CKD SCM-D Super Micro Cylinder, Double Rod (Bore 20-100)

CKD SCM-D super micro double-acting double-rod cylinder, bore 20 to 100 mm, with air or rubber cushion.

Key features

Double-rod (through-rod) construction with equal thrust both directions
Cushion: air both ends (B), rod end (R), head end (H) or rubber both ends (D)
Mountings 00, LB, FA (all bores) and TA (ø20-63)
Standard strokes 25 to 300 mm; 1 mm intermediate strokes up to 600 mm to order
Auto switch ready (built-in magnet); T0/T5/T8 reed and T1/T2/T3/T2W/T2Y/T2YD/T2J solid-state switches, rail or band (Z) mounting, ordered as suffix
Options J/L (bellows), Q, M (stainless rod), P6; rod-end accessories I/Y and bracket B2 as suffix

Specifications

Action	Double acting, double rod
Fluid	Compressed air
Max. operating pressure	1.0 MPa
Min. operating pressure	0.15 MPa (ø20-40), 0.1 MPa (ø50-100)
Proof pressure	1.6 MPa
Ambient temperature	-10 to 60°C (no freezing)
Piston speed	30 to 1000 mm/s
Lubrication	Not required
Source	CKD Korea catalog CB-029SK-9, p. 396-403

SCM-D-00-20B-25		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-00-20B-50		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-00-20B-75		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-00-20B-100		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-00-20B-125		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-00-20B-150		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-00-20B-200		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-00-20B-250		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-00-20B-300		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-00-20R-25		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-00-20R-50		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-00-20R-75		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-00-20R-100		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-00-20R-125		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-00-20R-150		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-00-20R-200		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-00-20R-250		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-00-20R-300		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-00-20H-25		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-00-20H-50		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-00-20H-75		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-00-20H-100		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-00-20H-125		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-00-20H-150		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-00-20H-200		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-00-20H-250		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-00-20H-300		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-00-20D-25		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-20D-50		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-20D-75		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-20D-100		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-20D-125		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-20D-150		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-20D-200		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-20D-250		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-20D-300		Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-20B-25		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-LB-20B-50		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-LB-20B-75		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-LB-20B-100		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-LB-20B-125		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-LB-20B-150		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-LB-20B-200		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-LB-20B-250		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-LB-20B-300		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-LB-20R-25		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-LB-20R-50		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-LB-20R-75		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-LB-20R-100		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-LB-20R-125		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-LB-20R-150		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-LB-20R-200		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-LB-20R-250		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-LB-20R-300		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-LB-20H-25		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-LB-20H-50		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-LB-20H-75		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-LB-20H-100		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-LB-20H-125		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-LB-20H-150		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-LB-20H-200		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-LB-20H-250		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-LB-20H-300		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-LB-20D-25		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-20D-50		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-20D-75		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-20D-100		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-20D-125		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-20D-150		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-20D-200		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-20D-250		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-20D-300		Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-20B-25		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-FA-20B-50		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-FA-20B-75		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-FA-20B-100		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-FA-20B-125		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-FA-20B-150		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-FA-20B-200		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-FA-20B-250		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-FA-20B-300		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-FA-20R-25		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-FA-20R-50		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-FA-20R-75		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-FA-20R-100		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-FA-20R-125		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-FA-20R-150		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-FA-20R-200		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-FA-20R-250		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-FA-20R-300		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-FA-20H-25		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-FA-20H-50		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-FA-20H-75		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-FA-20H-100		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-FA-20H-125		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-FA-20H-150		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-FA-20H-200		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-FA-20H-250		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-FA-20H-300		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-FA-20D-25		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-20D-50		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-20D-75		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-20D-100		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-20D-125		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-20D-150		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-20D-200		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-20D-250		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-20D-300		Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-20B-25		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-TA-20B-50		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-TA-20B-75		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-TA-20B-100		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-TA-20B-125		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-TA-20B-150		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-TA-20B-200		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-TA-20B-250		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-TA-20B-300		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-TA-20R-25		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-TA-20R-50		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-TA-20R-75		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-TA-20R-100		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-TA-20R-125		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-TA-20R-150		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-TA-20R-200		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-TA-20R-250		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-TA-20R-300		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-TA-20H-25		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-TA-20H-50		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-TA-20H-75		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-TA-20H-100		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-TA-20H-125		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-TA-20H-150		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-TA-20H-200		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-TA-20H-250		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-TA-20H-300		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-TA-20D-25		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-20D-50		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-20D-75		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-20D-100		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-20D-125		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-20D-150		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-20D-200		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-20D-250		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-20D-300		Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-25B-25		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-00-25B-50		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-00-25B-75		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-00-25B-100		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-00-25B-125		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-00-25B-150		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-00-25B-200		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-00-25B-250		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-00-25B-300		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-00-25R-25		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-00-25R-50		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-00-25R-75		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-00-25R-100		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-00-25R-125		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-00-25R-150		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-00-25R-200		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-00-25R-250		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-00-25R-300		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-00-25H-25		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-00-25H-50		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-00-25H-75		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-00-25H-100		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-00-25H-125		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-00-25H-150		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-00-25H-200		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-00-25H-250		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-00-25H-300		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-00-25D-25		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-25D-50		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-25D-75		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-25D-100		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-25D-125		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-25D-150		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-25D-200		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-25D-250		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-25D-300		Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-25B-25		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-LB-25B-50		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-LB-25B-75		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-LB-25B-100		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-LB-25B-125		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-LB-25B-150		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-LB-25B-200		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-LB-25B-250		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-LB-25B-300		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-LB-25R-25		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-LB-25R-50		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-LB-25R-75		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-LB-25R-100		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-LB-25R-125		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-LB-25R-150		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-LB-25R-200		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-LB-25R-250		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-LB-25R-300		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-LB-25H-25		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-LB-25H-50		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-LB-25H-75		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-LB-25H-100		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-LB-25H-125		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-LB-25H-150		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-LB-25H-200		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-LB-25H-250		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-LB-25H-300		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-LB-25D-25		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-25D-50		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-25D-75		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-25D-100		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-25D-125		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-25D-150		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-25D-200		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-25D-250		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-25D-300		Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-25B-25		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-FA-25B-50		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-FA-25B-75		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-FA-25B-100		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-FA-25B-125		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-FA-25B-150		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-FA-25B-200		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-FA-25B-250		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-FA-25B-300		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-FA-25R-25		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-FA-25R-50		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-FA-25R-75		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-FA-25R-100		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-FA-25R-125		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-FA-25R-150		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-FA-25R-200		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-FA-25R-250		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-FA-25R-300		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-FA-25H-25		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-FA-25H-50		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-FA-25H-75		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-FA-25H-100		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-FA-25H-125		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-FA-25H-150		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-FA-25H-200		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-FA-25H-250		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-FA-25H-300		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-FA-25D-25		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-25D-50		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-25D-75		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-25D-100		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-25D-125		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-25D-150		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-25D-200		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-25D-250		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-25D-300		Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-25B-25		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
SCM-D-TA-25B-50		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
SCM-D-TA-25B-75		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
SCM-D-TA-25B-100		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
