CKD ADK11-Z MULTILEX Dry Air Pilot Kick 2-Port Solenoid Valve

CKD ADK11-Z MULTILEX Dry Air Pilot Kick 2-Port Solenoid Valve

CKD MULTILEX ADK11-Z pilot-kick diaphragm NC 2-port solenoid valve for dry air, inert gas and low vacuum, Rc1/4 to Rc1.

Key features

  • Pilot kick poppet with diaphragm drive, operates from 0 MPa differential
  • Port sizes 1/4 to 1 with Rc, G or NPT threads
  • Bronze or stainless body with NBR or FKM seal, oil-free treated
  • Coils: 3A open frame DC, 5A diode AC; HP terminal box versions also available
  • Options not multiplied: mounting plate (B), cable gland/conduit, surge killer (S)

Specifications

Fluid Dry air (dew point -60°C+), inert gas, low vacuum
Model ADK11-Z normally closed
Operating pressure diff. 0-0.7 MPa (15A-25A 0-0.6 MPa)
Max. working pressure 2 MPa
Proof pressure 4 MPa (water)
Fluid temperature NBR -10 to 40°C, FKM 5 to 40°C
Orifice 12 / 12 / 16 / 23 / 28 mm
Coil insulation Class B (130)
Source CKD Korea catalog CB-03-1SK-9, p. 430-437
ADK11-8A-H3AZ-DC12V Port: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-H3AZ-DC24V Port: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-H3AZ-DC48V Port: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-H3AZ-DC100V Port: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-H5AZ-AC100V Port: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-H5AZ-AC200V Port: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8A-J3AZ-DC12V Port: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-J3AZ-DC24V Port: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-J3AZ-DC48V Port: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-J3AZ-DC100V Port: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-J5AZ-AC100V Port: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-J5AZ-AC200V Port: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8A-L3AZ-DC12V Port: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-L3AZ-DC24V Port: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-L3AZ-DC48V Port: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-L3AZ-DC100V Port: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-L5AZ-AC100V Port: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-L5AZ-AC200V Port: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8A-M3AZ-DC12V Port: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-M3AZ-DC24V Port: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-M3AZ-DC48V Port: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-M3AZ-DC100V Port: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-M5AZ-AC100V Port: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-M5AZ-AC200V Port: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-H3AZ-DC12V Port: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-H3AZ-DC24V Port: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-H3AZ-DC48V Port: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-H3AZ-DC100V Port: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-H5AZ-AC100V Port: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-H5AZ-AC200V Port: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-J3AZ-DC12V Port: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-J3AZ-DC24V Port: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-J3AZ-DC48V Port: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-J3AZ-DC100V Port: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-J5AZ-AC100V Port: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-J5AZ-AC200V Port: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-L3AZ-DC12V Port: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-L3AZ-DC24V Port: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-L3AZ-DC48V Port: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-L3AZ-DC100V Port: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-L5AZ-AC100V Port: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-L5AZ-AC200V Port: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-M3AZ-DC12V Port: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-M3AZ-DC24V Port: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-M3AZ-DC48V Port: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-M3AZ-DC100V Port: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-M5AZ-AC100V Port: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-M5AZ-AC200V Port: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-H3AZ-DC12V Port: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-H3AZ-DC24V Port: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-H3AZ-DC48V Port: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-H3AZ-DC100V Port: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-H5AZ-AC100V Port: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-H5AZ-AC200V Port: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-J3AZ-DC12V Port: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-J3AZ-DC24V Port: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-J3AZ-DC48V Port: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-J3AZ-DC100V Port: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-J5AZ-AC100V Port: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-J5AZ-AC200V Port: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-L3AZ-DC12V Port: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-L3AZ-DC24V Port: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-L3AZ-DC48V Port: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-L3AZ-DC100V Port: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-L5AZ-AC100V Port: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-L5AZ-AC200V Port: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-M3AZ-DC12V Port: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-M3AZ-DC24V Port: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-M3AZ-DC48V Port: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-M3AZ-DC100V Port: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-M5AZ-AC100V Port: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-M5AZ-AC200V Port: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-H3AZ-DC12V Port: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-H3AZ-DC24V Port: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-H3AZ-DC48V Port: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-H3AZ-DC100V Port: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-H5AZ-AC100V Port: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-H5AZ-AC200V Port: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-J3AZ-DC12V Port: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-J3AZ-DC24V Port: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-J3AZ-DC48V Port: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-J3AZ-DC100V Port: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-J5AZ-AC100V Port: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-J5AZ-AC200V Port: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-L3AZ-DC12V Port: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-L3AZ-DC24V Port: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-L3AZ-DC48V Port: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-L3AZ-DC100V Port: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-L5AZ-AC100V Port: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-L5AZ-AC200V Port: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-M3AZ-DC12V Port: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-M3AZ-DC24V Port: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-M3AZ-DC48V