CKD GAG31/35/41/45-Z MULTILEX Dry Air 3-Port Valve Manifold

CKD MULTILEX GAG31*/35*/41*/45*-Z universal direct-acting 3-port solenoid valve manifolds and actuators for dry air, inert gas and low vacuum.

Key features

Universal 3-port direct-acting valves on a manifold, 2-10 stations or single actuator (0)
GAG31*/41*-Z common supply / individual exhaust; GAG35*/45*-Z common supply / diverting
NO port Rc1/8-Rc3/8 by model digit; G and NPT versions orderable
Generated with brass body / NBR seal, oil-free (H); J/P/L/M/R orderable
Coils: 3A open frame DC, 5A diode AC; HP terminal box versions also available

Specifications

Fluid	Dry air (dew point -60°C+), inert gas, low vacuum
Fluid temperature	-10 to 45°C
Ambient temperature	-10 to 45°C
Coil insulation	Class B (130)
Valve seat leakage	0.2 cm3/min (ANR) max.
Mounting	Any orientation
Body/seal	Brass, NBR, oil-free (H)
Operating pressure diff.	0-1 MPa (by orifice)
Max. working pressure	1 MPa
Proof pressure	10 MPa (water)
Source	CKD Korea catalog CB-03-1SK-9, p. 418-421