SCM-D-TA-25B-125		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
SCM-D-TA-25B-150		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
SCM-D-TA-25B-200		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
SCM-D-TA-25B-250		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
SCM-D-TA-25B-300		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
SCM-D-TA-25R-25		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
SCM-D-TA-25R-50		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
SCM-D-TA-25R-75		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
SCM-D-TA-25R-100		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
SCM-D-TA-25R-125		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
SCM-D-TA-25R-150		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
SCM-D-TA-25R-200		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
SCM-D-TA-25R-250		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
SCM-D-TA-25R-300		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
SCM-D-TA-25H-25		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
SCM-D-TA-25H-50		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
SCM-D-TA-25H-75		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
SCM-D-TA-25H-100		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
SCM-D-TA-25H-125		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
SCM-D-TA-25H-150		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
SCM-D-TA-25H-200		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
SCM-D-TA-25H-250		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
SCM-D-TA-25H-300		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
SCM-D-TA-25D-25		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-25D-50		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-25D-75		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-25D-100		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-25D-125		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-25D-150		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-25D-200		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-25D-250		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-25D-300		Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-32B-25		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-32B-50		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-32B-75		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-32B-100		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-32B-125		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-32B-150		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-32B-200		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-32B-250		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-32B-300		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-32R-25		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-32R-50		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-32R-75		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-32R-100		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-32R-125		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-32R-150		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-32R-200		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-32R-250		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-32R-300		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-32H-25		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-32H-50		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-32H-75		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-32H-100		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-32H-125		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-32H-150		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-32H-200		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-32H-250		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-32H-300		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-32D-25		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-32D-50		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-32D-75		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-32D-100		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-32D-125		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-32D-150		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-32D-200		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-32D-250		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-32D-300		Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-32B-25		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-32B-50		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-32B-75		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-32B-100		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-32B-125		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-32B-150		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-32B-200		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-32B-250		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-32B-300		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-32R-25		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-32R-50		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-32R-75		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-32R-100		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-32R-125		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-32R-150		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-32R-200		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-32R-250		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-32R-300		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-32H-25		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-32H-50		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-32H-75		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-32H-100		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-32H-125		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-32H-150		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-32H-200		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-32H-250		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-32H-300		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-32D-25		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-32D-50		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-32D-75		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-32D-100		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-32D-125		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-32D-150		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-32D-200		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-32D-250		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-32D-300		Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-32B-25		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-32B-50		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-32B-75		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-32B-100		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-32B-125		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-32B-150		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-32B-200		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-32B-250		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-32B-300		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-32R-25		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-32R-50		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-32R-75		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-32R-100		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-32R-125		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-32R-150		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-32R-200		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-32R-250		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-32R-300		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-32H-25		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-32H-50		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-32H-75		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-32H-100		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-32H-125		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-32H-150		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-32H-200		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-32H-250		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-32H-300		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-32D-25		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-32D-50		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-32D-75		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-32D-100		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-32D-125		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-32D-150		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-32D-200		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-32D-250		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-32D-300		Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-32B-25		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-32B-50		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-32B-75		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-32B-100		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-32B-125		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-32B-150		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-32B-200		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-32B-250		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-32B-300		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-32R-25		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-32R-50		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-32R-75		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-32R-100		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-32R-125		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-32R-150		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-32R-200		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-32R-250		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-32R-300		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-32H-25		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-32H-50		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-32H-75		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-32H-100		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-32H-125		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-32H-150		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-32H-200		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-32H-250		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-32H-300		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-32D-25		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-32D-50		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-32D-75		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-32D-100		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-32D-125		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-32D-150		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-32D-200		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-32D-250		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-32D-300		Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-40B-25		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-40B-50		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-40B-75		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-40B-100		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-40B-125		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-40B-150		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-40B-200		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-40B-250		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-40B-300		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-40R-25		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-40R-50		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-40R-75		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-40R-100		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-40R-125		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-40R-150		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-40R-200		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-40R-250		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-40R-300		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-40H-25		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-40H-50		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-40H-75		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-40H-100		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-40H-125		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-40H-150		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-40H-200		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-40H-250		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-40H-300		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-40D-25		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-00-40D-50		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-00-40D-75		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-00-40D-100		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-00-40D-125		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-00-40D-150		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-00-40D-200		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-00-40D-250		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-00-40D-300		Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-40B-25		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-40B-50		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-40B-75		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-40B-100		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-40B-125		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-40B-150		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-40B-200		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-40B-250		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-40B-300		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-40R-25		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-40R-50		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-40R-75		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-40R-100		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-40R-125		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-40R-150		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-40R-200		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-40R-250		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-40R-300		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-40H-25		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-40H-50		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-40H-75		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-40H-100		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-40H-125		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-40H-150		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-40H-200		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-40H-250		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-40H-300		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-LB-40D-25		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-LB-40D-50		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-LB-40D-75		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-LB-40D-100		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-LB-40D-125		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-LB-40D-150		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-LB-40D-200		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-LB-40D-250		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-LB-40D-300		Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-40B-25		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-40B-50		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-40B-75		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-40B-100		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-40B-125		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-40B-150		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-40B-200		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-40B-250		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-40B-300		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-40R-25		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-40R-50		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-40R-75		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-40R-100		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-40R-125		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-40R-150		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-40R-200		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-40R-250		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-40R-300		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-40H-25		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-40H-50		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-40H-75		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-40H-100		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-40H-125		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-40H-150		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-40H-200		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-40H-250		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-40H-300		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-FA-40D-25		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-FA-40D-50		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-FA-40D-75		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-FA-40D-100		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-FA-40D-125		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-FA-40D-150		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-FA-40D-200		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-FA-40D-250		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-FA-40D-300		Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-40B-25		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-40B-50		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-40B-75		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-40B-100		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-40B-125		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-40B-150		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-40B-200		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-40B-250		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-40B-300		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-40R-25		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-40R-50		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-40R-75		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-40R-100		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-40R-125		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-40R-150		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-40R-200		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-40R-250		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-40R-300		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-40H-25		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-40H-50		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-40H-75		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-40H-100		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-40H-125		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-40H-150		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-40H-200		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-40H-250		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-40H-300		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-TA-40D-25		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
