CKD GLC Guideless Cylinder (Non-Rotating, Bore 40-100)

CKD GLC Guideless Cylinder (Non-Rotating, Bore 40-100)

CKD GLC guideless cylinder: a compact, lightweight double-acting cylinder with built-in anti-rotation and lateral load resistance, removing the need for external guides, bore equivalent 40 to 100 mm.

Key features

  • Built-in anti-rotation and lateral load resistant structure, no external guide required
  • Rod end shape selectable: female thread (no symbol), male thread (N) or flange (F)
  • Mountings: basic (00), axial foot (LB), rod-end flange (FA), head-end flange (FB)
  • Switch magnet built in; R-type (R0-R6) or strong-magnetic-field H0 (GLC-L2 code) switches appended
  • Port position R/T/S selectable as last code block; seal kits GLC-40K to GLC-100K

Specifications

Action Double acting
Fluid Compressed air
Operating pressure 0.15 to 1.0 MPa
Proof pressure 1.6 MPa
Ambient temperature -10 to 60 C (no freezing)
Port size Rc1/8 (40), Rc1/4 (50, 63), Rc3/8 (80, 100)
Piston speed 50 to 500 mm/s
Cushion Rubber cushion
Lubrication Not required
Max. stroke 500 (40-63), 700 (80), 800 (100) mm
Source CKD Korea catalog CB-030SK-9, p. 1281-1299
GLC-00-40-100 Mounting: Basic | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-40-100-N Mounting: Basic | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-40-100-F Mounting: Basic | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-40-200 Mounting: Basic | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-40-200-N Mounting: Basic | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-40-200-F Mounting: Basic | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-40-300 Mounting: Basic | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-40-300-N Mounting: Basic | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-40-300-F Mounting: Basic | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-40-400 Mounting: Basic | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-40-400-N Mounting: Basic | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-40-400-F Mounting: Basic | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-40-500 Mounting: Basic | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-40-500-N Mounting: Basic | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-40-500-F Mounting: Basic | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-50-100 Mounting: Basic | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-50-100-N Mounting: Basic | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-50-100-F Mounting: Basic | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-50-200 Mounting: Basic | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-50-200-N Mounting: Basic | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-50-200-F Mounting: Basic | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-50-300 Mounting: Basic | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-50-300-N Mounting: Basic | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-50-300-F Mounting: Basic | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-50-400 Mounting: Basic | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-50-400-N Mounting: Basic | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-50-400-F Mounting: Basic | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-50-500 Mounting: Basic | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-50-500-N Mounting: Basic | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-50-500-F Mounting: Basic | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-63-100 Mounting: Basic | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-63-100-N Mounting: Basic | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-63-100-F Mounting: Basic | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-63-200 Mounting: Basic | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-63-200-N Mounting: Basic | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-63-200-F Mounting: Basic | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-63-300 Mounting: Basic | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-63-300-N Mounting: Basic | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-63-300-F Mounting: Basic | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-63-400 Mounting: Basic | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-63-400-N Mounting: Basic | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-63-400-F Mounting: Basic | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-63-500 Mounting: Basic | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-63-500-N Mounting: Basic | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-63-500-F Mounting: Basic | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-80-100 Mounting: Basic | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-80-100-N Mounting: Basic | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-80-100-F Mounting: Basic | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-80-200 Mounting: Basic | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-80-200-N Mounting: Basic | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-80-200-F Mounting: Basic | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-80-300 Mounting: Basic | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-80-300-N Mounting: Basic | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-80-300-F Mounting: Basic | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-80-400 Mounting: Basic | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-80-400-N Mounting: Basic | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-80-400-F Mounting: Basic | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-80-500 Mounting: Basic | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-80-500-N Mounting: Basic | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-80-500-F Mounting: Basic | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-80-600 Mounting: Basic | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-00-80-600-N Mounting: Basic | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-00-80-600-F Mounting: Basic | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-00-80-700 Mounting: Basic | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-00-80-700-N Mounting: Basic | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-00-80-700-F Mounting: Basic | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-00-100-100 Mounting: Basic | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-100-100-N Mounting: Basic | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-100-100-F Mounting: Basic | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-100-200 Mounting: Basic | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-100-200-N Mounting: Basic | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-100-200-F Mounting: Basic | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-100-300 Mounting: Basic | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-100-300-N Mounting: Basic | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-100-300-F Mounting: Basic | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-100-400 Mounting: Basic | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-100-400-N Mounting: Basic | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-100-400-F Mounting: Basic | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-100-500 Mounting: Basic | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-100-500-N Mounting: Basic | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-100-500-F Mounting: Basic | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-100-600 Mounting: Basic | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-00-100-600-N Mounting: Basic | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-00-100-600-F Mounting: Basic | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-00-100-700 Mounting: Basic | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-00-100-700-N Mounting: Basic | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-00-100-700-F Mounting: Basic | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-00-100-800 Mounting: Basic | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-00-100-800-N Mounting: Basic | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-00-100-800-F Mounting: Basic | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange
