CKD GAB312/GAB352-Z MULTILEX Dry Air 2-Port Valve Manifold

CKD MULTILEX GAB312/GAB352-Z direct-acting NC 2-port solenoid valve manifolds and actuators for dry air, inert gas and low vacuum, 2-10 stations.

Key features

Direct-acting NC poppet valves on a common manifold; 2-10 stations or single actuator (0)
GAB_12-Z common supply (C port pressurized), GAB_52-Z individual supply (A port pressurized)
Generated with brass body / NBR seal, oil-free (H); J/P/L/M/R body-seal combinations orderable
Rc ports standard; G and NPT thread versions orderable (suffix G/N after model)
Coils: 3A open frame DC, 5A diode AC; HP terminal box versions also available
Options not multiplied: manual override (A), cable gland/conduit, surge killer (S)

Specifications

Fluid	Dry air (dew point -60°C+), inert gas, low vacuum
Fluid temperature	-10 to 45°C
Ambient temperature	-10 to 45°C
Coil insulation	Class B (130)
Valve seat leakage	0.2 cm3/min (ANR) max.
Mounting	Any orientation
Body/seal	Brass, NBR, oil-free (H)
Max. working pressure	5 MPa
Operating pressure diff.	0-4 MPa (by orifice)
Proof pressure	10 MPa (water)
Source	CKD Korea catalog CB-03-1SK-9, p. 408-411