SCM-D-TA-40D-50		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
SCM-D-TA-40D-75		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
SCM-D-TA-40D-100		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
SCM-D-TA-40D-125		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
SCM-D-TA-40D-150		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
SCM-D-TA-40D-200		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
SCM-D-TA-40D-250		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
SCM-D-TA-40D-300		Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
SCM-D-00-50B-25		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-50B-50		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-50B-75		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-50B-100		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-50B-125		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-50B-150		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-50B-200		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-50B-250		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-50B-300		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-50R-25		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-50R-50		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-50R-75		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-50R-100		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-50R-125		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-50R-150		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-50R-200		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-50R-250		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-50R-300		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-50H-25		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-50H-50		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-50H-75		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-50H-100		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-50H-125		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-50H-150		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-50H-200		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-50H-250		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-50H-300		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-50D-25		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-50D-50		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-50D-75		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-50D-100		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-50D-125		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-50D-150		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-50D-200		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-50D-250		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-50D-300		Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-50B-25		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-50B-50		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-50B-75		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-50B-100		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-50B-125		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-50B-150		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-50B-200		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-50B-250		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-50B-300		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-50R-25		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-50R-50		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-50R-75		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-50R-100		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-50R-125		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-50R-150		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-50R-200		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-50R-250		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-50R-300		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-50H-25		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-50H-50		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-50H-75		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-50H-100		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-50H-125		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-50H-150		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-50H-200		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-50H-250		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-50H-300		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-50D-25		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-50D-50		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-50D-75		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-50D-100		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-50D-125		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-50D-150		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-50D-200		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-50D-250		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-50D-300		Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-50B-25		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-50B-50		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-50B-75		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-50B-100		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-50B-125		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-50B-150		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-50B-200		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-50B-250		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-50B-300		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-50R-25		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-50R-50		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-50R-75		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-50R-100		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-50R-125		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-50R-150		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-50R-200		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-50R-250		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-50R-300		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-50H-25		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-50H-50		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-50H-75		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-50H-100		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-50H-125		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-50H-150		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-50H-200		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-50H-250		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-50H-300		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-50D-25		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-50D-50		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-50D-75		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-50D-100		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-50D-125		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-50D-150		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-50D-200		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-50D-250		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-50D-300		Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-50B-25		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-50B-50		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-50B-75		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-50B-100		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-50B-125		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-50B-150		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-50B-200		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-50B-250		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-50B-300		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-50R-25		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-50R-50		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-50R-75		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-50R-100		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-50R-125		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-50R-150		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-50R-200		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-50R-250		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-50R-300		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-50H-25		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-50H-50		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-50H-75		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-50H-100		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-50H-125		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-50H-150		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-50H-200		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-50H-250		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-50H-300		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-50D-25		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-50D-50		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-50D-75		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-50D-100		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-50D-125		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-50D-150		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-50D-200		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-50D-250		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-50D-300		Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-63B-25		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-63B-50		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-63B-75		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-63B-100		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-63B-125		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-63B-150		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-63B-200		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-63B-250		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-63B-300		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-63R-25		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-63R-50		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-63R-75		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-63R-100		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-63R-125		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-63R-150		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-63R-200		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-63R-250		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-63R-300		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-63H-25		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-63H-50		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-63H-75		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-63H-100		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-63H-125		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-63H-150		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-63H-200		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-63H-250		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-63H-300		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-63D-25		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-00-63D-50		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-00-63D-75		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-00-63D-100		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-00-63D-125		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-00-63D-150		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-00-63D-200		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-00-63D-250		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-00-63D-300		Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-63B-25		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-63B-50		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-63B-75		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-63B-100		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-63B-125		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-63B-150		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-63B-200		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-63B-250		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-63B-300		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-63R-25		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-63R-50		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-63R-75		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-63R-100		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-63R-125		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-63R-150		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-63R-200		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-63R-250		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-63R-300		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-63H-25		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-63H-50		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-63H-75		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-63H-100		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-63H-125		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-63H-150		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-63H-200		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-63H-250		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-63H-300		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-LB-63D-25		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-LB-63D-50		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-LB-63D-75		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-LB-63D-100		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-LB-63D-125		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-LB-63D-150		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-LB-63D-200		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-LB-63D-250		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-LB-63D-300		Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-63B-25		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-63B-50		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-63B-75		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-63B-100		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-63B-125		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-63B-150		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-63B-200		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-63B-250		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-63B-300		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-63R-25		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-63R-50		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-63R-75		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-63R-100		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-63R-125		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-63R-150		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-63R-200		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-63R-250		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-63R-300		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-63H-25		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-63H-50		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-63H-75		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-63H-100		