CKD GAB412/GAB452-Z MULTILEX Dry Air 2-Port Valve Manifold

CKD MULTILEX GAB412/GAB452-Z direct-acting NC 2-port solenoid valve manifolds and actuators for dry air, inert gas and low vacuum, 2-10 stations.

Key features

Direct-acting NC poppet valves on a common manifold; 2-10 stations or single actuator (0)
GAB_12-Z common supply (C port pressurized), GAB_52-Z individual supply (A port pressurized)
Generated with brass body / NBR seal, oil-free (H); J/P/L/M/R body-seal combinations orderable
Rc ports standard; G and NPT thread versions orderable (suffix G/N after model)
Coils: 3A open frame DC, 5A diode AC; HP terminal box versions also available
Options not multiplied: manual override (A), cable gland/conduit, surge killer (S)

Specifications

Fluid	Dry air (dew point -60°C+), inert gas, low vacuum
Fluid temperature	-10 to 45°C
Ambient temperature	-10 to 45°C
Coil insulation	Class B (130)
Valve seat leakage	0.2 cm3/min (ANR) max.
Mounting	Any orientation
Body/seal	Brass, NBR, oil-free (H)
Max. working pressure	5 MPa
Operating pressure diff.	0-4 MPa (by orifice)
Proof pressure	10 MPa (water)
Source	CKD Korea catalog CB-03-1SK-9, p. 408-411