GAB312-1-0-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-0-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-0-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-0-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-0-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-0-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-2-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-2-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-2-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-2-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-2-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-2-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-3-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-3-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-3-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-3-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-3-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-3-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-4-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-4-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-4-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-4-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-4-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-4-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-5-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-5-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-5-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-5-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-5-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-5-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-6-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-6-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-6-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-6-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-6-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-6-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-7-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-7-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-7-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-7-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-7-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-7-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-8-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-8-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-8-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-8-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-8-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-8-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-9-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-9-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-9-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-9-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-9-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-9-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-1-10-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-1-10-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-1-10-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-1-10-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-1-10-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-1-10-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-0-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-0-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-0-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-0-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-0-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-0-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-2-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-2-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-2-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-2-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-2-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-2-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-3-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-3-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-3-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-3-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-3-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-3-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-4-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-4-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-4-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-4-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-4-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-4-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-5-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-5-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-5-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-5-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-5-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-5-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-6-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-6-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-6-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-6-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-6-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-6-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-7-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-7-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-7-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-7-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-7-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-7-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-8-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-8-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-8-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-8-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-8-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-8-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-9-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-9-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-9-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-9-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-9-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-9-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-2-10-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-2-10-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-2-10-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-2-10-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-2-10-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-2-10-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-0-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-0-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-0-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-0-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-0-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-0-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-2-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-2-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-2-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-2-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-2-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-2-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-3-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-3-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-3-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-3-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-3-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-3-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-4-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-4-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-4-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-4-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-4-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-4-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-5-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-5-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-5-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-5-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-5-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-5-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-6-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-6-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-6-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-6-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-6-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-6-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-7-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-7-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-7-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-7-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-7-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-7-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-8-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-8-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-8-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-8-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-8-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-8-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-9-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-9-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-9-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-9-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-9-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-9-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-3-10-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-3-10-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-3-10-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-3-10-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-3-10-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-3-10-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-0-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-0-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-0-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-0-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-0-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-0-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-2-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-2-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-2-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-2-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-2-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-2-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-3-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-3-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-3-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-3-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-3-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-3-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-4-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-4-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-4-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-4-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-4-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-4-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-5-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-5-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-5-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-5-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-5-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-5-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-6-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-6-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-6-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-6-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-6-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-6-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-7-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-7-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-7-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-7-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-7-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-7-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-8-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-8-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-8-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-8-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-8-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-8-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-9-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-9-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-9-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-9-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-9-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-9-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-4-10-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-4-10-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-4-10-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-4-10-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-4-10-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-4-10-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-0-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-0-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-0-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-0-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-0-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-0-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-2-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-2-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-2-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-2-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-2-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-2-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-3-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-3-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-3-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-3-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-3-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-3-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-4-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-4-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-4-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-4-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-4-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-4-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-5-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-5-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-5-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-5-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-5-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-5-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-6-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-6-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-6-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-6-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-6-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-6-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-7-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-7-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-7-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-7-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-7-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-7-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-8-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-8-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-8-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-8-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-8-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-8-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-9-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-9-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-9-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-9-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-9-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-9-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-5-10-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-5-10-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-5-10-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-5-10-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-5-10-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-5-10-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-0-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-0-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-0-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-0-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-0-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-0-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-2-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-2-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-2-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-2-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-2-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-2-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-3-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-3-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-3-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-3-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-3-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-3-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-4-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-4-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-4-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-4-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-4-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-4-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-5-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-5-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-5-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-5-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-5-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-5-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-6-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-6-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-6-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-6-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-6-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-6-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-7-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-7-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-7-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-7-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-7-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-7-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-8-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-8-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-8-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-8-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-8-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-8-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-9-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-9-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-9-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-9-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-9-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-9-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB312-6-10-H3AZ-DC12V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB312-6-10-H3AZ-DC24V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB312-6-10-H3AZ-DC48V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB312-6-10-H3AZ-DC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB312-6-10-H5AZ-AC100V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB312-6-10-H5AZ-AC200V		Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-0-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-0-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-0-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-0-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-0-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-0-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-2-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-2-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-2-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-2-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-2-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-2-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-3-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-3-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-3-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-3-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-3-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-3-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-4-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-4-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-4-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-4-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-4-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-4-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-5-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-5-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-5-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-5-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-5-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-5-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-6-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-6-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-6-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-6-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-6-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-6-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-7-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-7-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-7-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-7-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-7-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-7-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-8-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-8-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-8-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-8-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-8-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-8-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-9-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-9-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-9-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-9-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-9-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-9-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-1-10-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-1-10-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-1-10-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-1-10-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-1-10-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-1-10-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-0-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-0-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-0-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-0-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-0-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-0-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-2-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-2-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-2-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-2-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-2-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-2-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-3-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-3-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-3-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-3-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-3-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-3-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-4-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-4-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-4-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-4-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-4-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-4-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-5-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-5-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-5-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-5-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-5-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-5-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-6-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-6-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-6-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-6-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-6-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-6-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-7-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-7-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-7-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-7-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-7-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-7-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-8-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-8-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-8-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-8-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-8-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-8-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-9-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-9-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-9-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-9-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-9-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-9-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-2-10-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-2-10-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-2-10-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-2-10-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-2-10-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-2-10-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-0-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-0-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-0-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-0-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-0-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-0-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-2-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-2-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-2-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-2-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-2-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-2-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-3-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-3-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-3-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-3-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-3-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-3-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-4-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-4-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-4-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-4-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-4-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-4-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-5-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-5-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-5-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-5-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-5-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-5-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-6-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-6-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-6-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-6-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-6-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-6-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-7-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-7-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-7-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-7-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-7-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-7-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-8-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-8-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-8-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-8-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-8-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-8-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-9-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-9-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-9-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-9-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-9-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-9-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-3-10-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-3-10-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-3-10-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-3-10-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-3-10-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-3-10-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-0-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-0-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-0-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-0-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-0-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-0-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-2-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-2-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-2-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-2-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-2-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-2-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-3-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-3-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-3-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-3-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-3-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-3-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-4-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-4-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-4-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-4-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-4-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-4-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-5-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-5-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-5-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-5-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-5-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-5-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-6-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-6-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-6-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-6-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-6-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-6-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-7-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-7-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-7-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-7-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-7-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-7-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-8-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-8-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-8-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-8-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-8-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-8-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-9-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-9-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-9-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-9-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-9-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-9-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-4-10-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-4-10-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-4-10-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-4-10-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-4-10-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-4-10-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-0-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-0-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-0-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-0-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-0-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-0-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-2-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-2-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-2-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-2-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-2-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-2-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-3-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-3-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-3-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-3-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-3-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-3-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-4-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-4-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-4-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-4-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-4-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-4-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-5-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-5-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-5-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-5-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-5-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-5-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-6-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-6-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-6-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-6-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-6-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-6-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-7-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-7-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-7-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-7-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-7-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-7-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-8-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-8-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-8-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-8-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-8-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-8-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-9-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-9-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-9-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-9-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-9-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-9-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-5-10-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-5-10-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-5-10-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-5-10-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-5-10-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-5-10-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-0-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-0-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-0-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-0-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-0-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-0-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-2-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-2-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-2-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-2-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-2-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-2-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-3-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-3-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-3-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-3-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-3-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-3-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-4-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-4-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-4-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-4-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-4-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-4-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-5-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-5-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-5-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-5-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-5-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-5-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-6-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-6-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-6-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-6-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-6-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-6-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-7-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-7-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-7-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-7-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-7-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-7-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-8-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-8-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-8-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-8-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-8-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-8-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-9-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-9-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-9-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-9-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-9-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-9-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB352-6-10-H3AZ-DC12V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB352-6-10-H3AZ-DC24V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB352-6-10-H3AZ-DC48V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB352-6-10-H3AZ-DC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB352-6-10-H5AZ-AC100V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB352-6-10-H5AZ-AC200V		Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V

