CKD 4F1/4F3-NM NAMUR 5-Port Solenoid Valve (Selex)

CKD 4F1/4F3-NM NAMUR 5-Port Solenoid Valve (Selex)

CKD 4F1/4F3-NM pilot operated 5-port Selex solenoid valves with NAMUR interface (Rc1/4) for direct mounting on rotary valve actuators.

Key features

  • NAMUR mounting face, piping ports Rc1/4 (C1/C2 on NAMUR face not threaded)
  • 2-position single or double solenoid
  • Wiring: DIN terminal box, grommet, conduit lead wire or IP65 round terminal box types
  • Outdoor version (W, round terminal box only) and surge killer (S) options
  • Flow C: 1.6 (4F1-NM), 3.1 dm3/(s.bar) (4F3-NM)
  • Lamp types BL/GL not available for DC12V

Specifications

Valve type Pilot operated soft spool valve
Fluid Compressed air
Max. operating pressure 1.0 MPa
Min. operating pressure 0.1 MPa
Proof pressure 1.5 MPa
Ambient temperature -10 to 60°C
Port NAMUR, Rc1/4
Manual override Locking (standard)
Source CKD Korea catalog CB-023SK-9, p. 1480-1485
4F110-NM-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F110-NM-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F110-NM-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F110-NM-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F110-NM-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F110-NM-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F110-NM-L-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F110-NM-L-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F110-NM-L-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F110-NM-L-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F110-NM-L-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F110-NM-L-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F110-NM-F-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F110-NM-F-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F110-NM-F-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F110-NM-F-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F110-NM-F-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F110-NM-F-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F110-NM-E-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F110-NM-E-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F110-NM-E-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F110-NM-E-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F110-NM-E-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC12V
4F110-NM-E-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC24V
4F110-NM-E1-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F110-NM-E1-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F110-NM-E1-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F110-NM-E1-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F110-NM-E1-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F110-NM-E1-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F110-NM-E2-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F110-NM-E2-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F110-NM-E2-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F110-NM-E2-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F110-NM-E2-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F110-NM-E2-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F110-NM-B1-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F110-NM-B1-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F110-NM-B1-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F110-NM-B1-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F110-NM-B1-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F110-NM-B1-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F110-NM-B-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F110-NM-B-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F110-NM-B-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F110-NM-B-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F110-NM-B-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F110-NM-B-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F110-NM-BL-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F110-NM-BL-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F110-NM-BL-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F110-NM-BL-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F110-NM-BL-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F110-NM-G-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F110-NM-G-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F110-NM-G-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F110-NM-G-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F110-NM-G-DC12V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F110-NM-G-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F110-NM-GL-AC100V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F110-NM-GL-AC200V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F110-NM-GL-AC110V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F110-NM-GL-AC220V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F110-NM-GL-DC24V Model: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F120-NM-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F120-NM-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F120-NM-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F120-NM-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F120-NM-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F120-NM-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F120-NM-L-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F120-NM-L-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F120-NM-L-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F120-NM-L-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F120-NM-L-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F120-NM-L-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F120-NM-F-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F120-NM-F-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F120-NM-F-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F120-NM-F-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F120-NM-F-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F120-NM-F-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F120-NM-E-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F120-NM-E-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F120-NM-E-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F120-NM-E-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F120-NM-E-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC12V
4F120-NM-E-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC24V
4F120-NM-E1-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F120-NM-E1-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F120-NM-E1-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F120-NM-E1-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F120-NM-E1-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F120-NM-E1-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F120-NM-E2-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F120-NM-E2-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F120-NM-E2-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F120-NM-E2-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F120-NM-E2-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F120-NM-E2-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F120-NM-B1-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F120-NM-B1-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F120-NM-B1-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F120-NM-B1-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F120-NM-B1-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F120-NM-B1-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F120-NM-B-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F120-NM-B-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F120-NM-B-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F120-NM-B-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F120-NM-B-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F120-NM-B-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F120-NM-BL-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F120-NM-BL-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F120-NM-BL-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F120-NM-BL-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F120-NM-BL-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F120-NM-G-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F120-NM-G-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F120-NM-G-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F120-NM-G-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F120-NM-G-DC12V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F120-NM-G-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F120-NM-GL-AC100V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F120-NM-GL-AC200V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F120-NM-GL-AC110V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F120-NM-GL-AC220V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F120-NM-GL-DC24V