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-63H-125		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-63H-150		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-63H-200		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-63H-250		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-63H-300		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-FA-63D-25		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-FA-63D-50		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-FA-63D-75		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-FA-63D-100		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-FA-63D-125		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-FA-63D-150		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-FA-63D-200		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-FA-63D-250		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-FA-63D-300		Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-63B-25		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-63B-50		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-63B-75		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-63B-100		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-63B-125		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-63B-150		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-63B-200		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-63B-250		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-63B-300		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-63R-25		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-63R-50		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-63R-75		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-63R-100		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-63R-125		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-63R-150		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-63R-200		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-63R-250		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-63R-300		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-63H-25		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-63H-50		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-63H-75		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-63H-100		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-63H-125		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-63H-150		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-63H-200		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-63H-250		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-63H-300		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-TA-63D-25		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
SCM-D-TA-63D-50		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
SCM-D-TA-63D-75		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
SCM-D-TA-63D-100		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
SCM-D-TA-63D-125		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
SCM-D-TA-63D-150		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
SCM-D-TA-63D-200		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
SCM-D-TA-63D-250		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
SCM-D-TA-63D-300		Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
SCM-D-00-80B-25		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-00-80B-50		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-00-80B-75		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-00-80B-100		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-00-80B-125		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-00-80B-150		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-00-80B-200		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-00-80B-250		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-00-80B-300		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-00-80R-25		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-00-80R-50		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-00-80R-75		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-00-80R-100		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-00-80R-125		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-00-80R-150		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-00-80R-200		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-00-80R-250		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-00-80R-300		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-00-80H-25		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-00-80H-50		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-00-80H-75		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-00-80H-100		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-00-80H-125		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-00-80H-150		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-00-80H-200		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-00-80H-250		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-00-80H-300		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-00-80D-25		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-00-80D-50		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-00-80D-75		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-00-80D-100		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-00-80D-125		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-00-80D-150		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-00-80D-200		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-00-80D-250		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-00-80D-300		Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-LB-80B-25		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-LB-80B-50		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-LB-80B-75		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-LB-80B-100		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-LB-80B-125		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-LB-80B-150		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-LB-80B-200		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-LB-80B-250		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-LB-80B-300		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-LB-80R-25		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-LB-80R-50		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-LB-80R-75		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-LB-80R-100		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-LB-80R-125		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-LB-80R-150		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-LB-80R-200		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-LB-80R-250		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-LB-80R-300		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-LB-80H-25		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-LB-80H-50		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-LB-80H-75		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-LB-80H-100		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-LB-80H-125		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-LB-80H-150		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-LB-80H-200		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-LB-80H-250		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-LB-80H-300		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-LB-80D-25		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-LB-80D-50		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-LB-80D-75		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-LB-80D-100		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-LB-80D-125		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-LB-80D-150		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-LB-80D-200		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-LB-80D-250		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-LB-80D-300		Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-FA-80B-25		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-FA-80B-50		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-FA-80B-75		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-FA-80B-100		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-FA-80B-125		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-FA-80B-150		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-FA-80B-200		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-FA-80B-250		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-FA-80B-300		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-FA-80R-25		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-FA-80R-50		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-FA-80R-75		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-FA-80R-100		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-FA-80R-125		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-FA-80R-150		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-FA-80R-200		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-FA-80R-250		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-FA-80R-300		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-FA-80H-25		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-FA-80H-50		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-FA-80H-75		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-FA-80H-100		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-FA-80H-125		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-FA-80H-150		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-FA-80H-200		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-FA-80H-250		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-FA-80H-300		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-FA-80D-25		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
SCM-D-FA-80D-50		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
SCM-D-FA-80D-75		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
SCM-D-FA-80D-100		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
SCM-D-FA-80D-125		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
SCM-D-FA-80D-150		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
SCM-D-FA-80D-200		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
SCM-D-FA-80D-250		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
SCM-D-FA-80D-300		Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
SCM-D-00-100B-25		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-00-100B-50		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-00-100B-75		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-00-100B-100		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-00-100B-125		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-00-100B-150		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-00-100B-200		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-00-100B-250		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-00-100B-300		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-00-100R-25		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-00-100R-50		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-00-100R-75		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-00-100R-100		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-00-100R-125		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-00-100R-150		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-00-100R-200		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-00-100R-250		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-00-100R-300		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-00-100H-25		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-00-100H-50		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-00-100H-75		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-00-100H-100		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-00-100H-125		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-00-100H-150		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-00-100H-200		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-00-100H-250		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-00-100H-300		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-00-100D-25		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-00-100D-50		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-00-100D-75		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-00-100D-100		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-00-100D-125		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-00-100D-150		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-00-100D-200		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-00-100D-250		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-00-100D-300		Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-LB-100B-25		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-LB-100B-50		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-LB-100B-75		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-LB-100B-100		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-LB-100B-125		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-LB-100B-150		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-LB-100B-200		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-LB-100B-250		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-LB-100B-300		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-LB-100R-25		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-LB-100R-50		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-LB-100R-75		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-LB-100R-100		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-LB-100R-125		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-LB-100R-150		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-LB-100R-200		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-LB-100R-250		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-LB-100R-300		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-LB-100H-25		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-LB-100H-50		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-LB-100H-75		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-LB-100H-100		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-LB-100H-125		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-LB-100H-150		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-LB-100H-200		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-LB-100H-250		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-LB-100H-300		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-LB-100D-25		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-LB-100D-50		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-LB-100D-75		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-LB-100D-100		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-LB-100D-125		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-LB-100D-150		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-LB-100D-200		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-LB-100D-250		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-LB-100D-300		Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-FA-100B-25		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-FA-100B-50		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-FA-100B-75		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-FA-100B-100		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-FA-100B-125		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-FA-100B-150		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-FA-100B-200		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-FA-100B-250		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-FA-100B-300		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-FA-100R-25		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-FA-100R-50		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-FA-100R-75		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-FA-100R-100		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-FA-100R-125		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-FA-100R-150		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-FA-100R-200		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-FA-100R-250		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-FA-100R-300		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-FA-100H-25		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-FA-100H-50		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-FA-100H-75		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-FA-100H-100		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-FA-100H-125		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-FA-100H-150		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-FA-100H-200		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-FA-100H-250		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-FA-100H-300		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/2
SCM-D-FA-100D-25		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
SCM-D-FA-100D-50		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
SCM-D-FA-100D-75		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
SCM-D-FA-100D-100		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
SCM-D-FA-100D-125		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
SCM-D-FA-100D-150		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
SCM-D-FA-100D-200		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
SCM-D-FA-100D-250		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