GAG311-1-0-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-0-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-0-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-0-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-0-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-0-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-2-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-2-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-2-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-2-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-2-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-2-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-3-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-3-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-3-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-3-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-3-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-3-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-4-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-4-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-4-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-4-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-4-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-4-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-5-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-5-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-5-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-5-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-5-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-5-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-6-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-6-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-6-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-6-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-6-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-6-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-7-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-7-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-7-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-7-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-7-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-7-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-8-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-8-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-8-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-8-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-8-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-8-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-9-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-9-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-9-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-9-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-9-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-9-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-1-10-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-1-10-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-1-10-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-1-10-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-1-10-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-1-10-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-0-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-0-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-0-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-0-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-0-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-0-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-2-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-2-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-2-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-2-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-2-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-2-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-3-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-3-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-3-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-3-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-3-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-3-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-4-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-4-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-4-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-4-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-4-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-4-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-5-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-5-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-5-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-5-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-5-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-5-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-6-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-6-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-6-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-6-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-6-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-6-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-7-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-7-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-7-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-7-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-7-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-7-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-8-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-8-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-8-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-8-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-8-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-8-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-9-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-9-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-9-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-9-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-9-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-9-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG311-2-10-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG311-2-10-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG311-2-10-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG311-2-10-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG311-2-10-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG311-2-10-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-0-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-0-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-0-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-0-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-0-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-0-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-2-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-2-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-2-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-2-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-2-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-2-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-3-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-3-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-3-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-3-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-3-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-3-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-4-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-4-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-4-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-4-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-4-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-4-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-5-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-5-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-5-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-5-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-5-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-5-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-6-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-6-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-6-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-6-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-6-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-6-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-7-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-7-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-7-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-7-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-7-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-7-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-8-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-8-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-8-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-8-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-8-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-8-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-9-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-9-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-9-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-9-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-9-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-9-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-1-10-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-1-10-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-1-10-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-1-10-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-1-10-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-1-10-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-0-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-0-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-0-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-0-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-0-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-0-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-2-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-2-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-2-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-2-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-2-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-2-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-3-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-3-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-3-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-3-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-3-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-3-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-4-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-4-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-4-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-4-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-4-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-4-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-5-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-5-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-5-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-5-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-5-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-5-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-6-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-6-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-6-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-6-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-6-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-6-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-7-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-7-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-7-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-7-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-7-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-7-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-8-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-8-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-8-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-8-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-8-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-8-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-9-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-9-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-9-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-9-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-9-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-9-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG312-2-10-H3AZ-DC12V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG312-2-10-H3AZ-DC24V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG312-2-10-H3AZ-DC48V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG312-2-10-H3AZ-DC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG312-2-10-H5AZ-AC100V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG312-2-10-H5AZ-AC200V		Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-0-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-0-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-0-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-0-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-0-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-0-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-2-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-2-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-2-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-2-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-2-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-2-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-3-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-3-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-3-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-3-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-3-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-3-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-4-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-4-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-4-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-4-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-4-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-4-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-5-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-5-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-5-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-5-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-5-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-5-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-6-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-6-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-6-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-6-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-6-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-6-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-7-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-7-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-7-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-7-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-7-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-7-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-8-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-8-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-8-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-8-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-8-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-8-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-9-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-9-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-9-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-9-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-9-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-9-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-1-10-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-1-10-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-1-10-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-1-10-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-1-10-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-1-10-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-0-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-0-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-0-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-0-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-0-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-0-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-2-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-2-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-2-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-2-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-2-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-2-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-3-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-3-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-3-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-3-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-3-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-3-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-4-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-4-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-4-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-4-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-4-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-4-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-5-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-5-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-5-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-5-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-5-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-5-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-6-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-6-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-6-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-6-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-6-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-6-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-7-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-7-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-7-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-7-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-7-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-7-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-8-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-8-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-8-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-8-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-8-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-8-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-9-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-9-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-9-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-9-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-9-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-9-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG351-2-10-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG351-2-10-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG351-2-10-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG351-2-10-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG351-2-10-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG351-2-10-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-0-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-0-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-0-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-0-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-0-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-0-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-2-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-2-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-2-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-2-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-2-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-2-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-3-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-3-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-3-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-3-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-3-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-3-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-4-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-4-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-4-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-4-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-4-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-4-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-5-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-5-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-5-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-5-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-5-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-5-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-6-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-6-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-6-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-6-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-6-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-6-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-7-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-7-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-7-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-7-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-7-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-7-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-8-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-8-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-8-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-8-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-8-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-8-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-9-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-9-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-9-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-9-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-9-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-9-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-1-10-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-1-10-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-1-10-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-1-10-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-1-10-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-1-10-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-0-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-0-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-0-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-0-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-0-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-0-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-2-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-2-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-2-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-2-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-2-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-2-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-3-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-3-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-3-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-3-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-3-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-3-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-4-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-4-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-4-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-4-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-4-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-4-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-5-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-5-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-5-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-5-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-5-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-5-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-6-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-6-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-6-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-6-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-6-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-6-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-7-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-7-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-7-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-7-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-7-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-7-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-8-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-8-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-8-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-8-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-8-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-8-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-9-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-9-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-9-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-9-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-9-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-9-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG352-2-10-H3AZ-DC12V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG352-2-10-H3AZ-DC24V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG352-2-10-H3AZ-DC48V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG352-2-10-H3AZ-DC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG352-2-10-H5AZ-AC100V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG352-2-10-H5AZ-AC200V		Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-0-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-0-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-0-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-0-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-0-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-0-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-2-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-2-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-2-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-2-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-2-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-2-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-3-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-3-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-3-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-3-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-3-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-3-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-4-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-4-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-4-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-4-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-4-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-4-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-5-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-5-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-5-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-5-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-5-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-5-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-6-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-6-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-6-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-6-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-6-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-6-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-7-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-7-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-7-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-7-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-7-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-7-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-8-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-8-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-8-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-8-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-8-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-8-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-9-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-9-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-9-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-9-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-9-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-9-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-1-10-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-1-10-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-1-10-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-1-10-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-1-10-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-1-10-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-0-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-0-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-0-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-0-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-0-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-0-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-2-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-2-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-2-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-2-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-2-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-2-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-3-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-3-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-3-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-3-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-3-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-3-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-4-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-4-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-4-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-4-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-4-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-4-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-5-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-5-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-5-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-5-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-5-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-5-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-6-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-6-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-6-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-6-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-6-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-6-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-7-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-7-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-7-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-7-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-7-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-7-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-8-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-8-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-8-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-8-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-8-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-8-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-9-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-9-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-9-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-9-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-9-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-9-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG412-2-10-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG412-2-10-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG412-2-10-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG412-2-10-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG412-2-10-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG412-2-10-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-0-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-0-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-0-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-0-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-0-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-0-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-2-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-2-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-2-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-2-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-2-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-2-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-3-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-3-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-3-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-3-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-3-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-3-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-4-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-4-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-4-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-4-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-4-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-4-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-5-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-5-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-5-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-5-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-5-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-5-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-6-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-6-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-6-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-6-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-6-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-6-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-7-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-7-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-7-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-7-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-7-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-7-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-8-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-8-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-8-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-8-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-8-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-8-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-9-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-9-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-9-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-9-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-9-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-9-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-1-10-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-1-10-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-1-10-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-1-10-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-1-10-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-1-10-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-0-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-0-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-0-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-0-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-0-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-0-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-2-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-2-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-2-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-2-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-2-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-2-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-3-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-3-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-3-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-3-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-3-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-3-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-4-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-4-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-4-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-4-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-4-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-4-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-5-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-5-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-5-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-5-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-5-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-5-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-6-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-6-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-6-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-6-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-6-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-6-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-7-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-7-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-7-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-7-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-7-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-7-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-8-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-8-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-8-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-8-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-8-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-8-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-9-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-9-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-9-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-9-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-9-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-9-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG413-2-10-H3AZ-DC12V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG413-2-10-H3AZ-DC24V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG413-2-10-H3AZ-DC48V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG413-2-10-H3AZ-DC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG413-2-10-H5AZ-AC100V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG413-2-10-H5AZ-AC200V		Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-0-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-0-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-0-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-0-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-0-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-0-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-2-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-2-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-2-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-2-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-2-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-2-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-3-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-3-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-3-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-3-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-3-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-3-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-4-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-4-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-4-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-4-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-4-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-4-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-5-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-5-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-5-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-5-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-5-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-5-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-6-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-6-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-6-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-6-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-6-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-6-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-7-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-7-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-7-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-7-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-7-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-7-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-8-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-8-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-8-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-8-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-8-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-8-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-9-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-9-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-9-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-9-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-9-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-9-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-1-10-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-1-10-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-1-10-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-1-10-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-1-10-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-1-10-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-0-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-0-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-0-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-0-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-0-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-0-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-2-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-2-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-2-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-2-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-2-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-2-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-3-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-3-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-3-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-3-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-3-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-3-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-4-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-4-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-4-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-4-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-4-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-4-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-5-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-5-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-5-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-5-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-5-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-5-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-6-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-6-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-6-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-6-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-6-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-6-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-7-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-7-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-7-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-7-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-7-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-7-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-8-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-8-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-8-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-8-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-8-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-8-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-9-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-9-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-9-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-9-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-9-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-9-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG452-2-10-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG452-2-10-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG452-2-10-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG452-2-10-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG452-2-10-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG452-2-10-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-0-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-0-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-0-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-0-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-0-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-0-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-2-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-2-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-2-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-2-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-2-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-2-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-3-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-3-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-3-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-3-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-3-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-3-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-4-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-4-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-4-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-4-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-4-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-4-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-5-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-5-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-5-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-5-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-5-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-5-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-6-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-6-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-6-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-6-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-6-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-6-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-7-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-7-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-7-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-7-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-7-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-7-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-8-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-8-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-8-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-8-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-8-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-8-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-9-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-9-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-9-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-9-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-9-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-9-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-1-10-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-1-10-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-1-10-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-1-10-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-1-10-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-1-10-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-0-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-0-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-0-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-0-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-0-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-0-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-2-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-2-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-2-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-2-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-2-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-2-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-3-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-3-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-3-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-3-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-3-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-3-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-4-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-4-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-4-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-4-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-4-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-4-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-5-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-5-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-5-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-5-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-5-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-5-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-6-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-6-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-6-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-6-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-6-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-6-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-7-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-7-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-7-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-7-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-7-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-7-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-8-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-8-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-8-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-8-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-8-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-8-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-9-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-9-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-9-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-9-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-9-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-9-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
GAG453-2-10-H3AZ-DC12V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
GAG453-2-10-H3AZ-DC24V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
GAG453-2-10-H3AZ-DC48V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
GAG453-2-10-H3AZ-DC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
GAG453-2-10-H5AZ-AC100V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
GAG453-2-10-H5AZ-AC200V		Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V

