CKD NRB500 Block Manifold Components (Blocks, Fittings, Plugs)

CKD NRB500 Block Manifold Components (Blocks, Fittings, Plugs)

Component blocks, cartridge fittings and plugs for building and extending CKD MNRB500 block manifold regulators.

Key features

  • Central supply blocks NRB500-NP and pressure-switch supply blocks NRB500-APS (lead 1/3/5 m)
  • DIN rail and direct-mount end blocks R and L
  • Regulator blocks NRB500A/B and regulator bodies RB500-00S/M
  • Cartridge push-in fittings for regulator and supply blocks; GWP blank plugs sold per 10
  • DIN rail NRB500-BAA (length in mm) and sub bases NRB500-NS ordered per specification

Specifications

Applicable series MNRB500A / MNRB500B
Max. operating pressure 0.8 MPa
Proof pressure 1.2 MPa
Ambient and fluid temperature 5 to 60 C
Ordering Mixed manifold spec sheet MNRB500-MX
Source CKD Korea catalog CB-024SK-9, p. 468-475
NRB500-NP-SC6 Part: Central supply block | Detail: Straight 6 mm
NRB500-APS-SC6 Part: Supply block with pressure switch | Detail: Straight 6 mm, lead 1 m
NRB500-APS-SC6-3 Part: Supply block with pressure switch | Detail: Straight 6 mm, lead 3 m
NRB500-APS-SC6-5 Part: Supply block with pressure switch | Detail: Straight 6 mm, lead 5 m
NRB500-NP-SC8 Part: Central supply block | Detail: Straight 8 mm
NRB500-APS-SC8 Part: Supply block with pressure switch | Detail: Straight 8 mm, lead 1 m
NRB500-APS-SC8-3 Part: Supply block with pressure switch | Detail: Straight 8 mm, lead 3 m
NRB500-APS-SC8-5 Part: Supply block with pressure switch | Detail: Straight 8 mm, lead 5 m
NRB500-NP-LC6 Part: Central supply block | Detail: Elbow 6 mm
NRB500-APS-LC6 Part: Supply block with pressure switch | Detail: Elbow 6 mm, lead 1 m
NRB500-APS-LC6-3 Part: Supply block with pressure switch | Detail: Elbow 6 mm, lead 3 m
NRB500-APS-LC6-5 Part: Supply block with pressure switch | Detail: Elbow 6 mm, lead 5 m
NRB500-NP-LC8 Part: Central supply block | Detail: Elbow 8 mm
NRB500-APS-LC8 Part: Supply block with pressure switch | Detail: Elbow 8 mm, lead 1 m
NRB500-APS-LC8-3 Part: Supply block with pressure switch | Detail: Elbow 8 mm, lead 3 m
NRB500-APS-LC8-5 Part: Supply block with pressure switch | Detail: Elbow 8 mm, lead 5 m
NRB500-NE Part: End block | Detail: DIN rail end block R
NRB500-NEL Part: End block | Detail: DIN rail end block L
NRB500-NED Part: End block | Detail: Direct end block R
NRB500-NEDL Part: End block | Detail: Direct end block L
NRB500A-SC4 Part: Regulator block (Central supply) | Detail: OUT straight 4
NRB500A-SC6 Part: Regulator block (Central supply) | Detail: OUT straight 6
NRB500A-LC4 Part: Regulator block (Central supply) | Detail: OUT elbow 4
NRB500A-LC6 Part: Regulator block (Central supply) | Detail: OUT elbow 6
NRB500A-SC4U Part: Regulator block (Central supply) | Detail: OUT straight 4, upward
NRB500A-SC6U Part: Regulator block (Central supply) | Detail: OUT straight 6, upward
NRB500B-SSC4 Part: Regulator block (Individual supply) | Detail: IN S / OUT S 4
NRB500B-SSC4U Part: Regulator block (Individual supply) | Detail: IN S / OUT S 4, upward
NRB500B-SSC6 Part: Regulator block (Individual supply) | Detail: IN S / OUT S 6
NRB500B-SSC6U Part: Regulator block (Individual supply) | Detail: IN S / OUT S 6, upward
NRB500B-SLC4 Part: Regulator block (Individual supply) | Detail: IN S / OUT L 4
NRB500B-SLC6 Part: Regulator block (Individual supply) | Detail: IN S / OUT L 6
NRB500B-LSC4 Part: Regulator block (Individual supply) | Detail: IN L / OUT S 4
NRB500B-LSC4U Part: Regulator block (Individual supply) | Detail: IN L / OUT S 4, upward
NRB500B-LSC6 Part: Regulator block (Individual supply) | Detail: IN L / OUT S 6
NRB500B-LSC6U Part: Regulator block (Individual supply) | Detail: IN L / OUT S 6, upward
NRB500B-LLC4 Part: Regulator block (Individual supply) | Detail: IN L / OUT L 4
NRB500B-LLC6 Part: Regulator block (Individual supply) | Detail: IN L / OUT L 6
RB500-00S Part: Regulator body | Detail: Single unit (RB500)
RB500-00M Part: Regulator body | Detail: Manifold (MNRB500A/B)
NRB500-JOINT-C4 Part: Cartridge fitting (regulator block) | Detail: Straight 4 mm
NRB500-JOINT-C6 Part: Cartridge fitting (regulator block) | Detail: Straight 6 mm
NRB500-JOINT-CL4 Part: Cartridge fitting (regulator block) | Detail: Elbow 4 mm
NRB500-JOINT-CL6 Part: Cartridge fitting (regulator block) | Detail: Elbow 6 mm
NRB500-JOINT-CLL4 Part: Cartridge fitting (regulator block) | Detail: Long elbow 4 (manifold) mm
NRB500-JOINT-CLL6 Part: Cartridge fitting (regulator block) | Detail: Long elbow 6 (manifold) mm
NRB500-Q-JOINT-6 Part: Cartridge fitting (supply block) | Detail: Straight 6 mm
NRB500-Q-JOINT-8 Part: Cartridge fitting (supply block) | Detail: Straight 8 mm
NRB500-Q-JOINT-L6 Part: Cartridge fitting (supply block) | Detail: Elbow 6 mm
NRB500-Q-JOINT-L8 Part: Cartridge fitting (supply block) | Detail: Elbow 8 mm