SCM-D-FA-100D-300		Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2

Pneumatic CylindersCKD

1080 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD SCM-D Super Micro Cylinder, Double Rod (Bore 20-100)

Brand CKD·Pneumatic Cylinders

Available part numbers (1080)

SCM-D-00-20B-25, SCM-D-00-20B-50, SCM-D-00-20B-75, SCM-D-00-20B-100, SCM-D-00-20B-125, SCM-D-00-20B-150, SCM-D-00-20B-200, SCM-D-00-20B-250, SCM-D-00-20B-300, SCM-D-00-20R-25 + 1070 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	SCM-D-00-20B-25	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-00-20B-50	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-00-20B-75	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-00-20B-100	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-00-20B-125	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-00-20B-150	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-00-20B-200	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-00-20B-250	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-00-20B-300	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-00-20R-25	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-00-20R-50	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-00-20R-75	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-00-20R-100	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-00-20R-125	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-00-20R-150	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-00-20R-200	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-00-20R-250	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-00-20R-300	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-00-20H-25	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-00-20H-50	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-00-20H-75	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-00-20H-100	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-00-20H-125	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-00-20H-150	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-00-20H-200	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-00-20H-250	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-00-20H-300	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-00-20D-25	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-20D-50	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-20D-75	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-20D-100	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-20D-125	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-20D-150	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-20D-200	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-20D-250	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-20D-300	Mounting: Basic (00) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-20B-25	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-LB-20B-50	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-LB-20B-75	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-LB-20B-100	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-LB-20B-125	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-LB-20B-150	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-LB-20B-200	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-LB-20B-250	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-LB-20B-300	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-LB-20R-25	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-LB-20R-50	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-LB-20R-75	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-LB-20R-100	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-LB-20R-125	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-LB-20R-150	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-LB-20R-200	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-LB-20R-250	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-LB-20R-300	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-LB-20H-25	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-LB-20H-50	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-LB-20H-75	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-LB-20H-100	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-LB-20H-125	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-LB-20H-150	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-LB-20H-200	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-LB-20H-250	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-LB-20H-300	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-LB-20D-25	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-20D-50	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-20D-75	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-20D-100	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-20D-125	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-20D-150	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-20D-200	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-20D-250	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-20D-300	Mounting: Axial foot (LB) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-20B-25	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-FA-20B-50	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-FA-20B-75	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-FA-20B-100	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-FA-20B-125	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-FA-20B-150	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-FA-20B-200	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-FA-20B-250	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-FA-20B-300	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-FA-20R-25	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-FA-20R-50	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-FA-20R-75	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-FA-20R-100	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-FA-20R-125	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-FA-20R-150	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-FA-20R-200	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-FA-20R-250	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-FA-20R-300	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-FA-20H-25	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-FA-20H-50	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-FA-20H-75	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-FA-20H-100	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-FA-20H-125	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-FA-20H-150	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-FA-20H-200	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-FA-20H-250	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-FA-20H-300	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-FA-20D-25	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-20D-50	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-20D-75	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-20D-100	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-20D-125	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-20D-150	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-20D-200	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-20D-250	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-20D-300	Mounting: Rod-side flange (FA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-20B-25	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-TA-20B-50	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-TA-20B-75	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-TA-20B-100	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-TA-20B-125	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-TA-20B-150	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-TA-20B-200	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-TA-20B-250	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-TA-20B-300	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-TA-20R-25	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-TA-20R-50	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-TA-20R-75	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-TA-20R-100	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-TA-20R-125	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-TA-20R-150	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-TA-20R-200	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-TA-20R-250	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-TA-20R-300	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-TA-20H-25	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-TA-20H-50	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-TA-20H-75	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-TA-20H-100	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-TA-20H-125	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-TA-20H-150	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-TA-20H-200	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-TA-20H-250	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-TA-20H-300	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-TA-20D-25	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-20D-50	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-20D-75	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-20D-100	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-20D-125	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-20D-150	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-20D-200	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-20D-250	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-20D-300	Mounting: Rod-side trunnion (TA) \| Bore: 20 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-25B-25	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-00-25B-50	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-00-25B-75	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-00-25B-100	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-00-25B-125	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-00-25B-150	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-00-25B-200	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-00-25B-250	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-00-25B-300	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-00-25R-25	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-00-25R-50	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-00-25R-75	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-00-25R-100	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-00-25R-125	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-00-25R-150	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-00-25R-200	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-00-25R-250	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-00-25R-300	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-00-25H-25	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-00-25H-50	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-00-25H-75	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-00-25H-100	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-00-25H-125	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-00-25H-150	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-00-25H-200	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-00-25H-250	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-00-25H-300	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-00-25D-25	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-25D-50	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-25D-75	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-25D-100	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-25D-125	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-25D-150	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-25D-200	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-25D-250	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-25D-300	Mounting: Basic (00) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-25B-25	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-LB-25B-50	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-LB-25B-75	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-LB-25B-100	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-LB-25B-125	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-LB-25B-150	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-LB-25B-200	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-LB-25B-250	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-LB-25B-300	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-LB-25R-25	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-LB-25R-50	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-LB-25R-75	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-LB-25R-100	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-LB-25R-125	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-LB-25R-150	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-LB-25R-200	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-LB-25R-250	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-LB-25R-300	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-LB-25H-25	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-LB-25H-50	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-LB-25H-75	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-LB-25H-100	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-LB-25H-125	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-LB-25H-150	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-LB-25H-200	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-LB-25H-250	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-LB-25H-300	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-LB-25D-25	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-25D-50	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-25D-75	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-25D-100	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-25D-125	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-25D-150	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-25D-200	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-25D-250	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-25D-300	Mounting: Axial foot (LB) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-25B-25	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-FA-25B-50	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-FA-25B-75	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-FA-25B-100	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-FA-25B-125	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-FA-25B-150	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-FA-25B-200	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-FA-25B-250	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-FA-25B-300	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-FA-25R-25	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-FA-25R-50	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-FA-25R-75	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-FA-25R-100	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-FA-25R-125	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-FA-25R-150	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-FA-25R-200	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-FA-25R-250	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-FA-25R-300	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-FA-25H-25	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-FA-25H-50	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-FA-25H-75	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-FA-25H-100	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-FA-25H-125	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-FA-25H-150	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-FA-25H-200	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-FA-25H-250	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-FA-25H-300	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-FA-25D-25	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-25D-50	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-25D-75	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-25D-100	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-25D-125	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-25D-150	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-25D-200	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-25D-250	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-25D-300	Mounting: Rod-side flange (FA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-25B-25	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: M5
	SCM-D-TA-25B-50	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: M5
	SCM-D-TA-25B-75	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: M5
	SCM-D-TA-25B-100	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: M5
	SCM-D-TA-25B-125	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: M5
	SCM-D-TA-25B-150	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: M5
	SCM-D-TA-25B-200	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: M5
	SCM-D-TA-25B-250	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: M5
	SCM-D-TA-25B-300	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: M5
	SCM-D-TA-25R-25	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: M5
	SCM-D-TA-25R-50	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: M5
