CKD MW3GA2/MW4GA2-R1-FP1 Manifold (Food Grade, I/O Connector)

CKD MW3GA2/MW4GA2-R1-FP1 Manifold (Food Grade, I/O Connector)

CKD MW3GA2/MW4GA2-R1-FP1 food-processing block manifold with individual M12 I/O connector wiring and direct A/B piping on the valve, for cylinders 20 to 80 mm bore.

Key features

  • FP1 food-processing series using NSF H1 registered grease
  • Central supply and exhaust with built-in exhaust malfunction prevention valve
  • 5-port (MW4GA2) 2-pos single/double and 3-pos valves; 3-port (MW3GA2) N.C./N.O. valves
  • R1 individual wiring: M12 I/O connector, 500 mm, lamp and surge killer standard
  • Up to 16 stations; A/B ports push-in 6/8 mm or Rc1/8, P/R push-in 8/10 mm
  • Options (M, H, F, Z1/Z3/Z8 spacers) and DIN rail mount D specified per manifold spec sheet

Specifications

Valve type Pilot-operated soft spool valve
Fluid Compressed air
Operating pressure 0.2 to 0.7 MPa
Proof pressure 1.05 MPa
Ambient temperature -5 to 55 C (no freezing)
Fluid temperature 5 to 55 C
Protection IP65 dust/jet-proof
Coil voltage DC24V (code 3)
Power consumption 0.6 W (surge killer and indicator std.)
Wiring R1 I/O connector M12, 500 mm
Mounting Direct mount (D = DIN rail, option)
Source CKD Korea catalog CC-1271K-5, p. 220-221
MW4GA210-C6-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 2
MW4GA210-C6-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 3
MW4GA210-C6-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 4
MW4GA210-C6-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 5
MW4GA210-C6-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 6
MW4GA210-C6-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 7
MW4GA210-C6-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 8
MW4GA210-C6-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 9
MW4GA210-C6-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 10
MW4GA210-C6-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 11
MW4GA210-C6-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 12
MW4GA210-C6-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 13
MW4GA210-C6-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 14
MW4GA210-C6-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 15
MW4GA210-C6-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 16
MW4GA210-C8-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 2
MW4GA210-C8-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 3
MW4GA210-C8-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 4
MW4GA210-C8-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 5
MW4GA210-C8-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 6
MW4GA210-C8-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 7
MW4GA210-C8-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 8
MW4GA210-C8-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 9
MW4GA210-C8-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 10
MW4GA210-C8-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 11
MW4GA210-C8-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 12
MW4GA210-C8-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 13
MW4GA210-C8-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 14
MW4GA210-C8-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 15
MW4GA210-C8-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 16
MW4GA210-CX-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 2
MW4GA210-CX-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 3
MW4GA210-CX-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 4
MW4GA210-CX-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 5
MW4GA210-CX-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 6
MW4GA210-CX-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 7
MW4GA210-CX-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 8
MW4GA210-CX-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 9
MW4GA210-CX-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 10
MW4GA210-CX-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 11
MW4GA210-CX-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 12
MW4GA210-CX-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 13
MW4GA210-CX-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 14
MW4GA210-CX-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 15
MW4GA210-CX-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 16
MW4GA210-06-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 2
MW4GA210-06-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 3
MW4GA210-06-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 4
MW4GA210-06-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 5
MW4GA210-06-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 6
MW4GA210-06-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 7
MW4GA210-06-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 8
MW4GA210-06-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 9
MW4GA210-06-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 10
MW4GA210-06-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 11
MW4GA210-06-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 12
MW4GA210-06-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 13
MW4GA210-06-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 14
MW4GA210-06-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 15
MW4GA210-06-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 16
MW4GA220-C6-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 2
MW4GA220-C6-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 3
MW4GA220-C6-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 4
MW4GA220-C6-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 5
MW4GA220-C6-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 6
MW4GA220-C6-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 7
MW4GA220-C6-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 8
MW4GA220-C6-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 9
MW4GA220-C6-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 10
MW4GA220-C6-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 11
MW4GA220-C6-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 12
MW4GA220-C6-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 13
MW4GA220-C6-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 14
MW4GA220-C6-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 15
MW4GA220-C6-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 16
MW4GA220-C8-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 2
MW4GA220-C8-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 3
MW4GA220-C8-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 4
MW4GA220-C8-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 5
MW4GA220-C8-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 6
MW4GA220-C8-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 7
MW4GA220-C8-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 8
MW4GA220-C8-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 9
MW4GA220-C8-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 10
MW4GA220-C8-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 11
MW4GA220-C8-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 12
MW4GA220-C8-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 13
MW4GA220-C8-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 14
MW4GA220-C8-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 15
MW4GA220-C8-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 16
MW4GA220-CX-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 2
MW4GA220-CX-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 3
MW4GA220-CX-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 4
MW4GA220-CX-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 5
MW4GA220-CX-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 6
MW4GA220-CX-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 7
MW4GA220-CX-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 8
MW4GA220-CX-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 9
MW4GA220-CX-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 10
MW4GA220-CX-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 11
MW4GA220-CX-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 12
MW4GA220-CX-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 13
MW4GA220-CX-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 14
MW4GA220-CX-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 15
MW4GA220-CX-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 16
MW4GA220-06-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 2
MW4GA220-06-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 3
MW4GA220-06-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 4
MW4GA220-06-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 5
MW4GA220-06-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 6
MW4GA220-06-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 7
MW4GA220-06-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 8
MW4GA220-06-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 9
MW4GA220-06-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 10
MW4GA220-06-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 11
MW4GA220-06-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 12
MW4GA220-06-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 13
MW4GA220-06-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 14
MW4GA220-06-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 15
MW4GA220-06-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 16
MW4GA230-C6-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 2
MW4GA230-C6-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 3
MW4GA230-C6-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 4
MW4GA230-C6-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 5
MW4GA230-C6-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 6
MW4GA230-C6-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 7
MW4GA230-C6-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 8
MW4GA230-C6-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 9
MW4GA230-C6-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 10
MW4GA230-C6-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 11
MW4GA230-C6-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 12
MW4GA230-C6-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 13
MW4GA230-C6-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 14
MW4GA230-C6-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 15
MW4GA230-C6-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 16
MW4GA230-C8-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 2
MW4GA230-C8-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 3
MW4GA230-C8-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 4