Solenoid ValvesCKD

720 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD GAB312/GAB352-Z MULTILEX Dry Air 2-Port Valve Manifold

Brand CKD·Solenoid Valves

Available part numbers (720)

GAB312-1-0-H3AZ-DC12V, GAB312-1-0-H3AZ-DC24V, GAB312-1-0-H3AZ-DC48V, GAB312-1-0-H3AZ-DC100V, GAB312-1-0-H5AZ-AC100V, GAB312-1-0-H5AZ-AC200V, GAB312-1-2-H3AZ-DC12V, GAB312-1-2-H3AZ-DC24V, GAB312-1-2-H3AZ-DC48V, GAB312-1-2-H3AZ-DC100V + 710 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	GAB312-1-0-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-0-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-0-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-0-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-0-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-0-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-2-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-2-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-2-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-2-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-2-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-2-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-3-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-3-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-3-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-3-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-3-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-3-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-4-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-4-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-4-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-4-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-4-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-4-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-5-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-5-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-5-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-5-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-5-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-5-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-6-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-6-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-6-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-6-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-6-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-6-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-7-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-7-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-7-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-7-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-7-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-7-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-8-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-8-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-8-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-8-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-8-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-8-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-9-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-9-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-9-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-9-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-9-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-9-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-1-10-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-1-10-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-1-10-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-1-10-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-1-10-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-1-10-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-0-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-0-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-0-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-0-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-0-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-0-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-2-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-2-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-2-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-2-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-2-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-2-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-3-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-3-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-3-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-3-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-3-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-3-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-4-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-4-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-4-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-4-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-4-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-4-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-5-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-5-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-5-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-5-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-5-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-5-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-6-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-6-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-6-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-6-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-6-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-6-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-7-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-7-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-7-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-7-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-7-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-7-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-8-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-8-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-8-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-8-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-8-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-8-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-9-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-9-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-9-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-9-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-9-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-9-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-2-10-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-2-10-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-2-10-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-2-10-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-2-10-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-2-10-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-0-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-0-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-0-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-0-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-0-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-0-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-2-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-2-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-2-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-2-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-2-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-2-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-3-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-3-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-3-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-3-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-3-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-3-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-4-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-4-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-4-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-4-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-4-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-4-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-5-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-5-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-5-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-5-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-5-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-5-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-6-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-6-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-6-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-6-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-6-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-6-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-7-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-7-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-7-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-7-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-7-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-7-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-8-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-8-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-8-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-8-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-8-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-8-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-9-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-9-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-9-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-9-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-9-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-9-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-3-10-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-3-10-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-3-10-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-3-10-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-3-10-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-3-10-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-0-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-0-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-0-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-0-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-0-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-0-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-2-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-2-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-2-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-2-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-2-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-2-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-3-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-3-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-3-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-3-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-3-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-3-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-4-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-4-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-4-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-4-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-4-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-4-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-5-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-5-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-5-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-5-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-5-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-5-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-6-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-6-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-6-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-6-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-6-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-6-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-7-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-7-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-7-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-7-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-7-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-7-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-8-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-8-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-8-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-8-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-8-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-8-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-9-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-9-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-9-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-9-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-9-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-9-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-4-10-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-4-10-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-4-10-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-4-10-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-4-10-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-4-10-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-0-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-0-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-0-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-0-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-0-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-0-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-2-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-2-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-2-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-2-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-2-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-2-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-3-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-3-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-3-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-3-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-3-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-3-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-4-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-4-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-4-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-4-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-4-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-4-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-5-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-5-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-5-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-5-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-5-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-5-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-6-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-6-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-6-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-6-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-6-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-6-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-7-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-7-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-7-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-7-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-7-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-7-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-8-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-8-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-8-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-8-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-8-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-8-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-9-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-9-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-9-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-9-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-9-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-9-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-5-10-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-5-10-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-5-10-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-5-10-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-5-10-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-5-10-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-0-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-0-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-0-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-0-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-0-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-0-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-2-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-2-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-2-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-2-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-2-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-2-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-3-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-3-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-3-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-3-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-3-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-3-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-4-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-4-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-4-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-4-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-4-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-4-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-5-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-5-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-5-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-5-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-5-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-5-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-6-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-6-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-6-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-6-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-6-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-6-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-7-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-7-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-7-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-7-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-7-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-7-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-8-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-8-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-8-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-8-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-8-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-8-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-9-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-9-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-9-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-9-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-9-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-9-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB312-6-10-H3AZ-DC12V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB312-6-10-H3AZ-DC24V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB312-6-10-H3AZ-DC48V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB312-6-10-H3AZ-DC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB312-6-10-H5AZ-AC100V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB312-6-10-H5AZ-AC200V	