Model: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F310-NM-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F310-NM-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F310-NM-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F310-NM-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F310-NM-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F310-NM-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F310-NM-L-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F310-NM-L-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F310-NM-L-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F310-NM-L-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F310-NM-L-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F310-NM-L-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F310-NM-F-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F310-NM-F-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F310-NM-F-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F310-NM-F-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F310-NM-F-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F310-NM-F-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F310-NM-E-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F310-NM-E-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F310-NM-E-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F310-NM-E-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F310-NM-E-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC12V
4F310-NM-E-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC24V
4F310-NM-E1-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F310-NM-E1-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F310-NM-E1-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F310-NM-E1-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F310-NM-E1-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F310-NM-E1-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F310-NM-E2-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F310-NM-E2-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F310-NM-E2-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F310-NM-E2-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F310-NM-E2-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F310-NM-E2-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F310-NM-B1-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F310-NM-B1-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F310-NM-B1-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F310-NM-B1-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F310-NM-B1-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F310-NM-B1-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F310-NM-B-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F310-NM-B-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F310-NM-B-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F310-NM-B-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F310-NM-B-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F310-NM-B-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F310-NM-BL-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F310-NM-BL-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F310-NM-BL-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F310-NM-BL-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F310-NM-BL-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F310-NM-G-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F310-NM-G-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F310-NM-G-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F310-NM-G-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F310-NM-G-DC12V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F310-NM-G-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F310-NM-GL-AC100V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F310-NM-GL-AC200V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F310-NM-GL-AC110V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F310-NM-GL-AC220V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F310-NM-GL-DC24V Model: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F320-NM-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F320-NM-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F320-NM-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F320-NM-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F320-NM-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F320-NM-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F320-NM-L-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F320-NM-L-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F320-NM-L-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F320-NM-L-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F320-NM-L-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F320-NM-L-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F320-NM-F-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F320-NM-F-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F320-NM-F-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F320-NM-F-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F320-NM-F-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F320-NM-F-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F320-NM-E-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F320-NM-E-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F320-NM-E-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F320-NM-E-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F320-NM-E-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC12V
4F320-NM-E-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC24V
4F320-NM-E1-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F320-NM-E1-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F320-NM-E1-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F320-NM-E1-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F320-NM-E1-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F320-NM-E1-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F320-NM-E2-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F320-NM-E2-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F320-NM-E2-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F320-NM-E2-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F320-NM-E2-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F320-NM-E2-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F320-NM-B1-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F320-NM-B1-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F320-NM-B1-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F320-NM-B1-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F320-NM-B1-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F320-NM-B1-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F320-NM-B-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F320-NM-B-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F320-NM-B-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F320-NM-B-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F320-NM-B-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F320-NM-B-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F320-NM-BL-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F320-NM-BL-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F320-NM-BL-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F320-NM-BL-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F320-NM-BL-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F320-NM-G-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F320-NM-G-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F320-NM-G-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F320-NM-G-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F320-NM-G-DC12V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F320-NM-G-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F320-NM-GL-AC100V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F320-NM-GL-AC200V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F320-NM-GL-AC110V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F320-NM-GL-AC220V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F320-NM-GL-DC24V Model: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F110-NM Legacy code: 4F110-NM NAMUR valve base model (see full codes)
4F120-NM Legacy code: 4F120-NM NAMUR valve base model (see full codes)
4F310-NM Legacy code: 4F310-NM NAMUR valve base model (see full codes)
4F320-NM Legacy code: 4F320-NM NAMUR valve base model (see full codes)
Solenoid ValvesCKD
260 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD 4F1/4F3-NM NAMUR 5-Port Solenoid Valve (Selex)

Brand CKD·Solenoid Valves

Available part numbers (260)

