CKD SCM-D-FP1 Super Micro Cylinder (Double Rod)

CKD SCM-D-FP1 double-acting double-rod super micro cylinder, bore 20-100 mm, with NSF H1 food-grade grease.

Key features

NSF H1 registered food-grade grease used on sliding parts (FP1 food processing specification)
Super micro cylinder with switch magnet built in
Auto switches (T0H/T2H/T3H/T2WH etc.) with count R/H/D/T/4, band mounting Z, bellows J/K/L, switch rail Q, stainless rod M and rod-end I/Y/B1/B2 ordered as suffixes
Intermediate strokes in 1 mm steps; NPT (N) / G (G) port threads made to order
Standard strokes 25-300 mm (max. 600 mm)

Specifications

Fluid	Compressed air
Max. operating pressure	1.0 MPa
Min. operating pressure	0.1 MPa (20-40), 0.05 MPa (50-100)
Proof pressure	1.6 MPa
Ambient temperature	-10 to 60 C
Piston speed	30-1000 mm/s
Type	Double acting, double rod (D)
Source	CKD Korea catalog CC-1271K, p. 64-68

SCM-D-00-20B-25-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-20B-50-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-20B-75-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-20B-100-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-20B-125-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-20B-150-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-20B-200-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-20B-250-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-20B-300-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-20R-25-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-20R-50-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-20R-75-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-20R-100-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-20R-125-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-20R-150-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-20R-200-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-20R-250-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-20R-300-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-20H-25-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-20H-50-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-20H-75-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-20H-100-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-20H-125-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-20H-150-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-20H-200-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-20H-250-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-20H-300-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-20D-25-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-20D-50-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-20D-75-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-20D-100-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-20D-125-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-20D-150-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-20D-200-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-20D-250-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-20D-300-FP1		Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-20B-25-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-20B-50-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-20B-75-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-20B-100-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-20B-125-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-20B-150-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-20B-200-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-20B-250-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-20B-300-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-20R-25-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-20R-50-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-20R-75-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-20R-100-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-20R-125-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-20R-150-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-20R-200-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-20R-250-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-20R-300-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-20H-25-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-20H-50-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-20H-75-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-20H-100-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-20H-125-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-20H-150-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-20H-200-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-20H-250-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-20H-300-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-20D-25-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-20D-50-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-20D-75-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-20D-100-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-20D-125-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-20D-150-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-20D-200-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-20D-250-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-20D-300-FP1		Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-20B-25-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-20B-50-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-20B-75-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-20B-100-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-20B-125-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-20B-150-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-20B-200-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-20B-250-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-20B-300-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-20R-25-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-20R-50-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-20R-75-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-20R-100-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-20R-125-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-20R-150-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-20R-200-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-20R-250-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-20R-300-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-20H-25-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-20H-50-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-20H-75-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-20H-100-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-20H-125-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-20H-150-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-20H-200-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-20H-250-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-20H-300-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-20D-25-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-20D-50-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-20D-75-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-20D-100-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-20D-125-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-20D-150-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-20D-200-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-20D-250-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-20D-300-FP1		Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-TA-20B-25-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-TA-20B-50-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-TA-20B-75-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-TA-20B-100-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-TA-20B-125-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-TA-20B-150-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-TA-20B-200-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-TA-20B-250-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-TA-20B-300-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-TA-20R-25-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-TA-20R-50-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-TA-20R-75-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-TA-20R-100-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-TA-20R-125-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-TA-20R-150-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-TA-20R-200-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-TA-20R-250-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-TA-20R-300-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-TA-20H-25-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-TA-20H-50-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-TA-20H-75-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-TA-20H-100-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-TA-20H-125-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-TA-20H-150-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-TA-20H-200-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-TA-20H-250-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-TA-20H-300-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-TA-20D-25-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-TA-20D-50-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-TA-20D-75-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-TA-20D-100-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-TA-20D-125-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-TA-20D-150-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-TA-20D-200-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-TA-20D-250-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-TA-20D-300-FP1		Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-00-25B-25-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-25B-50-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-25B-75-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-25B-100-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-25B-125-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-25B-150-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-25B-200-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-25B-250-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-25B-300-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-25R-25-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-25R-50-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-25R-75-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-25R-100-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-25R-125-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-25R-150-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-25R-200-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-25R-250-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-25R-300-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-25H-25-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-25H-50-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-25H-75-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-25H-100-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-25H-125-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-25H-150-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-25H-200-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-25H-250-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-25H-300-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-25D-25-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-25D-50-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-25D-75-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-25D-100-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-25D-125-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-25D-150-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-25D-200-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-25D-250-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-25D-300-FP1		Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-25B-25-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-25B-50-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-25B-75-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-25B-100-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-25B-125-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-25B-150-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-25B-200-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-25B-250-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-25B-300-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-25R-25-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-25R-50-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-25R-75-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-25R-100-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-25R-125-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-25R-150-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-25R-200-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-25R-250-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-25R-300-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-25H-25-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-25H-50-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-25H-75-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-25H-100-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-25H-125-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-25H-150-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-25H-200-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-25H-250-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-25H-300-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-25D-25-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-25D-50-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-25D-75-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-25D-100-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-25D-125-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-25D-150-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-25D-200-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-25D-250-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-25D-300-FP1		Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-25B-25-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-25B-50-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-25B-75-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-25B-100-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-25B-125-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-25B-150-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-25B-200-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-25B-250-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-25B-300-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-25R-25-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-25R-50-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-25R-75-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-25R-100-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-25R-125-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-25R-150-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-25R-200-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-25R-250-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-25R-300-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-25H-25-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-25H-50-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-25H-75-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-25H-100-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-25H-125-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-25H-150-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-25H-200-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-25H-250-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-25H-300-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-25D-25-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-25D-50-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-25D-75-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-25D-100-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-25D-125-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-25D-150-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-25D-200-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-25D-250-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-25D-300-FP1		Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-TA-25B-25-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-TA-25B-50-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-TA-25B-75-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-TA-25B-100-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-TA-25B-125-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-TA-25B-150-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-TA-25B-200-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-TA-25B-250-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-TA-25B-300-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-TA-25R-25-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-TA-25R-50-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-TA-25R-75-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-TA-25R-100-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-TA-25R-125-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-TA-25R-150-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-TA-25R-200-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-TA-25R-250-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-TA-25R-300-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-TA-25H-25-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-TA-25H-50-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-TA-25H-75-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-TA-25H-100-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-TA-25H-125-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-TA-25H-150-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-TA-25H-200-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-TA-25H-250-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-TA-25H-300-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-TA-25D-25-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-TA-25D-50-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-TA-25D-75-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-TA-25D-100-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-TA-25D-125-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-TA-25D-150-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-TA-25D-200-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-TA-25D-250-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-TA-25D-300-FP1		Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-00-32B-25-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-32B-50-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-32B-75-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-32B-100-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-32B-125-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-32B-150-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-32B-200-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-32B-250-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-32B-300-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-32R-25-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-32R-50-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-32R-75-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-32R-100-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-32R-125-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-32R-150-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-32R-200-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-32R-250-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-32R-300-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-32H-25-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-32H-50-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-32H-75-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-32H-100-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-32H-125-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-32H-150-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-32H-200-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-32H-250-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-32H-300-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-32D-25-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-32D-50-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-32D-75-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-32D-100-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-32D-125-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-32D-150-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-32D-200-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-32D-250-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-32D-300-FP1		Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-32B-25-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-32B-50-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-32B-75-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-32B-100-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-32B-125-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-32B-150-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-32B-200-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-32B-250-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-32B-300-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-32R-25-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-32R-50-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-32R-75-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-32R-100-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-32R-125-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-32R-150-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-32R-200-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-32R-250-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-32R-300-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-32H-25-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-32H-50-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-32H-75-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-32H-100-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-32H-125-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-32H-150-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-32H-200-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-32H-250-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-32H-300-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-32D-25-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-32D-50-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-32D-75-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-32D-100-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-32D-125-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-32D-150-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-32D-200-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-32D-250-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-32D-300-FP1		Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-32B-25-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-32B-50-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-32B-75-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-32B-100-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-32B-125-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-32B-150-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-32B-200-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-32B-250-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-32B-300-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-32R-25-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-32R-50-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-32R-75-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-32R-100-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-32R-125-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-32R-150-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-32R-200-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-32R-250-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-32R-300-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-32H-25-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-32H-50-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-32H-75-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-32H-100-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-32H-125-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-32H-150-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-32H-200-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-32H-250-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-32H-300-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-32D-25-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-32D-50-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-32D-75-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-32D-100-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-32D-125-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-32D-150-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-32D-200-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-32D-250-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-32D-300-FP1		Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-TA-32B-25-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-TA-32B-50-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-TA-32B-75-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-TA-32B-100-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-TA-32B-125-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-TA-32B-150-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-TA-32B-200-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-TA-32B-250-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-TA-32B-300-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-TA-32R-25-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-TA-32R-50-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-TA-32R-75-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-TA-32R-100-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-TA-32R-125-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-TA-32R-150-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-TA-32R-200-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-TA-32R-250-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-TA-32R-300-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-TA-32H-25-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-TA-32H-50-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-TA-32H-75-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-TA-32H-100-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-TA-32H-125-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-TA-32H-150-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-TA-32H-200-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-TA-32H-250-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-TA-32H-300-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-TA-32D-25-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-TA-32D-50-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-TA-32D-75-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-TA-32D-100-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-TA-32D-125-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-TA-32D-150-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-TA-32D-200-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-TA-32D-250-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-TA-32D-300-FP1		Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-00-40B-25-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-40B-50-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-40B-75-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-40B-100-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-40B-125-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-40B-150-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-40B-200-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-40B-250-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-40B-300-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-40R-25-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-40R-50-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-40R-75-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-40R-100-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-40R-125-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-40R-150-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-40R-200-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-40R-250-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-40R-300-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-40H-25-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-40H-50-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-40H-75-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-40H-100-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-40H-125-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-40H-150-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-40H-200-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-40H-250-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-40H-300-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-40D-25-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-40D-50-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-40D-75-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-40D-100-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-40D-125-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-40D-150-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-40D-200-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-40D-250-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-40D-300-FP1		Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-40B-25-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-40B-50-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-40B-75-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-40B-100-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-40B-125-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-40B-150-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-40B-200-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-40B-250-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-40B-300-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-40R-25-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-40R-50-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-40R-75-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-40R-100-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-40R-125-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-40R-150-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-40R-200-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-40R-250-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-40R-300-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-40H-25-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-40H-50-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-40H-75-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-40H-100-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-40H-125-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-40H-150-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-40H-200-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-40H-250-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-40H-300-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-40D-25-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-40D-50-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-40D-75-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-40D-100-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-40D-125-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-40D-150-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-40D-200-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-40D-250-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-40D-300-FP1		Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-40B-25-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-40B-50-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-40B-75-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-40B-100-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-40B-125-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-40B-150-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-40B-200-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-40B-250-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-40B-300-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-40R-25-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-40R-50-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-40R-75-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-40R-100-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-40R-125-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-40R-150-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-40R-200-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-40R-250-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-40R-300-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-40H-25-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-40H-50-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-40H-75-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-40H-100-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-40H-125-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-40H-150-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-40H-200-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-40H-250-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-40H-300-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-40D-25-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-40D-50-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-40D-75-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-40D-100-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-40D-125-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-40D-150-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-40D-200-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-40D-250-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-40D-300-FP1		Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-TA-40B-25-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-TA-40B-50-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-TA-40B-75-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-TA-40B-100-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-TA-40B-125-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-TA-40B-150-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-TA-40B-200-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-TA-40B-250-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-TA-40B-300-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-TA-40R-25-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-TA-40R-50-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-TA-40R-75-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-TA-40R-100-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-TA-40R-125-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-TA-40R-150-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-TA-40R-200-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-TA-40R-250-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-TA-40R-300-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-TA-40H-25-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-TA-40H-50-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-TA-40H-75-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-TA-40H-100-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-TA-40H-125-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-TA-40H-150-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-TA-40H-200-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-TA-40H-250-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-TA-40H-300-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-TA-40D-25-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-TA-40D-50-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-TA-40D-75-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-TA-40D-100-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-TA-40D-125-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-TA-40D-150-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-TA-40D-200-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-TA-40D-250-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-TA-40D-300-FP1		Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-00-50B-25-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-50B-50-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-50B-75-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-50B-100-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-50B-125-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-50B-150-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-50B-200-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-50B-250-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-50B-300-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-50R-25-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-50R-50-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-50R-75-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-50R-100-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-50R-125-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-50R-150-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-50R-200-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-50R-250-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-50R-300-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-50H-25-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-50H-50-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-50H-75-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-50H-100-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-50H-125-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-50H-150-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-50H-200-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-50H-250-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-50H-300-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-50D-25-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-50D-50-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-50D-75-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-50D-100-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-50D-125-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-50D-150-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-50D-200-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-50D-250-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-50D-300-FP1		Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-50B-25-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-50B-50-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-50B-75-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-50B-100-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-50B-125-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-50B-150-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-50B-200-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-50B-250-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-50B-300-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-50R-25-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-50R-50-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-50R-75-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-50R-100-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-50R-125-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-50R-150-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-50R-200-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-50R-250-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-50R-300-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-50H-25-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-50H-50-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-50H-75-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-50H-100-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-50H-125-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-50H-150-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-50H-200-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-50H-250-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-50H-300-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-50D-25-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-50D-50-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-50D-75-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-50D-100-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-50D-125-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-50D-150-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-50D-200-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-50D-250-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-50D-300-FP1		Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-50B-25-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-50B-50-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-50B-75-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-50B-100-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-50B-125-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-50B-150-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-50B-200-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-50B-250-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-50B-300-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-50R-25-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-50R-50-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-50R-75-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-50R-100-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-50R-125-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-50R-150-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-50R-200-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-50R-250-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-50R-300-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-50H-25-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-50H-50-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-50H-75-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-50H-100-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-50H-125-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-50H-150-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-50H-200-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-50H-250-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-50H-300-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-50D-25-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-50D-50-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-50D-75-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-50D-100-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-50D-125-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-50D-150-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-50D-200-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-50D-250-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-50D-300-FP1		Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-TA-50B-25-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-TA-50B-50-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-TA-50B-75-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-TA-50B-100-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-TA-50B-125-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-TA-50B-150-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-TA-50B-200-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-TA-50B-250-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-TA-50B-300-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-TA-50R-25-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-TA-50R-50-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-TA-50R-75-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-TA-50R-100-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-TA-50R-125-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-TA-50R-150-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-TA-50R-200-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-TA-50R-250-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-TA-50R-300-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-TA-50H-25-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-TA-50H-50-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-TA-50H-75-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-TA-50H-100-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-TA-50H-125-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-TA-50H-150-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-TA-50H-200-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-TA-50H-250-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-TA-50H-300-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-TA-50D-25-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-TA-50D-50-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-TA-50D-75-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-TA-50D-100-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-TA-50D-125-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-TA-50D-150-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-TA-50D-200-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-TA-50D-250-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-TA-50D-300-FP1		Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-00-63B-25-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-63B-50-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-63B-75-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-63B-100-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-63B-125-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-63B-150-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-63B-200-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-63B-250-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-63B-300-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-63R-25-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-63R-50-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-63R-75-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-63R-100-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-63R-125-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-63R-150-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-63R-200-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-63R-250-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-63R-300-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-63H-25-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-63H-50-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-63H-75-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-63H-100-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-63H-125-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-63H-150-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-63H-200-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-63H-250-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-63H-300-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-63D-25-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-63D-50-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-63D-75-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-63D-100-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-63D-125-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-63D-150-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-63D-200-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-63D-250-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-63D-300-FP1		Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-63B-25-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-63B-50-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-63B-75-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-63B-100-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-63B-125-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-63B-150-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-63B-200-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-63B-250-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-63B-300-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-63R-25-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-63R-50-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-63R-75-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-63R-100-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-63R-125-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-63R-150-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-63R-200-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-63R-250-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-63R-300-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-63H-25-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-63H-50-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-63H-75-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-63H-100-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-63H-125-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-63H-150-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-63H-200-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-63H-250-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-63H-300-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-63D-25-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-63D-50-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-63D-75-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-63D-100-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-63D-125-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-63D-150-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-63D-200-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-63D-250-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-63D-300-FP1		Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-63B-25-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-63B-50-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-63B-75-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-63B-100-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-63B-125-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-63B-150-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-63B-200-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-63B-250-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-63B-300-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-63R-25-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-63R-50-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-63R-75-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-63R-100-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-63R-125-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-63R-150-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-63R-200-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-63R-250-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-63R-300-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-63H-25-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-63H-50-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-63H-75-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-63H-100-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-63H-125-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-63H-150-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-63H-200-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-63H-250-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-63H-300-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-63D-25-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-63D-50-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-63D-75-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-63D-100-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-63D-125-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-63D-150-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-63D-200-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-63D-250-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-63D-300-FP1		Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-TA-63B-25-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-TA-63B-50-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-TA-63B-75-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-TA-63B-100-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-TA-63B-125-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-TA-63B-150-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-TA-63B-200-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-TA-63B-250-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-TA-63B-300-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-TA-63R-25-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-TA-63R-50-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-TA-63R-75-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-TA-63R-100-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-TA-63R-125-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-TA-63R-150-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-TA-63R-200-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-TA-63R-250-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-TA-63R-300-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-TA-63H-25-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-TA-63H-50-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-TA-63H-75-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-TA-63H-100-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-TA-63H-125-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-TA-63H-150-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-TA-63H-200-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-TA-63H-250-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-TA-63H-300-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-TA-63D-25-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-TA-63D-50-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-TA-63D-75-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-TA-63D-100-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-TA-63D-125-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-TA-63D-150-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-TA-63D-200-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-TA-63D-250-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-TA-63D-300-FP1		Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-00-80B-25-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-80B-50-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-80B-75-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-80B-100-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-80B-125-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-80B-150-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-80B-200-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-80B-250-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-80B-300-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-80R-25-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-80R-50-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-80R-75-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-80R-100-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-80R-125-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-80R-150-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-80R-200-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-80R-250-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-80R-300-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-80H-25-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-80H-50-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-80H-75-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-80H-100-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-80H-125-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-80H-150-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-80H-200-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-80H-250-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-80H-300-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-80D-25-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-80D-50-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-80D-75-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-80D-100-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-80D-125-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-80D-150-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-80D-200-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-80D-250-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-80D-300-FP1		Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-80B-25-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-80B-50-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-80B-75-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-80B-100-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-80B-125-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-80B-150-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-80B-200-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-80B-250-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-80B-300-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-80R-25-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-80R-50-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-80R-75-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-80R-100-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-80R-125-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-80R-150-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-80R-200-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-80R-250-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-80R-300-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-80H-25-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-80H-50-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-80H-75-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-80H-100-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-80H-125-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-80H-150-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-80H-200-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-80H-250-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-80H-300-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-80D-25-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-80D-50-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-80D-75-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-80D-100-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-80D-125-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-80D-150-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-80D-200-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-80D-250-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-80D-300-FP1		Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-80B-25-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-80B-50-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-80B-75-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-80B-100-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-80B-125-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-80B-150-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-80B-200-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-80B-250-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-80B-300-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-80R-25-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-80R-50-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-80R-75-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-80R-100-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-80R-125-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-80R-150-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-80R-200-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-80R-250-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-80R-300-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-80H-25-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-80H-50-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-80H-75-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-80H-100-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-80H-125-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-80H-150-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-80H-200-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-80H-250-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-80H-300-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-80D-25-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-80D-50-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-80D-75-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-80D-100-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-80D-125-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-80D-150-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-80D-200-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-80D-250-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-80D-300-FP1		Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-00-100B-25-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-00-100B-50-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-00-100B-75-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-00-100B-100-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-00-100B-125-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-00-100B-150-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-00-100B-200-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-00-100B-250-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-00-100B-300-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-00-100R-25-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-00-100R-50-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-00-100R-75-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-00-100R-100-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-00-100R-125-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-00-100R-150-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-00-100R-200-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-00-100R-250-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-00-100R-300-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-00-100H-25-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-00-100H-50-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-00-100H-75-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-00-100H-100-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-00-100H-125-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-00-100H-150-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-00-100H-200-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-00-100H-250-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-00-100H-300-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-00-100D-25-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-00-100D-50-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-00-100D-75-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-00-100D-100-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-00-100D-125-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-00-100D-150-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-00-100D-200-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-00-100D-250-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-00-100D-300-FP1		Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-LB-100B-25-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-LB-100B-50-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-LB-100B-75-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-LB-100B-100-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-LB-100B-125-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-LB-100B-150-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-LB-100B-200-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-LB-100B-250-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-LB-100B-300-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-LB-100R-25-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-LB-100R-50-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-LB-100R-75-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-LB-100R-100-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-LB-100R-125-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-LB-100R-150-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-LB-100R-200-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-LB-100R-250-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-LB-100R-300-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-LB-100H-25-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-LB-100H-50-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-LB-100H-75-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-LB-100H-100-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-LB-100H-125-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-LB-100H-150-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-LB-100H-200-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-LB-100H-250-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-LB-100H-300-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-LB-100D-25-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-LB-100D-50-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-LB-100D-75-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-LB-100D-100-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-LB-100D-125-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-LB-100D-150-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-LB-100D-200-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-LB-100D-250-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-LB-100D-300-FP1		Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
SCM-D-FA-100B-25-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 25 mm
SCM-D-FA-100B-50-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 50 mm
SCM-D-FA-100B-75-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 75 mm
SCM-D-FA-100B-100-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 100 mm
SCM-D-FA-100B-125-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 125 mm
SCM-D-FA-100B-150-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 150 mm
SCM-D-FA-100B-200-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 200 mm
SCM-D-FA-100B-250-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 250 mm
SCM-D-FA-100B-300-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 300 mm
SCM-D-FA-100R-25-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 25 mm
SCM-D-FA-100R-50-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 50 mm
SCM-D-FA-100R-75-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 75 mm
SCM-D-FA-100R-100-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 100 mm
SCM-D-FA-100R-125-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 125 mm
SCM-D-FA-100R-150-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 150 mm
SCM-D-FA-100R-200-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 200 mm
SCM-D-FA-100R-250-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 250 mm
SCM-D-FA-100R-300-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 300 mm
SCM-D-FA-100H-25-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 25 mm
SCM-D-FA-100H-50-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 50 mm
SCM-D-FA-100H-75-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 75 mm
SCM-D-FA-100H-100-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 100 mm
SCM-D-FA-100H-125-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 125 mm
SCM-D-FA-100H-150-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 150 mm
SCM-D-FA-100H-200-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 200 mm
SCM-D-FA-100H-250-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 250 mm
SCM-D-FA-100H-300-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 300 mm
SCM-D-FA-100D-25-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
SCM-D-FA-100D-50-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
SCM-D-FA-100D-75-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
SCM-D-FA-100D-100-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
SCM-D-FA-100D-125-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
SCM-D-FA-100D-150-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
SCM-D-FA-100D-200-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
SCM-D-FA-100D-250-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
SCM-D-FA-100D-300-FP1		Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm

Pneumatic CylindersCKD

1080 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD SCM-D-FP1 Super Micro Cylinder (Double Rod)

Brand CKD·Pneumatic Cylinders

Available part numbers (1080)