	SCM-D-TA-25R-75	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: M5
	SCM-D-TA-25R-100	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: M5
	SCM-D-TA-25R-125	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: M5
	SCM-D-TA-25R-150	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: M5
	SCM-D-TA-25R-200	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: M5
	SCM-D-TA-25R-250	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: M5
	SCM-D-TA-25R-300	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: M5
	SCM-D-TA-25H-25	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: M5
	SCM-D-TA-25H-50	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: M5
	SCM-D-TA-25H-75	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: M5
	SCM-D-TA-25H-100	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: M5
	SCM-D-TA-25H-125	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: M5
	SCM-D-TA-25H-150	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: M5
	SCM-D-TA-25H-200	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: M5
	SCM-D-TA-25H-250	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: M5
	SCM-D-TA-25H-300	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: M5
	SCM-D-TA-25D-25	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-25D-50	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-25D-75	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-25D-100	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-25D-125	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-25D-150	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-25D-200	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-25D-250	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-25D-300	Mounting: Rod-side trunnion (TA) \| Bore: 25 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-32B-25	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-32B-50	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-32B-75	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-32B-100	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-32B-125	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-32B-150	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-32B-200	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-32B-250	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-32B-300	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-32R-25	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-32R-50	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-32R-75	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-32R-100	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-32R-125	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-32R-150	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-32R-200	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-32R-250	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-32R-300	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-32H-25	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-32H-50	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-32H-75	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-32H-100	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-32H-125	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-32H-150	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-32H-200	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-32H-250	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-32H-300	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-32D-25	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-32D-50	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-32D-75	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-32D-100	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-32D-125	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-32D-150	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-32D-200	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-32D-250	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-32D-300	Mounting: Basic (00) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-32B-25	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-32B-50	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-32B-75	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-32B-100	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-32B-125	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-32B-150	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-32B-200	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-32B-250	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-32B-300	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-32R-25	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-32R-50	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-32R-75	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-32R-100	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-32R-125	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-32R-150	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-32R-200	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-32R-250	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-32R-300	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-32H-25	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-32H-50	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-32H-75	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-32H-100	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-32H-125	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-32H-150	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-32H-200	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-32H-250	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-32H-300	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-32D-25	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-32D-50	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-32D-75	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-32D-100	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-32D-125	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-32D-150	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-32D-200	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-32D-250	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-32D-300	Mounting: Axial foot (LB) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-32B-25	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-32B-50	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-32B-75	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-32B-100	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-32B-125	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-32B-150	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-32B-200	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-32B-250	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-32B-300	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-32R-25	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-32R-50	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-32R-75	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-32R-100	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-32R-125	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-32R-150	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-32R-200	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-32R-250	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-32R-300	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-32H-25	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-32H-50	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-32H-75	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-32H-100	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-32H-125	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-32H-150	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-32H-200	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-32H-250	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-32H-300	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-32D-25	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-32D-50	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-32D-75	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-32D-100	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-32D-125	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-32D-150	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-32D-200	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-32D-250	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-32D-300	Mounting: Rod-side flange (FA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-32B-25	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-32B-50	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-32B-75	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-32B-100	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-32B-125	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-32B-150	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-32B-200	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-32B-250	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-32B-300	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-32R-25	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-32R-50	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-32R-75	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-32R-100	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-32R-125	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-32R-150	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-32R-200	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-32R-250	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-32R-300	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-32H-25	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-32H-50	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-32H-75	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-32H-100	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-32H-125	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-32H-150	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-32H-200	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-32H-250	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-32H-300	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-32D-25	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-32D-50	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-32D-75	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-32D-100	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-32D-125	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-32D-150	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-32D-200	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-32D-250	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-32D-300	Mounting: Rod-side trunnion (TA) \| Bore: 32 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-40B-25	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-40B-50	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-40B-75	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-40B-100	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-40B-125	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-40B-150	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-40B-200	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-40B-250	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-40B-300	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-40R-25	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-40R-50	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-40R-75	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-40R-100	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-40R-125	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-40R-150	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-40R-200	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-40R-250	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-40R-300	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-40H-25	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-40H-50	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-40H-75	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-40H-100	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-40H-125	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-40H-150	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-40H-200	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-40H-250	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-40H-300	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-40D-25	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-00-40D-50	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-00-40D-75	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-00-40D-100	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-00-40D-125	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-00-40D-150	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-00-40D-200	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-00-40D-250	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-00-40D-300	Mounting: Basic (00) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-40B-25	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-40B-50	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-40B-75	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-40B-100	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-40B-125	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-40B-150	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-40B-200	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-40B-250	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-40B-300	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-40R-25	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-40R-50	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-40R-75	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-40R-100	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-40R-125	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-40R-150	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-40R-200	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-40R-250	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-40R-300	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-40H-25	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-40H-50	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-40H-75	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-40H-100	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-40H-125	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-40H-150	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-40H-200	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-40H-250	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-40H-300	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-LB-40D-25	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-LB-40D-50	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-LB-40D-75	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-LB-40D-100	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-LB-40D-125	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-LB-40D-150	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-LB-40D-200	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-LB-40D-250	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-LB-40D-300	Mounting: Axial foot (LB) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-40B-25	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-40B-50	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-40B-75	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-40B-100	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-40B-125	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-40B-150	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-40B-200	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-40B-250	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-40B-300	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-40R-25	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-40R-50	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-40R-75	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-40R-100	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-40R-125	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-40R-150	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-40R-200	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-40R-250	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-40R-300	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-40H-25	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-40H-50	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-40H-75	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-40H-100	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-40H-125	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-40H-150	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-40H-200	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-40H-250	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-40H-300	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-FA-40D-25	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-FA-40D-50	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-FA-40D-75	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-FA-40D-100	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-FA-40D-125	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-FA-40D-150	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-FA-40D-200	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-FA-40D-250	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-FA-40D-300	Mounting: Rod-side flange (FA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-40B-25	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-40B-50	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-40B-75	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-40B-100	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-40B-125	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-40B-150	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-40B-200	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-40B-250	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-40B-300	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-40R-25	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-40R-50	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-40R-75	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-40R-100	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-40R-125	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-40R-150	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-40R-200	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-40R-250	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-40R-300	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-40H-25	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-40H-50	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-40H-75	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-40H-100	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-40H-125	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-40H-150	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-40H-200	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-40H-250	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-40H-300	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-TA-40D-25	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/8