Solenoid ValvesCKD

960 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD GAG31/35/41/45-Z MULTILEX Dry Air 3-Port Valve Manifold

Brand CKD·Solenoid Valves

Available part numbers (960)

GAG311-1-0-H3AZ-DC12V, GAG311-1-0-H3AZ-DC24V, GAG311-1-0-H3AZ-DC48V, GAG311-1-0-H3AZ-DC100V, GAG311-1-0-H5AZ-AC100V, GAG311-1-0-H5AZ-AC200V, GAG311-1-2-H3AZ-DC12V, GAG311-1-2-H3AZ-DC24V, GAG311-1-2-H3AZ-DC48V, GAG311-1-2-H3AZ-DC100V + 950 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	GAG311-1-0-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-0-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-0-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-0-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-0-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-0-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-2-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-2-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-2-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-2-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-2-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-2-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-3-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-3-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-3-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-3-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-3-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-3-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-4-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-4-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-4-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-4-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-4-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-4-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-5-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-5-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-5-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-5-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-5-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-5-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-6-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-6-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-6-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-6-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-6-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-6-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-7-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-7-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-7-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-7-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-7-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-7-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-8-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-8-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-8-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-8-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-8-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-8-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-9-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-9-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-9-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-9-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-9-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-9-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-1-10-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-1-10-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-1-10-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-1-10-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-1-10-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-1-10-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-0-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-0-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-0-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-0-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-0-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-0-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-2-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-2-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-2-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-2-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-2-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-2-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-3-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-3-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-3-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-3-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-3-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-3-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-4-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-4-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-4-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-4-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-4-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-4-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-5-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-5-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-5-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-5-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-5-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-5-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-6-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-6-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-6-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-6-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-6-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-6-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-7-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-7-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-7-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-7-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-7-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-7-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-8-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-8-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-8-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-8-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-8-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-8-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-9-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-9-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-9-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-9-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-9-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-9-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG311-2-10-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG311-2-10-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG311-2-10-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG311-2-10-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG311-2-10-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG311-2-10-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-0-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-0-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-0-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-0-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-0-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-0-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-2-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-2-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-2-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-2-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-2-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-2-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-3-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-3-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-3-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-3-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-3-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-3-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-4-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-4-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-4-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-4-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-4-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-4-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-5-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-5-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-5-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-5-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-5-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-5-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-6-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-6-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-6-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-6-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-6-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-6-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-7-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-7-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-7-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-7-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-7-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-7-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-8-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-8-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-8-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-8-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-8-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-8-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-9-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-9-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-9-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-9-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-9-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-9-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-1-10-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-1-10-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-1-10-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-1-10-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-1-10-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-1-10-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-0-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-0-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-0-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-0-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-0-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-0-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-2-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-2-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-2-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-2-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-2-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-2-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-3-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-3-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-3-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-3-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-3-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-3-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-4-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-4-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-4-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-4-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-4-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-4-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-5-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-5-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-5-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-5-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-5-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-5-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-6-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-6-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-6-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-6-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-6-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-6-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-7-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-7-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-7-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-7-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-7-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-7-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-8-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-8-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-8-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-8-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-8-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-8-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-9-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-9-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-9-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-9-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-9-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-9-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG312-2-10-H3AZ-DC12V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG312-2-10-H3AZ-DC24V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG312-2-10-H3AZ-DC48V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG312-2-10-H3AZ-DC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG312-2-10-H5AZ-AC100V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG312-2-10-H5AZ-AC200V	Model: GAG31 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-0-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-0-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-0-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-0-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-0-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-0-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-2-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-2-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-2-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-2-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-2-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-2-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-3-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-3-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-3-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-3-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-3-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-3-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-4-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-4-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-4-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-4-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-4-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-4-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-5-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-5-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-5-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-5-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-5-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-5-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-6-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-6-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-6-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-6-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-6-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-6-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-7-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-7-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-7-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-7-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-7-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-7-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-8-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-8-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-8-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-8-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-8-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-8-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-9-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-9-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-9-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-9-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-9-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-9-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-1-10-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-1-10-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-1-10-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-1-10-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-1-10-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-1-10-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-0-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-0-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-0-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-0-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-0-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-0-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-2-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-2-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-2-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-2-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-2-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-2-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-3-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-3-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-3-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-3-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-3-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-3-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-4-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-4-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-4-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