Port: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-M3AZ-DC100V Port: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-M5AZ-AC100V Port: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-M5AZ-AC200V Port: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-H3AZ-DC12V Port: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-H3AZ-DC24V Port: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-H3AZ-DC48V Port: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-H3AZ-DC100V Port: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-H5AZ-AC100V Port: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-H5AZ-AC200V Port: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-J3AZ-DC12V Port: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-J3AZ-DC24V Port: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-J3AZ-DC48V Port: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-J3AZ-DC100V Port: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-J5AZ-AC100V Port: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-J5AZ-AC200V Port: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-L3AZ-DC12V Port: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-L3AZ-DC24V Port: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-L3AZ-DC48V Port: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-L3AZ-DC100V Port: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-L5AZ-AC100V Port: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-L5AZ-AC200V Port: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-M3AZ-DC12V Port: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-M3AZ-DC24V Port: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-M3AZ-DC48V Port: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-M3AZ-DC100V Port: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-M5AZ-AC100V Port: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-M5AZ-AC200V Port: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-H3AZ-DC12V Port: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-H3AZ-DC24V Port: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-H3AZ-DC48V Port: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-H3AZ-DC100V Port: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-H5AZ-AC100V Port: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-H5AZ-AC200V Port: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-J3AZ-DC12V Port: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-J3AZ-DC24V Port: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-J3AZ-DC48V Port: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-J3AZ-DC100V Port: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-J5AZ-AC100V Port: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-J5AZ-AC200V Port: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-L3AZ-DC12V Port: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-L3AZ-DC24V Port: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-L3AZ-DC48V Port: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-L3AZ-DC100V Port: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-L5AZ-AC100V Port: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-L5AZ-AC200V Port: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-M3AZ-DC12V Port: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-M3AZ-DC24V Port: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-M3AZ-DC48V Port: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-M3AZ-DC100V Port: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-M5AZ-AC100V Port: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-M5AZ-AC200V Port: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-H3AZ-DC12V Port: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-H3AZ-DC24V Port: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-H3AZ-DC48V Port: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-H3AZ-DC100V Port: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-H5AZ-AC100V Port: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-H5AZ-AC200V Port: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-J3AZ-DC12V Port: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-J3AZ-DC24V Port: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-J3AZ-DC48V Port: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-J3AZ-DC100V Port: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-J5AZ-AC100V Port: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-J5AZ-AC200V Port: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-L3AZ-DC12V Port: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-L3AZ-DC24V Port: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-L3AZ-DC48V Port: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-L3AZ-DC100V Port: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-L5AZ-AC100V Port: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-L5AZ-AC200V Port: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-M3AZ-DC12V Port: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-M3AZ-DC24V Port: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-M3AZ-DC48V Port: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-M3AZ-DC100V Port: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-M5AZ-AC100V Port: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-M5AZ-AC200V Port: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-H3AZ-DC12V Port: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-H3AZ-DC24V Port: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-H3AZ-DC48V Port: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-H3AZ-DC100V Port: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-H5AZ-AC100V Port: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-H5AZ-AC200V Port: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-J3AZ-DC12V Port: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-J3AZ-DC24V Port: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-J3AZ-DC48V Port: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-J3AZ-DC100V Port: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-J5AZ-AC100V Port: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-J5AZ-AC200V Port: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-L3AZ-DC12V Port: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-L3AZ-DC24V Port: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-L3AZ-DC48V Port: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-L3AZ-DC100V Port: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-L5AZ-AC100V Port: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-L5AZ-AC200V Port: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-M3AZ-DC12V Port: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-M3AZ-DC24V Port: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-M3AZ-DC48V Port: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-M3AZ-DC100V Port: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-M5AZ-AC100V Port: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-M5AZ-AC200V Port: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-H3AZ-DC12V Port: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-H3AZ-DC24V Port: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-H3AZ-DC48V Port: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-H3AZ-DC100V Port: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-H5AZ-AC100V Port: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-H5AZ-AC200V Port: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-J3AZ-DC12V Port: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-J3AZ-DC24V