GLC-LB-40-100 Mounting: Axial foot | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-40-100-N Mounting: Axial foot | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-40-100-F Mounting: Axial foot | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-40-200 Mounting: Axial foot | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-40-200-N Mounting: Axial foot | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-40-200-F Mounting: Axial foot | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-40-300 Mounting: Axial foot | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-40-300-N Mounting: Axial foot | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-40-300-F Mounting: Axial foot | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-40-400 Mounting: Axial foot | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-40-400-N Mounting: Axial foot | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-40-400-F Mounting: Axial foot | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-40-500 Mounting: Axial foot | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-40-500-N Mounting: Axial foot | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-40-500-F Mounting: Axial foot | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-50-100 Mounting: Axial foot | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-50-100-N Mounting: Axial foot | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-50-100-F Mounting: Axial foot | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-50-200 Mounting: Axial foot | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-50-200-N Mounting: Axial foot | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-50-200-F Mounting: Axial foot | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-50-300 Mounting: Axial foot | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-50-300-N Mounting: Axial foot | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-50-300-F Mounting: Axial foot | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-50-400 Mounting: Axial foot | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-50-400-N Mounting: Axial foot | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-50-400-F Mounting: Axial foot | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-50-500 Mounting: Axial foot | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-50-500-N Mounting: Axial foot | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-50-500-F Mounting: Axial foot | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-63-100 Mounting: Axial foot | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-63-100-N Mounting: Axial foot | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-63-100-F Mounting: Axial foot | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-63-200 Mounting: Axial foot | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-63-200-N Mounting: Axial foot | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-63-200-F Mounting: Axial foot | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-63-300 Mounting: Axial foot | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-63-300-N Mounting: Axial foot | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-63-300-F Mounting: Axial foot | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-63-400 Mounting: Axial foot | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-63-400-N Mounting: Axial foot | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-63-400-F Mounting: Axial foot | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-63-500 Mounting: Axial foot | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-63-500-N Mounting: Axial foot | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-63-500-F Mounting: Axial foot | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-80-100 Mounting: Axial foot | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-80-100-N Mounting: Axial foot | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-80-100-F Mounting: Axial foot | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-80-200 Mounting: Axial foot | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-80-200-N Mounting: Axial foot | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-80-200-F Mounting: Axial foot | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-80-300 Mounting: Axial foot | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-80-300-N Mounting: Axial foot | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-80-300-F Mounting: Axial foot | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-80-400 Mounting: Axial foot | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-80-400-N Mounting: Axial foot | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-80-400-F Mounting: Axial foot | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-80-500 Mounting: Axial foot | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-80-500-N Mounting: Axial foot | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-80-500-F Mounting: Axial foot | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-80-600 Mounting: Axial foot | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-LB-80-600-N Mounting: Axial foot | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-LB-80-600-F Mounting: Axial foot | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-LB-80-700 Mounting: Axial foot | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-LB-80-700-N Mounting: Axial foot | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-LB-80-700-F Mounting: Axial foot | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-LB-100-100 Mounting: Axial foot | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-100-100-N Mounting: Axial foot | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-100-100-F Mounting: Axial foot | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-100-200 Mounting: Axial foot | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-100-200-N Mounting: Axial foot | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-100-200-F Mounting: Axial foot | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-100-300 Mounting: Axial foot | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-100-300-N Mounting: Axial foot | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-100-300-F Mounting: Axial foot | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-100-400 Mounting: Axial foot | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-100-400-N Mounting: Axial foot | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-100-400-F Mounting: Axial foot | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-100-500 Mounting: Axial foot | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-100-500-N Mounting: Axial foot | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-100-500-F Mounting: Axial foot | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-100-600 Mounting: Axial foot | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-LB-100-600-N Mounting: Axial foot | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-LB-100-600-F Mounting: Axial foot | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-LB-100-700 Mounting: Axial foot | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-LB-100-700-N Mounting: Axial foot | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-LB-100-700-F Mounting: Axial foot | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-LB-100-800 Mounting: Axial foot | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-LB-100-800-N Mounting: Axial foot | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-LB-100-800-F Mounting: Axial foot | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange
GLC-FA-40-100 Mounting: Rod-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-40-100-N Mounting: Rod-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-40-100-F Mounting: Rod-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-40-200 Mounting: Rod-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-40-200-N Mounting: Rod-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-40-200-F Mounting: Rod-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-40-300 Mounting: Rod-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-40-300-N Mounting: Rod-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-40-300-F Mounting: Rod-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-40-400 Mounting: Rod-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-40-400-N Mounting: Rod-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-40-400-F Mounting: Rod-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-40-500 Mounting: Rod-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-40-500-N Mounting: Rod-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-40-500-F Mounting: Rod-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-50-100 Mounting: Rod-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-50-100-N Mounting: Rod-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-50-100-F Mounting: Rod-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-50-200 Mounting: Rod-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-50-200-N Mounting: Rod-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-50-200-F Mounting: Rod-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-50-300 Mounting: Rod-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-50-300-N Mounting: Rod-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-50-300-F Mounting: Rod-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-50-400 Mounting: Rod-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-50-400-N Mounting: Rod-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-50-400-F Mounting: Rod-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-50-500 Mounting: Rod-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-50-500-N Mounting: Rod-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-50-500-F Mounting: Rod-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-63-100 Mounting: Rod-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-63-100-N Mounting: Rod-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-63-100-F Mounting: Rod-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-63-200 Mounting: Rod-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-63-200-N Mounting: Rod-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-63-200-F Mounting: Rod-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-63-300 Mounting: Rod-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-63-300-N Mounting: Rod-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-63-300-F Mounting: Rod-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-63-400 Mounting: Rod-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-63-400-N Mounting: Rod-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-63-400-F Mounting: Rod-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-63-500 Mounting: Rod-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-63-500-N Mounting: Rod-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-63-500-F Mounting: Rod-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-80-100 Mounting: Rod-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-80-100-N Mounting: Rod-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-80-100-F Mounting: Rod-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-80-200 Mounting: Rod-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-80-200-N Mounting: Rod-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-80-200-F Mounting: Rod-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-80-300 Mounting: Rod-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-80-300-N Mounting: Rod-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-80-300-F Mounting: Rod-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-80-400 Mounting: Rod-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-80-400-N Mounting: Rod-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-80-400-F Mounting: Rod-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-80-500 Mounting: Rod-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-80-500-N Mounting: Rod-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-80-500-F Mounting: Rod-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-80-600 Mounting: Rod-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FA-80-600-N Mounting: Rod-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FA-80-600-F Mounting: Rod-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-FA-80-700 Mounting: Rod-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FA-80-700-N Mounting: Rod-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FA-80-700-F Mounting: Rod-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-FA-100-100 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-100-100-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-100-100-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-100-200 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-100-200-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-100-200-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-100-300 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-100-300-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-100-300-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-100-400 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-100-400-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-100-400-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-100-500 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-100-500-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-100-500-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-100-600 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FA-100-600-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FA-100-600-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-FA-100-700 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FA-100-700-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FA-100-700-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-FA-100-800 Mounting: Rod-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-FA-100-800-N Mounting: Rod-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-FA-100-800-F Mounting: Rod-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange
GLC-FB-40-100 Mounting: Head-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-40-100-N Mounting: Head-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-40-100-F Mounting: Head-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-40-200 Mounting: Head-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-40-200-N Mounting: Head-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-40-200-F Mounting: Head-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-40-300 Mounting: Head-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-40-300-N Mounting: Head-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-40-300-F Mounting: Head-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-40-400 Mounting: Head-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-40-400-N Mounting: Head-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-40-400-F Mounting: Head-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-40-500 Mounting: Head-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-40-500-N Mounting: Head-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-40-500-F Mounting: Head-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-50-100 Mounting: Head-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-50-100-N Mounting: Head-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-50-100-F Mounting: Head-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-50-200 Mounting: Head-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-50-200-N Mounting: Head-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-50-200-F Mounting: Head-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-50-300 Mounting: Head-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-50-300-N Mounting: Head-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-50-300-F Mounting: Head-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-50-400 Mounting: Head-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-50-400-N Mounting: Head-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-50-400-F Mounting: Head-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-50-500 Mounting: Head-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-50-500-N Mounting: Head-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-50-500-F Mounting: Head-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-63-100 Mounting: Head-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-63-100-N Mounting: Head-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-63-100-F Mounting: Head-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-63-200 Mounting: Head-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-63-200-N Mounting: Head-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-63-200-F Mounting: Head-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-63-300 Mounting: Head-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-63-300-N Mounting: Head-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-63-300-F Mounting: Head-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-63-400 Mounting: Head-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-63-400-N Mounting: Head-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-63-400-F Mounting: Head-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-63-500 Mounting: Head-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-63-500-N Mounting: Head-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-63-500-F Mounting: Head-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-80-100 Mounting: Head-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-80-100-N Mounting: Head-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-80-100-F Mounting: Head-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-80-200 Mounting: Head-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-80-200-N Mounting: Head-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-80-200-F Mounting: Head-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-80-300 Mounting: Head-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-80-300-N Mounting: Head-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-80-300-F Mounting: Head-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-80-400 Mounting: Head-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-80-400-N Mounting: Head-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-80-400-F Mounting: Head-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-80-500 Mounting: Head-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-80-500-N Mounting: Head-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-80-500-F Mounting: Head-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-80-600 Mounting: Head-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FB-80-600-N Mounting: Head-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FB-80-600-F Mounting: Head-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-FB-80-700 Mounting: Head-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FB-80-700-N Mounting: Head-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FB-80-700-F Mounting: Head-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-FB-100-100 Mounting: Head-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-100-100-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-100-100-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-100-200 Mounting: Head-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-100-200-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-100-200-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-100-300 Mounting: Head-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-100-300-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-100-300-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-100-400 Mounting: Head-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-100-400-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-100-400-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-100-500 Mounting: Head-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-100-500-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-100-500-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-100-600 Mounting: Head-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FB-100-600-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FB-100-600-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-FB-100-700 Mounting: Head-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FB-100-700-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FB-100-700-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-FB-100-800 Mounting: Head-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-FB-100-800-N Mounting: Head-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-FB-100-800-F Mounting: Head-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange
Pneumatic CylindersCKD
360 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD GLC Guideless Cylinder (Non-Rotating, Bore 40-100)