	SCM-D-TA-40D-50	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/8
	SCM-D-TA-40D-75	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/8
	SCM-D-TA-40D-100	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/8
	SCM-D-TA-40D-125	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/8
	SCM-D-TA-40D-150	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/8
	SCM-D-TA-40D-200	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/8
	SCM-D-TA-40D-250	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/8
	SCM-D-TA-40D-300	Mounting: Rod-side trunnion (TA) \| Bore: 40 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/8
	SCM-D-00-50B-25	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-50B-50	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-50B-75	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-50B-100	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-50B-125	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-50B-150	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-50B-200	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-50B-250	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-50B-300	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-50R-25	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-50R-50	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-50R-75	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-50R-100	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-50R-125	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-50R-150	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-50R-200	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-50R-250	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-50R-300	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-50H-25	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-50H-50	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-50H-75	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-50H-100	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-50H-125	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-50H-150	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-50H-200	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-50H-250	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-50H-300	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-50D-25	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-50D-50	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-50D-75	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-50D-100	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-50D-125	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-50D-150	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-50D-200	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-50D-250	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-50D-300	Mounting: Basic (00) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-50B-25	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-50B-50	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-50B-75	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-50B-100	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-50B-125	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-50B-150	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-50B-200	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-50B-250	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-50B-300	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-50R-25	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-50R-50	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-50R-75	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-50R-100	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-50R-125	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-50R-150	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-50R-200	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-50R-250	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-50R-300	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-50H-25	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-50H-50	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-50H-75	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-50H-100	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-50H-125	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-50H-150	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-50H-200	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-50H-250	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-50H-300	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-50D-25	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-50D-50	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-50D-75	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-50D-100	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-50D-125	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-50D-150	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-50D-200	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-50D-250	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-50D-300	Mounting: Axial foot (LB) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-50B-25	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-50B-50	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-50B-75	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-50B-100	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-50B-125	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-50B-150	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-50B-200	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-50B-250	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-50B-300	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-50R-25	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-50R-50	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-50R-75	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-50R-100	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-50R-125	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-50R-150	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-50R-200	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-50R-250	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-50R-300	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-50H-25	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-50H-50	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-50H-75	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-50H-100	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-50H-125	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-50H-150	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-50H-200	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-50H-250	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-50H-300	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-50D-25	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-50D-50	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-50D-75	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-50D-100	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-50D-125	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-50D-150	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-50D-200	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-50D-250	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-50D-300	Mounting: Rod-side flange (FA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-50B-25	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-50B-50	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-50B-75	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-50B-100	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-50B-125	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-50B-150	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-50B-200	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-50B-250	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-50B-300	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-50R-25	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-50R-50	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-50R-75	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-50R-100	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-50R-125	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-50R-150	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-50R-200	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-50R-250	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-50R-300	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-50H-25	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-50H-50	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-50H-75	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-50H-100	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-50H-125	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-50H-150	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-50H-200	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-50H-250	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-50H-300	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-50D-25	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-50D-50	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-50D-75	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-50D-100	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-50D-125	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-50D-150	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-50D-200	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-50D-250	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-50D-300	Mounting: Rod-side trunnion (TA) \| Bore: 50 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-63B-25	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-63B-50	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-63B-75	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-63B-100	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-63B-125	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-63B-150	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-63B-200	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-63B-250	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-63B-300	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-63R-25	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-63R-50	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-63R-75	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-63R-100	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-63R-125	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-63R-150	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-63R-200	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-63R-250	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-63R-300	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-63H-25	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-63H-50	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-63H-75	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-63H-100	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-63H-125	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-63H-150	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-63H-200	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-63H-250	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-63H-300	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-63D-25	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-00-63D-50	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-00-63D-75	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-00-63D-100	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-00-63D-125	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-00-63D-150	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-00-63D-200	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-00-63D-250	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-00-63D-300	Mounting: Basic (00) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-63B-25	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-63B-50	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-63B-75	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-63B-100	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-63B-125	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-63B-150	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-63B-200	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-63B-250	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-63B-300	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-63R-25	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-63R-50	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-63R-75	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-63R-100	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-63R-125	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-63R-150	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-63R-200	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-63R-250	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-63R-300	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-63H-25	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-63H-50	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-63H-75	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-63H-100	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-63H-125	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-63H-150	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-63H-200	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-63H-250	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-63H-300	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-LB-63D-25	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-LB-63D-50	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-LB-63D-75	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-LB-63D-100	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-LB-63D-125	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-LB-63D-150	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-LB-63D-200	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-LB-63D-250	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-LB-63D-300	Mounting: Axial foot (LB) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-63B-25	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-63B-50	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-63B-75	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-63B-100	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-63B-125	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-63B-150	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-63B-200	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-63B-250	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-63B-300	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-63R-25	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-63R-50	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-63R-75	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-63R-100	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-63R-125	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-63R-150	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-63R-200	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-63R-250	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-63R-300	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-63H-25	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-63H-50	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-63H-75	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-63H-100	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-63H-125	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-63H-150	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-63H-200	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-63H-250	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-63H-300	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-FA-63D-25	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-FA-63D-50	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-FA-63D-75	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-FA-63D-100	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-FA-63D-125	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-FA-63D-150	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-FA-63D-200	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-FA-63D-250	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-FA-63D-300	Mounting: Rod-side flange (FA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-63B-25	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-63B-50	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-63B-75	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-63B-100	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-63B-125	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-63B-150	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-63B-200	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-63B-250	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-63B-300	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-63R-25	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-63R-50	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-63R-75	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-63R-100	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-63R-125	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-63R-150	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-63R-200	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-63R-250	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-63R-300	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-63H-25	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-63H-50	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-63H-75	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-63H-100	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-63H-125	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-63H-150	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-63H-200	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-63H-250	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-63H-300	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-TA-63D-25	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/4
