CKD DSC-FP1 Speed Controller with Dial (Food Grade, R1/8-1/2)

CKD DSC-FP1 Speed Controller with Dial (Food Grade, R1/8-1/2)

CKD DSC-FP1 dial speed controllers whose numbered dial shows the needle setting, for repeatable cylinder speed adjustment.

Key features

  • FP1 food-processing series using NSF H1 registered grease
  • Dial indicates needle position; 1 to 10 turns control range
  • Meter-out standard or meter-in I; standard or low flow L
  • Ports R1/8 to R1/2, push-in tubes 4 to 12 mm

Specifications

Fluid Compressed air
Max. operating pressure 1.0 MPa
Min. operating pressure 0.05 MPa
Proof pressure 1.5 MPa
Fluid temperature 5 to 60 C
Source CKD Korea catalog CC-1271K-5, p. 300-301
DSC-6-4-FP1 Port: R1/8 | Tube OD: 4 mm | Control: Meter-out | Flow type: Standard flow
DSC-6-4-L-FP1 Port: R1/8 | Tube OD: 4 mm | Control: Meter-out | Flow type: Low flow
DSC-6-4-I-FP1 Port: R1/8 | Tube OD: 4 mm | Control: Meter-in | Flow type: Standard flow
DSC-6-4-IL-FP1 Port: R1/8 | Tube OD: 4 mm | Control: Meter-in | Flow type: Low flow
DSC-6-6-FP1 Port: R1/8 | Tube OD: 6 mm | Control: Meter-out | Flow type: Standard flow
DSC-6-6-L-FP1 Port: R1/8 | Tube OD: 6 mm | Control: Meter-out | Flow type: Low flow
DSC-6-6-I-FP1 Port: R1/8 | Tube OD: 6 mm | Control: Meter-in | Flow type: Standard flow
DSC-6-6-IL-FP1 Port: R1/8 | Tube OD: 6 mm | Control: Meter-in | Flow type: Low flow
DSC-6-8-FP1 Port: R1/8 | Tube OD: 8 mm | Control: Meter-out | Flow type: Standard flow
DSC-6-8-L-FP1 Port: R1/8 | Tube OD: 8 mm | Control: Meter-out | Flow type: Low flow
DSC-6-8-I-FP1 Port: R1/8 | Tube OD: 8 mm | Control: Meter-in | Flow type: Standard flow
DSC-6-8-IL-FP1 Port: R1/8 | Tube OD: 8 mm | Control: Meter-in | Flow type: Low flow
DSC-8-6-FP1 Port: R1/4 | Tube OD: 6 mm | Control: Meter-out | Flow type: Standard flow
DSC-8-6-L-FP1 Port: R1/4 | Tube OD: 6 mm | Control: Meter-out | Flow type: Low flow
DSC-8-6-I-FP1 Port: R1/4 | Tube OD: 6 mm | Control: Meter-in | Flow type: Standard flow
DSC-8-6-IL-FP1 Port: R1/4 | Tube OD: 6 mm | Control: Meter-in | Flow type: Low flow
DSC-8-8-FP1 Port: R1/4 | Tube OD: 8 mm | Control: Meter-out | Flow type: Standard flow
DSC-8-8-L-FP1 Port: R1/4 | Tube OD: 8 mm | Control: Meter-out | Flow type: Low flow
DSC-8-8-I-FP1 Port: R1/4 | Tube OD: 8 mm | Control: Meter-in | Flow type: Standard flow
DSC-8-8-IL-FP1 Port: R1/4 | Tube OD: 8 mm | Control: Meter-in | Flow type: Low flow
DSC-8-10-FP1 Port: R1/4 | Tube OD: 10 mm | Control: Meter-out | Flow type: Standard flow
DSC-8-10-L-FP1 Port: R1/4 | Tube OD: 10 mm | Control: Meter-out | Flow type: Low flow
DSC-8-10-I-FP1 Port: R1/4 | Tube OD: 10 mm | Control: Meter-in | Flow type: Standard flow
DSC-8-10-IL-FP1 Port: R1/4 | Tube OD: 10 mm | Control: Meter-in | Flow type: Low flow
DSC-10-6-FP1 Port: R3/8 | Tube OD: 6 mm | Control: Meter-out | Flow type: Standard flow
DSC-10-6-L-FP1 Port: R3/8 | Tube OD: 6 mm | Control: Meter-out | Flow type: Low flow
DSC-10-6-I-FP1 Port: R3/8 | Tube OD: 6 mm | Control: Meter-in | Flow type: Standard flow
DSC-10-6-IL-FP1 Port: R3/8 | Tube OD: 6 mm | Control: Meter-in | Flow type: Low flow
DSC-10-8-FP1 Port: R3/8 | Tube OD: 8 mm | Control: Meter-out | Flow type: Standard flow
DSC-10-8-L-FP1 Port: R3/8 | Tube OD: 8 mm | Control: Meter-out | Flow type: Low flow
DSC-10-8-I-FP1 Port: R3/8 | Tube OD: 8 mm | Control: Meter-in | Flow type: Standard flow
DSC-10-8-IL-FP1 Port: R3/8 | Tube OD: 8 mm | Control: Meter-in | Flow type: Low flow
DSC-10-10-FP1 Port: R3/8 | Tube OD: 10 mm | Control: Meter-out | Flow type: Standard flow
DSC-10-10-L-FP1 Port: R3/8 | Tube OD: 10 mm | Control: Meter-out | Flow type: Low flow
DSC-10-10-I-FP1 Port: R3/8 | Tube OD: 10 mm | Control: Meter-in | Flow type: Standard flow
DSC-10-10-IL-FP1 Port: R3/8 | Tube OD: 10 mm | Control: Meter-in | Flow type: Low flow
DSC-10-12-FP1 Port: R3/8 | Tube OD: 12 mm | Control: Meter-out | Flow type: Standard flow
DSC-10-12-L-FP1 Port: R3/8 | Tube OD: 12 mm | Control: Meter-out | Flow type: Low flow
DSC-10-12-I-FP1 Port: R3/8 | Tube OD: 12 mm | Control: Meter-in | Flow type: Standard flow
DSC-10-12-IL-FP1 Port: R3/8 | Tube OD: 12 mm | Control: Meter-in | Flow type: Low flow
DSC-15-10-FP1 Port: R1/2 | Tube OD: 10 mm | Control: Meter-out | Flow type: Standard flow
DSC-15-10-L-FP1 Port: R1/2 | Tube OD: 10 mm | Control: Meter-out | Flow type: Low flow
DSC-15-10-I-FP1 Port: R1/2 | Tube OD: 10 mm | Control: Meter-in | Flow type: Standard flow
DSC-15-10-IL-FP1 Port: R1/2 | Tube OD: 10 mm | Control: Meter-in | Flow type: Low flow
DSC-15-12-FP1 Port: R1/2 | Tube OD: 12 mm | Control: Meter-out | Flow type: Standard flow
DSC-15-12-L-FP1 Port: R1/2 | Tube OD: 12 mm | Control: Meter-out | Flow type: Low flow
DSC-15-12-I-FP1 Port: R1/2 | Tube OD: 12 mm | Control: Meter-in | Flow type: Standard flow
DSC-15-12-IL-FP1 Port: R1/2 | Tube OD: 12 mm | Control: Meter-in | Flow type: Low flow
Speed ControllersCKD
48 product codes available in this family