SCM-D-00-20B-25-FP1, SCM-D-00-20B-50-FP1, SCM-D-00-20B-75-FP1, SCM-D-00-20B-100-FP1, SCM-D-00-20B-125-FP1, SCM-D-00-20B-150-FP1, SCM-D-00-20B-200-FP1, SCM-D-00-20B-250-FP1, SCM-D-00-20B-300-FP1, SCM-D-00-20R-25-FP1 + 1070 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	SCM-D-00-20B-25-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-20B-50-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-20B-75-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-20B-100-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-20B-125-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-20B-150-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-20B-200-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-20B-250-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-20B-300-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-20R-25-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-20R-50-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-20R-75-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-20R-100-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-20R-125-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-20R-150-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-20R-200-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-20R-250-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-20R-300-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-20H-25-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-20H-50-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-20H-75-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-20H-100-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-20H-125-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-20H-150-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-20H-200-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-20H-250-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-20H-300-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-20D-25-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-20D-50-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-20D-75-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-20D-100-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-20D-125-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-20D-150-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-20D-200-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-20D-250-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-20D-300-FP1	Mounting: Basic \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-20B-25-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-20B-50-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-20B-75-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-20B-100-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-20B-125-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-20B-150-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-20B-200-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-20B-250-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-20B-300-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-20R-25-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-20R-50-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-20R-75-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-20R-100-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-20R-125-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-20R-150-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-20R-200-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-20R-250-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-20R-300-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-20H-25-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-20H-50-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-20H-75-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-20H-100-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-20H-125-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-20H-150-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-20H-200-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-20H-250-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-20H-300-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-20D-25-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-20D-50-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-20D-75-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-20D-100-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-20D-125-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-20D-150-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-20D-200-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-20D-250-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-20D-300-FP1	Mounting: Axial foot \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-20B-25-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-20B-50-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-20B-75-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-20B-100-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-20B-125-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-20B-150-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-20B-200-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-20B-250-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-20B-300-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-20R-25-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-20R-50-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-20R-75-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-20R-100-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-20R-125-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-20R-150-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-20R-200-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-20R-250-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-20R-300-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-20H-25-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-20H-50-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-20H-75-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-20H-100-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-20H-125-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-20H-150-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-20H-200-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-20H-250-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-20H-300-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-20D-25-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-20D-50-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-20D-75-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-20D-100-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-20D-125-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-20D-150-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-20D-200-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-20D-250-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-20D-300-FP1	Mounting: Rod-side flange \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-TA-20B-25-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-TA-20B-50-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-TA-20B-75-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-TA-20B-100-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-TA-20B-125-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-TA-20B-150-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-TA-20B-200-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-TA-20B-250-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-TA-20B-300-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-TA-20R-25-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-TA-20R-50-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-TA-20R-75-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-TA-20R-100-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-TA-20R-125-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-TA-20R-150-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-TA-20R-200-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-TA-20R-250-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-TA-20R-300-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-TA-20H-25-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-TA-20H-50-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-TA-20H-75-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-TA-20H-100-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-TA-20H-125-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-TA-20H-150-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-TA-20H-200-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-TA-20H-250-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-TA-20H-300-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-TA-20D-25-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-TA-20D-50-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-TA-20D-75-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-TA-20D-100-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-TA-20D-125-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-TA-20D-150-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-TA-20D-200-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-TA-20D-250-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-TA-20D-300-FP1	Mounting: Rod-side trunnion \| Bore: 20 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-00-25B-25-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-25B-50-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-25B-75-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-25B-100-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-25B-125-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-25B-150-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-25B-200-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-25B-250-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-25B-300-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-25R-25-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-25R-50-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-25R-75-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-25R-100-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-25R-125-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-25R-150-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-25R-200-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-25R-250-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-25R-300-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-25H-25-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-25H-50-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-25H-75-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-25H-100-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-25H-125-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-25H-150-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-25H-200-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-25H-250-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-25H-300-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-25D-25-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-25D-50-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-25D-75-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-25D-100-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-25D-125-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-25D-150-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-25D-200-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-25D-250-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-25D-300-FP1	Mounting: Basic \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-25B-25-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-25B-50-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-25B-75-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-25B-100-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-25B-125-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-25B-150-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-25B-200-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-25B-250-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-25B-300-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-25R-25-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-25R-50-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-25R-75-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-25R-100-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-25R-125-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-25R-150-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-25R-200-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-25R-250-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-25R-300-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-25H-25-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-25H-50-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-25H-75-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-25H-100-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-25H-125-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-25H-150-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-25H-200-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-25H-250-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-25H-300-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-25D-25-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-25D-50-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-25D-75-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-25D-100-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-25D-125-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-25D-150-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-25D-200-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-25D-250-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-25D-300-FP1	Mounting: Axial foot \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-25B-25-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-25B-50-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-25B-75-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-25B-100-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-25B-125-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-25B-150-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-25B-200-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-25B-250-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-25B-300-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-25R-25-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-25R-50-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-25R-75-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-25R-100-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-25R-125-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-25R-150-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-25R-200-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-25R-250-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-25R-300-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-25H-25-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-25H-50-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-25H-75-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-25H-100-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-25H-125-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-25H-150-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-25H-200-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-25H-250-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-25H-300-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-25D-25-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-25D-50-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-25D-75-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-25D-100-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-25D-125-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-25D-150-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-25D-200-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-25D-250-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-25D-300-FP1	Mounting: Rod-side flange \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-TA-25B-25-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-TA-25B-50-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-TA-25B-75-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-TA-25B-100-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-TA-25B-125-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-TA-25B-150-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-TA-25B-200-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-TA-25B-250-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-TA-25B-300-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-TA-25R-25-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-TA-25R-50-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-TA-25R-75-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-TA-25R-100-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-TA-25R-125-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-TA-25R-150-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-TA-25R-200-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-TA-25R-250-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-TA-25R-300-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-TA-25H-25-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-TA-25H-50-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-TA-25H-75-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-TA-25H-100-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-TA-25H-125-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-TA-25H-150-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-TA-25H-200-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-TA-25H-250-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-TA-25H-300-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-TA-25D-25-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-TA-25D-50-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-TA-25D-75-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-TA-25D-100-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-TA-25D-125-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-TA-25D-150-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-TA-25D-200-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-TA-25D-250-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-TA-25D-300-FP1	