GAB412-1-0-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-0-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-0-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-0-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-0-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-0-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-2-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-2-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-2-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-2-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-2-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-2-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-3-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-3-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-3-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-3-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-3-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-3-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-4-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-4-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-4-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-4-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-4-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-4-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-5-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-5-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-5-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-5-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-5-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-5-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-6-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-6-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-6-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-6-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-6-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-6-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-7-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-7-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-7-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-7-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-7-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-7-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-8-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-8-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-8-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-8-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-8-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-8-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-9-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-9-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-9-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-9-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-9-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-9-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-1-10-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-1-10-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-1-10-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-1-10-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-1-10-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-1-10-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-0-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-0-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-0-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-0-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-0-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-0-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-2-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-2-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-2-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-2-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-2-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-2-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-3-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-3-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-3-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-3-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-3-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-3-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-4-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-4-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-4-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-4-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-4-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-4-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-5-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-5-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-5-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-5-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-5-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-5-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-6-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-6-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-6-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-6-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-6-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-6-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-7-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-7-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-7-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-7-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-7-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-7-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-8-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-8-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-8-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-8-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-8-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-8-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-9-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-9-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-9-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-9-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-9-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-9-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-2-10-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-2-10-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-2-10-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-2-10-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-2-10-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-2-10-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-0-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-0-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-0-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-0-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-0-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-0-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-2-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-2-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-2-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-2-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-2-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-2-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-3-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-3-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-3-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-3-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-3-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-3-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-4-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-4-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-4-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-4-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-4-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-4-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-5-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-5-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-5-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-5-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-5-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-5-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-6-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-6-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-6-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-6-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-6-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-6-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-7-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-7-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-7-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-7-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-7-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-7-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-8-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-8-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-8-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-8-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-8-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-8-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-9-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-9-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-9-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-9-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-9-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-9-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-3-10-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-3-10-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-3-10-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-3-10-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-3-10-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-3-10-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-0-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-0-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-0-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-0-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-0-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-0-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-2-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-2-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-2-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-2-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-2-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-2-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-3-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-3-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-3-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-3-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-3-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-3-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-4-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-4-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-4-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-4-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-4-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-4-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-5-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-5-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-5-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-5-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-5-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-5-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-6-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-6-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-6-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-6-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-6-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-6-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-7-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-7-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-7-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-7-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-7-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-7-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-8-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-8-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-8-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-8-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-8-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-8-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-9-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-9-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-9-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-9-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-9-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-9-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-4-10-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-4-10-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-4-10-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-4-10-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-4-10-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-4-10-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-0-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-0-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-0-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-0-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-0-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-0-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-2-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-2-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-2-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-2-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-2-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-2-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-3-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-3-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-3-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-3-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-3-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-3-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-4-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-4-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-4-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-4-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-4-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-4-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-5-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-5-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-5-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-5-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-5-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-5-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-6-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-6-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-6-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-6-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-6-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-6-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-7-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-7-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-7-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-7-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-7-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-7-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-8-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-8-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-8-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-8-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-8-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-8-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-9-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-9-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-9-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-9-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-9-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-9-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-5-10-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-5-10-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-5-10-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-5-10-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-5-10-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-5-10-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-0-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-0-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-0-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-0-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-0-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-0-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-2-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-2-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-2-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-2-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-2-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-2-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-3-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-3-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-3-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-3-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-3-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-3-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-4-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-4-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-4-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-4-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-4-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-4-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-5-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-5-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-5-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-5-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-5-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-5-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-6-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-6-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-6-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-6-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-6-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-6-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-7-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-7-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-7-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-7-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-7-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-7-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-8-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-8-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-8-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-8-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-8-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-8-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-9-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-9-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-9-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-9-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-9-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-9-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-6-10-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-6-10-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-6-10-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-6-10-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-6-10-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-6-10-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-0-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-0-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-0-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-0-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-0-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-0-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-2-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-2-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-2-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-2-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-2-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-2-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-3-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-3-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-3-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-3-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-3-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-3-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-4-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-4-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-4-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-4-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-4-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-4-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-5-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-5-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-5-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-5-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-5-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-5-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-6-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-6-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-6-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-6-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-6-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-6-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-7-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-7-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-7-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-7-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-7-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-7-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-8-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-8-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-8-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-8-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-8-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-8-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-9-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-9-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-9-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-9-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-9-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-9-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB412-7-10-H3AZ-DC12V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB412-7-10-H3AZ-DC24V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB412-7-10-H3AZ-DC48V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB412-7-10-H3AZ-DC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB412-7-10-H5AZ-AC100V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB412-7-10-H5AZ-AC200V		Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-0-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-0-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-0-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-0-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-0-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-0-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-2-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-2-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-2-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-2-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-2-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-2-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-3-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-3-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-3-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-3-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-3-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-3-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-4-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-4-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-4-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-4-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-4-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-4-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-5-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-5-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-5-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-5-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-5-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-5-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-6-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-6-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-6-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-6-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-6-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-6-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-7-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-7-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-7-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-7-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-7-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-7-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-8-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-8-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-8-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-8-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-8-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-8-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-9-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-9-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-9-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-9-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-9-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-9-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-1-10-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-1-10-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-1-10-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-1-10-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-1-10-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-1-10-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-0-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-0-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-0-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-0-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-0-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-0-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-2-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-2-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-2-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-2-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-2-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-2-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-3-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-3-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-3-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-3-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-3-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-3-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-4-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-4-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-4-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-4-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-4-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-4-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-5-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-5-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-5-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-5-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-5-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-5-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-6-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-6-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-6-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-6-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-6-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-6-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-7-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-7-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-7-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-7-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-7-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-7-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-8-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-8-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-8-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-8-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-8-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-8-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-9-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-9-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-9-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-9-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-9-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-9-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-2-10-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-2-10-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-2-10-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-2-10-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-2-10-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-2-10-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-0-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-0-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-0-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-0-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-0-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-0-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-2-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-2-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-2-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-2-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-2-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-2-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-3-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-3-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-3-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-3-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-3-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-3-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-4-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-4-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-4-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-4-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-4-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-4-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-5-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-5-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-5-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-5-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-5-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-5-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-6-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-6-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-6-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-6-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-6-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-6-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-7-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-7-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-7-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-7-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-7-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-7-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-8-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-8-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-8-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-8-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-8-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-8-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-9-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-9-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-9-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-9-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-9-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-9-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-3-10-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-3-10-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-3-10-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-3-10-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-3-10-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-3-10-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-0-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-0-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-0-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-0-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-0-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-0-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-2-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-2-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-2-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-2-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-2-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-2-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-3-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-3-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-3-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-3-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-3-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-3-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-4-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-4-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-4-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-4-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-4-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-4-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-5-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-5-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-5-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-5-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-5-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-5-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-6-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-6-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-6-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-6-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-6-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-6-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-7-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-7-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-7-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-7-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-7-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-7-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-8-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-8-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-8-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-8-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-8-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-8-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-9-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-9-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-9-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-9-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-9-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-9-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-4-10-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-4-10-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-4-10-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-4-10-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-4-10-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-4-10-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-0-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-0-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-0-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-0-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-0-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-0-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-2-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-2-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-2-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-2-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-2-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-2-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-3-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-3-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-3-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-3-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-3-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-3-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-4-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-4-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-4-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-4-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-4-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-4-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-5-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-5-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-5-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-5-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-5-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-5-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-6-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-6-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-6-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-6-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-6-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-6-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-7-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-7-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-7-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-7-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-7-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-7-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-8-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-8-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-8-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-8-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-8-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-8-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-9-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-9-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-9-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-9-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-9-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-9-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-5-10-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-5-10-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-5-10-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-5-10-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-5-10-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-5-10-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-0-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-0-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-0-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-0-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-0-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-0-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-2-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-2-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-2-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-2-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-2-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-2-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-3-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-3-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-3-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-3-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-3-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-3-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-4-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-4-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-4-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-4-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-4-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-4-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-5-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-5-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-5-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-5-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-5-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-5-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-6-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-6-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-6-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-6-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-6-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-6-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-7-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-7-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-7-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-7-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-7-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-7-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-8-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-8-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-8-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-8-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-8-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-8-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-9-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-9-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-9-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-9-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-9-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-9-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-6-10-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-6-10-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-6-10-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-6-10-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-6-10-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-6-10-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-0-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-0-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-0-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-0-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-0-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-0-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-2-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-2-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-2-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-2-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-2-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-2-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-3-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-3-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-3-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-3-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-3-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-3-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-4-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-4-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-4-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-4-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-4-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-4-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-5-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-5-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-5-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-5-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-5-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-5-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-6-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-6-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-6-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-6-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-6-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-6-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-7-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-7-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-7-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-7-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-7-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-7-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-8-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-8-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-8-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-8-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-8-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-8-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-9-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-9-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-9-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-9-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-9-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-9-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAB452-7-10-H3AZ-DC12V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAB452-7-10-H3AZ-DC24V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAB452-7-10-H3AZ-DC48V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAB452-7-10-H3AZ-DC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAB452-7-10-H5AZ-AC100V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAB452-7-10-H5AZ-AC200V		Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V

