CKD C1050-C8050-W-FP1 R.M Combination (Food Grade, Rc1/8-1)

CKD C1050-C8050-W-FP1 R.M Combination (Food Grade, Rc1/8-1)

CKD R.M combination C1050-W to C8050-W FP1: regulator and oil mist filter integrated in one food-processing unit.

Key features

  • FP1 food-processing white series using NSF H1 registered grease
  • Regulator + oil mist filter
  • Set pressure 0.1 to 0.85 MPa
  • Drain: manual cock or auto drain F1 (N.C.)
  • Ports Rc1/8 to Rc1
  • Other options (bowl Z/M/M1, Q, L, N, T/T8/T6, X1), piping adapter sets and gauge options added per ordering chart

Specifications

Fluid Compressed air
Max. operating pressure 1.0 MPa
Proof pressure 1.5 MPa
Ambient/fluid temperature 5 to 60 C
Outlet oil content 0.01 mg/m3 or less
Set pressure 0.1 to 0.85 MPa
Source CKD Korea catalog CC-1271K-5, p. 260-261
C1050-6-W-FP1 Model: C1050-W | Port: Rc1/8 | Drain: Manual drain cock
C1050-6-W-F1-FP1 Model: C1050-W | Port: Rc1/8 | Drain: Auto drain N.C.
C1050-8-W-FP1 Model: C1050-W | Port: Rc1/4 | Drain: Manual drain cock
C1050-8-W-F1-FP1 Model: C1050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C2050-8-W-FP1 Model: C2050-W | Port: Rc1/4 | Drain: Manual drain cock
C2050-8-W-F1-FP1 Model: C2050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C2050-10-W-FP1 Model: C2050-W | Port: Rc3/8 | Drain: Manual drain cock
C2050-10-W-F1-FP1 Model: C2050-W | Port: Rc3/8 | Drain: Auto drain N.C.
C2550-8-W-FP1 Model: C2550-W | Port: Rc1/4 | Drain: Manual drain cock
C2550-8-W-F1-FP1 Model: C2550-W | Port: Rc1/4 | Drain: Auto drain N.C.
C2550-10-W-FP1 Model: C2550-W | Port: Rc3/8 | Drain: Manual drain cock
C2550-10-W-F1-FP1 Model: C2550-W | Port: Rc3/8 | Drain: Auto drain N.C.
C3050-8-W-FP1 Model: C3050-W | Port: Rc1/4 | Drain: Manual drain cock
C3050-8-W-F1-FP1 Model: C3050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C3050-10-W-FP1 Model: C3050-W | Port: Rc3/8 | Drain: Manual drain cock
C3050-10-W-F1-FP1 Model: C3050-W | Port: Rc3/8 | Drain: Auto drain N.C.
C4050-8-W-FP1 Model: C4050-W | Port: Rc1/4 | Drain: Manual drain cock
C4050-8-W-F1-FP1 Model: C4050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C4050-10-W-FP1 Model: C4050-W | Port: Rc3/8 | Drain: Manual drain cock
C4050-10-W-F1-FP1 Model: C4050-W | Port: Rc3/8 | Drain: Auto drain N.C.
C4050-15-W-FP1 Model: C4050-W | Port: Rc1/2 | Drain: Manual drain cock
C4050-15-W-F1-FP1 Model: C4050-W | Port: Rc1/2 | Drain: Auto drain N.C.
C4050-20-W-FP1 Model: C4050-W | Port: Rc3/4 | Drain: Manual drain cock
C4050-20-W-F1-FP1 Model: C4050-W | Port: Rc3/4 | Drain: Auto drain N.C.
C6050-20-W-FP1 Model: C6050-W | Port: Rc3/4 | Drain: Manual drain cock
C6050-20-W-F1-FP1 Model: C6050-W | Port: Rc3/4 | Drain: Auto drain N.C.
C6050-25-W-FP1 Model: C6050-W | Port: Rc1 | Drain: Manual drain cock
C6050-25-W-F1-FP1 Model: C6050-W | Port: Rc1 | Drain: Auto drain N.C.
C8050-20-W-FP1 Model: C8050-W | Port: Rc3/4 | Drain: Manual drain cock
C8050-20-W-F1-FP1 Model: C8050-W | Port: Rc3/4 | Drain: Auto drain N.C.
C8050-25-W-FP1 Model: C8050-W | Port: Rc1 | Drain: Manual drain cock
C8050-25-W-F1-FP1 Model: C8050-W | Port: Rc1 | Drain: Auto drain N.C.
FRL UnitsCKD
32 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD C1050-C8050-W-FP1 R.M Combination (Food Grade, Rc1/8-1)