4F110-NM-AC100V, 4F110-NM-AC200V, 4F110-NM-AC110V, 4F110-NM-AC220V, 4F110-NM-DC12V, 4F110-NM-DC24V, 4F110-NM-L-AC100V, 4F110-NM-L-AC200V, 4F110-NM-L-AC110V, 4F110-NM-L-AC220V + 250 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
4F110-NM-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F110-NM-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F110-NM-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F110-NM-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F110-NM-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F110-NM-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F110-NM-L-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F110-NM-L-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F110-NM-L-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F110-NM-L-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F110-NM-L-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F110-NM-L-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F110-NM-F-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F110-NM-F-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F110-NM-F-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F110-NM-F-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F110-NM-F-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F110-NM-F-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F110-NM-E-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F110-NM-E-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F110-NM-E-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F110-NM-E-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F110-NM-E-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC12V
4F110-NM-E-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC24V
4F110-NM-E1-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F110-NM-E1-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F110-NM-E1-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F110-NM-E1-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F110-NM-E1-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F110-NM-E1-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F110-NM-E2-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F110-NM-E2-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F110-NM-E2-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F110-NM-E2-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F110-NM-E2-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F110-NM-E2-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F110-NM-B1-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F110-NM-B1-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F110-NM-B1-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F110-NM-B1-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F110-NM-B1-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F110-NM-B1-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F110-NM-B-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F110-NM-B-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F110-NM-B-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F110-NM-B-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F110-NM-B-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F110-NM-B-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F110-NM-BL-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F110-NM-BL-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F110-NM-BL-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F110-NM-BL-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F110-NM-BL-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F110-NM-G-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F110-NM-G-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F110-NM-G-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F110-NM-G-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F110-NM-G-DC12VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F110-NM-G-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F110-NM-GL-AC100VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F110-NM-GL-AC200VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F110-NM-GL-AC110VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F110-NM-GL-AC220VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F110-NM-GL-DC24VModel: 4F1-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F120-NM-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F120-NM-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F120-NM-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F120-NM-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F120-NM-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F120-NM-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F120-NM-L-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F120-NM-L-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F120-NM-L-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F120-NM-L-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F120-NM-L-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F120-NM-L-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F120-NM-F-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F120-NM-F-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F120-NM-F-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F120-NM-F-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F120-NM-F-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F120-NM-F-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F120-NM-E-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F120-NM-E-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F120-NM-E-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F120-NM-E-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F120-NM-E-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC12V
4F120-NM-E-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC24V
4F120-NM-E1-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F120-NM-E1-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F120-NM-E1-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F120-NM-E1-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F120-NM-E1-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F120-NM-E1-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F120-NM-E2-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F120-NM-E2-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F120-NM-E2-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F120-NM-E2-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F120-NM-E2-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F120-NM-E2-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F120-NM-B1-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F120-NM-B1-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F120-NM-B1-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F120-NM-B1-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F120-NM-B1-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F120-NM-B1-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F120-NM-B-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F120-NM-B-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F120-NM-B-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F120-NM-B-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F120-NM-B-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F120-NM-B-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F120-NM-BL-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F120-NM-BL-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F120-NM-BL-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F120-NM-BL-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F120-NM-BL-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F120-NM-G-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F120-NM-G-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F120-NM-G-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F120-NM-G-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F120-NM-G-DC12VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F120-NM-G-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F120-NM-GL-AC100VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F120-NM-GL-AC200VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F120-NM-GL-AC110VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F120-NM-GL-AC220VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F120-NM-GL-DC24VModel: 4F1-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F310-NM-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F310-NM-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F310-NM-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F310-NM-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F310-NM-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F310-NM-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F310-NM-L-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F310-NM-L-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F310-NM-L-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F310-NM-L-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F310-NM-L-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F310-NM-L-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F310-NM-F-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F310-NM-F-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F310-NM-F-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F310-NM-F-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F310-NM-F-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F310-NM-F-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F310-NM-E-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F310-NM-E-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F310-NM-E-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F310-NM-E-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F310-NM-E-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC12V