Mounting: Rod-side trunnion \| Bore: 25 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-00-32B-25-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-32B-50-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-32B-75-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-32B-100-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-32B-125-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-32B-150-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-32B-200-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-32B-250-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-32B-300-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-32R-25-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-32R-50-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-32R-75-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-32R-100-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-32R-125-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-32R-150-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-32R-200-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-32R-250-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-32R-300-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-32H-25-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-32H-50-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-32H-75-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-32H-100-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-32H-125-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-32H-150-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-32H-200-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-32H-250-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-32H-300-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-32D-25-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-32D-50-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-32D-75-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-32D-100-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-32D-125-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-32D-150-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-32D-200-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-32D-250-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-32D-300-FP1	Mounting: Basic \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-32B-25-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-32B-50-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-32B-75-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-32B-100-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-32B-125-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-32B-150-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-32B-200-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-32B-250-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-32B-300-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-32R-25-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-32R-50-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-32R-75-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-32R-100-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-32R-125-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-32R-150-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-32R-200-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-32R-250-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-32R-300-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-32H-25-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-32H-50-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-32H-75-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-32H-100-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-32H-125-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-32H-150-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-32H-200-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-32H-250-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-32H-300-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-32D-25-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-32D-50-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-32D-75-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-32D-100-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-32D-125-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-32D-150-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-32D-200-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-32D-250-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-32D-300-FP1	Mounting: Axial foot \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-32B-25-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-32B-50-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-32B-75-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-32B-100-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-32B-125-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-32B-150-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-32B-200-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-32B-250-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-32B-300-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-32R-25-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-32R-50-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-32R-75-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-32R-100-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-32R-125-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-32R-150-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-32R-200-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-32R-250-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-32R-300-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-32H-25-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-32H-50-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-32H-75-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-32H-100-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-32H-125-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-32H-150-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-32H-200-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-32H-250-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-32H-300-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-32D-25-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-32D-50-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-32D-75-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-32D-100-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-32D-125-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-32D-150-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-32D-200-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-32D-250-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-32D-300-FP1	Mounting: Rod-side flange \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-TA-32B-25-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-TA-32B-50-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-TA-32B-75-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-TA-32B-100-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-TA-32B-125-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-TA-32B-150-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-TA-32B-200-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-TA-32B-250-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-TA-32B-300-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-TA-32R-25-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-TA-32R-50-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-TA-32R-75-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-TA-32R-100-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-TA-32R-125-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-TA-32R-150-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-TA-32R-200-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-TA-32R-250-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-TA-32R-300-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-TA-32H-25-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-TA-32H-50-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-TA-32H-75-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-TA-32H-100-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-TA-32H-125-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-TA-32H-150-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-TA-32H-200-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-TA-32H-250-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-TA-32H-300-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-TA-32D-25-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-TA-32D-50-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-TA-32D-75-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-TA-32D-100-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-TA-32D-125-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-TA-32D-150-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-TA-32D-200-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-TA-32D-250-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-TA-32D-300-FP1	Mounting: Rod-side trunnion \| Bore: 32 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-00-40B-25-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-40B-50-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-40B-75-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-40B-100-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-40B-125-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-40B-150-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-40B-200-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-40B-250-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-40B-300-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-40R-25-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-40R-50-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-40R-75-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-40R-100-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-40R-125-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-40R-150-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-40R-200-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-40R-250-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-40R-300-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-40H-25-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-40H-50-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-40H-75-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-40H-100-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-40H-125-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-40H-150-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-40H-200-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-40H-250-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-40H-300-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-40D-25-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-40D-50-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-40D-75-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-40D-100-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-40D-125-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-40D-150-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-40D-200-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-40D-250-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-40D-300-FP1	Mounting: Basic \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-40B-25-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-40B-50-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-40B-75-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-40B-100-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-40B-125-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-40B-150-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-40B-200-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-40B-250-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-40B-300-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-40R-25-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-40R-50-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-40R-75-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-40R-100-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-40R-125-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-40R-150-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-40R-200-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-40R-250-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-40R-300-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-40H-25-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-40H-50-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-40H-75-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-40H-100-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-40H-125-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-40H-150-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-40H-200-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-40H-250-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-40H-300-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-40D-25-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-40D-50-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-40D-75-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-40D-100-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-40D-125-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-40D-150-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-40D-200-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-40D-250-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-40D-300-FP1	Mounting: Axial foot \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-40B-25-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-40B-50-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-40B-75-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-40B-100-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-40B-125-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-40B-150-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-40B-200-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-40B-250-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-40B-300-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-40R-25-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-40R-50-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-40R-75-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-40R-100-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-40R-125-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-40R-150-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-40R-200-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-40R-250-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-40R-300-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-40H-25-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-40H-50-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-40H-75-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-40H-100-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-40H-125-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-40H-150-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-40H-200-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-40H-250-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-40H-300-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-40D-25-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-40D-50-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-40D-75-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-40D-100-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-40D-125-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-40D-150-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-40D-200-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-40D-250-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-40D-300-FP1	Mounting: Rod-side flange \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-TA-40B-25-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-TA-40B-50-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-TA-40B-75-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-TA-40B-100-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-TA-40B-125-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-TA-40B-150-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-TA-40B-200-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-TA-40B-250-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-TA-40B-300-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-TA-40R-25-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-TA-40R-50-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-TA-40R-75-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-TA-40R-100-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-TA-40R-125-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-TA-40R-150-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-TA-40R-200-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-TA-40R-250-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-TA-40R-300-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-TA-40H-25-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-TA-40H-50-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-TA-40H-75-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-TA-40H-100-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-TA-40H-125-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-TA-40H-150-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-TA-40H-200-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-TA-40H-250-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-TA-40H-300-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-TA-40D-25-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-TA-40D-50-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-TA-40D-75-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-TA-40D-100-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-TA-40D-125-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-TA-40D-150-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-TA-40D-200-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-TA-40D-250-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-TA-40D-300-FP1	Mounting: Rod-side trunnion \| Bore: 40 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-00-50B-25-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-50B-50-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-50B-75-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-50B-100-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-50B-125-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-50B-150-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-50B-200-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-50B-250-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-50B-300-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-50R-25-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-50R-50-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-50R-75-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-50R-100-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-50R-125-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-50R-150-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-50R-200-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-50R-250-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-50R-300-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-50H-25-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-50H-50-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-50H-75-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-50H-100-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-50H-125-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-50H-150-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-50H-200-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-50H-250-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-50H-300-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-50D-25-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-50D-50-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-50D-75-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-50D-100-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-50D-125-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-50D-150-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-50D-200-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-50D-250-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-50D-300-FP1	Mounting: Basic \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-50B-25-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-50B-50-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-50B-75-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-50B-100-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-50B-125-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-50B-150-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-50B-200-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-50B-250-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-50B-300-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-50R-25-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-50R-50-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-50R-75-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-50R-100-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-50R-125-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-50R-150-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-50R-200-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-50R-250-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-50R-300-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-50H-25-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-50H-50-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-50H-75-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-50H-100-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-50H-125-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-50H-150-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-50H-200-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-50H-250-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-50H-300-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-50D-25-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-50D-50-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-50D-75-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-50D-100-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-50D-125-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-50D-150-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-50D-200-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-50D-250-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-50D-300-FP1	Mounting: Axial foot \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-50B-25-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-50B-50-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-50B-75-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-50B-100-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-50B-125-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-50B-150-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-50B-200-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-50B-250-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-50B-300-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-50R-25-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-50R-50-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-50R-75-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-50R-100-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-50R-125-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-50R-150-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-50R-200-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-50R-250-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-50R-300-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-50H-25-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-50H-50-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-50H-75-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-50H-100-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-50H-125-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-50H-150-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-50H-200-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-50H-250-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-50H-300-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-50D-25-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-50D-50-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-50D-75-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-50D-100-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-50D-125-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-50D-150-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-50D-200-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-50D-250-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-50D-300-FP1	Mounting: Rod-side flange \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-TA-50B-25-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-TA-50B-50-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-TA-50B-75-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-TA-50B-100-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-TA-50B-125-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-TA-50B-150-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-TA-50B-200-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-TA-50B-250-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-TA-50B-300-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-TA-50R-25-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-TA-50R-50-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-TA-50R-75-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-TA-50R-100-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-TA-50R-125-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-TA-50R-150-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-TA-50R-200-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-TA-50R-250-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-TA-50R-300-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-TA-50H-25-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-TA-50H-50-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-TA-50H-75-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-TA-50H-100-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-TA-50H-125-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-TA-50H-150-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-TA-50H-200-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-TA-50H-250-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-TA-50H-300-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-TA-50D-25-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-TA-50D-50-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-TA-50D-75-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-TA-50D-100-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-TA-50D-125-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-TA-50D-150-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-TA-50D-200-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-TA-50D-250-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-TA-50D-300-FP1	Mounting: Rod-side trunnion \| Bore: 50 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-00-63B-25-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-63B-50-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-63B-75-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-63B-100-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-63B-125-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-63B-150-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-63B-200-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-63B-250-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-63B-300-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-63R-25-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-63R-50-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-63R-75-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-63R-100-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-63R-125-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-63R-150-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-63R-200-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-63R-250-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-63R-300-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-63H-25-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-63H-50-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-63H-75-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-63H-100-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-63H-125-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-63H-150-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-63H-200-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-63H-250-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-63H-300-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-63D-25-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-63D-50-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-63D-75-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-63D-100-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-63D-125-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-63D-150-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-63D-200-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-63D-250-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-63D-300-FP1	Mounting: Basic \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-63B-25-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-63B-50-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-63B-75-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-63B-100-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-63B-125-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-63B-150-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-63B-200-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-63B-250-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-63B-300-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-63R-25-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-63R-50-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-63R-75-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-63R-100-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-63R-125-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-63R-150-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-63R-200-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-63R-250-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-63R-300-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-63H-25-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-63H-50-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-63H-75-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-63H-100-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-63H-125-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-63H-150-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-63H-200-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-63H-250-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-63H-300-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-63D-25-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-63D-50-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-63D-75-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-63D-100-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-63D-125-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-63D-150-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-63D-200-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-63D-250-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-63D-300-FP1	Mounting: Axial foot \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-63B-25-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-63B-50-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-63B-75-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-63B-100-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-63B-125-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-63B-150-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-63B-200-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-63B-250-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-63B-300-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-63R-25-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-63R-50-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-63R-75-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-63R-100-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-63R-125-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-63R-150-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-63R-200-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-63R-250-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-63R-300-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-63H-25-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-63H-50-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-63H-75-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-63H-100-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-63H-125-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-63H-150-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-63H-200-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-63H-250-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-63H-300-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-63D-25-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-63D-50-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-63D-75-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-63D-100-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-63D-125-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-63D-150-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-63D-200-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-63D-250-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-63D-300-FP1	