CKD NAB-6X2191/6X2192 Medium-Pressure Cylinder Valve (MTO)

CKD NAB-6X2191 (NC) / NAB-6X2192 (NO) made-to-order air-operated cylinder valves for compressed air up to 1.5 MPa, Rc1/8.

Key features

Air-operated cylinder valve for medium-pressure compressed air up to 1.5 MPa
SUS304 body, FKM valve element
NC (6X2191) or NO (6X2192) type
Pilot port Rc1/8
Made-to-order product

Specifications

Fluid	Compressed air
Operating pressure	0-1.5 MPa
Proof pressure	3.0 MPa
Port	Rc1/8
Orifice	3 mm
Pilot pressure	0.35-0.7 MPa
Source	CKD Korea catalog CB-03-1SK-9, p. 1238-1239

NAB-6X2191		Action: NC (normally closed)
NAB-6X2192		Action: NO (normally open)

Air Operated ValvesCKD

2 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD NAB-6X2191/6X2192 Medium-Pressure Cylinder Valve (MTO)

Brand CKD·Air Operated Valves

Available part numbers (2)

NAB-6X2191, NAB-6X2192

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