MW4GA230-C8-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 5
MW4GA230-C8-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 6
MW4GA230-C8-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 7
MW4GA230-C8-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 8
MW4GA230-C8-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 9
MW4GA230-C8-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 10
MW4GA230-C8-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 11
MW4GA230-C8-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 12
MW4GA230-C8-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 13
MW4GA230-C8-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 14
MW4GA230-C8-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 15
MW4GA230-C8-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 16
MW4GA230-CX-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 2
MW4GA230-CX-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 3
MW4GA230-CX-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 4
MW4GA230-CX-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 5
MW4GA230-CX-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 6
MW4GA230-CX-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 7
MW4GA230-CX-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 8
MW4GA230-CX-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 9
MW4GA230-CX-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 10
MW4GA230-CX-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 11
MW4GA230-CX-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 12
MW4GA230-CX-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 13
MW4GA230-CX-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 14
MW4GA230-CX-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 15
MW4GA230-CX-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 16
MW4GA230-06-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 2
MW4GA230-06-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 3
MW4GA230-06-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 4
MW4GA230-06-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 5
MW4GA230-06-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 6
MW4GA230-06-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 7
MW4GA230-06-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 8
MW4GA230-06-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 9
MW4GA230-06-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 10
MW4GA230-06-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 11
MW4GA230-06-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 12
MW4GA230-06-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 13
MW4GA230-06-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 14
MW4GA230-06-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 15
MW4GA230-06-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 16
MW4GA240-C6-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 2
MW4GA240-C6-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 3
MW4GA240-C6-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 4
MW4GA240-C6-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 5
MW4GA240-C6-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 6
MW4GA240-C6-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 7
MW4GA240-C6-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 8
MW4GA240-C6-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 9
MW4GA240-C6-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 10
MW4GA240-C6-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 11
MW4GA240-C6-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 12
MW4GA240-C6-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 13
MW4GA240-C6-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 14
MW4GA240-C6-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 15
MW4GA240-C6-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 16
MW4GA240-C8-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 2
MW4GA240-C8-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 3
MW4GA240-C8-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 4
MW4GA240-C8-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 5
MW4GA240-C8-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 6
MW4GA240-C8-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 7
MW4GA240-C8-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 8
MW4GA240-C8-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 9
MW4GA240-C8-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 10
MW4GA240-C8-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 11
MW4GA240-C8-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 12
MW4GA240-C8-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 13
MW4GA240-C8-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 14
MW4GA240-C8-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 15
MW4GA240-C8-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 16
MW4GA240-CX-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 2
MW4GA240-CX-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 3
MW4GA240-CX-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 4
MW4GA240-CX-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 5
MW4GA240-CX-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 6
MW4GA240-CX-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 7
MW4GA240-CX-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 8
MW4GA240-CX-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 9
MW4GA240-CX-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 10
MW4GA240-CX-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 11
MW4GA240-CX-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 12
MW4GA240-CX-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 13
MW4GA240-CX-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 14
MW4GA240-CX-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 15
MW4GA240-CX-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 16
MW4GA240-06-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 2
MW4GA240-06-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 3
MW4GA240-06-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 4
MW4GA240-06-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 5
MW4GA240-06-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 6
MW4GA240-06-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 7
MW4GA240-06-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 8
MW4GA240-06-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 9
MW4GA240-06-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 10
MW4GA240-06-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 11
MW4GA240-06-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 12
MW4GA240-06-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 13
MW4GA240-06-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 14
MW4GA240-06-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 15
MW4GA240-06-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 16
MW4GA250-C6-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 2
MW4GA250-C6-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 3
MW4GA250-C6-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 4
MW4GA250-C6-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 5
MW4GA250-C6-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 6
MW4GA250-C6-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 7
MW4GA250-C6-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 8
MW4GA250-C6-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 9
MW4GA250-C6-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 10
MW4GA250-C6-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 11
MW4GA250-C6-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 12
MW4GA250-C6-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 13
MW4GA250-C6-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 14
MW4GA250-C6-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 15
MW4GA250-C6-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 16
MW4GA250-C8-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 2
MW4GA250-C8-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 3
MW4GA250-C8-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 4
MW4GA250-C8-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 5
MW4GA250-C8-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 6
MW4GA250-C8-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 7
MW4GA250-C8-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 8
MW4GA250-C8-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 9
MW4GA250-C8-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 10
MW4GA250-C8-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 11
MW4GA250-C8-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 12
MW4GA250-C8-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 13
MW4GA250-C8-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 14
MW4GA250-C8-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 15
MW4GA250-C8-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 16
MW4GA250-CX-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 2
MW4GA250-CX-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 3
MW4GA250-CX-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 4
MW4GA250-CX-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 5
MW4GA250-CX-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 6
MW4GA250-CX-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 7
MW4GA250-CX-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 8
MW4GA250-CX-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 9
MW4GA250-CX-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 10
MW4GA250-CX-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 11
MW4GA250-CX-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 12
MW4GA250-CX-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 13
MW4GA250-CX-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 14
MW4GA250-CX-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 15
MW4GA250-CX-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 16
MW4GA250-06-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 2
MW4GA250-06-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 3
MW4GA250-06-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 4
MW4GA250-06-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 5
MW4GA250-06-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 6
MW4GA250-06-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 7
MW4GA250-06-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 8
MW4GA250-06-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 9
MW4GA250-06-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 10