Port: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-J3AZ-DC48V Port: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-J3AZ-DC100V Port: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-J5AZ-AC100V Port: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-J5AZ-AC200V Port: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-L3AZ-DC12V Port: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-L3AZ-DC24V Port: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-L3AZ-DC48V Port: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-L3AZ-DC100V Port: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-L5AZ-AC100V Port: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-L5AZ-AC200V Port: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-M3AZ-DC12V Port: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-M3AZ-DC24V Port: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-M3AZ-DC48V Port: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-M3AZ-DC100V Port: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-M5AZ-AC100V Port: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-M5AZ-AC200V Port: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-H3AZ-DC12V Port: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-H3AZ-DC24V Port: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-H3AZ-DC48V Port: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-H3AZ-DC100V Port: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-H5AZ-AC100V Port: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-H5AZ-AC200V Port: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-J3AZ-DC12V Port: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-J3AZ-DC24V Port: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-J3AZ-DC48V Port: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-J3AZ-DC100V Port: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-J5AZ-AC100V Port: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-J5AZ-AC200V Port: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-L3AZ-DC12V Port: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-L3AZ-DC24V Port: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-L3AZ-DC48V Port: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-L3AZ-DC100V Port: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-L5AZ-AC100V Port: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-L5AZ-AC200V Port: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-M3AZ-DC12V Port: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-M3AZ-DC24V Port: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-M3AZ-DC48V Port: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-M3AZ-DC100V Port: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-M5AZ-AC100V Port: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-M5AZ-AC200V Port: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-H3AZ-DC12V Port: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-H3AZ-DC24V Port: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-H3AZ-DC48V Port: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-H3AZ-DC100V Port: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-H5AZ-AC100V Port: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-H5AZ-AC200V Port: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-J3AZ-DC12V Port: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-J3AZ-DC24V Port: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-J3AZ-DC48V Port: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-J3AZ-DC100V Port: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-J5AZ-AC100V Port: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-J5AZ-AC200V Port: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-L3AZ-DC12V Port: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-L3AZ-DC24V Port: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-L3AZ-DC48V Port: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-L3AZ-DC100V Port: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-L5AZ-AC100V Port: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-L5AZ-AC200V Port: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-M3AZ-DC12V Port: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-M3AZ-DC24V Port: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-M3AZ-DC48V Port: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-M3AZ-DC100V Port: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-M5AZ-AC100V Port: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-M5AZ-AC200V Port: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-H3AZ-DC12V Port: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-H3AZ-DC24V Port: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-H3AZ-DC48V Port: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-H3AZ-DC100V Port: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-H5AZ-AC100V Port: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-H5AZ-AC200V Port: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-J3AZ-DC12V Port: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-J3AZ-DC24V Port: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-J3AZ-DC48V Port: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-J3AZ-DC100V Port: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-J5AZ-AC100V Port: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-J5AZ-AC200V Port: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-L3AZ-DC12V Port: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-L3AZ-DC24V Port: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-L3AZ-DC48V Port: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-L3AZ-DC100V Port: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-L5AZ-AC100V Port: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-L5AZ-AC200V Port: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-M3AZ-DC12V Port: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-M3AZ-DC24V Port: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-M3AZ-DC48V Port: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-M3AZ-DC100V Port: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-M5AZ-AC100V Port: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-M5AZ-AC200V Port: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-H3AZ-DC12V Port: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-H3AZ-DC24V Port: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-H3AZ-DC48V Port: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-H3AZ-DC100V Port: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-H5AZ-AC100V Port: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-H5AZ-AC200V Port: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-J3AZ-DC12V Port: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-J3AZ-DC24V Port: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-J3AZ-DC48V Port: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-J3AZ-DC100V Port: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-J5AZ-AC100V Port: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-J5AZ-AC200V Port: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-L3AZ-DC12V Port: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-L3AZ-DC24V Port: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-L3AZ-DC48V Port: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-L3AZ-DC100V Port: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-L5AZ-AC100V Port: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-L5AZ-AC200V Port: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-M3AZ-DC12V