4F310-NM-E-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Grommet lead wire | Voltage: DC24V
4F310-NM-E1-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F310-NM-E1-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F310-NM-E1-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F310-NM-E1-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F310-NM-E1-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F310-NM-E1-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F310-NM-E2-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F310-NM-E2-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F310-NM-E2-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F310-NM-E2-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F310-NM-E2-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F310-NM-E2-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F310-NM-B1-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F310-NM-B1-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F310-NM-B1-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F310-NM-B1-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F310-NM-B1-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F310-NM-B1-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F310-NM-B-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F310-NM-B-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F310-NM-B-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F310-NM-B-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F310-NM-B-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F310-NM-B-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F310-NM-BL-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F310-NM-BL-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F310-NM-BL-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F310-NM-BL-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F310-NM-BL-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F310-NM-G-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F310-NM-G-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F310-NM-G-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F310-NM-G-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F310-NM-G-DC12VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F310-NM-G-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F310-NM-GL-AC100VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F310-NM-GL-AC200VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F310-NM-GL-AC110VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F310-NM-GL-AC220VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F310-NM-GL-DC24VModel: 4F3-NM | Switching: 2-position single | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F320-NM-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC100V 50/60Hz
4F320-NM-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC200V 50/60Hz
4F320-NM-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC110V 50/60Hz
4F320-NM-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: AC220V 50/60Hz
4F320-NM-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC12V
4F320-NM-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11 | Voltage: DC24V
4F320-NM-L-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC100V 50/60Hz
4F320-NM-L-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC200V 50/60Hz
4F320-NM-L-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC110V 50/60Hz
4F320-NM-L-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: AC220V 50/60Hz
4F320-NM-L-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC12V
4F320-NM-L-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box Pg11, lamp | Voltage: DC24V
4F320-NM-F-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC100V 50/60Hz
4F320-NM-F-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC200V 50/60Hz
4F320-NM-F-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC110V 50/60Hz
4F320-NM-F-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: AC220V 50/60Hz
4F320-NM-F-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC12V
4F320-NM-F-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: DIN terminal box G1/2 | Voltage: DC24V
4F320-NM-E-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC100V 50/60Hz
4F320-NM-E-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC200V 50/60Hz
4F320-NM-E-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC110V 50/60Hz
4F320-NM-E-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: AC220V 50/60Hz
4F320-NM-E-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC12V
4F320-NM-E-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Grommet lead wire | Voltage: DC24V
4F320-NM-E1-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC100V 50/60Hz
4F320-NM-E1-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC200V 50/60Hz
4F320-NM-E1-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC110V 50/60Hz
4F320-NM-E1-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: AC220V 50/60Hz
4F320-NM-E1-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC12V
4F320-NM-E1-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire CTC19 | Voltage: DC24V
4F320-NM-E2-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC100V 50/60Hz
4F320-NM-E2-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC200V 50/60Hz
4F320-NM-E2-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC110V 50/60Hz
4F320-NM-E2-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: AC220V 50/60Hz
4F320-NM-E2-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC12V
4F320-NM-E2-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Conduit lead wire G1/2 | Voltage: DC24V
4F320-NM-B1-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC100V 50/60Hz
4F320-NM-B1-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC200V 50/60Hz
4F320-NM-B1-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC110V 50/60Hz
4F320-NM-B1-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: AC220V 50/60Hz
4F320-NM-B1-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC12V
4F320-NM-B1-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G3/4 | Voltage: DC24V
4F320-NM-B-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC100V 50/60Hz
4F320-NM-B-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC200V 50/60Hz
4F320-NM-B-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC110V 50/60Hz
4F320-NM-B-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: AC220V 50/60Hz
4F320-NM-B-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC12V
4F320-NM-B-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Round terminal box G1/2 | Voltage: DC24V
4F320-NM-BL-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC100V 50/60Hz
4F320-NM-BL-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC200V 50/60Hz
4F320-NM-BL-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC110V 50/60Hz
4F320-NM-BL-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: AC220V 50/60Hz
4F320-NM-BL-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2 with lamp | Voltage: DC24V
4F320-NM-G-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC100V 50/60Hz
4F320-NM-G-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC200V 50/60Hz
4F320-NM-G-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC110V 50/60Hz
4F320-NM-G-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: AC220V 50/60Hz
4F320-NM-G-DC12VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC12V
4F320-NM-G-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground A-15a | Voltage: DC24V
4F320-NM-GL-AC100VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC100V 50/60Hz
4F320-NM-GL-AC200VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC200V 50/60Hz
4F320-NM-GL-AC110VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC110V 50/60Hz
4F320-NM-GL-AC220VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: AC220V 50/60Hz
4F320-NM-GL-DC24VModel: 4F3-NM | Switching: 2-position double | Wiring: Round box G1/2, ground, lamp | Voltage: DC24V
4F110-NMLegacy code: 4F110-NM NAMUR valve base model (see full codes)
4F120-NMLegacy code: 4F120-NM NAMUR valve base model (see full codes)
4F310-NMLegacy code: 4F310-NM NAMUR valve base model (see full codes)
4F320-NMLegacy code: 4F320-NM NAMUR valve base model (see full codes)

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