MW4GA250-06-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 11
MW4GA250-06-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 12
MW4GA250-06-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 13
MW4GA250-06-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 14
MW4GA250-06-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 15
MW4GA250-06-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 16
MW4GA280-C6-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 2
MW4GA280-C6-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 3
MW4GA280-C6-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 4
MW4GA280-C6-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 5
MW4GA280-C6-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 6
MW4GA280-C6-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 7
MW4GA280-C6-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 8
MW4GA280-C6-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 9
MW4GA280-C6-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 10
MW4GA280-C6-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 11
MW4GA280-C6-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 12
MW4GA280-C6-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 13
MW4GA280-C6-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 14
MW4GA280-C6-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 15
MW4GA280-C6-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 16
MW4GA280-C8-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 2
MW4GA280-C8-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 3
MW4GA280-C8-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 4
MW4GA280-C8-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 5
MW4GA280-C8-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 6
MW4GA280-C8-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 7
MW4GA280-C8-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 8
MW4GA280-C8-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 9
MW4GA280-C8-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 10
MW4GA280-C8-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 11
MW4GA280-C8-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 12
MW4GA280-C8-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 13
MW4GA280-C8-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 14
MW4GA280-C8-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 15
MW4GA280-C8-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 16
MW4GA280-CX-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 2
MW4GA280-CX-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 3
MW4GA280-CX-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 4
MW4GA280-CX-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 5
MW4GA280-CX-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 6
MW4GA280-CX-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 7
MW4GA280-CX-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 8
MW4GA280-CX-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 9
MW4GA280-CX-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 10
MW4GA280-CX-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 11
MW4GA280-CX-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 12
MW4GA280-CX-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 13
MW4GA280-CX-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 14
MW4GA280-CX-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 15
MW4GA280-CX-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 16
MW4GA280-06-R1-2-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 2
MW4GA280-06-R1-3-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 3
MW4GA280-06-R1-4-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 4
MW4GA280-06-R1-5-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 5
MW4GA280-06-R1-6-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 6
MW4GA280-06-R1-7-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 7
MW4GA280-06-R1-8-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 8
MW4GA280-06-R1-9-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 9
MW4GA280-06-R1-10-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 10
MW4GA280-06-R1-11-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 11
MW4GA280-06-R1-12-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 12
MW4GA280-06-R1-13-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 13
MW4GA280-06-R1-14-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 14
MW4GA280-06-R1-15-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 15
MW4GA280-06-R1-16-3-FP1 Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 16
MW3GA210-C6-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 2
MW3GA210-C6-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 3
MW3GA210-C6-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 4
MW3GA210-C6-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 5
MW3GA210-C6-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 6
MW3GA210-C6-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 7
MW3GA210-C6-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 8
MW3GA210-C6-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 9
MW3GA210-C6-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 10
MW3GA210-C6-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 11
MW3GA210-C6-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 12
MW3GA210-C6-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 13
MW3GA210-C6-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 14
MW3GA210-C6-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 15
MW3GA210-C6-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 16
MW3GA210-C8-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 2
MW3GA210-C8-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 3
MW3GA210-C8-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 4
MW3GA210-C8-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 5
MW3GA210-C8-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 6
MW3GA210-C8-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 7
MW3GA210-C8-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 8
MW3GA210-C8-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 9
MW3GA210-C8-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 10
MW3GA210-C8-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 11
MW3GA210-C8-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 12
MW3GA210-C8-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 13
MW3GA210-C8-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 14
MW3GA210-C8-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 15
MW3GA210-C8-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 16
MW3GA210-CX-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 2
MW3GA210-CX-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 3
MW3GA210-CX-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 4
MW3GA210-CX-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 5
MW3GA210-CX-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 6
MW3GA210-CX-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 7
MW3GA210-CX-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 8
MW3GA210-CX-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 9
MW3GA210-CX-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 10
MW3GA210-CX-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 11
MW3GA210-CX-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 12
MW3GA210-CX-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 13
MW3GA210-CX-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 14
MW3GA210-CX-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 15
MW3GA210-CX-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 16
MW3GA210-06-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 2
MW3GA210-06-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 3
MW3GA210-06-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 4
MW3GA210-06-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 5
MW3GA210-06-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 6
MW3GA210-06-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 7
MW3GA210-06-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 8
MW3GA210-06-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 9
MW3GA210-06-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 10
MW3GA210-06-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 11
MW3GA210-06-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 12
MW3GA210-06-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 13
MW3GA210-06-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 14
MW3GA210-06-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 15
MW3GA210-06-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 16
MW3GA2110-C6-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 2
MW3GA2110-C6-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 3
MW3GA2110-C6-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 4
MW3GA2110-C6-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 5
MW3GA2110-C6-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 6
MW3GA2110-C6-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 7
MW3GA2110-C6-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 8
MW3GA2110-C6-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 9
MW3GA2110-C6-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 10
MW3GA2110-C6-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 11
MW3GA2110-C6-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 12
MW3GA2110-C6-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 13
MW3GA2110-C6-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 14
MW3GA2110-C6-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 15
MW3GA2110-C6-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 16
MW3GA2110-C8-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 2
MW3GA2110-C8-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 3
MW3GA2110-C8-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 4
MW3GA2110-C8-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 5
MW3GA2110-C8-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 6
MW3GA2110-C8-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 7
MW3GA2110-C8-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 8
MW3GA2110-C8-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 9
MW3GA2110-C8-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 10
MW3GA2110-C8-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 11
MW3GA2110-C8-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 12
MW3GA2110-C8-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 13
MW3GA2110-C8-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 14
