CKD HMC-HP1 Wide Parallel Hand (Long-Life)

CKD HMC-HP1 long-life wide-opening parallel hand with twin pistons, bore ø10x2 to ø40x2 and finger stroke 20 to 200 mm.

Key features

Wide-type parallel hand for large workpieces; short, middle and long stroke versions
Gripping force 14 N (ø10) to 396 N (ø40) at 0.5 MPa
Max. operating pressure 0.6 MPa; repeatability ±0.1 mm
Switch magnet built in; T-type switches (T2H/T2V, T2HR3/T2VR3, T3H/T3V, T3PH/T3PV), lead 1/3/5 m; example HMC-32A-T2H-R-HP1
Outline dimensions as wide parallel hand catalog CC-1580

Specifications

Action	Double acting
Max. operating pressure	0.6 MPa
Min. operating pressure	0.1-0.15 MPa
Port size	M5 (ø10-ø25), Rc1/8 (ø32, ø40)
Ambient temperature	-10 to 60°C
Source	CKD Korea catalog CC-1421KR-7, p. 172-174

HMC-10A-HP1		Bore: 10 mm x2 \| Stroke type: Short \| Stroke: 20 mm
HMC-10B-HP1		Bore: 10 mm x2 \| Stroke type: Middle \| Stroke: 40 mm
HMC-10C-HP1		Bore: 10 mm x2 \| Stroke type: Long \| Stroke: 60 mm
HMC-16A-HP1		Bore: 16 mm x2 \| Stroke type: Short \| Stroke: 30 mm
HMC-16B-HP1		Bore: 16 mm x2 \| Stroke type: Middle \| Stroke: 60 mm
HMC-16C-HP1		Bore: 16 mm x2 \| Stroke type: Long \| Stroke: 80 mm
HMC-20A-HP1		Bore: 20 mm x2 \| Stroke type: Short \| Stroke: 40 mm
HMC-20B-HP1		Bore: 20 mm x2 \| Stroke type: Middle \| Stroke: 80 mm
HMC-20C-HP1		Bore: 20 mm x2 \| Stroke type: Long \| Stroke: 100 mm
HMC-25A-HP1		Bore: 25 mm x2 \| Stroke type: Short \| Stroke: 50 mm
HMC-25B-HP1		Bore: 25 mm x2 \| Stroke type: Middle \| Stroke: 100 mm
HMC-25C-HP1		Bore: 25 mm x2 \| Stroke type: Long \| Stroke: 120 mm
HMC-32A-HP1		Bore: 32 mm x2 \| Stroke type: Short \| Stroke: 70 mm
HMC-32B-HP1		Bore: 32 mm x2 \| Stroke type: Middle \| Stroke: 120 mm
HMC-32C-HP1		Bore: 32 mm x2 \| Stroke type: Long \| Stroke: 160 mm
HMC-40A-HP1		Bore: 40 mm x2 \| Stroke type: Short \| Stroke: 100 mm
HMC-40B-HP1		Bore: 40 mm x2 \| Stroke type: Middle \| Stroke: 160 mm
HMC-40C-HP1		Bore: 40 mm x2 \| Stroke type: Long \| Stroke: 200 mm