Mounting: Rod-side flange \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-TA-63B-25-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-TA-63B-50-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-TA-63B-75-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-TA-63B-100-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-TA-63B-125-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-TA-63B-150-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-TA-63B-200-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-TA-63B-250-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-TA-63B-300-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-TA-63R-25-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-TA-63R-50-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-TA-63R-75-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-TA-63R-100-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-TA-63R-125-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-TA-63R-150-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-TA-63R-200-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-TA-63R-250-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-TA-63R-300-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-TA-63H-25-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-TA-63H-50-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-TA-63H-75-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-TA-63H-100-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-TA-63H-125-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-TA-63H-150-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-TA-63H-200-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-TA-63H-250-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-TA-63H-300-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-TA-63D-25-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-TA-63D-50-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-TA-63D-75-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-TA-63D-100-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-TA-63D-125-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-TA-63D-150-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-TA-63D-200-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-TA-63D-250-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-TA-63D-300-FP1	Mounting: Rod-side trunnion \| Bore: 63 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-00-80B-25-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-80B-50-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-80B-75-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-80B-100-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-80B-125-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-80B-150-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-80B-200-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-80B-250-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-80B-300-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-80R-25-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-80R-50-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-80R-75-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-80R-100-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-80R-125-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-80R-150-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-80R-200-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-80R-250-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-80R-300-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-80H-25-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-80H-50-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-80H-75-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-80H-100-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-80H-125-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-80H-150-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-80H-200-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-80H-250-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-80H-300-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-80D-25-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-80D-50-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-80D-75-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-80D-100-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-80D-125-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-80D-150-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-80D-200-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-80D-250-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-80D-300-FP1	Mounting: Basic \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-80B-25-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-80B-50-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-80B-75-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-80B-100-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-80B-125-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-80B-150-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-80B-200-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-80B-250-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-80B-300-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-80R-25-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-80R-50-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-80R-75-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-80R-100-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-80R-125-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-80R-150-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-80R-200-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-80R-250-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-80R-300-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-80H-25-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-80H-50-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-80H-75-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-80H-100-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-80H-125-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-80H-150-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-80H-200-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-80H-250-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-80H-300-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-80D-25-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-80D-50-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-80D-75-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-80D-100-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-80D-125-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-80D-150-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-80D-200-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-80D-250-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-80D-300-FP1	Mounting: Axial foot \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-80B-25-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-80B-50-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-80B-75-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-80B-100-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-80B-125-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-80B-150-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-80B-200-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-80B-250-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-80B-300-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-80R-25-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-80R-50-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-80R-75-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-80R-100-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-80R-125-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-80R-150-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-80R-200-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-80R-250-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-80R-300-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-80H-25-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-80H-50-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-80H-75-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-80H-100-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-80H-125-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-80H-150-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-80H-200-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-80H-250-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-80H-300-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-80D-25-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-80D-50-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-80D-75-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-80D-100-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-80D-125-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-80D-150-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-80D-200-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-80D-250-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-80D-300-FP1	Mounting: Rod-side flange \| Bore: 80 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-00-100B-25-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-00-100B-50-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-00-100B-75-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-00-100B-100-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-00-100B-125-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-00-100B-150-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-00-100B-200-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-00-100B-250-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-00-100B-300-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-00-100R-25-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-00-100R-50-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-00-100R-75-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-00-100R-100-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-00-100R-125-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-00-100R-150-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-00-100R-200-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-00-100R-250-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-00-100R-300-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-00-100H-25-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-00-100H-50-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-00-100H-75-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-00-100H-100-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-00-100H-125-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-00-100H-150-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-00-100H-200-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-00-100H-250-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-00-100H-300-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-00-100D-25-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-00-100D-50-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-00-100D-75-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-00-100D-100-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-00-100D-125-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-00-100D-150-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-00-100D-200-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-00-100D-250-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-00-100D-300-FP1	Mounting: Basic \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-LB-100B-25-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-LB-100B-50-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-LB-100B-75-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-LB-100B-100-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-LB-100B-125-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-LB-100B-150-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-LB-100B-200-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-LB-100B-250-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-LB-100B-300-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-LB-100R-25-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-LB-100R-50-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-LB-100R-75-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-LB-100R-100-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-LB-100R-125-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-LB-100R-150-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-LB-100R-200-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-LB-100R-250-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-LB-100R-300-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-LB-100H-25-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-LB-100H-50-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-LB-100H-75-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-LB-100H-100-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-LB-100H-125-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-LB-100H-150-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-LB-100H-200-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-LB-100H-250-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-LB-100H-300-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-LB-100D-25-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-LB-100D-50-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-LB-100D-75-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-LB-100D-100-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-LB-100D-125-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-LB-100D-150-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-LB-100D-200-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-LB-100D-250-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-LB-100D-300-FP1	Mounting: Axial foot \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm
	SCM-D-FA-100B-25-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 25 mm
	SCM-D-FA-100B-50-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 50 mm
	SCM-D-FA-100B-75-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 75 mm
	SCM-D-FA-100B-100-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 100 mm
	SCM-D-FA-100B-125-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 125 mm
	SCM-D-FA-100B-150-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 150 mm
	SCM-D-FA-100B-200-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 200 mm
	SCM-D-FA-100B-250-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 250 mm
	SCM-D-FA-100B-300-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, both ends \| Stroke: 300 mm
	SCM-D-FA-100R-25-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 25 mm
	SCM-D-FA-100R-50-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 50 mm
	SCM-D-FA-100R-75-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 75 mm
	SCM-D-FA-100R-100-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 100 mm
	SCM-D-FA-100R-125-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 125 mm
	SCM-D-FA-100R-150-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 150 mm
	SCM-D-FA-100R-200-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 200 mm
	SCM-D-FA-100R-250-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 250 mm
	SCM-D-FA-100R-300-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, rod end \| Stroke: 300 mm
	SCM-D-FA-100H-25-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 25 mm
	SCM-D-FA-100H-50-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 50 mm
	SCM-D-FA-100H-75-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 75 mm
	SCM-D-FA-100H-100-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 100 mm
	SCM-D-FA-100H-125-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 125 mm
	SCM-D-FA-100H-150-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 150 mm
	SCM-D-FA-100H-200-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 200 mm
	SCM-D-FA-100H-250-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 250 mm
	SCM-D-FA-100H-300-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Air, head end \| Stroke: 300 mm
	SCM-D-FA-100D-25-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 25 mm
	SCM-D-FA-100D-50-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 50 mm
	SCM-D-FA-100D-75-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 75 mm
	SCM-D-FA-100D-100-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 100 mm
	SCM-D-FA-100D-125-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 125 mm
	SCM-D-FA-100D-150-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 150 mm
	SCM-D-FA-100D-200-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 200 mm
	SCM-D-FA-100D-250-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 250 mm
	SCM-D-FA-100D-300-FP1	Mounting: Rod-side flange \| Bore: 100 mm \| Cushion: Rubber, both ends \| Stroke: 300 mm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

CKD SCM-D-FP1 Super Micro Cylinder (Double Rod)
