CKD ADK21 MULTILEX Large Bore Pilot Kick 2-Port Solenoid Valve

CKD ADK21 MULTILEX Large Bore Pilot Kick 2-Port Solenoid Valve

CKD MULTILEX ADK21 large-bore pilot-kick diaphragm NC 2-port solenoid valve, Rc1-1/4 to Rc2 or 32-50 flange, from 0 MPa differential.

Key features

  • Pilot kick poppet with diaphragm drive, operates from 0 MPa differential
  • Rc1-1/4 to Rc2 threaded or 32/40/50 JIS 10K flange bodies (flanges sold separately)
  • Bronze or stainless body with NBR or FKM seal; oil-free treated H/J/L/M on request
  • Coil housings: open frame lead (standard) or HP terminal box; class H and diode coils also available
  • Options not multiplied: cable gland/conduit, surge killer (S)

Specifications

Model ADK21 NC
Fluid Air, low vacuum, water, kerosene, oil (50 mm2/s)
Operating pressure diff. 0-0.7 MPa
Max. working pressure 1 MPa
Proof pressure 3.2 MPa (water)
Fluid temperature -10 to 60°C
Orifice 35 / 43 / 53 mm
Cv 25 / 34 / 53
Mounting Coil-up vertical only
Source CKD Korea catalog CB-03-1SK-9, p. 388-393
ADK21-32A-03A-AC100V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-03A-AC200V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-03A-DC12V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-03A-DC24V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-03A-DC48V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-03A-DC100V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-03M-AC100V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-03M-AC200V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-03M-DC12V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-03M-DC24V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-03M-DC48V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-03M-DC100V Port: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32A-B3A-AC100V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-B3A-AC200V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-B3A-DC12V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-B3A-DC24V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-B3A-DC48V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-B3A-DC100V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-B3M-AC100V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-B3M-AC200V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-B3M-DC12V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-B3M-DC24V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-B3M-DC48V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-B3M-DC100V Port: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32A-D3A-AC100V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-D3A-AC200V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-D3A-DC12V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-D3A-DC24V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-D3A-DC48V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-D3A-DC100V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-D3M-AC100V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-D3M-AC200V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-D3M-DC12V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-D3M-DC24V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-D3M-DC48V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-D3M-DC100V Port: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32A-E3A-AC100V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-E3A-AC200V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-E3A-DC12V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-E3A-DC24V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-E3A-DC48V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-E3A-DC100V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-E3M-AC100V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-E3M-AC200V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-E3M-DC12V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-E3M-DC24V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-E3M-DC48V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-E3M-DC100V Port: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-03A-AC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-03A-AC200V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-03A-DC12V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-03A-DC24V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-03A-DC48V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-03A-DC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-03M-AC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-03M-AC200V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-03M-DC12V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-03M-DC24V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-03M-DC48V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-03M-DC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-B3A-AC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-B3A-AC200V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-B3A-DC12V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-B3A-DC24V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-B3A-DC48V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-B3A-DC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-B3M-AC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-B3M-AC200V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-B3M-DC12V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-B3M-DC24V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-B3M-DC48V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-B3M-DC100V Port: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-D3A-AC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-D3A-AC200V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-D3A-DC12V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-D3A-DC24V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-D3A-DC48V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-D3A-DC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-D3M-AC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-D3M-AC200V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-D3M-DC12V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-D3M-DC24V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-D3M-DC48V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-D3M-DC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-E3A-AC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-E3A-AC200V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-E3A-DC12V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-E3A-DC24V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-E3A-DC48V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-E3A-DC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-E3M-AC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-E3M-AC200V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-E3M-DC12V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-E3M-DC24V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-E3M-DC48V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-E3M-DC100V Port: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-03A-AC100V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-03A-AC200V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-03A-DC12V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-03A-DC24V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-03A-DC48V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-03A-DC100V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-03M-AC100V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-03M-AC200V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-03M-DC12V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-03M-DC24V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-03M-DC48V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-03M-DC100V Port: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-B3A-AC100V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-B3A-AC200V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-B3A-DC12V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-B3A-DC24V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-B3A-DC48V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-B3A-DC100V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-B3M-AC100V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-B3M-AC200V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-B3M-DC12V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-B3M-DC24V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-B3M-DC48V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-B3M-DC100V Port: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-D3A-AC100V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-D3A-AC200V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-D3A-DC12V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-D3A-DC24V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-D3A-DC48V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-D3A-DC100V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-D3M-AC100V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-D3M-AC200V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-D3M-DC12V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-D3M-DC24V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-D3M-DC48V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-D3M-DC100V