Model: GAB312 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-0-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-0-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-0-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-0-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-0-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-0-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-2-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-2-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-2-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-2-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-2-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-2-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-3-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-3-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-3-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-3-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-3-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-3-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-4-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-4-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-4-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-4-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-4-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-4-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-5-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-5-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-5-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-5-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-5-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-5-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-6-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-6-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-6-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-6-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-6-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-6-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-7-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-7-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-7-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-7-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-7-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-7-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-8-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-8-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-8-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-8-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-8-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-8-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-9-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-9-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-9-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-9-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-9-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-9-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-1-10-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-1-10-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-1-10-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-1-10-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-1-10-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-1-10-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-0-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-0-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-0-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-0-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-0-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-0-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-2-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-2-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-2-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-2-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-2-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-2-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-3-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-3-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-3-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-3-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-3-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-3-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-4-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-4-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-4-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-4-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-4-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-4-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-5-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-5-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-5-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-5-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-5-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-5-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-6-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-6-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-6-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-6-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-6-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-6-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-7-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-7-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-7-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-7-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-7-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-7-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-8-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-8-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-8-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-8-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-8-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-8-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-9-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-9-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-9-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-9-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-9-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-9-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-2-10-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-2-10-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-2-10-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-2-10-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-2-10-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-2-10-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-0-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-0-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-0-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-0-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-0-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-0-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-2-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-2-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-2-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-2-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-2-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-2-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-3-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-3-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-3-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-3-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-3-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-3-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-4-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-4-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-4-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-4-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-4-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-4-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-5-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-5-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-5-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-5-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-5-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-5-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-6-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-6-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-6-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-6-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-6-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-6-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-7-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-7-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-7-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-7-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-7-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-7-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-8-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-8-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-8-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-8-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-8-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-8-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-9-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-9-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-9-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-9-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-9-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-9-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-3-10-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-3-10-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-3-10-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-3-10-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-3-10-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-3-10-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-0-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-0-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-0-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-0-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-0-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-0-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-2-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-2-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-2-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-2-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-2-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-2-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-3-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-3-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-3-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-3-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-3-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-3-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-4-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-4-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-4-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-4-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-4-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-4-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-5-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-5-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-5-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-5-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-5-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-5-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-6-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-6-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-6-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-6-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-6-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-6-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-7-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-7-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-7-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-7-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-7-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-7-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-8-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-8-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-8-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-8-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-8-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-8-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-9-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-9-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-9-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-9-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-9-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-9-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-4-10-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-4-10-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-4-10-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-4-10-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-4-10-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-4-10-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-0-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-0-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-0-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-0-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-0-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-0-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-2-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-2-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-2-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-2-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-2-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-2-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-3-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-3-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-3-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-3-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-3-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-3-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-4-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-4-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-4-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-4-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-4-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-4-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-5-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-5-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-5-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-5-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-5-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-5-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-6-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-6-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-6-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-6-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-6-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-6-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-7-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-7-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-7-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-7-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-7-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-7-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-8-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-8-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-8-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-8-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-8-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-8-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-9-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-9-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-9-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-9-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-9-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-9-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-5-10-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-5-10-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-5-10-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-5-10-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-5-10-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-5-10-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-0-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-0-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-0-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-0-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-0-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-0-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-2-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-2-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-2-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-2-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-2-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-2-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-3-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-3-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-3-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-3-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-3-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-3-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-4-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-4-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-4-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-4-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-4-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-4-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-5-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-5-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-5-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-5-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-5-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-5-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-6-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-6-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-6-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-6-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-6-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-6-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-7-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-7-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-7-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-7-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-7-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-7-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-8-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-8-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-8-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-8-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-8-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-8-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-9-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-9-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-9-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-9-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-9-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-9-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB352-6-10-H3AZ-DC12V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB352-6-10-H3AZ-DC24V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB352-6-10-H3AZ-DC48V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB352-6-10-H3AZ-DC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB352-6-10-H5AZ-AC100V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB352-6-10-H5AZ-AC200V	Model: GAB352 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

CKD GAB312/GAB352-Z MULTILEX Dry Air 2-Port Valve Manifold