Brand CKD·Pneumatic Cylinders

Available part numbers (360)

GLC-00-40-100, GLC-00-40-100-N, GLC-00-40-100-F, GLC-00-40-200, GLC-00-40-200-N, GLC-00-40-200-F, GLC-00-40-300, GLC-00-40-300-N, GLC-00-40-300-F, GLC-00-40-400 + 350 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GLC-00-40-100Mounting: Basic | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-40-100-NMounting: Basic | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-40-100-FMounting: Basic | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-40-200Mounting: Basic | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-40-200-NMounting: Basic | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-40-200-FMounting: Basic | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-40-300Mounting: Basic | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-40-300-NMounting: Basic | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-40-300-FMounting: Basic | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-40-400Mounting: Basic | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-40-400-NMounting: Basic | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-40-400-FMounting: Basic | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-40-500Mounting: Basic | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-40-500-NMounting: Basic | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-40-500-FMounting: Basic | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-50-100Mounting: Basic | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-50-100-NMounting: Basic | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-50-100-FMounting: Basic | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-50-200Mounting: Basic | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-50-200-NMounting: Basic | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-50-200-FMounting: Basic | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-50-300Mounting: Basic | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-50-300-NMounting: Basic | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-50-300-FMounting: Basic | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-50-400Mounting: Basic | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-50-400-NMounting: Basic | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-50-400-FMounting: Basic | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-50-500Mounting: Basic | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-50-500-NMounting: Basic | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-50-500-FMounting: Basic | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-63-100Mounting: Basic | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-63-100-NMounting: Basic | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-63-100-FMounting: Basic | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-63-200Mounting: Basic | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-63-200-NMounting: Basic | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-63-200-FMounting: Basic | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-63-300Mounting: Basic | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-63-300-NMounting: Basic | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-63-300-FMounting: Basic | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-63-400Mounting: Basic | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-63-400-NMounting: Basic | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-63-400-FMounting: Basic | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-63-500Mounting: Basic | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-63-500-NMounting: Basic | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-63-500-FMounting: Basic | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-80-100Mounting: Basic | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-80-100-NMounting: Basic | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-80-100-FMounting: Basic | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-80-200Mounting: Basic | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-80-200-NMounting: Basic | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-80-200-FMounting: Basic | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-80-300Mounting: Basic | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-80-300-NMounting: Basic | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-80-300-FMounting: Basic | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-80-400Mounting: Basic | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-80-400-NMounting: Basic | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-80-400-FMounting: Basic | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-80-500Mounting: Basic | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-80-500-NMounting: Basic | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-80-500-FMounting: Basic | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-80-600Mounting: Basic | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-00-80-600-NMounting: Basic | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-00-80-600-FMounting: Basic | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-00-80-700Mounting: Basic | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-00-80-700-NMounting: Basic | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-00-80-700-FMounting: Basic | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-00-100-100Mounting: Basic | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-00-100-100-NMounting: Basic | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-00-100-100-FMounting: Basic | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-00-100-200Mounting: Basic | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-00-100-200-NMounting: Basic | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-00-100-200-FMounting: Basic | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-00-100-300Mounting: Basic | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-00-100-300-NMounting: Basic | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-00-100-300-FMounting: Basic | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-00-100-400Mounting: Basic | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-00-100-400-NMounting: Basic | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-00-100-400-FMounting: Basic | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-00-100-500Mounting: Basic | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-00-100-500-NMounting: Basic | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-00-100-500-FMounting: Basic | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-00-100-600Mounting: Basic | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-00-100-600-NMounting: Basic | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-00-100-600-FMounting: Basic | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-00-100-700Mounting: Basic | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-00-100-700-NMounting: Basic | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-00-100-700-FMounting: Basic | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-00-100-800Mounting: Basic | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-00-100-800-NMounting: Basic | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-00-100-800-FMounting: Basic | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange
GLC-LB-40-100Mounting: Axial foot | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-40-100-NMounting: Axial foot | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-40-100-FMounting: Axial foot | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-40-200Mounting: Axial foot | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-40-200-NMounting: Axial foot | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-40-200-FMounting: Axial foot | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-40-300Mounting: Axial foot | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-40-300-NMounting: Axial foot | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-40-300-FMounting: Axial foot | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-40-400Mounting: Axial foot | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-40-400-NMounting: Axial foot | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-40-400-FMounting: Axial foot | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-40-500Mounting: Axial foot | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-40-500-NMounting: Axial foot | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-40-500-FMounting: Axial foot | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-50-100Mounting: Axial foot | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-50-100-NMounting: Axial foot | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-50-100-FMounting: Axial foot | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-50-200Mounting: Axial foot | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-50-200-NMounting: Axial foot | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-50-200-FMounting: Axial foot | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-50-300Mounting: Axial foot | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-50-300-NMounting: Axial foot | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-50-300-FMounting: Axial foot | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-50-400Mounting: Axial foot | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-50-400-NMounting: Axial foot | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-50-400-FMounting: Axial foot | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-50-500Mounting: Axial foot | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-50-500-NMounting: Axial foot | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-50-500-FMounting: Axial foot | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-63-100Mounting: Axial foot | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-63-100-NMounting: Axial foot | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-63-100-FMounting: Axial foot | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-63-200Mounting: Axial foot | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-63-200-NMounting: Axial foot | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-63-200-FMounting: Axial foot | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-63-300Mounting: Axial foot | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-63-300-NMounting: Axial foot | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-63-300-FMounting: Axial foot | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-63-400Mounting: Axial foot | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-63-400-NMounting: Axial foot | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-63-400-FMounting: Axial foot | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-63-500Mounting: Axial foot | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-63-500-NMounting: Axial foot | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-63-500-FMounting: Axial foot | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-80-100Mounting: Axial foot | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-80-100-NMounting: Axial foot | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-80-100-FMounting: Axial foot | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-80-200Mounting: Axial foot | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-80-200-NMounting: Axial foot | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-80-200-FMounting: Axial foot | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-80-300Mounting: Axial foot | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-80-300-NMounting: Axial foot | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-80-300-FMounting: Axial foot | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-80-400Mounting: Axial foot | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-80-400-NMounting: Axial foot | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-80-400-FMounting: Axial foot | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-80-500Mounting: Axial foot | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-80-500-NMounting: Axial foot | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-80-500-FMounting: Axial foot | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-80-600Mounting: Axial foot | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-LB-80-600-NMounting: Axial foot | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-LB-80-600-FMounting: Axial foot | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-LB-80-700Mounting: Axial foot | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-LB-80-700-NMounting: Axial foot | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-LB-80-700-FMounting: Axial foot | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-LB-100-100Mounting: Axial foot | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-LB-100-100-NMounting: Axial foot | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-LB-100-100-FMounting: Axial foot | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-LB-100-200Mounting: Axial foot | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-LB-100-200-NMounting: Axial foot | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-LB-100-200-FMounting: Axial foot | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-LB-100-300Mounting: Axial foot | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-LB-100-300-NMounting: Axial foot | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-LB-100-300-FMounting: Axial foot | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-LB-100-400Mounting: Axial foot | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-LB-100-400-NMounting: Axial foot | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-LB-100-400-FMounting: Axial foot | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-LB-100-500Mounting: Axial foot | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-LB-100-500-NMounting: Axial foot | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-LB-100-500-FMounting: Axial foot | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-LB-100-600Mounting: Axial foot | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-LB-100-600-NMounting: Axial foot | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-LB-100-600-FMounting: Axial foot | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-LB-100-700Mounting: Axial foot | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-LB-100-700-NMounting: Axial foot | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-LB-100-700-FMounting: Axial foot | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-LB-100-800Mounting: Axial foot | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-LB-100-800-NMounting: Axial foot | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-LB-100-800-FMounting: Axial foot | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange
GLC-FA-40-100Mounting: Rod-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-40-100-NMounting: Rod-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-40-100-FMounting: Rod-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-40-200Mounting: Rod-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-40-200-NMounting: Rod-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-40-200-FMounting: Rod-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-40-300Mounting: Rod-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-40-300-NMounting: Rod-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-40-300-FMounting: Rod-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-40-400Mounting: Rod-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-40-400-NMounting: Rod-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-40-400-FMounting: Rod-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-40-500Mounting: Rod-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-40-500-NMounting: Rod-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-40-500-FMounting: Rod-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-50-100Mounting: Rod-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-50-100-NMounting: Rod-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-50-100-FMounting: Rod-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-50-200Mounting: Rod-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-50-200-NMounting: Rod-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-50-200-FMounting: Rod-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-50-300Mounting: Rod-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-50-300-NMounting: Rod-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-50-300-FMounting: Rod-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-50-400Mounting: Rod-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-50-400-NMounting: Rod-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-50-400-FMounting: Rod-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-50-500Mounting: Rod-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-50-500-NMounting: Rod-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-50-500-FMounting: Rod-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-63-100Mounting: Rod-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-63-100-NMounting: Rod-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-63-100-FMounting: Rod-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-63-200Mounting: Rod-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-63-200-NMounting: Rod-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-63-200-FMounting: Rod-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-63-300Mounting: Rod-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-63-300-NMounting: Rod-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-63-300-FMounting: Rod-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-63-400Mounting: Rod-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-63-400-NMounting: Rod-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-63-400-FMounting: Rod-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-63-500Mounting: Rod-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-63-500-NMounting: Rod-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-63-500-FMounting: Rod-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-80-100Mounting: Rod-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-80-100-NMounting: Rod-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-80-100-FMounting: Rod-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-80-200Mounting: Rod-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-80-200-NMounting: Rod-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-80-200-FMounting: Rod-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-80-300Mounting: Rod-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-80-300-NMounting: Rod-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-80-300-FMounting: Rod-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-80-400Mounting: Rod-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-80-400-NMounting: Rod-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-80-400-FMounting: Rod-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-80-500Mounting: Rod-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-80-500-NMounting: Rod-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-80-500-FMounting: Rod-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-80-600Mounting: Rod-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FA-80-600-NMounting: Rod-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FA-80-600-FMounting: Rod-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-FA-80-700Mounting: Rod-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FA-80-700-NMounting: Rod-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FA-80-700-FMounting: Rod-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-FA-100-100Mounting: Rod-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FA-100-100-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FA-100-100-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-FA-100-200Mounting: Rod-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FA-100-200-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FA-100-200-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-FA-100-300Mounting: Rod-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FA-100-300-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FA-100-300-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-FA-100-400Mounting: Rod-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FA-100-400-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FA-100-400-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-FA-100-500Mounting: Rod-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FA-100-500-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FA-100-500-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-FA-100-600Mounting: Rod-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FA-100-600-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FA-100-600-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-FA-100-700Mounting: Rod-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FA-100-700-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FA-100-700-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-FA-100-800Mounting: Rod-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-FA-100-800-NMounting: Rod-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-FA-100-800-FMounting: Rod-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange
GLC-FB-40-100Mounting: Head-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-40-100-NMounting: Head-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-40-100-FMounting: Head-end flange | Bore: 40 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-40-200Mounting: Head-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-40-200-NMounting: Head-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-40-200-FMounting: Head-end flange | Bore: 40 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-40-300Mounting: Head-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-40-300-NMounting: Head-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-40-300-FMounting: Head-end flange | Bore: 40 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-40-400Mounting: Head-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-40-400-NMounting: Head-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-40-400-FMounting: Head-end flange | Bore: 40 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-40-500Mounting: Head-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-40-500-NMounting: Head-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-40-500-FMounting: Head-end flange | Bore: 40 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-50-100Mounting: Head-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-50-100-NMounting: Head-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-50-100-FMounting: Head-end flange | Bore: 50 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-50-200Mounting: Head-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-50-200-NMounting: Head-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-50-200-FMounting: Head-end flange | Bore: 50 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-50-300Mounting: Head-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-50-300-NMounting: Head-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-50-300-FMounting: Head-end flange | Bore: 50 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-50-400Mounting: Head-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-50-400-NMounting: Head-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-50-400-FMounting: Head-end flange | Bore: 50 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-50-500Mounting: Head-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-50-500-NMounting: Head-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-50-500-FMounting: Head-end flange | Bore: 50 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-63-100Mounting: Head-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-63-100-NMounting: Head-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-63-100-FMounting: Head-end flange | Bore: 63 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-63-200Mounting: Head-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-63-200-NMounting: Head-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-63-200-FMounting: Head-end flange | Bore: 63 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-63-300Mounting: Head-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-63-300-NMounting: Head-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-63-300-FMounting: Head-end flange | Bore: 63 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-63-400Mounting: Head-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-63-400-NMounting: Head-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-63-400-FMounting: Head-end flange | Bore: 63 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-63-500Mounting: Head-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-63-500-NMounting: Head-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-63-500-FMounting: Head-end flange | Bore: 63 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-80-100Mounting: Head-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-80-100-NMounting: Head-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-80-100-FMounting: Head-end flange | Bore: 80 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-80-200Mounting: Head-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-80-200-NMounting: Head-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-80-200-FMounting: Head-end flange | Bore: 80 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-80-300Mounting: Head-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-80-300-NMounting: Head-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-80-300-FMounting: Head-end flange | Bore: 80 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-80-400Mounting: Head-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-80-400-NMounting: Head-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-80-400-FMounting: Head-end flange | Bore: 80 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-80-500Mounting: Head-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-80-500-NMounting: Head-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-80-500-FMounting: Head-end flange | Bore: 80 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-80-600Mounting: Head-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FB-80-600-NMounting: Head-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FB-80-600-FMounting: Head-end flange | Bore: 80 mm | Stroke: 600 mm | Rod end: Flange
GLC-FB-80-700Mounting: Head-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FB-80-700-NMounting: Head-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FB-80-700-FMounting: Head-end flange | Bore: 80 mm | Stroke: 700 mm | Rod end: Flange
GLC-FB-100-100Mounting: Head-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Female thread
GLC-FB-100-100-NMounting: Head-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Male thread
GLC-FB-100-100-FMounting: Head-end flange | Bore: 100 mm | Stroke: 100 mm | Rod end: Flange
GLC-FB-100-200Mounting: Head-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Female thread
GLC-FB-100-200-NMounting: Head-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Male thread
GLC-FB-100-200-FMounting: Head-end flange | Bore: 100 mm | Stroke: 200 mm | Rod end: Flange
GLC-FB-100-300Mounting: Head-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Female thread
GLC-FB-100-300-NMounting: Head-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Male thread
GLC-FB-100-300-FMounting: Head-end flange | Bore: 100 mm | Stroke: 300 mm | Rod end: Flange
GLC-FB-100-400Mounting: Head-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Female thread
GLC-FB-100-400-NMounting: Head-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Male thread
GLC-FB-100-400-FMounting: Head-end flange | Bore: 100 mm | Stroke: 400 mm | Rod end: Flange
GLC-FB-100-500Mounting: Head-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Female thread
GLC-FB-100-500-NMounting: Head-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Male thread
GLC-FB-100-500-FMounting: Head-end flange | Bore: 100 mm | Stroke: 500 mm | Rod end: Flange
GLC-FB-100-600Mounting: Head-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Female thread
GLC-FB-100-600-NMounting: Head-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Male thread
GLC-FB-100-600-FMounting: Head-end flange | Bore: 100 mm | Stroke: 600 mm | Rod end: Flange
GLC-FB-100-700Mounting: Head-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Female thread
GLC-FB-100-700-NMounting: Head-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Male thread
GLC-FB-100-700-FMounting: Head-end flange | Bore: 100 mm | Stroke: 700 mm | Rod end: Flange
GLC-FB-100-800Mounting: Head-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Female thread
GLC-FB-100-800-NMounting: Head-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Male thread
GLC-FB-100-800-FMounting: Head-end flange | Bore: 100 mm | Stroke: 800 mm | Rod end: Flange

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