MW3GA2110-C8-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 15
MW3GA2110-C8-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 16
MW3GA2110-CX-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 2
MW3GA2110-CX-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 3
MW3GA2110-CX-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 4
MW3GA2110-CX-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 5
MW3GA2110-CX-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 6
MW3GA2110-CX-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 7
MW3GA2110-CX-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 8
MW3GA2110-CX-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 9
MW3GA2110-CX-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 10
MW3GA2110-CX-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 11
MW3GA2110-CX-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 12
MW3GA2110-CX-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 13
MW3GA2110-CX-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 14
MW3GA2110-CX-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 15
MW3GA2110-CX-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 16
MW3GA2110-06-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 2
MW3GA2110-06-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 3
MW3GA2110-06-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 4
MW3GA2110-06-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 5
MW3GA2110-06-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 6
MW3GA2110-06-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 7
MW3GA2110-06-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 8
MW3GA2110-06-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 9
MW3GA2110-06-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 10
MW3GA2110-06-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 11
MW3GA2110-06-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 12
MW3GA2110-06-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 13
MW3GA2110-06-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 14
MW3GA2110-06-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 15
MW3GA2110-06-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 16
MW3GA280-C6-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 2
MW3GA280-C6-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 3
MW3GA280-C6-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 4
MW3GA280-C6-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 5
MW3GA280-C6-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 6
MW3GA280-C6-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 7
MW3GA280-C6-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 8
MW3GA280-C6-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 9
MW3GA280-C6-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 10
MW3GA280-C6-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 11
MW3GA280-C6-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 12
MW3GA280-C6-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 13
MW3GA280-C6-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 14
MW3GA280-C6-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 15
MW3GA280-C6-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 16
MW3GA280-C8-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 2
MW3GA280-C8-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 3
MW3GA280-C8-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 4
MW3GA280-C8-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 5
MW3GA280-C8-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 6
MW3GA280-C8-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 7
MW3GA280-C8-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 8
MW3GA280-C8-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 9
MW3GA280-C8-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 10
MW3GA280-C8-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 11
MW3GA280-C8-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 12
MW3GA280-C8-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 13
MW3GA280-C8-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 14
MW3GA280-C8-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 15
MW3GA280-C8-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 16
MW3GA280-CX-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 2
MW3GA280-CX-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 3
MW3GA280-CX-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 4
MW3GA280-CX-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 5
MW3GA280-CX-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 6
MW3GA280-CX-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 7
MW3GA280-CX-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 8
MW3GA280-CX-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 9
MW3GA280-CX-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 10
MW3GA280-CX-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 11
MW3GA280-CX-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 12
MW3GA280-CX-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 13
MW3GA280-CX-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 14
MW3GA280-CX-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 15
MW3GA280-CX-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 16
MW3GA280-06-R1-2-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 2
MW3GA280-06-R1-3-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 3
MW3GA280-06-R1-4-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 4
MW3GA280-06-R1-5-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 5
MW3GA280-06-R1-6-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 6
MW3GA280-06-R1-7-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 7
MW3GA280-06-R1-8-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 8
MW3GA280-06-R1-9-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 9
MW3GA280-06-R1-10-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 10
MW3GA280-06-R1-11-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 11
MW3GA280-06-R1-12-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 12
MW3GA280-06-R1-13-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 13
MW3GA280-06-R1-14-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 14
MW3GA280-06-R1-15-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 15
MW3GA280-06-R1-16-3-FP1 Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 16
NW4GA210-C6-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA210-C8-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA210-06-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 2-pos single | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA220-C6-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA220-C8-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA220-06-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 2-pos double | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA230-C6-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA230-C8-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA230-06-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA240-C6-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA240-C8-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA240-06-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA250-C6-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA250-C8-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA250-06-R1-3-FP1 Item: NW4GA2 valve block with valve | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: Block (1 station)
NW3GA210-C6-R1-3-FP1 Item: NW3GA2 valve block with valve | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW3GA210-C8-R1-3-FP1 Item: NW3GA2 valve block with valve | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW3GA210-06-R1-3-FP1 Item: NW3GA2 valve block with valve | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: Block (1 station)
NW3GA2110-C6-R1-3-FP1 Item: NW3GA2 valve block with valve | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW3GA2110-C8-R1-3-FP1 Item: NW3GA2 valve block with valve | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW3GA2110-06-R1-3-FP1 Item: NW3GA2 valve block with valve | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: Block (1 station)
W4GA219-C6-3-FP1 Item: W4GA2 valve for manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: Single valve
W4GA219-C8-3-FP1 Item: W4GA2 valve for manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: Single valve
W4GA219-06-3-FP1 Item: W4GA2 valve for manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: Single valve
W4GA229-C6-3-FP1 Item: W4GA2 valve for manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: Single valve
W4GA229-C8-3-FP1 Item: W4GA2 valve for manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: Single valve
W4GA229-06-3-FP1 Item: W4GA2 valve for manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: Single valve
W4GA239-C6-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: Single valve
W4GA239-C8-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: Single valve
W4GA239-06-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: Single valve
W4GA249-C6-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: Single valve
W4GA249-C8-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: Single valve
W4GA249-06-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: Single valve
W4GA259-C6-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: Single valve
W4GA259-C8-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: Single valve
W4GA259-06-3-FP1 Item: W4GA2 valve for manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: Single valve
W3GA219-C6-3-FP1 Item: W3GA2 valve for manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: Single valve
W3GA219-C8-3-FP1 Item: W3GA2 valve for manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: Single valve
W3GA219-06-3-FP1 Item: W3GA2 valve for manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: Single valve
W3GA2119-C6-3-FP1 Item: W3GA2 valve for manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: Single valve
W3GA2119-C8-3-FP1 Item: W3GA2 valve for manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: Single valve
W3GA2119-06-3-FP1 Item: W3GA2 valve for manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: Single valve
Valve ManifoldsCKD
582 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD MW3GA2/MW4GA2-R1-FP1 Manifold (Food Grade, I/O Connector)

Brand CKD·Valve Manifolds

Available part numbers (582)

MW4GA210-C6-R1-2-3-FP1, MW4GA210-C6-R1-3-3-FP1, MW4GA210-C6-R1-4-3-FP1, MW4GA210-C6-R1-5-3-FP1, MW4GA210-C6-R1-6-3-FP1, MW4GA210-C6-R1-7-3-FP1, MW4GA210-C6-R1-8-3-FP1, MW4GA210-C6-R1-9-3-FP1, MW4GA210-C6-R1-10-3-FP1, MW4GA210-C6-R1-11-3-FP1 + 572 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MW4GA210-C6-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 2