Port: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-E3A-AC100V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-E3A-AC200V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-E3A-DC12V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-E3A-DC24V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-E3A-DC48V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-E3A-DC100V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-E3M-AC100V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-E3M-AC200V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-E3M-DC12V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-E3M-DC24V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-E3M-DC48V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-E3M-DC100V Port: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-03A-AC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-03A-AC200V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-03A-DC12V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-03A-DC24V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-03A-DC48V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-03A-DC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-03M-AC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-03M-AC200V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-03M-DC12V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-03M-DC24V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-03M-DC48V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-03M-DC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-B3A-AC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-B3A-AC200V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-B3A-DC12V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-B3A-DC24V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-B3A-DC48V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-B3A-DC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-B3M-AC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-B3M-AC200V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-B3M-DC12V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-B3M-DC24V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-B3M-DC48V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-B3M-DC100V Port: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-D3A-AC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-D3A-AC200V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-D3A-DC12V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-D3A-DC24V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-D3A-DC48V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-D3A-DC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-D3M-AC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-D3M-AC200V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-D3M-DC12V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-D3M-DC24V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-D3M-DC48V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-D3M-DC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-E3A-AC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-E3A-AC200V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-E3A-DC12V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-E3A-DC24V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-E3A-DC48V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-E3A-DC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-E3M-AC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-E3M-AC200V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-E3M-DC12V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-E3M-DC24V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-E3M-DC48V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-E3M-DC100V Port: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-03A-AC100V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-03A-AC200V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-03A-DC12V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-03A-DC24V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-03A-DC48V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-03A-DC100V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-03M-AC100V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-03M-AC200V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-03M-DC12V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-03M-DC24V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-03M-DC48V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-03M-DC100V Port: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-B3A-AC100V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-B3A-AC200V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-B3A-DC12V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-B3A-DC24V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-B3A-DC48V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-B3A-DC100V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-B3M-AC100V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-B3M-AC200V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-B3M-DC12V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-B3M-DC24V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-B3M-DC48V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-B3M-DC100V Port: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-D3A-AC100V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-D3A-AC200V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-D3A-DC12V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-D3A-DC24V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-D3A-DC48V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-D3A-DC100V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-D3M-AC100V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-D3M-AC200V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-D3M-DC12V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-D3M-DC24V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-D3M-DC48V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-D3M-DC100V Port: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-E3A-AC100V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-E3A-AC200V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-E3A-DC12V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-E3A-DC24V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-E3A-DC48V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-E3A-DC100V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-E3M-AC100V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-E3M-AC200V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-E3M-DC12V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-E3M-DC24V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-E3M-DC48V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-E3M-DC100V Port: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-03A-AC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-03A-AC200V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-03A-DC12V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-03A-DC24V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-03A-DC48V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-03A-DC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-03M-AC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-03M-AC200V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-03M-DC12V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-03M-DC24V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-03M-DC48V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-03M-DC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-B3A-AC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-B3A-AC200V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-B3A-DC12V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-B3A-DC24V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-B3A-DC48V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-B3A-DC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-B3M-AC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-B3M-AC200V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-B3M-DC12V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-B3M-DC24V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-B3M-DC48V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-B3M-DC100V Port: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-D3A-AC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-D3A-AC200V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-D3A-DC12V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-D3A-DC24V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-D3A-DC48V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-D3A-DC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-D3M-AC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-D3M-AC200V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-D3M-DC12V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-D3M-DC24V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-D3M-DC48V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-D3M-DC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-E3A-AC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-E3A-AC200V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-E3A-DC12V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-E3A-DC24V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-E3A-DC48V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-E3A-DC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-E3M-AC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-E3M-AC200V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-E3M-DC12V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-E3M-DC24V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-E3M-DC48V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-E3M-DC100V Port: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
Solenoid ValvesCKD
288 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD ADK21 MULTILEX Large Bore Pilot Kick 2-Port Solenoid Valve

Brand CKD·Solenoid Valves

Available part numbers (288)

