CKD 4KB1-4 Master Valve (Air Pilot, Sub-plate Piping)

CKD 4KB1-4 Master Valve (Air Pilot, Sub-plate Piping)

CKD 4KB1-4 air-piloted 5-port master valves (Selex valves without solenoid) with sub-plate piping, as single valves or valves for M4KB manifolds.

Key features

  • 5-port air pilot valve: 2-position single/double, 3-position all-ports-blocked, A-B-R or P-A-B connection
  • Sub-plate P/A/B ports Rc1/8 (4KB1) to Rc1/2 (4KB4), Rc, NPT or G threads
  • Manifold master valves (xx8-00) supplied with gasket and mounting screws
  • M5 pilot ports PA/PB; 4KB1 has common R1/R2 exhaust
  • Suits cylinders ø20 to ø160; lubrication not required

Specifications

Valve type Pilot operated soft spool valve (air pilot)
Fluid Compressed air
Max. operating pressure 0.70 MPa
Proof pressure 1.05 MPa
Ambient temperature -5 to 50°C
Pilot port M5
Pilot pressure (2-pos. single) (0.6 x operating pressure + 0.06) to 0.7 MPa
Source CKD Korea catalog CB-023SK-9, p. 1432-1437
4KB111-06 Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/8
4KB111-06N Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/8
4KB111-06G Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/8
4KB118-00 Model: 4KB1 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB121-06 Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/8
4KB121-06N Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/8
4KB121-06G Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/8
4KB128-00 Model: 4KB1 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB131-06 Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/8
4KB131-06N Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/8
4KB131-06G Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/8
4KB138-00 Model: 4KB1 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB141-06 Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/8
4KB141-06N Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/8
4KB141-06G Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/8
4KB148-00 Model: 4KB1 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB151-06 Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/8
4KB151-06N Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/8
4KB151-06G Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/8
4KB158-00 Model: 4KB1 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only
4KB211-06 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/8
4KB211-08 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/4
4KB211-06N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/8
4KB211-08N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/4
4KB211-06G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/8
4KB211-08G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/4
4KB218-00 Model: 4KB2 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB221-06 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/8
4KB221-08 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/4
4KB221-06N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/8
4KB221-08N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/4
4KB221-06G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/8
4KB221-08G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/4
4KB228-00 Model: 4KB2 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB231-06 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/8
4KB231-08 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/4
4KB231-06N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/8
4KB231-08N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/4
4KB231-06G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/8
4KB231-08G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/4
4KB238-00 Model: 4KB2 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB241-06 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/8
4KB241-08 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/4
4KB241-06N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/8
4KB241-08N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/4
4KB241-06G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/8
4KB241-08G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/4
4KB248-00 Model: 4KB2 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB251-06 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/8
4KB251-08 Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/4
4KB251-06N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/8
4KB251-08N Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/4
4KB251-06G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/8
4KB251-08G Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/4
4KB258-00 Model: 4KB2 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only
4KB311-08 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/4
4KB311-10 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc3/8
4KB311-08N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/4
4KB311-10N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT3/8
4KB311-08G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/4
4KB311-10G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G3/8
4KB318-00 Model: 4KB3 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB321-08 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/4
4KB321-10 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc3/8
4KB321-08N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/4
4KB321-10N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT3/8
4KB321-08G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/4
4KB321-10G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G3/8
4KB328-00 Model: 4KB3 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB331-08 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/4
4KB331-10 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc3/8
4KB331-08N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/4
4KB331-10N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT3/8
4KB331-08G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/4
4KB331-10G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G3/8
4KB338-00 Model: 4KB3 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB341-08 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/4
4KB341-10 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc3/8
4KB341-08N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/4
4KB341-10N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT3/8
4KB341-08G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/4
4KB341-10G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G3/8
4KB348-00 Model: 4KB3 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB351-08 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/4
4KB351-10 Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc3/8
4KB351-08N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/4
4KB351-10N Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT3/8
4KB351-08G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/4
4KB351-10G Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G3/8
4KB358-00 Model: 4KB3 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only
4KB411-10 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc3/8
4KB411-15 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/2
4KB411-10N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT3/8
4KB411-15N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/2
4KB411-10G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G3/8
4KB411-15G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/2
4KB418-00 Model: 4KB4 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB421-10 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc3/8
4KB421-15 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/2
4KB421-10N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT3/8
4KB421-15N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/2
4KB421-10G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G3/8
4KB421-15G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/2
4KB428-00 Model: 4KB4 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB431-10 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc3/8
4KB431-15 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/2
4KB431-10N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT3/8
4KB431-15N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/2
4KB431-10G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G3/8
4KB431-15G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/2
4KB438-00 Model: 4KB4 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB441-10 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc3/8
4KB441-15 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/2
4KB441-10N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT3/8
4KB441-15N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/2
4KB441-10G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G3/8
4KB441-15G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/2
4KB448-00 Model: 4KB4 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB451-10 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc3/8
4KB451-15 Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/2
4KB451-10N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT3/8
4KB451-15N Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/2
4KB451-10G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G3/8
4KB451-15G Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/2
4KB458-00 Model: 4KB4 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only
Air Operated ValvesCKD
125 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD 4KB1-4 Master Valve (Air Pilot, Sub-plate Piping)

