CKD BW/JW/AW400/AW800 Outdoor FRL Brackets, Joiners and Adapters

CKD BW/JW/AW400/AW800 Outdoor FRL Brackets, Joiners and Adapters

CKD outdoor-series accessories for FRL units and drain separators: T-bracket sets, joiner sets and piping adapter sets.

Key features

  • T-bracket sets BW310-W / BW410-W / BW810-W for 3000, 4000 and 8000 series units
  • Joiner sets C4000-JW400-W and C8000-JW800-W for modular connection
  • Piping adapter sets AW400/AW800 Rc1/4 to Rc1 1/4, also with bracket (B31W/B41W/B81W)
  • Aluminium die-cast body with stainless steel mounting screws

Specifications

Material Aluminium die-cast
Screws Stainless steel
Series Outdoor WP series
Applicable units FW/RW/LW/MW/WW-W, FXW-W
Seal (4000 size) O-ring JIS B2401-P21
Seal (8000 size) O-ring AS568-127
Source CKD Korea catalog CC-1276K, p. 32-32
BW310-W Type: T bracket set | Port size: - | Applicable: 3000 series, FX1004
AW400-8-W-B31W Type: Adapter set with bracket | Port size: Rc1/4 | Applicable: 3000, FX1004
AW400-10-W-B31W Type: Adapter set with bracket | Port size: Rc3/8 | Applicable: 3000, FX1004
AW400-15-W-B31W Type: Adapter set with bracket | Port size: Rc1/2 | Applicable: 3000, FX1004
FRL AccessoriesCKD
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD BW/JW/AW400/AW800 Outdoor FRL Brackets, Joiners and Adapters

Brand CKD·FRL Accessories

Available part numbers (4)

BW310-W, AW400-8-W-B31W, AW400-10-W-B31W, AW400-15-W-B31W

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
BW310-WType: T bracket set | Port size: - | Applicable: 3000 series, FX1004
AW400-8-W-B31WType: Adapter set with bracket | Port size: Rc1/4 | Applicable: 3000, FX1004
AW400-10-W-B31WType: Adapter set with bracket | Port size: Rc3/8 | Applicable: 3000, FX1004
AW400-15-W-B31WType: Adapter set with bracket | Port size: Rc1/2 | Applicable: 3000, FX1004