Solenoid ValvesCKD

840 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD GAB412/GAB452-Z MULTILEX Dry Air 2-Port Valve Manifold

Brand CKD·Solenoid Valves

Available part numbers (840)

GAB412-1-0-H3AZ-DC12V, GAB412-1-0-H3AZ-DC24V, GAB412-1-0-H3AZ-DC48V, GAB412-1-0-H3AZ-DC100V, GAB412-1-0-H5AZ-AC100V, GAB412-1-0-H5AZ-AC200V, GAB412-1-2-H3AZ-DC12V, GAB412-1-2-H3AZ-DC24V, GAB412-1-2-H3AZ-DC48V, GAB412-1-2-H3AZ-DC100V + 830 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	GAB412-1-0-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-0-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-0-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-0-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-0-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-0-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-2-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-2-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-2-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-2-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-2-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-2-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-3-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-3-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-3-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-3-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-3-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-3-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-4-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-4-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-4-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-4-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-4-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-4-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-5-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-5-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-5-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-5-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-5-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-5-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-6-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-6-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-6-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-6-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-6-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-6-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-7-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-7-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-7-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-7-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-7-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-7-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-8-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-8-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-8-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-8-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-8-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-8-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-9-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-9-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-9-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-9-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-9-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-9-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-1-10-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-1-10-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-1-10-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-1-10-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-1-10-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-1-10-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-0-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-0-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-0-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-0-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-0-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-0-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-2-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-2-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-2-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-2-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-2-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-2-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-3-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-3-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-3-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-3-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-3-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-3-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-4-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-4-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-4-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-4-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-4-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-4-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-5-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-5-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-5-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-5-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-5-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-5-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-6-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-6-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-6-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-6-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-6-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-6-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-7-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-7-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-7-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-7-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-7-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-7-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-8-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-8-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-8-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-8-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-8-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-8-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-9-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-9-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-9-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-9-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-9-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-9-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-2-10-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-2-10-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-2-10-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-2-10-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-2-10-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-2-10-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-0-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-0-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-0-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-0-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-0-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-0-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-2-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-2-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-2-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-2-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-2-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-2-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-3-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-3-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-3-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-3-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-3-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-3-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-4-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-4-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-4-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-4-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-4-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-4-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-5-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-5-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-5-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-5-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-5-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-5-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-6-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-6-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-6-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-6-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-6-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-6-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-7-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-7-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-7-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-7-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-7-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-7-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-8-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-8-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-8-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-8-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-8-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-8-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-9-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-9-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-9-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-9-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-9-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-9-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-3-10-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-3-10-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-3-10-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-3-10-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-3-10-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-3-10-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-0-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-0-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-0-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-0-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-0-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-0-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-2-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-2-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-2-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-2-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-2-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-2-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-3-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-3-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-3-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-3-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-3-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-3-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-4-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-4-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-4-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-4-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-4-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-4-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-5-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-5-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-5-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-5-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-5-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-5-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-6-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-6-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-6-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-6-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-6-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-6-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-7-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-7-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-7-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-7-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-7-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-7-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-8-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-8-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-8-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-8-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-8-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-8-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-9-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-9-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-9-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-9-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-9-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-9-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-4-10-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-4-10-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-4-10-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-4-10-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-4-10-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-4-10-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-0-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-0-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-0-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-0-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-0-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-0-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-2-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-2-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-2-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-2-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-2-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-2-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-3-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-3-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-3-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-3-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-3-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-3-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-4-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-4-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-4-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-4-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-4-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-4-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-5-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-5-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-5-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-5-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-5-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-5-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-6-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-6-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-6-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-6-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-6-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-6-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-7-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-7-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-7-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-7-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-7-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-7-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-8-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-8-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-8-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-8-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-8-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-8-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-9-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-9-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-9-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-9-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-9-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-9-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-5-10-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-5-10-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-5-10-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-5-10-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-5-10-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-5-10-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-0-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-0-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-0-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-0-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-0-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-0-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-2-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-2-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-2-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-2-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-2-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-2-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-3-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-3-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-3-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-3-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-3-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-3-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-4-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-4-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-4-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-4-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-4-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-4-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-5-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-5-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-5-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-5-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-5-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-5-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-6-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-6-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-6-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-6-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-6-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-6-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-7-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-7-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-7-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-7-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-7-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-7-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-8-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-8-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-8-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-8-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-8-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-8-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-9-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-9-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-9-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-9-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-9-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-9-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-6-10-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-6-10-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-6-10-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-6-10-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-6-10-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-6-10-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-0-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-0-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-0-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-0-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-0-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-0-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-2-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-2-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-2-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-2-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-2-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-2-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-3-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-3-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-3-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-3-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-3-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-3-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-4-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-4-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-4-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-4-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-4-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-4-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-5-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-5-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-5-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-5-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-5-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-5-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-6-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-6-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-6-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-6-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-6-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-6-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-7-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-7-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-7-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-7-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-7-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-7-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-8-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-8-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-8-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-8-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-8-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-8-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-9-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-9-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-9-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-9-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-9-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-9-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB412-7-10-H3AZ-DC12V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB412-7-10-H3AZ-DC24V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB412-7-10-H3AZ-DC48V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB412-7-10-H3AZ-DC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB412-7-10-H5AZ-AC100V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB412-7-10-H5AZ-AC200V	