Brand CKD·FRL Units

Available part numbers (32)

C1050-6-W-FP1, C1050-6-W-F1-FP1, C1050-8-W-FP1, C1050-8-W-F1-FP1, C2050-8-W-FP1, C2050-8-W-F1-FP1, C2050-10-W-FP1, C2050-10-W-F1-FP1, C2550-8-W-FP1, C2550-8-W-F1-FP1 + 22 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
C1050-6-W-FP1Model: C1050-W | Port: Rc1/8 | Drain: Manual drain cock
C1050-6-W-F1-FP1Model: C1050-W | Port: Rc1/8 | Drain: Auto drain N.C.
C1050-8-W-FP1Model: C1050-W | Port: Rc1/4 | Drain: Manual drain cock
C1050-8-W-F1-FP1Model: C1050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C2050-8-W-FP1Model: C2050-W | Port: Rc1/4 | Drain: Manual drain cock
C2050-8-W-F1-FP1Model: C2050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C2050-10-W-FP1Model: C2050-W | Port: Rc3/8 | Drain: Manual drain cock
C2050-10-W-F1-FP1Model: C2050-W | Port: Rc3/8 | Drain: Auto drain N.C.
C2550-8-W-FP1Model: C2550-W | Port: Rc1/4 | Drain: Manual drain cock
C2550-8-W-F1-FP1Model: C2550-W | Port: Rc1/4 | Drain: Auto drain N.C.
C2550-10-W-FP1Model: C2550-W | Port: Rc3/8 | Drain: Manual drain cock
C2550-10-W-F1-FP1Model: C2550-W | Port: Rc3/8 | Drain: Auto drain N.C.
C3050-8-W-FP1Model: C3050-W | Port: Rc1/4 | Drain: Manual drain cock
C3050-8-W-F1-FP1Model: C3050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C3050-10-W-FP1Model: C3050-W | Port: Rc3/8 | Drain: Manual drain cock
C3050-10-W-F1-FP1Model: C3050-W | Port: Rc3/8 | Drain: Auto drain N.C.
C4050-8-W-FP1Model: C4050-W | Port: Rc1/4 | Drain: Manual drain cock
C4050-8-W-F1-FP1Model: C4050-W | Port: Rc1/4 | Drain: Auto drain N.C.
C4050-10-W-FP1Model: C4050-W | Port: Rc3/8 | Drain: Manual drain cock
C4050-10-W-F1-FP1Model: C4050-W | Port: Rc3/8 | Drain: Auto drain N.C.
C4050-15-W-FP1Model: C4050-W | Port: Rc1/2 | Drain: Manual drain cock
C4050-15-W-F1-FP1Model: C4050-W | Port: Rc1/2 | Drain: Auto drain N.C.
C4050-20-W-FP1Model: C4050-W | Port: Rc3/4 | Drain: Manual drain cock
C4050-20-W-F1-FP1Model: C4050-W | Port: Rc3/4 | Drain: Auto drain N.C.
C6050-20-W-FP1Model: C6050-W | Port: Rc3/4 | Drain: Manual drain cock
C6050-20-W-F1-FP1Model: C6050-W | Port: Rc3/4 | Drain: Auto drain N.C.
C6050-25-W-FP1Model: C6050-W | Port: Rc1 | Drain: Manual drain cock
C6050-25-W-F1-FP1Model: C6050-W | Port: Rc1 | Drain: Auto drain N.C.
C8050-20-W-FP1Model: C8050-W | Port: Rc3/4 | Drain: Manual drain cock
C8050-20-W-F1-FP1Model: C8050-W | Port: Rc3/4 | Drain: Auto drain N.C.
C8050-25-W-FP1Model: C8050-W | Port: Rc1 | Drain: Manual drain cock
C8050-25-W-F1-FP1Model: C8050-W | Port: Rc1 | Drain: Auto drain N.C.