MW4GA210-C6-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 3
MW4GA210-C6-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 4
MW4GA210-C6-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 5
MW4GA210-C6-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 6
MW4GA210-C6-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 7
MW4GA210-C6-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 8
MW4GA210-C6-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 9
MW4GA210-C6-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 10
MW4GA210-C6-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 11
MW4GA210-C6-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 12
MW4GA210-C6-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 13
MW4GA210-C6-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 14
MW4GA210-C6-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 15
MW4GA210-C6-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: 16
MW4GA210-C8-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 2
MW4GA210-C8-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 3
MW4GA210-C8-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 4
MW4GA210-C8-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 5
MW4GA210-C8-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 6
MW4GA210-C8-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 7
MW4GA210-C8-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 8
MW4GA210-C8-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 9
MW4GA210-C8-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 10
MW4GA210-C8-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 11
MW4GA210-C8-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 12
MW4GA210-C8-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 13
MW4GA210-C8-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 14
MW4GA210-C8-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 15
MW4GA210-C8-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: 16
MW4GA210-CX-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 2
MW4GA210-CX-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 3
MW4GA210-CX-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 4
MW4GA210-CX-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 5
MW4GA210-CX-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 6
MW4GA210-CX-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 7
MW4GA210-CX-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 8
MW4GA210-CX-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 9
MW4GA210-CX-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 10
MW4GA210-CX-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 11
MW4GA210-CX-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 12
MW4GA210-CX-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 13
MW4GA210-CX-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 14
MW4GA210-CX-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 15
MW4GA210-CX-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Push-in mix | Stations: 16
MW4GA210-06-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 2
MW4GA210-06-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 3
MW4GA210-06-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 4
MW4GA210-06-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 5
MW4GA210-06-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 6
MW4GA210-06-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 7
MW4GA210-06-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 8
MW4GA210-06-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 9
MW4GA210-06-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 10
MW4GA210-06-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 11
MW4GA210-06-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 12
MW4GA210-06-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 13
MW4GA210-06-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 14
MW4GA210-06-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 15
MW4GA210-06-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: 16
MW4GA220-C6-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 2
MW4GA220-C6-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 3
MW4GA220-C6-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 4
MW4GA220-C6-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 5
MW4GA220-C6-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 6
MW4GA220-C6-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 7
MW4GA220-C6-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 8
MW4GA220-C6-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 9
MW4GA220-C6-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 10
MW4GA220-C6-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 11
MW4GA220-C6-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 12
MW4GA220-C6-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 13
MW4GA220-C6-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 14
MW4GA220-C6-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 15
MW4GA220-C6-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: 16
MW4GA220-C8-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 2
MW4GA220-C8-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 3
MW4GA220-C8-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 4
MW4GA220-C8-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 5
MW4GA220-C8-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 6
MW4GA220-C8-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 7
MW4GA220-C8-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 8
MW4GA220-C8-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 9
MW4GA220-C8-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 10
MW4GA220-C8-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 11
MW4GA220-C8-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 12
MW4GA220-C8-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 13
MW4GA220-C8-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 14
MW4GA220-C8-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 15
MW4GA220-C8-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: 16
MW4GA220-CX-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 2
MW4GA220-CX-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 3
MW4GA220-CX-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 4
MW4GA220-CX-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 5
MW4GA220-CX-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 6
MW4GA220-CX-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 7
MW4GA220-CX-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 8
MW4GA220-CX-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 9
MW4GA220-CX-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 10
MW4GA220-CX-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 11
MW4GA220-CX-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 12
MW4GA220-CX-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 13
MW4GA220-CX-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 14
MW4GA220-CX-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 15
MW4GA220-CX-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Push-in mix | Stations: 16
MW4GA220-06-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 2
MW4GA220-06-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 3
MW4GA220-06-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 4
MW4GA220-06-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 5
MW4GA220-06-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 6
MW4GA220-06-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 7
MW4GA220-06-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 8
MW4GA220-06-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 9
MW4GA220-06-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 10
MW4GA220-06-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 11
MW4GA220-06-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 12
MW4GA220-06-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 13
MW4GA220-06-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 14
MW4GA220-06-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 15
MW4GA220-06-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: 16
MW4GA230-C6-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 2
MW4GA230-C6-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 3
MW4GA230-C6-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 4
MW4GA230-C6-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 5
MW4GA230-C6-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 6
MW4GA230-C6-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 7
MW4GA230-C6-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 8
MW4GA230-C6-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 9
MW4GA230-C6-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 10
MW4GA230-C6-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 11
MW4GA230-C6-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 12
MW4GA230-C6-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 13
MW4GA230-C6-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 14
MW4GA230-C6-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 15
MW4GA230-C6-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: 16
MW4GA230-C8-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 2
MW4GA230-C8-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 3
MW4GA230-C8-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 4
MW4GA230-C8-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 5
MW4GA230-C8-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 6
MW4GA230-C8-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 7
MW4GA230-C8-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 8
MW4GA230-C8-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 9
MW4GA230-C8-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 10
MW4GA230-C8-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 11
MW4GA230-C8-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 12
MW4GA230-C8-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 13
MW4GA230-C8-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 14
MW4GA230-C8-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 15
MW4GA230-C8-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: 16
MW4GA230-CX-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 2
MW4GA230-CX-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 3
MW4GA230-CX-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 4
MW4GA230-CX-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 5
