CKD EV2500-FL Electro-Pneumatic Regulator for LBC (Made to Order)

CKD EV2500-FL Electro-Pneumatic Regulator for LBC (Made to Order)

CKD EV2500-FL made-to-order electro-pneumatic regulator dedicated to the LBC air bearing actuator, controlling 0 to 0.1 MPa in normally open configuration.

Key features

  • Pressure control range 0 to 0.1 MPa, NO type (rod does not extend at power off)
  • Input signal 0-10 V, 0-5 V, 4-20 mA / 1-5 V or 10 kOhm potentiometer
  • Identification number FL298410/11/12 matches LBC-01/05/30
  • Cable option C11 (1 m) / C13 (3 m) and bracket option B (C type) / B4 (B type) inserted before the ID number
  • Monitor output 1-1.8 V DC; linearity within 0.5% F.S.

Specifications

Fluid Clean compressed air (JIS B 8392-1 1.3.2)
Supply pressure 0.2 to 0.3 MPa
Port size Rc1/4
Proof pressure 0.7 MPa
Control range 0 to 0.1 MPa
Power supply 24 V DC +/-10%
Current consumption 0.1 A or less
Ambient temperature 5 to 50 C
Mass 330 g
Source CKD Korea catalog CB-030SK-9, p. 1089-1091
EV2500-008-FL298410 Input signal: 0-10 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-008-FL298411 Input signal: 0-10 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-008-FL298412 Input signal: 0-10 V DC | For actuator: LBC-30 | ID number: FL298412
EV2500-108-FL298410 Input signal: 0-5 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-108-FL298411 Input signal: 0-5 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-108-FL298412 Input signal: 0-5 V DC | For actuator: LBC-30 | ID number: FL298412
EV2500-208-FL298410 Input signal: 4-20 mA DC or 1-5 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-208-FL298411 Input signal: 4-20 mA DC or 1-5 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-208-FL298412 Input signal: 4-20 mA DC or 1-5 V DC | For actuator: LBC-30 | ID number: FL298412
EV2500-308-FL298410 Input signal: 10 kOhm pot. or 0-10 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-308-FL298411 Input signal: 10 kOhm pot. or 0-10 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-308-FL298412 Input signal: 10 kOhm pot. or 0-10 V DC | For actuator: LBC-30 | ID number: FL298412
Electro-Pneumatic RegulatorsCKD
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD EV2500-FL Electro-Pneumatic Regulator for LBC (Made to Order)

Brand CKD·Electro-Pneumatic Regulators

Available part numbers (12)

EV2500-008-FL298410, EV2500-008-FL298411, EV2500-008-FL298412, EV2500-108-FL298410, EV2500-108-FL298411, EV2500-108-FL298412, EV2500-208-FL298410, EV2500-208-FL298411, EV2500-208-FL298412, EV2500-308-FL298410 + 2 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EV2500-008-FL298410Input signal: 0-10 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-008-FL298411Input signal: 0-10 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-008-FL298412Input signal: 0-10 V DC | For actuator: LBC-30 | ID number: FL298412
EV2500-108-FL298410Input signal: 0-5 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-108-FL298411Input signal: 0-5 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-108-FL298412Input signal: 0-5 V DC | For actuator: LBC-30 | ID number: FL298412
EV2500-208-FL298410Input signal: 4-20 mA DC or 1-5 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-208-FL298411Input signal: 4-20 mA DC or 1-5 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-208-FL298412Input signal: 4-20 mA DC or 1-5 V DC | For actuator: LBC-30 | ID number: FL298412
EV2500-308-FL298410Input signal: 10 kOhm pot. or 0-10 V DC | For actuator: LBC-01 | ID number: FL298410
EV2500-308-FL298411Input signal: 10 kOhm pot. or 0-10 V DC | For actuator: LBC-05 | ID number: FL298411
EV2500-308-FL298412Input signal: 10 kOhm pot. or 0-10 V DC | For actuator: LBC-30 | ID number: FL298412
