CKD CKW-A-HP1 3-Jaw Chuck (Long-Life, No Rubber Cover)

CKD CKW-A-HP1 3-Jaw Chuck (Long-Life, No Rubber Cover)

CKD CKW-A-HP1 long-life double-acting three-jaw air chuck for centring round workpieces, bore ø16 to ø40.

Key features

  • Three jaws move synchronously for centring round parts; jaw stroke 4, 6, 8 mm
  • Gripping force 16/14 N (ø16) to 130/118 N (ø40) open/close at 0.5 MPa
  • Optional high-precision locating hole (A)
  • Switch magnet built in; F-type solid-state switches (F2S/F3S, F2H/F2V, F3H/F3V, F3PH/F3PV); example CKW-A16DN-F2H-D-HP1
  • Outline dimensions as 3-jaw chuck catalog CC-1581

Specifications

Action Double acting
Max. operating pressure 0.7 MPa
Port size M3 (ø16), M5 (ø20-ø40)
Repeatability ±0.01 mm
Ambient temperature -10 to 60°C
Source CKD Korea catalog CC-1421KR-7, p. 178-179
CKW-A16DN-HP1 Bore: 16 mm | Locating hole: None | Grip force open/close: 16/14 N | Mass: 0.08 kg
CKW-A16DA-HP1 Bore: 16 mm | Locating hole: Yes | Grip force open/close: 16/14 N | Mass: 0.08 kg
CKW-A20DN-HP1 Bore: 20 mm | Locating hole: None | Grip force open/close: 28/25 N | Mass: 0.13 kg
CKW-A20DA-HP1 Bore: 20 mm | Locating hole: Yes | Grip force open/close: 28/25 N | Mass: 0.13 kg
CKW-A25DN-HP1 Bore: 25 mm | Locating hole: None | Grip force open/close: 47/42 N | Mass: 0.17 kg
CKW-A25DA-HP1 Bore: 25 mm | Locating hole: Yes | Grip force open/close: 47/42 N | Mass: 0.17 kg
CKW-A32DN-HP1 Bore: 32 mm | Locating hole: None | Grip force open/close: 82/74 N | Mass: 0.31 kg
CKW-A32DA-HP1 Bore: 32 mm | Locating hole: Yes | Grip force open/close: 82/74 N | Mass: 0.31 kg
CKW-A40DN-HP1 Bore: 40 mm | Locating hole: None | Grip force open/close: 130/118 N | Mass: 0.46 kg
CKW-A40DA-HP1 Bore: 40 mm | Locating hole: Yes | Grip force open/close: 130/118 N | Mass: 0.46 kg
Air GrippersCKD
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →
