OElement: M oil mist 0.01 um | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128M-150-OElement: M oil mist 0.01 um | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160M-200-OElement: M oil mist 0.01 um | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192M-200-OElement: M oil mist 0.01 um | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256M-200-OElement: M oil mist 0.01 um | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3016X-50-OElement: X activated carbon | Flow: 16 m3/min | Flange: 2B | Spec: Outdoor (O)
AF3032X-80-OElement: X activated carbon | Flow: 32 m3/min | Flange: 3B | Spec: Outdoor (O)
AF3048X-100-OElement: X activated carbon | Flow: 48 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3064X-100-OElement: X activated carbon | Flow: 64 m3/min | Flange: 4B | Spec: Outdoor (O)
AF3080X-150-OElement: X activated carbon | Flow: 80 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3096X-150-OElement: X activated carbon | Flow: 96 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3128X-150-OElement: X activated carbon | Flow: 128 m3/min | Flange: 6B | Spec: Outdoor (O)
AF3160X-200-OElement: X activated carbon | Flow: 160 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3192X-200-OElement: X activated carbon | Flow: 192 m3/min | Flange: 8B | Spec: Outdoor (O)
AF3256X-200-OElement: X activated carbon | Flow: 256 m3/min | Flange: 8B | Spec: Outdoor (O)