Port: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-M3AZ-DC24V Port: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-M3AZ-DC48V Port: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-M3AZ-DC100V Port: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-M5AZ-AC100V Port: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-M5AZ-AC200V Port: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-H3AZ-DC12V Port: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-H3AZ-DC24V Port: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-H3AZ-DC48V Port: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-H3AZ-DC100V Port: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-H5AZ-AC100V Port: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-H5AZ-AC200V Port: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-J3AZ-DC12V Port: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-J3AZ-DC24V Port: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-J3AZ-DC48V Port: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-J3AZ-DC100V Port: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-J5AZ-AC100V Port: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-J5AZ-AC200V Port: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-L3AZ-DC12V Port: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-L3AZ-DC24V Port: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-L3AZ-DC48V Port: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-L3AZ-DC100V Port: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-L5AZ-AC100V Port: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-L5AZ-AC200V Port: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-M3AZ-DC12V Port: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-M3AZ-DC24V Port: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-M3AZ-DC48V Port: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-M3AZ-DC100V Port: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-M5AZ-AC100V Port: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-M5AZ-AC200V Port: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-H3AZ-DC12V Port: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-H3AZ-DC24V Port: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-H3AZ-DC48V Port: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-H3AZ-DC100V Port: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-H5AZ-AC100V Port: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-H5AZ-AC200V Port: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-J3AZ-DC12V Port: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-J3AZ-DC24V Port: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-J3AZ-DC48V Port: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-J3AZ-DC100V Port: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-J5AZ-AC100V Port: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-J5AZ-AC200V Port: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-L3AZ-DC12V Port: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-L3AZ-DC24V Port: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-L3AZ-DC48V Port: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-L3AZ-DC100V Port: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-L5AZ-AC100V Port: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-L5AZ-AC200V Port: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-M3AZ-DC12V Port: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-M3AZ-DC24V Port: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-M3AZ-DC48V Port: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-M3AZ-DC100V Port: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-M5AZ-AC100V Port: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-M5AZ-AC200V Port: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
Solenoid ValvesCKD
360 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD ADK11-Z MULTILEX Dry Air Pilot Kick 2-Port Solenoid Valve

Brand CKD·Solenoid Valves

Available part numbers (360)

ADK11-8A-H3AZ-DC12V, ADK11-8A-H3AZ-DC24V, ADK11-8A-H3AZ-DC48V, ADK11-8A-H3AZ-DC100V, ADK11-8A-H5AZ-AC100V, ADK11-8A-H5AZ-AC200V, ADK11-8A-J3AZ-DC12V, ADK11-8A-J3AZ-DC24V, ADK11-8A-J3AZ-DC48V, ADK11-8A-J3AZ-DC100V + 350 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ADK11-8A-H3AZ-DC12VPort: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-H3AZ-DC24VPort: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-H3AZ-DC48VPort: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-H3AZ-DC100VPort: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-H5AZ-AC100VPort: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-H5AZ-AC200VPort: Rc1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8A-J3AZ-DC12VPort: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-J3AZ-DC24VPort: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-J3AZ-DC48VPort: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-J3AZ-DC100VPort: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-J5AZ-AC100VPort: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-J5AZ-AC200VPort: Rc1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8A-L3AZ-DC12VPort: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-L3AZ-DC24VPort: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-L3AZ-DC48VPort: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-L3AZ-DC100VPort: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-L5AZ-AC100VPort: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-L5AZ-AC200VPort: Rc1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8A-M3AZ-DC12VPort: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8A-M3AZ-DC24VPort: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8A-M3AZ-DC48VPort: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8A-M3AZ-DC100VPort: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8A-M5AZ-AC100VPort: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8A-M5AZ-AC200VPort: Rc1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-H3AZ-DC12VPort: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-H3AZ-DC24VPort: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-H3AZ-DC48VPort: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-H3AZ-DC100VPort: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-H5AZ-AC100VPort: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-H5AZ-AC200VPort: G1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-J3AZ-DC12VPort: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-J3AZ-DC24VPort: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-J3AZ-DC48VPort: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-J3AZ-DC100VPort: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-J5AZ-AC100VPort: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-J5AZ-AC200VPort: G1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-L3AZ-DC12VPort: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-L3AZ-DC24VPort: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-L3AZ-DC48VPort: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-L3AZ-DC100VPort: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-L5AZ-AC100VPort: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-L5AZ-AC200VPort: G1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8G-M3AZ-DC12VPort: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8G-M3AZ-DC24VPort: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8G-M3AZ-DC48VPort: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8G-M3AZ-DC100VPort: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8G-M5AZ-AC100VPort: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8G-M5AZ-AC200VPort: G1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-H3AZ-DC12VPort: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-H3AZ-DC24VPort: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-H3AZ-DC48VPort: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-H3AZ-DC100VPort: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-H5AZ-AC100VPort: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-H5AZ-AC200VPort: NPT1/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-J3AZ-DC12VPort: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-J3AZ-DC24VPort: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-J3AZ-DC48VPort: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-J3AZ-DC100VPort: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-J5AZ-AC100VPort: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-J5AZ-AC200VPort: NPT1/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-L3AZ-DC12VPort: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-L3AZ-DC24VPort: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-L3AZ-DC48VPort: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-L3AZ-DC100VPort: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-L5AZ-AC100VPort: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-L5AZ-AC200VPort: NPT1/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-8N-M3AZ-DC12VPort: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-8N-M3AZ-DC24VPort: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-8N-M3AZ-DC48VPort: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-8N-M3AZ-DC100VPort: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-8N-M5AZ-AC100VPort: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-8N-M5AZ-AC200VPort: NPT1/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-H3AZ-DC12VPort: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-H3AZ-DC24VPort: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-H3AZ-DC48VPort: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-H3AZ-DC100VPort: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-H5AZ-AC100VPort: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-H5AZ-AC200VPort: Rc3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-J3AZ-DC12VPort: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-J3AZ-DC24VPort: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-J3AZ-DC48VPort: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-J3AZ-DC100VPort: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-J5AZ-AC100VPort: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-J5AZ-AC200VPort: Rc3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-L3AZ-DC12VPort: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-L3AZ-DC24VPort: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-L3AZ-DC48VPort: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-L3AZ-DC100VPort: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-L5AZ-AC100VPort: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-L5AZ-AC200VPort: Rc3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10A-M3AZ-DC12VPort: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10A-M3AZ-DC24VPort: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10A-M3AZ-DC48VPort: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10A-M3AZ-DC100VPort: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10A-M5AZ-AC100VPort: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10A-M5AZ-AC200VPort: Rc3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-H3AZ-DC12VPort: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-H3AZ-DC24VPort: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-H3AZ-DC48VPort: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-H3AZ-DC100VPort: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-H5AZ-AC100VPort: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-H5AZ-AC200VPort: G3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-J3AZ-DC12VPort: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-J3AZ-DC24VPort: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-J3AZ-DC48VPort: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-J3AZ-DC100VPort: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-J5AZ-AC100VPort: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-J5AZ-AC200VPort: G3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-L3AZ-DC12VPort: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-L3AZ-DC24VPort: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-L3AZ-DC48VPort: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-L3AZ-DC100VPort: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-L5AZ-AC100VPort: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-L5AZ-AC200VPort: G3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10G-M3AZ-DC12VPort: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10G-M3AZ-DC24VPort: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10G-M3AZ-DC48VPort: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10G-M3AZ-DC100VPort: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10G-M5AZ-AC100VPort: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10G-M5AZ-AC200VPort: G3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-H3AZ-DC12VPort: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-H3AZ-DC24VPort: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-H3AZ-DC48VPort: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-H3AZ-DC100VPort: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-H5AZ-AC100VPort: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-H5AZ-AC200VPort: NPT3/8 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-J3AZ-DC12VPort: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-J3AZ-DC24VPort: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-J3AZ-DC48VPort: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-J3AZ-DC100VPort: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-J5AZ-AC100VPort: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-J5AZ-AC200VPort: NPT3/8 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-L3AZ-DC12VPort: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-L3AZ-DC24VPort: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-L3AZ-DC48VPort: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-L3AZ-DC100VPort: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-L5AZ-AC100VPort: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-L5AZ-AC200VPort: NPT3/8 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-10N-M3AZ-DC12VPort: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-10N-M3AZ-DC24VPort: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-10N-M3AZ-DC48VPort: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-10N-M3AZ-DC100VPort: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-10N-M5AZ-AC100VPort: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-10N-M5AZ-AC200VPort: NPT3/8 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-H3AZ-DC12VPort: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-H3AZ-DC24VPort: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-H3AZ-DC48VPort: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-H3AZ-DC100VPort: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-H5AZ-AC100VPort: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-H5AZ-AC200VPort: Rc1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-J3AZ-DC12VPort: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-J3AZ-DC24VPort: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-J3AZ-DC48VPort: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-J3AZ-DC100VPort: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-J5AZ-AC100VPort: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-J5AZ-AC200VPort: Rc1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-L3AZ-DC12VPort: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-L3AZ-DC24VPort: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-L3AZ-DC48VPort: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-L3AZ-DC100VPort: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-L5AZ-AC100VPort: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-L5AZ-AC200VPort: Rc1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15A-M3AZ-DC12VPort: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15A-M3AZ-DC24VPort: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15A-M3AZ-DC48VPort: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15A-M3AZ-DC100VPort: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15A-M5AZ-AC100VPort: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15A-M5AZ-AC200VPort: Rc1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-H3AZ-DC12VPort: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-H3AZ-DC24VPort: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-H3AZ-DC48VPort: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-H3AZ-DC100VPort: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-H5AZ-AC100VPort: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-H5AZ-AC200VPort: G1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-J3AZ-DC12VPort: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-J3AZ-DC24VPort: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-J3AZ-DC48VPort: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-J3AZ-DC100VPort: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-J5AZ-AC100VPort: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-J5AZ-AC200VPort: G1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-L3AZ-DC12VPort: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-L3AZ-DC24VPort: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-L3AZ-DC48VPort: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-L3AZ-DC100VPort: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-L5AZ-AC100VPort: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-L5AZ-AC200VPort: G1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15G-M3AZ-DC12VPort: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15G-M3AZ-DC24VPort: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15G-M3AZ-DC48VPort: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15G-M3AZ-DC100VPort: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15G-M5AZ-AC100VPort: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15G-M5AZ-AC200VPort: G1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-H3AZ-DC12VPort: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-H3AZ-DC24VPort: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-H3AZ-DC48VPort: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-H3AZ-DC100VPort: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-H5AZ-AC100VPort: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-H5AZ-AC200VPort: NPT1/2 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-J3AZ-DC12VPort: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-J3AZ-DC24VPort: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-J3AZ-DC48VPort: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-J3AZ-DC100VPort: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-J5AZ-AC100VPort: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-J5AZ-AC200VPort: NPT1/2 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-L3AZ-DC12VPort: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-L3AZ-DC24VPort: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-L3AZ-DC48VPort: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-L3AZ-DC100VPort: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-L5AZ-AC100VPort: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-L5AZ-AC200VPort: NPT1/2 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-15N-M3AZ-DC12VPort: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-15N-M3AZ-DC24VPort: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-15N-M3AZ-DC48VPort: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-15N-M3AZ-DC100VPort: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-15N-M5AZ-AC100VPort: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-15N-M5AZ-AC200VPort: NPT1/2 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-H3AZ-DC12VPort: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-H3AZ-DC24VPort: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-H3AZ-DC48VPort: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-H3AZ-DC100VPort: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-H5AZ-AC100VPort: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-H5AZ-AC200VPort: Rc3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-J3AZ-DC12VPort: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-J3AZ-DC24VPort: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-J3AZ-DC48VPort: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-J3AZ-DC100VPort: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-J5AZ-AC100VPort: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-J5AZ-AC200VPort: Rc3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-L3AZ-DC12VPort: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-L3AZ-DC24VPort: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-L3AZ-DC48VPort: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-L3AZ-DC100VPort: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-L5AZ-AC100VPort: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-L5AZ-AC200VPort: Rc3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20A-M3AZ-DC12VPort: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20A-M3AZ-DC24VPort: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20A-M3AZ-DC48VPort: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20A-M3AZ-DC100VPort: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20A-M5AZ-AC100VPort: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20A-M5AZ-AC200VPort: Rc3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-H3AZ-DC12VPort: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-H3AZ-DC24VPort: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-H3AZ-DC48VPort: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-H3AZ-DC100VPort: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-H5AZ-AC100VPort: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-H5AZ-AC200VPort: G3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-J3AZ-DC12VPort: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-J3AZ-DC24VPort: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-J3AZ-DC48VPort: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-J3AZ-DC100VPort: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-J5AZ-AC100VPort: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-J5AZ-AC200VPort: G3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-L3AZ-DC12VPort: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-L3AZ-DC24VPort: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-L3AZ-DC48VPort: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-L3AZ-DC100VPort: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-L5AZ-AC100VPort: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-L5AZ-AC200VPort: G3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20G-M3AZ-DC12VPort: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20G-M3AZ-DC24VPort: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20G-M3AZ-DC48VPort: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20G-M3AZ-DC100VPort: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20G-M5AZ-AC100VPort: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20G-M5AZ-AC200VPort: G3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-H3AZ-DC12VPort: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-H3AZ-DC24VPort: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-H3AZ-DC48VPort: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-H3AZ-DC100VPort: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-H5AZ-AC100VPort: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-H5AZ-AC200VPort: NPT3/4 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-J3AZ-DC12VPort: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-J3AZ-DC24VPort: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-J3AZ-DC48VPort: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-J3AZ-DC100VPort: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-J5AZ-AC100VPort: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-J5AZ-AC200VPort: NPT3/4 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-L3AZ-DC12VPort: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-L3AZ-DC24VPort: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-L3AZ-DC48VPort: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-L3AZ-DC100VPort: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-L5AZ-AC100VPort: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-L5AZ-AC200VPort: NPT3/4 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-20N-M3AZ-DC12VPort: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-20N-M3AZ-DC24VPort: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-20N-M3AZ-DC48VPort: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-20N-M3AZ-DC100VPort: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-20N-M5AZ-AC100VPort: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-20N-M5AZ-AC200VPort: NPT3/4 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-H3AZ-DC12VPort: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-H3AZ-DC24VPort: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-H3AZ-DC48VPort: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-H3AZ-DC100VPort: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-H5AZ-AC100VPort: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-H5AZ-AC200VPort: Rc1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-J3AZ-DC12VPort: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-J3AZ-DC24VPort: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-J3AZ-DC48VPort: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-J3AZ-DC100VPort: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-J5AZ-AC100VPort: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-J5AZ-AC200VPort: Rc1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-L3AZ-DC12VPort: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-L3AZ-DC24VPort: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-L3AZ-DC48VPort: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-L3AZ-DC100VPort: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-L5AZ-AC100VPort: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-L5AZ-AC200VPort: Rc1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25A-M3AZ-DC12VPort: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25A-M3AZ-DC24VPort: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25A-M3AZ-DC48VPort: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25A-M3AZ-DC100VPort: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25A-M5AZ-AC100VPort: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25A-M5AZ-AC200VPort: Rc1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-H3AZ-DC12VPort: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-H3AZ-DC24VPort: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-H3AZ-DC48VPort: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-H3AZ-DC100VPort: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-H5AZ-AC100VPort: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-H5AZ-AC200VPort: G1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-J3AZ-DC12VPort: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-J3AZ-DC24VPort: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-J3AZ-DC48VPort: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-J3AZ-DC100VPort: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-J5AZ-AC100VPort: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-J5AZ-AC200VPort: G1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-L3AZ-DC12VPort: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-L3AZ-DC24VPort: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-L3AZ-DC48VPort: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-L3AZ-DC100VPort: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-L5AZ-AC100VPort: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-L5AZ-AC200VPort: G1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25G-M3AZ-DC12VPort: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25G-M3AZ-DC24VPort: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25G-M3AZ-DC48VPort: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25G-M3AZ-DC100VPort: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25G-M5AZ-AC100VPort: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25G-M5AZ-AC200VPort: G1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-H3AZ-DC12VPort: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-H3AZ-DC24VPort: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-H3AZ-DC48VPort: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-H3AZ-DC100VPort: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-H5AZ-AC100VPort: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-H5AZ-AC200VPort: NPT1 | Body/seal: Bronze, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-J3AZ-DC12VPort: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-J3AZ-DC24VPort: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-J3AZ-DC48VPort: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-J3AZ-DC100VPort: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-J5AZ-AC100VPort: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-J5AZ-AC200VPort: NPT1 | Body/seal: Bronze, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-L3AZ-DC12VPort: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-L3AZ-DC24VPort: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-L3AZ-DC48VPort: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-L3AZ-DC100VPort: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-L5AZ-AC100VPort: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-L5AZ-AC200VPort: NPT1 | Body/seal: Stainless, NBR, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V
ADK11-25N-M3AZ-DC12VPort: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC12V
ADK11-25N-M3AZ-DC24VPort: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC24V
ADK11-25N-M3AZ-DC48VPort: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC48V
ADK11-25N-M3AZ-DC100VPort: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead wire (DC) | Voltage: DC100V
ADK11-25N-M5AZ-AC100VPort: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC100V
ADK11-25N-M5AZ-AC200VPort: NPT1 | Body/seal: Stainless, FKM, oil-free | Coil: Open frame lead, diode (AC) | Voltage: AC200V

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