MW4GA230-CX-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 6
MW4GA230-CX-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 7
MW4GA230-CX-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 8
MW4GA230-CX-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 9
MW4GA230-CX-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 10
MW4GA230-CX-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 11
MW4GA230-CX-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 12
MW4GA230-CX-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 13
MW4GA230-CX-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 14
MW4GA230-CX-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 15
MW4GA230-CX-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Push-in mix | Stations: 16
MW4GA230-06-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 2
MW4GA230-06-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 3
MW4GA230-06-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 4
MW4GA230-06-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 5
MW4GA230-06-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 6
MW4GA230-06-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 7
MW4GA230-06-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 8
MW4GA230-06-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 9
MW4GA230-06-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 10
MW4GA230-06-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 11
MW4GA230-06-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 12
MW4GA230-06-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 13
MW4GA230-06-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 14
MW4GA230-06-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 15
MW4GA230-06-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: 16
MW4GA240-C6-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 2
MW4GA240-C6-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 3
MW4GA240-C6-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 4
MW4GA240-C6-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 5
MW4GA240-C6-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 6
MW4GA240-C6-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 7
MW4GA240-C6-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 8
MW4GA240-C6-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 9
MW4GA240-C6-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 10
MW4GA240-C6-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 11
MW4GA240-C6-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 12
MW4GA240-C6-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 13
MW4GA240-C6-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 14
MW4GA240-C6-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 15
MW4GA240-C6-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: 16
MW4GA240-C8-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 2
MW4GA240-C8-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 3
MW4GA240-C8-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 4
MW4GA240-C8-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 5
MW4GA240-C8-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 6
MW4GA240-C8-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 7
MW4GA240-C8-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 8
MW4GA240-C8-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 9
MW4GA240-C8-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 10
MW4GA240-C8-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 11
MW4GA240-C8-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 12
MW4GA240-C8-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 13
MW4GA240-C8-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 14
MW4GA240-C8-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 15
MW4GA240-C8-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: 16
MW4GA240-CX-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 2
MW4GA240-CX-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 3
MW4GA240-CX-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 4
MW4GA240-CX-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 5
MW4GA240-CX-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 6
MW4GA240-CX-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 7
MW4GA240-CX-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 8
MW4GA240-CX-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 9
MW4GA240-CX-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 10
MW4GA240-CX-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 11
MW4GA240-CX-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 12
MW4GA240-CX-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 13
MW4GA240-CX-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 14
MW4GA240-CX-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 15
MW4GA240-CX-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in mix | Stations: 16
MW4GA240-06-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 2
MW4GA240-06-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 3
MW4GA240-06-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 4
MW4GA240-06-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 5
MW4GA240-06-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 6
MW4GA240-06-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 7
MW4GA240-06-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 8
MW4GA240-06-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 9
MW4GA240-06-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 10
MW4GA240-06-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 11
MW4GA240-06-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 12
MW4GA240-06-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 13
MW4GA240-06-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 14
MW4GA240-06-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 15
MW4GA240-06-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: 16
MW4GA250-C6-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 2
MW4GA250-C6-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 3
MW4GA250-C6-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 4
MW4GA250-C6-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 5
MW4GA250-C6-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 6
MW4GA250-C6-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 7
MW4GA250-C6-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 8
MW4GA250-C6-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 9
MW4GA250-C6-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 10
MW4GA250-C6-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 11
MW4GA250-C6-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 12
MW4GA250-C6-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 13
MW4GA250-C6-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 14
MW4GA250-C6-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 15
MW4GA250-C6-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: 16
MW4GA250-C8-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 2
MW4GA250-C8-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 3
MW4GA250-C8-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 4
MW4GA250-C8-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 5
MW4GA250-C8-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 6
MW4GA250-C8-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 7
MW4GA250-C8-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 8
MW4GA250-C8-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 9
MW4GA250-C8-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 10
MW4GA250-C8-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 11
MW4GA250-C8-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 12
MW4GA250-C8-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 13
MW4GA250-C8-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 14
MW4GA250-C8-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 15
MW4GA250-C8-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: 16
MW4GA250-CX-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 2
MW4GA250-CX-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 3
MW4GA250-CX-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 4
MW4GA250-CX-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 5
MW4GA250-CX-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 6
MW4GA250-CX-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 7
MW4GA250-CX-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 8
MW4GA250-CX-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 9
MW4GA250-CX-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 10
MW4GA250-CX-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 11
MW4GA250-CX-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 12
MW4GA250-CX-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 13
MW4GA250-CX-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 14
MW4GA250-CX-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 15
MW4GA250-CX-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in mix | Stations: 16
MW4GA250-06-R1-2-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 2
MW4GA250-06-R1-3-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 3
MW4GA250-06-R1-4-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 4
MW4GA250-06-R1-5-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 5
MW4GA250-06-R1-6-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 6
MW4GA250-06-R1-7-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 7
MW4GA250-06-R1-8-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 8
MW4GA250-06-R1-9-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 9
MW4GA250-06-R1-10-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 10
MW4GA250-06-R1-11-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 11
MW4GA250-06-R1-12-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 12
MW4GA250-06-R1-13-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 13
MW4GA250-06-R1-14-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 14
MW4GA250-06-R1-15-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 15
MW4GA250-06-R1-16-3-FP1Item: MW4GA2 manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: 16
MW4GA280-C6-R1-2-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 2
MW4GA280-C6-R1-3-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 3
MW4GA280-C6-R1-4-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 4
MW4GA280-C6-R1-5-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 5
MW4GA280-C6-R1-6-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 6
MW4GA280-C6-R1-7-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 7
MW4GA280-C6-R1-8-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 8
