CKD AMG303R/403R/503R Air Operated 3-Port Valve for Chemicals

CKD AMG303R/403R/503R Air Operated 3-Port Valve for Chemicals

CKD AMG303R/403R/503R made-to-order air-operated 3-port (NC + NO pair) diaphragm valves for chemicals and pure water, orifice 6 to 20 mm.

Key features

  • Fluororesin construction: PVDF actuator, PTFE diaphragm, integrated tube fittings
  • Connections: Super 300 type Pillar fitting (P series, UP) or F-LOCK 60 series fitting (UR), metric and inch tubes
  • Orifice: AMG303R 6-10 mm, AMG403R 15-16 mm, AMG503R 20 mm; PTFE body
  • Actuator 00 ON-OFF with indicator or 10 with flow adjustment; A port position L or R
  • Sensor-equipped actuators (A1/A3/B1/B3 NPN, C1/D1 PNP; cable 1 m or 3 m) replace 00/10 in the code and are not expanded
  • Made to order; AMG403R/503R subject to export control. Example: AMG303R-10UP-00L

Specifications

Fluid Chemicals, pure water, air, N2 gas
Fluid temperature 5 to 120 C (HF 5-80 C; F-LOCK 5-100 C)
Proof pressure 1.0 MPa
Operating pressure A-B / B-A 0-0.5 MPa
Seat leakage 0 (water)
Back pressure 0-0.5 MPa
Operating (pilot) pressure 0.35-0.5 MPa
Pilot port Rc1/8
Mass 0.50 / 1.0 / 2.1 kg (303/403/503)
Source CKD Korea catalog CB-03-1SK-9, p. 1192-1197
