CKD ADK11-W Outdoor Pilot Kick 2-Port Solenoid Valve (MULTILEX, NC)

CKD ADK11-W outdoor-use MULTILEX pilot kick poppet diaphragm 2-port solenoid valve (NC) with stainless body and metal round terminal box, Rc1/2 to Rc1.

Key features

Outdoor W series: passed 960 h combined cycle test, 1000 h accelerated weathering and 400 h ozone exposure
Pilot kick poppet diaphragm drive; operates from 0 MPa differential
Stainless steel body with FKM seal (E); air, low vacuum, water, kerosene and oil
Metal round terminal box (G1/2) with sealing, IP65; 3L version with indicator lamp
Options not expanded: mounting plate B, marine cable gland D/E/F, surge killer S
Order example: ADK11-15A-E3EW-AC100V

Specifications

Valve type	Pilot kick poppet diaphragm, NC
Fluid	Air, low vacuum, water, kerosene, oil (50 mm2/s or less)
Operating pressure differential	0-1.0 MPa (oil 0.6 MPa)
Proof pressure	4 MPa
Fluid temperature	5 to 60 C
Ambient temperature	-10 to 60 C
Environment	Indoor / outdoor
Body / seal	Stainless steel / FKM
Protection	IP65
Mounting	Coil upward, vertical only
Source	CKD Korea catalog CB-03-1SK-9, p. 1142-1145

ADK11-15A-E3EW-AC100V		Port: Rc1/2 \| Orifice: 16 mm \| Coil housing: 3E Round terminal box \| Voltage: AC100V \| Cv: 4.5
ADK11-15A-E3EW-AC200V		Port: Rc1/2 \| Orifice: 16 mm \| Coil housing: 3E Round terminal box \| Voltage: AC200V \| Cv: 4.5
ADK11-15A-E3LW-AC100V		Port: Rc1/2 \| Orifice: 16 mm \| Coil housing: 3L Round terminal box with lamp \| Voltage: AC100V \| Cv: 4.5
ADK11-15A-E3LW-AC200V		Port: Rc1/2 \| Orifice: 16 mm \| Coil housing: 3L Round terminal box with lamp \| Voltage: AC200V \| Cv: 4.5
ADK11-20A-E3EW-AC100V		Port: Rc3/4 \| Orifice: 23 mm \| Coil housing: 3E Round terminal box \| Voltage: AC100V \| Cv: 8.6
ADK11-20A-E3EW-AC200V		Port: Rc3/4 \| Orifice: 23 mm \| Coil housing: 3E Round terminal box \| Voltage: AC200V \| Cv: 8.6
ADK11-20A-E3LW-AC100V		Port: Rc3/4 \| Orifice: 23 mm \| Coil housing: 3L Round terminal box with lamp \| Voltage: AC100V \| Cv: 8.6
ADK11-20A-E3LW-AC200V		Port: Rc3/4 \| Orifice: 23 mm \| Coil housing: 3L Round terminal box with lamp \| Voltage: AC200V \| Cv: 8.6
ADK11-25A-E3EW-AC100V		Port: Rc1 \| Orifice: 28 mm \| Coil housing: 3E Round terminal box \| Voltage: AC100V \| Cv: 12.0
ADK11-25A-E3EW-AC200V		Port: Rc1 \| Orifice: 28 mm \| Coil housing: 3E Round terminal box \| Voltage: AC200V \| Cv: 12.0
ADK11-25A-E3LW-AC100V		Port: Rc1 \| Orifice: 28 mm \| Coil housing: 3L Round terminal box with lamp \| Voltage: AC100V \| Cv: 12.0
ADK11-25A-E3LW-AC200V		Port: Rc1 \| Orifice: 28 mm \| Coil housing: 3L Round terminal box with lamp \| Voltage: AC200V \| Cv: 12.0
