CKD MSD-HP1 Long-life Small Compact Cylinder (Bore 6, 8 mm)

CKD MSD-HP1 Long-life Small Compact Cylinder (Bore 6, 8 mm)

CKD MSD-HP1 long-life double-acting small compact cylinder for bores 6 and 8 mm.

Key features

  • HP1 long-life design: optimised sliding parts, rated for 20 million+ cycles (about 4x conventional, CKD test conditions)
  • MSD (no magnet) or MSD-L (switch magnet built in)
  • Front piping (standard) or rear piping (R)
  • Standard strokes 5-30 mm in 5 mm steps (standard strokes only)
  • Auto switches F0H/F2H/F3H/F2YH etc. with R/H/D count ordered via code (not expanded)

Specifications

Operation Double acting, single rod
Fluid Compressed air
Max. operating pressure 1.0 MPa
Min. operating pressure 0.15 MPa
Proof pressure 1.6 MPa
Ambient temperature -10 to 60 C (no freezing)
Port size M3
Piston speed 50-500 mm/s
Cushion None
Code format MSD[-L]-<bore>-<stroke>[-R]-HP1
Source CKD Korea catalog CC-1421KR-7, p. 38-40
