CKD MSDG-L-HP1 Long-life Guided Compact Cylinder (Bore 6-16 mm)

CKD MSDG-L-HP1 Long-life Guided Compact Cylinder (Bore 6-16 mm)

CKD MSDG-L-HP1 long-life double-acting small compact cylinder with integrated guide and built-in switch magnet.

Key features

  • HP1 long-life design: optimised sliding parts, rated for 20 million+ cycles (about 4x conventional, CKD test conditions)
  • Guide built into the compact body; switch magnet built in
  • Front piping (standard) or rear piping (R)
  • Standard strokes 5-30 mm in 5 mm steps (standard strokes only)
  • Auto switches F0H/F2H/F3H/F2YH etc. with R/H/D count (not expanded)

Specifications

Operation Double acting, guided
Fluid Compressed air
Max. operating pressure 1.0 MPa
Min. operating pressure 0.2 MPa (6), 0.15 MPa (8), 0.1 MPa (12, 16)
Proof pressure 1.6 MPa
Ambient temperature 5 to 60 C
Port size M3 (6, 8), M5 front / M3 rear (12, 16)
Piston speed 50-500 mm/s
Cushion Rubber cushion
Code format MSDG-L-<bore>-<stroke>[-R]-HP1
Source CKD Korea catalog CC-1421KR-7, p. 42-44
MSDG-L-6-5-HP1 Bore: 6 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-6-5-R-HP1 Bore: 6 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-6-10-HP1 Bore: 6 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-6-10-R-HP1 Bore: 6 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-6-15-HP1 Bore: 6 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-6-15-R-HP1 Bore: 6 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-6-20-HP1 Bore: 6 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-6-20-R-HP1 Bore: 6 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-6-25-HP1 Bore: 6 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-6-25-R-HP1 Bore: 6 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-6-30-HP1 Bore: 6 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-6-30-R-HP1 Bore: 6 mm | Stroke: 30 mm | Piping: Rear piping
MSDG-L-8-5-HP1 Bore: 8 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-8-5-R-HP1 Bore: 8 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-8-10-HP1 Bore: 8 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-8-10-R-HP1 Bore: 8 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-8-15-HP1 Bore: 8 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-8-15-R-HP1 Bore: 8 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-8-20-HP1 Bore: 8 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-8-20-R-HP1 Bore: 8 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-8-25-HP1 Bore: 8 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-8-25-R-HP1 Bore: 8 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-8-30-HP1 Bore: 8 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-8-30-R-HP1 Bore: 8 mm | Stroke: 30 mm | Piping: Rear piping
MSDG-L-12-5-HP1 Bore: 12 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-12-5-R-HP1 Bore: 12 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-12-10-HP1 Bore: 12 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-12-10-R-HP1 Bore: 12 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-12-15-HP1 Bore: 12 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-12-15-R-HP1 Bore: 12 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-12-20-HP1 Bore: 12 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-12-20-R-HP1 Bore: 12 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-12-25-HP1 Bore: 12 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-12-25-R-HP1 Bore: 12 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-12-30-HP1 Bore: 12 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-12-30-R-HP1 Bore: 12 mm | Stroke: 30 mm | Piping: Rear piping
MSDG-L-16-5-HP1 Bore: 16 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-16-5-R-HP1 Bore: 16 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-16-10-HP1 Bore: 16 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-16-10-R-HP1 Bore: 16 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-16-15-HP1 Bore: 16 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-16-15-R-HP1 Bore: 16 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-16-20-HP1 Bore: 16 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-16-20-R-HP1 Bore: 16 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-16-25-HP1 Bore: 16 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-16-25-R-HP1 Bore: 16 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-16-30-HP1 Bore: 16 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-16-30-R-HP1 Bore: 16 mm | Stroke: 30 mm | Piping: Rear piping
Guided CylindersCKD
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD MSDG-L-HP1 Long-life Guided Compact Cylinder (Bore 6-16 mm)

Brand CKD·Guided Cylinders

Available part numbers (48)

MSDG-L-6-5-HP1, MSDG-L-6-5-R-HP1, MSDG-L-6-10-HP1, MSDG-L-6-10-R-HP1, MSDG-L-6-15-HP1, MSDG-L-6-15-R-HP1, MSDG-L-6-20-HP1, MSDG-L-6-20-R-HP1, MSDG-L-6-25-HP1, MSDG-L-6-25-R-HP1 + 38 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MSDG-L-6-5-HP1Bore: 6 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-6-5-R-HP1Bore: 6 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-6-10-HP1Bore: 6 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-6-10-R-HP1Bore: 6 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-6-15-HP1Bore: 6 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-6-15-R-HP1Bore: 6 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-6-20-HP1Bore: 6 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-6-20-R-HP1Bore: 6 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-6-25-HP1Bore: 6 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-6-25-R-HP1Bore: 6 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-6-30-HP1Bore: 6 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-6-30-R-HP1Bore: 6 mm | Stroke: 30 mm | Piping: Rear piping
MSDG-L-8-5-HP1Bore: 8 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-8-5-R-HP1Bore: 8 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-8-10-HP1Bore: 8 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-8-10-R-HP1Bore: 8 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-8-15-HP1Bore: 8 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-8-15-R-HP1Bore: 8 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-8-20-HP1Bore: 8 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-8-20-R-HP1Bore: 8 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-8-25-HP1Bore: 8 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-8-25-R-HP1Bore: 8 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-8-30-HP1Bore: 8 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-8-30-R-HP1Bore: 8 mm | Stroke: 30 mm | Piping: Rear piping
MSDG-L-12-5-HP1Bore: 12 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-12-5-R-HP1Bore: 12 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-12-10-HP1Bore: 12 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-12-10-R-HP1Bore: 12 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-12-15-HP1Bore: 12 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-12-15-R-HP1Bore: 12 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-12-20-HP1Bore: 12 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-12-20-R-HP1Bore: 12 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-12-25-HP1Bore: 12 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-12-25-R-HP1Bore: 12 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-12-30-HP1Bore: 12 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-12-30-R-HP1Bore: 12 mm | Stroke: 30 mm | Piping: Rear piping
MSDG-L-16-5-HP1Bore: 16 mm | Stroke: 5 mm | Piping: Front piping
MSDG-L-16-5-R-HP1Bore: 16 mm | Stroke: 5 mm | Piping: Rear piping
MSDG-L-16-10-HP1Bore: 16 mm | Stroke: 10 mm | Piping: Front piping
MSDG-L-16-10-R-HP1Bore: 16 mm | Stroke: 10 mm | Piping: Rear piping
MSDG-L-16-15-HP1Bore: 16 mm | Stroke: 15 mm | Piping: Front piping
MSDG-L-16-15-R-HP1Bore: 16 mm | Stroke: 15 mm | Piping: Rear piping
MSDG-L-16-20-HP1Bore: 16 mm | Stroke: 20 mm | Piping: Front piping
MSDG-L-16-20-R-HP1Bore: 16 mm | Stroke: 20 mm | Piping: Rear piping
MSDG-L-16-25-HP1Bore: 16 mm | Stroke: 25 mm | Piping: Front piping
MSDG-L-16-25-R-HP1Bore: 16 mm | Stroke: 25 mm | Piping: Rear piping
MSDG-L-16-30-HP1Bore: 16 mm | Stroke: 30 mm | Piping: Front piping
MSDG-L-16-30-R-HP1Bore: 16 mm | Stroke: 30 mm | Piping: Rear piping