	SCM-D-TA-63D-50	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/4
	SCM-D-TA-63D-75	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/4
	SCM-D-TA-63D-100	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/4
	SCM-D-TA-63D-125	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/4
	SCM-D-TA-63D-150	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/4
	SCM-D-TA-63D-200	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/4
	SCM-D-TA-63D-250	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/4
	SCM-D-TA-63D-300	Mounting: Rod-side trunnion (TA) \| Bore: 63 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/4
	SCM-D-00-80B-25	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-00-80B-50	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-00-80B-75	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-00-80B-100	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-00-80B-125	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-00-80B-150	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-00-80B-200	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-00-80B-250	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-00-80B-300	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-00-80R-25	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-00-80R-50	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-00-80R-75	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-00-80R-100	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-00-80R-125	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-00-80R-150	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-00-80R-200	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-00-80R-250	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-00-80R-300	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-00-80H-25	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-00-80H-50	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-00-80H-75	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-00-80H-100	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-00-80H-125	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-00-80H-150	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-00-80H-200	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-00-80H-250	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-00-80H-300	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-00-80D-25	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-00-80D-50	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-00-80D-75	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-00-80D-100	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-00-80D-125	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-00-80D-150	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-00-80D-200	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-00-80D-250	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-00-80D-300	Mounting: Basic (00) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-LB-80B-25	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-LB-80B-50	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-LB-80B-75	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-LB-80B-100	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-LB-80B-125	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-LB-80B-150	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-LB-80B-200	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-LB-80B-250	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-LB-80B-300	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-LB-80R-25	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-LB-80R-50	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-LB-80R-75	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-LB-80R-100	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-LB-80R-125	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-LB-80R-150	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-LB-80R-200	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-LB-80R-250	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-LB-80R-300	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-LB-80H-25	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-LB-80H-50	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-LB-80H-75	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-LB-80H-100	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-LB-80H-125	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-LB-80H-150	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-LB-80H-200	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-LB-80H-250	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-LB-80H-300	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-LB-80D-25	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-LB-80D-50	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-LB-80D-75	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-LB-80D-100	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-LB-80D-125	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-LB-80D-150	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-LB-80D-200	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-LB-80D-250	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-LB-80D-300	Mounting: Axial foot (LB) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-FA-80B-25	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-FA-80B-50	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-FA-80B-75	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-FA-80B-100	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-FA-80B-125	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-FA-80B-150	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-FA-80B-200	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-FA-80B-250	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-FA-80B-300	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-FA-80R-25	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-FA-80R-50	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-FA-80R-75	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-FA-80R-100	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-FA-80R-125	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-FA-80R-150	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-FA-80R-200	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-FA-80R-250	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-FA-80R-300	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-FA-80H-25	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-FA-80H-50	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-FA-80H-75	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-FA-80H-100	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-FA-80H-125	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-FA-80H-150	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-FA-80H-200	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-FA-80H-250	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-FA-80H-300	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-FA-80D-25	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc3/8
	SCM-D-FA-80D-50	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc3/8
	SCM-D-FA-80D-75	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc3/8
	SCM-D-FA-80D-100	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc3/8
	SCM-D-FA-80D-125	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc3/8
	SCM-D-FA-80D-150	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc3/8
	SCM-D-FA-80D-200	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc3/8
	SCM-D-FA-80D-250	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc3/8
	SCM-D-FA-80D-300	Mounting: Rod-side flange (FA) \| Bore: 80 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc3/8
	SCM-D-00-100B-25	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-00-100B-50	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-00-100B-75	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-00-100B-100	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-00-100B-125	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-00-100B-150	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-00-100B-200	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-00-100B-250	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-00-100B-300	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-00-100R-25	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-00-100R-50	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-00-100R-75	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-00-100R-100	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-00-100R-125	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-00-100R-150	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-00-100R-200	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-00-100R-250	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-00-100R-300	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-00-100H-25	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-00-100H-50	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-00-100H-75	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-00-100H-100	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-00-100H-125	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-00-100H-150	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-00-100H-200	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-00-100H-250	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-00-100H-300	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-00-100D-25	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-00-100D-50	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-00-100D-75	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-00-100D-100	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-00-100D-125	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-00-100D-150	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-00-100D-200	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-00-100D-250	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-00-100D-300	Mounting: Basic (00) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-LB-100B-25	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-LB-100B-50	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-LB-100B-75	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-LB-100B-100	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-LB-100B-125	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-LB-100B-150	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-LB-100B-200	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-LB-100B-250	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-LB-100B-300	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-LB-100R-25	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-LB-100R-50	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-LB-100R-75	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-LB-100R-100	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-LB-100R-125	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-LB-100R-150	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-LB-100R-200	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-LB-100R-250	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-LB-100R-300	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-LB-100H-25	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-LB-100H-50	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-LB-100H-75	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-LB-100H-100	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-LB-100H-125	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-LB-100H-150	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-LB-100H-200	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-LB-100H-250	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-LB-100H-300	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-LB-100D-25	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-LB-100D-50	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-LB-100D-75	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-LB-100D-100	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-LB-100D-125	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-LB-100D-150	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-LB-100D-200	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-LB-100D-250	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-LB-100D-300	Mounting: Axial foot (LB) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-FA-100B-25	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-FA-100B-50	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-FA-100B-75	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-FA-100B-100	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-FA-100B-125	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-FA-100B-150	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-FA-100B-200	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-FA-100B-250	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-FA-100B-300	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-FA-100R-25	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-FA-100R-50	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-FA-100R-75	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-FA-100R-100	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-FA-100R-125	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-FA-100R-150	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-FA-100R-200	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-FA-100R-250	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-FA-100R-300	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, rod end \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-FA-100H-25	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-FA-100H-50	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-FA-100H-75	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-FA-100H-100	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-FA-100H-125	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-FA-100H-150	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-FA-100H-200	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-FA-100H-250	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-FA-100H-300	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Air cushion, head end \| Stroke: 300 mm \| Port: Rc1/2
	SCM-D-FA-100D-25	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 25 mm \| Port: Rc1/2
	SCM-D-FA-100D-50	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 50 mm \| Port: Rc1/2
	SCM-D-FA-100D-75	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 75 mm \| Port: Rc1/2
	SCM-D-FA-100D-100	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 100 mm \| Port: Rc1/2
	SCM-D-FA-100D-125	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 125 mm \| Port: Rc1/2
	SCM-D-FA-100D-150	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 150 mm \| Port: Rc1/2
	SCM-D-FA-100D-200	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 200 mm \| Port: Rc1/2
	SCM-D-FA-100D-250	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 250 mm \| Port: Rc1/2
	SCM-D-FA-100D-300	Mounting: Rod-side flange (FA) \| Bore: 100 mm \| Cushion: Rubber cushion, both ends \| Stroke: 300 mm \| Port: Rc1/2

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

CKD SCM-D Super Micro Cylinder, Double Rod (Bore 20-100)