Brand CKD·Air Operated Valves

Available part numbers (125)

4KB111-06, 4KB111-06N, 4KB111-06G, 4KB118-00, 4KB121-06, 4KB121-06N, 4KB121-06G, 4KB128-00, 4KB131-06, 4KB131-06N + 115 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
4KB111-06Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/8
4KB111-06NModel: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/8
4KB111-06GModel: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/8
4KB118-00Model: 4KB1 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB121-06Model: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/8
4KB121-06NModel: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/8
4KB121-06GModel: 4KB1 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/8
4KB128-00Model: 4KB1 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB131-06Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/8
4KB131-06NModel: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/8
4KB131-06GModel: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/8
4KB138-00Model: 4KB1 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB141-06Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/8
4KB141-06NModel: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/8
4KB141-06GModel: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/8
4KB148-00Model: 4KB1 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB151-06Model: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/8
4KB151-06NModel: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/8
4KB151-06GModel: 4KB1 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/8
4KB158-00Model: 4KB1 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only
4KB211-06Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/8
4KB211-08Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/4
4KB211-06NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/8
4KB211-08NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/4
4KB211-06GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/8
4KB211-08GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/4
4KB218-00Model: 4KB2 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB221-06Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/8
4KB221-08Model: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/4
4KB221-06NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/8
4KB221-08NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/4
4KB221-06GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/8
4KB221-08GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/4
4KB228-00Model: 4KB2 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB231-06Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/8
4KB231-08Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/4
4KB231-06NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/8
4KB231-08NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/4
4KB231-06GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/8
4KB231-08GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/4
4KB238-00Model: 4KB2 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB241-06Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/8
4KB241-08Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/4
4KB241-06NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/8
4KB241-08NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/4
4KB241-06GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/8
4KB241-08GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/4
4KB248-00Model: 4KB2 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB251-06Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/8
4KB251-08Model: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/4
4KB251-06NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/8
4KB251-08NModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/4
4KB251-06GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/8
4KB251-08GModel: 4KB2 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/4
4KB258-00Model: 4KB2 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only
4KB311-08Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/4
4KB311-10Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc3/8
4KB311-08NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/4
4KB311-10NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT3/8
4KB311-08GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/4
4KB311-10GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G3/8
4KB318-00Model: 4KB3 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB321-08Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/4
4KB321-10Model: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc3/8
4KB321-08NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/4
4KB321-10NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT3/8
4KB321-08GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/4
4KB321-10GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G3/8
4KB328-00Model: 4KB3 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB331-08Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/4
4KB331-10Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc3/8
4KB331-08NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/4
4KB331-10NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT3/8
4KB331-08GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/4
4KB331-10GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G3/8
4KB338-00Model: 4KB3 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB341-08Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/4
4KB341-10Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc3/8
4KB341-08NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/4
4KB341-10NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT3/8
4KB341-08GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/4
4KB341-10GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G3/8
4KB348-00Model: 4KB3 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB351-08Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/4
4KB351-10Model: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc3/8
4KB351-08NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/4
4KB351-10NModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT3/8
4KB351-08GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/4
4KB351-10GModel: 4KB3 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G3/8
4KB358-00Model: 4KB3 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only
4KB411-10Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc3/8
4KB411-15Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: Rc1/2
4KB411-10NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT3/8
4KB411-15NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: NPT1/2
4KB411-10GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G3/8
4KB411-15GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position single | Port: G1/2
4KB418-00Model: 4KB4 | Type: Master valve for manifold | Switching: 2-position single | Port: Valve only
4KB421-10Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc3/8
4KB421-15Model: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: Rc1/2
4KB421-10NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT3/8
4KB421-15NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: NPT1/2
4KB421-10GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G3/8
4KB421-15GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 2-position double | Port: G1/2
4KB428-00Model: 4KB4 | Type: Master valve for manifold | Switching: 2-position double | Port: Valve only
4KB431-10Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc3/8
4KB431-15Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: Rc1/2
4KB431-10NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT3/8
4KB431-15NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: NPT1/2
4KB431-10GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G3/8
4KB431-15GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position all ports blocked | Port: G1/2
4KB438-00Model: 4KB4 | Type: Master valve for manifold | Switching: 3-position all ports blocked | Port: Valve only
4KB441-10Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc3/8
4KB441-15Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: Rc1/2
4KB441-10NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT3/8
4KB441-15NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: NPT1/2
4KB441-10GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G3/8
4KB441-15GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position A-B-R connection | Port: G1/2
4KB448-00Model: 4KB4 | Type: Master valve for manifold | Switching: 3-position A-B-R connection | Port: Valve only
4KB451-10Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc3/8
4KB451-15Model: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: Rc1/2
4KB451-10NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT3/8
4KB451-15NModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: NPT1/2
4KB451-10GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G3/8
4KB451-15GModel: 4KB4 | Type: Master valve with sub-plate | Switching: 3-position P-A-B connection | Port: G1/2
4KB458-00Model: 4KB4 | Type: Master valve for manifold | Switching: 3-position P-A-B connection | Port: Valve only

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