-4-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-4-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-4-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-5-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-5-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-5-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-5-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-5-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-5-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-6-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-6-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-6-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-6-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-6-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-6-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-7-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-7-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-7-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-7-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-7-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-7-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-8-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-8-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-8-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-8-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-8-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-8-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-9-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-9-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-9-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-9-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-9-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-9-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG351-2-10-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG351-2-10-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG351-2-10-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG351-2-10-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG351-2-10-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG351-2-10-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-0-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-0-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-0-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-0-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-0-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-0-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-2-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-2-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-2-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-2-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-2-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-2-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-3-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-3-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-3-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-3-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-3-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-3-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-4-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-4-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-4-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-4-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-4-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-4-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-5-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-5-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-5-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-5-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-5-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-5-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-6-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-6-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-6-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-6-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-6-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-6-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-7-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-7-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-7-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-7-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-7-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-7-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-8-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-8-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-8-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-8-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-8-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-8-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-9-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-9-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-9-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-9-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-9-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-9-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-1-10-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-1-10-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-1-10-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-1-10-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-1-10-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-1-10-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 1.5 / BODY 1.5 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-0-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-0-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-0-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-0-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-0-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-0-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-2-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-2-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-2-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-2-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-2-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-2-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-3-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-3-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-3-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-3-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-3-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-3-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-4-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-4-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-4-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-4-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-4-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-4-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-5-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-5-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-5-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-5-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-5-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-5-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-6-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-6-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-6-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-6-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-6-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-6-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-7-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-7-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-7-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-7-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-7-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-7-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-8-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-8-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-8-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-8-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-8-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-8-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-9-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-9-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-9-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-9-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-9-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-9-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG352-2-10-H3AZ-DC12V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG352-2-10-H3AZ-DC24V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG352-2-10-H3AZ-DC48V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG352-2-10-H3AZ-DC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG352-2-10-H5AZ-AC100V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG352-2-10-H5AZ-AC200V	Model: GAG35 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-0-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-0-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-0-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-0-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-0-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-0-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-2-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-2-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-2-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-2-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-2-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-2-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-3-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-3-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-3-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-3-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-3-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-3-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-4-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-4-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-4-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-4-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-4-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-4-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-5-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-5-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-5-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-5-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-5-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-5-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-6-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-6-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-6-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-6-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-6-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-6-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-7-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-7-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-7-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-7-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-7-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-7-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-8-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-8-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-8-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-8-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-8-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-8-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-9-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-9-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-9-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-9-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-9-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-9-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-1-10-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-1-10-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-1-10-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-1-10-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-1-10-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-1-10-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-0-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-0-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-0-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-0-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-0-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-0-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-2-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-2-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-2-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-2-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-2-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-2-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-3-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-3-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-3-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-3-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-3-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-3-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-4-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-4-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-4-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-4-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-4-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-4-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-5-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-5-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-5-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-5-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-5-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-5-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-6-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-6-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-6-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-6-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-6-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-6-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-7-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-7-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-7-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-7-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-7-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-7-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-8-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-8-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-8-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-8-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-8-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-8-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-9-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-9-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-9-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-9-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-9-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-9-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG412-2-10-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG412-2-10-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG412-2-10-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG412-2-10-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG412-2-10-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG412-2-10-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-0-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-0-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-0-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-0-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-0-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-0-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-2-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-2-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-2-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-2-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-2-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-2-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-3-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-3-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-3-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-3-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-3-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-3-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-4-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-4-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-4-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-4-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-4-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-4-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-5-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-5-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-5-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-5-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-5-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-5-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-6-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-6-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-6-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-6-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-6-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-6-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-7-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-7-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-7-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-7-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-7-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-7-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-8-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-8-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-8-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-8-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-8-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-8-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-9-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-9-