ADK21-32A-03A-AC100V, ADK21-32A-03A-AC200V, ADK21-32A-03A-DC12V, ADK21-32A-03A-DC24V, ADK21-32A-03A-DC48V, ADK21-32A-03A-DC100V, ADK21-32A-03M-AC100V, ADK21-32A-03M-AC200V, ADK21-32A-03M-DC12V, ADK21-32A-03M-DC24V + 278 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ADK21-32A-03A-AC100VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-03A-AC200VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-03A-DC12VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-03A-DC24VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-03A-DC48VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-03A-DC100VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-03M-AC100VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-03M-AC200VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-03M-DC12VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-03M-DC24VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-03M-DC48VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-03M-DC100VPort: Rc1-1/4 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32A-B3A-AC100VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-B3A-AC200VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-B3A-DC12VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-B3A-DC24VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-B3A-DC48VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-B3A-DC100VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-B3M-AC100VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-B3M-AC200VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-B3M-DC12VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-B3M-DC24VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-B3M-DC48VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-B3M-DC100VPort: Rc1-1/4 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32A-D3A-AC100VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-D3A-AC200VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-D3A-DC12VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-D3A-DC24VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-D3A-DC48VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-D3A-DC100VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-D3M-AC100VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-D3M-AC200VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-D3M-DC12VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-D3M-DC24VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-D3M-DC48VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-D3M-DC100VPort: Rc1-1/4 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32A-E3A-AC100VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32A-E3A-AC200VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32A-E3A-DC12VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32A-E3A-DC24VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32A-E3A-DC48VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32A-E3A-DC100VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32A-E3M-AC100VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32A-E3M-AC200VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32A-E3M-DC12VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32A-E3M-DC24VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32A-E3M-DC48VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32A-E3M-DC100VPort: Rc1-1/4 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-03A-AC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-03A-AC200VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-03A-DC12VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-03A-DC24VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-03A-DC48VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-03A-DC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-03M-AC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-03M-AC200VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-03M-DC12VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-03M-DC24VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-03M-DC48VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-03M-DC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-B3A-AC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-B3A-AC200VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-B3A-DC12VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-B3A-DC24VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-B3A-DC48VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-B3A-DC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-B3M-AC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-B3M-AC200VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-B3M-DC12VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-B3M-DC24VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-B3M-DC48VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-B3M-DC100VPort: 32 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-D3A-AC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-D3A-AC200VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-D3A-DC12VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-D3A-DC24VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-D3A-DC48VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-D3A-DC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-D3M-AC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-D3M-AC200VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-D3M-DC12VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-D3M-DC24VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-D3M-DC48VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-D3M-DC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-32F-E3A-AC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-32F-E3A-AC200VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-32F-E3A-DC12VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-32F-E3A-DC24VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-32F-E3A-DC48VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-32F-E3A-DC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-32F-E3M-AC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-32F-E3M-AC200VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-32F-E3M-DC12VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-32F-E3M-DC24VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-32F-E3M-DC48VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-32F-E3M-DC100VPort: 32 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-03A-AC100VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-03A-AC200VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-03A-DC12VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-03A-DC24VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-03A-DC48VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-03A-DC100VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-03M-AC100VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-03M-AC200VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-03M-DC12VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-03M-DC24VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-03M-DC48VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-03M-DC100VPort: Rc1-1/2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-B3A-AC100VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-B3A-AC200VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-B3A-DC12VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-B3A-DC24VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-B3A-DC48VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-B3A-DC100VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-B3M-AC100VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-B3M-AC200VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-B3M-DC12VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-B3M-DC24VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-B3M-DC48VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-B3M-DC100VPort: Rc1-1/2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-D3A-AC100VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-D3A-AC200VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-D3A-DC12VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-D3A-DC24VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-D3A-DC48VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-D3A-DC100VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-D3M-AC100VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-D3M-AC200VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-D3M-DC12VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-D3M-DC24VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-D3M-DC48VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-D3M-DC100VPort: Rc1-1/2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40A-E3A-AC100VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40A-E3A-AC200VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40A-E3A-DC12VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40A-E3A-DC24VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40A-E3A-DC48VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40A-E3A-DC100VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40A-E3M-AC100VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40A-E3M-AC200VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40A-E3M-DC12VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40A-E3M-DC24VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40A-E3M-DC48VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40A-E3M-DC100VPort: Rc1-1/2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-03A-AC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-03A-AC200VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-03A-DC12VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-03A-DC24VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-03A-DC48VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-03A-DC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-03M-AC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-03M-AC200VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-03M-DC12VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-03M-DC24VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-03M-DC48VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-03M-DC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-B3A-AC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-B3A-AC200VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-B3A-DC12VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-B3A-DC24VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-B3A-DC48VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-B3A-DC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-B3M-AC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-B3M-AC200VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-B3M-DC12VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-B3M-DC24VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-B3M-DC48VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-B3M-DC100VPort: 40 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-D3A-AC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-D3A-AC200VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-D3A-DC12VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-D3A-DC24VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-D3A-DC48VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-D3A-DC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-D3M-AC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-D3M-AC200VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-D3M-DC12VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-D3M-DC24VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-D3M-DC48VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-D3M-DC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-40F-E3A-AC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-40F-E3A-AC200VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-40F-E3A-DC12VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-40F-E3A-DC24VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-40F-E3A-DC48VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-40F-E3A-DC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-40F-E3M-AC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-40F-E3M-AC200VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-40F-E3M-DC12VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-40F-E3M-DC24VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-40F-E3M-DC48VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-40F-E3M-DC100VPort: 40 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-03A-AC100VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-03A-AC200VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-03A-DC12VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-03A-DC24VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-03A-DC48VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-03A-DC100VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-03M-AC100VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-03M-AC200VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-03M-DC12VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-03M-DC24VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-03M-DC48VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-03M-DC100VPort: Rc2 | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-B3A-AC100VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-B3A-AC200VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-B3A-DC12VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-B3A-DC24VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-B3A-DC48VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-B3A-DC100VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-B3M-AC100VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-B3M-AC200VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-B3M-DC12VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-B3M-DC24VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-B3M-DC48VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-B3M-DC100VPort: Rc2 | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-D3A-AC100VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-D3A-AC200VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-D3A-DC12VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-D3A-DC24VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-D3A-DC48VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-D3A-DC100VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-D3M-AC100VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-D3M-AC200VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-D3M-DC12VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-D3M-DC24VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-D3M-DC48VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-D3M-DC100VPort: Rc2 | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50A-E3A-AC100VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50A-E3A-AC200VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50A-E3A-DC12VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50A-E3A-DC24VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50A-E3A-DC48VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50A-E3A-DC100VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50A-E3M-AC100VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50A-E3M-AC200VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50A-E3M-DC12VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50A-E3M-DC24VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50A-E3M-DC48VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50A-E3M-DC100VPort: Rc2 | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-03A-AC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-03A-AC200VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-03A-DC12VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-03A-DC24VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-03A-DC48VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-03A-DC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-03M-AC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-03M-AC200VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-03M-DC12VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-03M-DC24VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-03M-DC48VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-03M-DC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-B3A-AC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-B3A-AC200VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-B3A-DC12VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-B3A-DC24VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-B3A-DC48VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-B3A-DC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-B3M-AC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-B3M-AC200VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-B3M-DC12VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-B3M-DC24VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-B3M-DC48VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-B3M-DC100VPort: 50 flange (JIS 10K) | Body/seal: Bronze body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-D3A-AC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-D3A-AC200VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-D3A-DC12VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-D3A-DC24VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-D3A-DC48VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-D3A-DC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-D3M-AC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-D3M-AC200VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-D3M-DC12VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-D3M-DC24VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-D3M-DC48VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-D3M-DC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, NBR seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V
ADK21-50F-E3A-AC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC100V
ADK21-50F-E3A-AC200VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: AC200V
ADK21-50F-E3A-DC12VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC12V
ADK21-50F-E3A-DC24VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC24V
ADK21-50F-E3A-DC48VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC48V
ADK21-50F-E3A-DC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame lead wire (IP65) | Voltage: DC100V
ADK21-50F-E3M-AC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC100V
ADK21-50F-E3M-AC200VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: AC200V
ADK21-50F-E3M-DC12VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC12V
ADK21-50F-E3M-DC24VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC24V
ADK21-50F-E3M-DC48VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC48V
ADK21-50F-E3M-DC100VPort: 50 flange (JIS 10K) | Body/seal: Stainless body, FKM seal | Coil housing: Open frame, HP terminal box | Voltage: DC100V

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