MW4GA280-C6-R1-9-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 9
MW4GA280-C6-R1-10-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 10
MW4GA280-C6-R1-11-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 11
MW4GA280-C6-R1-12-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 12
MW4GA280-C6-R1-13-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 13
MW4GA280-C6-R1-14-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 14
MW4GA280-C6-R1-15-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 15
MW4GA280-C6-R1-16-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 16
MW4GA280-C8-R1-2-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 2
MW4GA280-C8-R1-3-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 3
MW4GA280-C8-R1-4-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 4
MW4GA280-C8-R1-5-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 5
MW4GA280-C8-R1-6-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 6
MW4GA280-C8-R1-7-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 7
MW4GA280-C8-R1-8-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 8
MW4GA280-C8-R1-9-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 9
MW4GA280-C8-R1-10-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 10
MW4GA280-C8-R1-11-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 11
MW4GA280-C8-R1-12-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 12
MW4GA280-C8-R1-13-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 13
MW4GA280-C8-R1-14-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 14
MW4GA280-C8-R1-15-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 15
MW4GA280-C8-R1-16-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 16
MW4GA280-CX-R1-2-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 2
MW4GA280-CX-R1-3-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 3
MW4GA280-CX-R1-4-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 4
MW4GA280-CX-R1-5-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 5
MW4GA280-CX-R1-6-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 6
MW4GA280-CX-R1-7-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 7
MW4GA280-CX-R1-8-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 8
MW4GA280-CX-R1-9-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 9
MW4GA280-CX-R1-10-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 10
MW4GA280-CX-R1-11-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 11
MW4GA280-CX-R1-12-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 12
MW4GA280-CX-R1-13-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 13
MW4GA280-CX-R1-14-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 14
MW4GA280-CX-R1-15-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 15
MW4GA280-CX-R1-16-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 16
MW4GA280-06-R1-2-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 2
MW4GA280-06-R1-3-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 3
MW4GA280-06-R1-4-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 4
MW4GA280-06-R1-5-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 5
MW4GA280-06-R1-6-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 6
MW4GA280-06-R1-7-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 7
MW4GA280-06-R1-8-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 8
MW4GA280-06-R1-9-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 9
MW4GA280-06-R1-10-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 10
MW4GA280-06-R1-11-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 11
MW4GA280-06-R1-12-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 12
MW4GA280-06-R1-13-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 13
MW4GA280-06-R1-14-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 14
MW4GA280-06-R1-15-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 15
MW4GA280-06-R1-16-3-FP1Item: MW4GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 16
MW3GA210-C6-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 2
MW3GA210-C6-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 3
MW3GA210-C6-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 4
MW3GA210-C6-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 5
MW3GA210-C6-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 6
MW3GA210-C6-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 7
MW3GA210-C6-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 8
MW3GA210-C6-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 9
MW3GA210-C6-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 10
MW3GA210-C6-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 11
MW3GA210-C6-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 12
MW3GA210-C6-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 13
MW3GA210-C6-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 14
MW3GA210-C6-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 15
MW3GA210-C6-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: 16
MW3GA210-C8-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 2
MW3GA210-C8-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 3
MW3GA210-C8-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 4
MW3GA210-C8-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 5
MW3GA210-C8-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 6
MW3GA210-C8-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 7
MW3GA210-C8-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 8
MW3GA210-C8-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 9
MW3GA210-C8-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 10
MW3GA210-C8-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 11
MW3GA210-C8-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 12
MW3GA210-C8-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 13
MW3GA210-C8-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 14
MW3GA210-C8-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 15
MW3GA210-C8-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: 16
MW3GA210-CX-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 2
MW3GA210-CX-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 3
MW3GA210-CX-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 4
MW3GA210-CX-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 5
MW3GA210-CX-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 6
MW3GA210-CX-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 7
MW3GA210-CX-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 8
MW3GA210-CX-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 9
MW3GA210-CX-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 10
MW3GA210-CX-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 11
MW3GA210-CX-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 12
MW3GA210-CX-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 13
MW3GA210-CX-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 14
MW3GA210-CX-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 15
MW3GA210-CX-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Push-in mix | Stations: 16
MW3GA210-06-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 2
MW3GA210-06-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 3
MW3GA210-06-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 4
MW3GA210-06-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 5
MW3GA210-06-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 6
MW3GA210-06-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 7
MW3GA210-06-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 8
MW3GA210-06-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 9
MW3GA210-06-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 10
MW3GA210-06-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 11
MW3GA210-06-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 12
MW3GA210-06-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 13
MW3GA210-06-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 14
MW3GA210-06-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 15
MW3GA210-06-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: 16
MW3GA2110-C6-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 2
MW3GA2110-C6-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 3
MW3GA2110-C6-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 4
MW3GA2110-C6-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 5
MW3GA2110-C6-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 6
MW3GA2110-C6-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 7
MW3GA2110-C6-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 8
MW3GA2110-C6-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 9
MW3GA2110-C6-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 10
MW3GA2110-C6-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 11
MW3GA2110-C6-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 12
MW3GA2110-C6-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 13
MW3GA2110-C6-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 14
MW3GA2110-C6-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 15
MW3GA2110-C6-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: 16
MW3GA2110-C8-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 2
MW3GA2110-C8-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 3
MW3GA2110-C8-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 4
MW3GA2110-C8-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 5
MW3GA2110-C8-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 6
MW3GA2110-C8-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 7
MW3GA2110-C8-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 8
MW3GA2110-C8-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 9
MW3GA2110-C8-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 10
MW3GA2110-C8-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 11
MW3GA2110-C8-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 12
MW3GA2110-C8-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 13
MW3GA2110-C8-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 14
MW3GA2110-C8-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 15
MW3GA2110-C8-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: 16
MW3GA2110-CX-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 2
MW3GA2110-CX-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 3
MW3GA2110-CX-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 4
MW3GA2110-CX-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 5
MW3GA2110-CX-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 6
MW3GA2110-CX-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 7
MW3GA2110-CX-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 8
MW3GA2110-CX-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 9