Model: GAB412 common supply (C) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-0-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-0-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-0-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-0-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-0-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-0-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-2-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-2-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-2-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-2-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-2-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-2-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-3-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-3-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-3-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-3-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-3-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-3-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-4-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-4-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-4-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-4-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-4-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-4-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-5-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-5-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-5-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-5-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-5-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-5-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-6-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-6-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-6-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-6-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-6-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-6-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-7-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-7-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-7-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-7-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-7-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-7-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-8-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-8-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-8-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-8-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-8-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-8-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-9-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-9-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-9-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-9-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-9-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-9-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-1-10-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-1-10-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-1-10-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-1-10-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-1-10-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-1-10-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-0-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-0-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-0-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-0-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-0-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-0-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-2-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-2-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-2-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-2-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-2-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-2-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-3-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-3-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-3-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-3-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-3-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-3-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-4-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-4-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-4-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-4-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-4-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-4-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-5-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-5-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-5-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-5-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-5-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-5-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-6-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-6-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-6-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-6-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-6-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-6-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-7-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-7-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-7-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-7-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-7-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-7-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-8-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-8-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-8-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-8-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-8-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-8-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-9-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-9-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-9-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-9-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-9-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-9-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-2-10-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-2-10-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-2-10-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-2-10-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-2-10-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-2-10-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 2 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-0-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-0-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-0-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-0-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-0-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-0-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-2-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-2-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-2-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-2-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-2-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-2-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-3-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-3-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-3-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-3-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-3-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-3-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-4-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-4-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-4-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-4-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-4-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-4-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-5-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-5-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-5-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-5-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-5-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-5-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-6-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-6-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-6-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-6-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-6-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-6-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-7-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-7-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-7-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-7-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-7-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-7-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-8-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-8-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-8-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-8-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-8-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-8-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-9-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-9-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-9-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-9-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-9-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-9-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-3-10-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-3-10-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-3-10-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-3-10-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-3-10-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-3-10-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-0-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-0-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-0-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-0-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-0-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-0-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-2-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-2-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-2-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-2-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-2-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-2-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-3-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-3-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-3-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-3-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-3-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-3-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-4-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-4-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-4-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-4-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-4-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-4-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-5-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-5-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-5-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-5-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-5-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-5-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-6-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-6-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-6-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-6-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-6-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-6-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-7-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-7-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-7-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-7-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-7-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-7-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-8-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-8-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-8-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-8-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-8-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-8-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-9-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-9-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-9-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-9-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-9-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-9-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-4-10-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-4-10-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-4-10-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-4-10-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-4-10-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-4-10-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 3.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-0-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-0-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-0-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-0-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-0-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-0-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-2-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-2-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-2-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-2-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-2-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-2-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-3-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-3-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-3-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-3-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-3-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-3-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-4-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-4-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-4-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-4-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-4-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-4-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-5-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-5-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-5-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-5-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-5-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-5-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-6-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-6-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-6-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-6-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-6-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-6-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-7-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-7-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-7-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-7-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-7-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-7-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-8-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-8-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-8-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-8-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-8-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-8-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-9-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-9-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-9-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-9-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-9-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-9-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-5-10-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-5-10-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-5-10-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-5-10-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-5-10-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-5-10-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 4 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-0-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-0-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-0-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-0-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-0-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-0-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-2-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-2-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-2-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-2-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-2-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-2-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-3-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-3-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-3-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-3-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-3-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-3-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-4-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-4-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-4-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-4-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-4-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-4-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-5-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-5-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-5-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-5-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-5-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-5-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-6-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-6-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-6-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-6-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-6-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-6-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-7-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-7-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-7-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-7-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-7-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-7-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-8-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-8-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-8-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-8-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-8-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-8-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-9-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-9-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-9-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-9-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-9-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-9-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-6-10-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-6-10-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-6-10-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-6-10-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-6-10-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-6-10-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-0-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-0-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-0-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-0-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-0-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-0-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-2-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-2-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-2-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-2-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-2-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-2-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-3-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-3-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-3-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-3-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-3-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-3-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-4-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-4-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-4-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-4-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-4-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-4-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-5-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-5-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-5-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-5-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-5-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-5-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-6-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-6-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-6-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-6-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-6-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-6-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-7-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-7-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-7-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-7-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-7-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-7-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-8-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-8-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-8-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-8-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-8-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-8-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-9-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-9-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-9-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-9-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-9-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-9-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAB452-7-10-H3AZ-DC12V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAB452-7-10-H3AZ-DC24V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAB452-7-10-H3AZ-DC48V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAB452-7-10-H3AZ-DC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAB452-7-10-H5AZ-AC100V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAB452-7-10-H5AZ-AC200V	Model: GAB452 individual supply (A) \| Orifice: 7 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

CKD GAB412/GAB452-Z MULTILEX Dry Air 2-Port Valve Manifold