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-9-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-9-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-9-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-9-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-1-10-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-1-10-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-1-10-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-1-10-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-1-10-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-1-10-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-0-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-0-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-0-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-0-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-0-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-0-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-2-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-2-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-2-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-2-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-2-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-2-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-3-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-3-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-3-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-3-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-3-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-3-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-4-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-4-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-4-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-4-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-4-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-4-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-5-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-5-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-5-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-5-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-5-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-5-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-6-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-6-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-6-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-6-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-6-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-6-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-7-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-7-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-7-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-7-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-7-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-7-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-8-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-8-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-8-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-8-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-8-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-8-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-9-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-9-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-9-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-9-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-9-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-9-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG413-2-10-H3AZ-DC12V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG413-2-10-H3AZ-DC24V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG413-2-10-H3AZ-DC48V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG413-2-10-H3AZ-DC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG413-2-10-H5AZ-AC100V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG413-2-10-H5AZ-AC200V	Model: GAG41 indiv. exhaust, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-0-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-0-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-0-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-0-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-0-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-0-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-2-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-2-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-2-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-2-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-2-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-2-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-3-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-3-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-3-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-3-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-3-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-3-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-4-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-4-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-4-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-4-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-4-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-4-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-5-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-5-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-5-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-5-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-5-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-5-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-6-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-6-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-6-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-6-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-6-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-6-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-7-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-7-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-7-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-7-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-7-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-7-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-8-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-8-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-8-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-8-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-8-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-8-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-9-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-9-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-9-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-9-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-9-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-9-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-1-10-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-1-10-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-1-10-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-1-10-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-1-10-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-1-10-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-0-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-0-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-0-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-0-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-0-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-0-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-2-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-2-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-2-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-2-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-2-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-2-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-3-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-3-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-3-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-3-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-3-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-3-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-4-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-4-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-4-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-4-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-4-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-4-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-5-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-5-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-5-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-5-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-5-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-5-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-6-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-6-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-6-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-6-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-6-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-6-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-7-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-7-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-7-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-7-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-7-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-7-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-8-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-8-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-8-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-8-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-8-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-8-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-9-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-9-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-9-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-9-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-9-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-9-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG452-2-10-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG452-2-10-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG452-2-10-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG452-2-10-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG452-2-10-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG452-2-10-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc1/4 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-0-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-0-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-0-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-0-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-0-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-0-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-2-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-2-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-2-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-2-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-2-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-2-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-3-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-3-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-3-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-3-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-3-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-3-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-4-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-4-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-4-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-4-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-4-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-4-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-5-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-5-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-5-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-5-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-5-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-5-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-6-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-6-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-6-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-6-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-6-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-6-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-7-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-7-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-7-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-7-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-7-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-7-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-8-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-8-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-8-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-8-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-8-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-8-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-9-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-9-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-9-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-9-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-9-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-9-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-1-10-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-1-10-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-1-10-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-1-10-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-1-10-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-1-10-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.0 / BODY 2.0 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-0-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-0-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-0-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-0-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-0-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-0-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: Actuator (single) \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-2-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-2-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-2-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-2-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-2-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-2-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 2 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-3-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-3-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-3-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-3-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-3-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-3-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 3 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-4-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-4-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-4-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-4-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-4-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-4-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 4 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-5-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-5-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-5-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-5-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-5-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-5-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 5 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-6-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-6-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-6-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-6-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-6-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-6-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 6 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-7-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-7-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-7-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-7-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-7-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-7-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 7 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-8-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-8-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-8-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-8-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-8-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-8-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 8 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-9-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-9-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-9-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-9-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-9-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-9-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 9 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V
	GAG453-2-10-H3AZ-DC12V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC12V
	GAG453-2-10-H3AZ-DC24V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC24V
	GAG453-2-10-H3AZ-DC48V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC48V
	GAG453-2-10-H3AZ-DC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead wire (DC) \| Voltage: DC100V
	GAG453-2-10-H5AZ-AC100V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC100V
	GAG453-2-10-H5AZ-AC200V	Model: GAG45 diverting, NO port Rc3/8 \| Orifice: TOP 2.3 / BODY 2.3 mm \| Stations: 10 stations \| Coil: Open frame lead, diode (AC) \| Voltage: AC200V

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

CKD GAG31/35/41/45-Z MULTILEX Dry Air 3-Port Valve Manifold