MW3GA2110-CX-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 10
MW3GA2110-CX-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 11
MW3GA2110-CX-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 12
MW3GA2110-CX-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 13
MW3GA2110-CX-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 14
MW3GA2110-CX-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 15
MW3GA2110-CX-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Push-in mix | Stations: 16
MW3GA2110-06-R1-2-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 2
MW3GA2110-06-R1-3-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 3
MW3GA2110-06-R1-4-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 4
MW3GA2110-06-R1-5-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 5
MW3GA2110-06-R1-6-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 6
MW3GA2110-06-R1-7-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 7
MW3GA2110-06-R1-8-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 8
MW3GA2110-06-R1-9-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 9
MW3GA2110-06-R1-10-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 10
MW3GA2110-06-R1-11-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 11
MW3GA2110-06-R1-12-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 12
MW3GA2110-06-R1-13-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 13
MW3GA2110-06-R1-14-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 14
MW3GA2110-06-R1-15-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 15
MW3GA2110-06-R1-16-3-FP1Item: MW3GA2 manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: 16
MW3GA280-C6-R1-2-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 2
MW3GA280-C6-R1-3-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 3
MW3GA280-C6-R1-4-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 4
MW3GA280-C6-R1-5-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 5
MW3GA280-C6-R1-6-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 6
MW3GA280-C6-R1-7-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 7
MW3GA280-C6-R1-8-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 8
MW3GA280-C6-R1-9-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 9
MW3GA280-C6-R1-10-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 10
MW3GA280-C6-R1-11-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 11
MW3GA280-C6-R1-12-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 12
MW3GA280-C6-R1-13-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 13
MW3GA280-C6-R1-14-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 14
MW3GA280-C6-R1-15-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 15
MW3GA280-C6-R1-16-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 6 mm | Stations: 16
MW3GA280-C8-R1-2-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 2
MW3GA280-C8-R1-3-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 3
MW3GA280-C8-R1-4-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 4
MW3GA280-C8-R1-5-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 5
MW3GA280-C8-R1-6-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 6
MW3GA280-C8-R1-7-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 7
MW3GA280-C8-R1-8-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 8
MW3GA280-C8-R1-9-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 9
MW3GA280-C8-R1-10-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 10
MW3GA280-C8-R1-11-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 11
MW3GA280-C8-R1-12-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 12
MW3GA280-C8-R1-13-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 13
MW3GA280-C8-R1-14-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 14
MW3GA280-C8-R1-15-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 15
MW3GA280-C8-R1-16-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in 8 mm | Stations: 16
MW3GA280-CX-R1-2-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 2
MW3GA280-CX-R1-3-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 3
MW3GA280-CX-R1-4-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 4
MW3GA280-CX-R1-5-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 5
MW3GA280-CX-R1-6-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 6
MW3GA280-CX-R1-7-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 7
MW3GA280-CX-R1-8-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 8
MW3GA280-CX-R1-9-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 9
MW3GA280-CX-R1-10-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 10
MW3GA280-CX-R1-11-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 11
MW3GA280-CX-R1-12-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 12
MW3GA280-CX-R1-13-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 13
MW3GA280-CX-R1-14-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 14
MW3GA280-CX-R1-15-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 15
MW3GA280-CX-R1-16-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Push-in mix | Stations: 16
MW3GA280-06-R1-2-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 2
MW3GA280-06-R1-3-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 3
MW3GA280-06-R1-4-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 4
MW3GA280-06-R1-5-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 5
MW3GA280-06-R1-6-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 6
MW3GA280-06-R1-7-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 7
MW3GA280-06-R1-8-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 8
MW3GA280-06-R1-9-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 9
MW3GA280-06-R1-10-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 10
MW3GA280-06-R1-11-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 11
MW3GA280-06-R1-12-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 12
MW3GA280-06-R1-13-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 13
MW3GA280-06-R1-14-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 14
MW3GA280-06-R1-15-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 15
MW3GA280-06-R1-16-3-FP1Item: MW3GA2 manifold | Switching: Mixed manifold | A/B port: Rc1/8 | Stations: 16
NW4GA210-C6-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA210-C8-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA210-06-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 2-pos single | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA220-C6-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA220-C8-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA220-06-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 2-pos double | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA230-C6-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA230-C8-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA230-06-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA240-C6-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA240-C8-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA240-06-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: Block (1 station)
NW4GA250-C6-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW4GA250-C8-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW4GA250-06-R1-3-FP1Item: NW4GA2 valve block with valve | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: Block (1 station)
NW3GA210-C6-R1-3-FP1Item: NW3GA2 valve block with valve | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW3GA210-C8-R1-3-FP1Item: NW3GA2 valve block with valve | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW3GA210-06-R1-3-FP1Item: NW3GA2 valve block with valve | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: Block (1 station)
NW3GA2110-C6-R1-3-FP1Item: NW3GA2 valve block with valve | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: Block (1 station)
NW3GA2110-C8-R1-3-FP1Item: NW3GA2 valve block with valve | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: Block (1 station)
NW3GA2110-06-R1-3-FP1Item: NW3GA2 valve block with valve | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: Block (1 station)
W4GA219-C6-3-FP1Item: W4GA2 valve for manifold | Switching: 2-pos single | A/B port: Push-in 6 mm | Stations: Single valve
W4GA219-C8-3-FP1Item: W4GA2 valve for manifold | Switching: 2-pos single | A/B port: Push-in 8 mm | Stations: Single valve
W4GA219-06-3-FP1Item: W4GA2 valve for manifold | Switching: 2-pos single | A/B port: Rc1/8 | Stations: Single valve
W4GA229-C6-3-FP1Item: W4GA2 valve for manifold | Switching: 2-pos double | A/B port: Push-in 6 mm | Stations: Single valve
W4GA229-C8-3-FP1Item: W4GA2 valve for manifold | Switching: 2-pos double | A/B port: Push-in 8 mm | Stations: Single valve
W4GA229-06-3-FP1Item: W4GA2 valve for manifold | Switching: 2-pos double | A/B port: Rc1/8 | Stations: Single valve
W4GA239-C6-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 6 mm | Stations: Single valve
W4GA239-C8-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos all ports blocked | A/B port: Push-in 8 mm | Stations: Single valve
W4GA239-06-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos all ports blocked | A/B port: Rc1/8 | Stations: Single valve
W4GA249-C6-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 6 mm | Stations: Single valve
W4GA249-C8-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos A-B-R connection | A/B port: Push-in 8 mm | Stations: Single valve
W4GA249-06-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos A-B-R connection | A/B port: Rc1/8 | Stations: Single valve
W4GA259-C6-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 6 mm | Stations: Single valve
W4GA259-C8-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos P-A-B connection | A/B port: Push-in 8 mm | Stations: Single valve
W4GA259-06-3-FP1Item: W4GA2 valve for manifold | Switching: 3-pos P-A-B connection | A/B port: Rc1/8 | Stations: Single valve
W3GA219-C6-3-FP1Item: W3GA2 valve for manifold | Switching: 2-pos single N.C. | A/B port: Push-in 6 mm | Stations: Single valve
W3GA219-C8-3-FP1Item: W3GA2 valve for manifold | Switching: 2-pos single N.C. | A/B port: Push-in 8 mm | Stations: Single valve
W3GA219-06-3-FP1Item: W3GA2 valve for manifold | Switching: 2-pos single N.C. | A/B port: Rc1/8 | Stations: Single valve
W3GA2119-C6-3-FP1Item: W3GA2 valve for manifold | Switching: 2-pos single N.O. | A/B port: Push-in 6 mm | Stations: Single valve
W3GA2119-C8-3-FP1Item: W3GA2 valve for manifold | Switching: 2-pos single N.O. | A/B port: Push-in 8 mm | Stations: Single valve
W3GA2119-06-3-FP1Item: W3GA2 valve for manifold | Switching: 2-pos single N.O. | A/B port: Rc1/8 | Stations: Single valve

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
