CKD SCM-LD Super Micro Cylinder, Direct Foot (Bore 20-63)

CKD SCM-LD Super Micro Cylinder, Direct Foot (Bore 20-63)

CKD SCM-LD super micro double-acting cylinder with integrated direct foot mounting, bore 20 to 63 mm.

Key features

  • Foot integrated into the cylinder covers for compact, rigid mounting
  • Rubber cushion on both ends (D)
  • Standard strokes 25 to 300 mm; 1 mm intermediate strokes up to 300 mm
  • Auto switch ready (built-in magnet); T0/T5/T8 reed and T1/T2/T3/T2W/T2Y/T2YD/T2J solid-state switches, rail or band (Z) mounting, ordered as suffix
  • Options Q, M (stainless rod), P6; accessories I/Y as suffix

Specifications

Action Double acting
Mounting Direct foot (LD)
Fluid Compressed air
Max. operating pressure 1.0 MPa
Min. operating pressure 0.1 MPa (ø20-40), 0.05 MPa (ø50-63)
Proof pressure 1.6 MPa
Ambient temperature -10 to 60°C (no freezing)
Piston speed 30 to 1000 mm/s
Cushion Rubber cushion, both ends (D)
Source CKD Korea catalog CB-029SK-9, p. 428-432
SCM-LD-20D-25 Bore: 20 mm | Stroke: 25 mm | Port: Rc1/8
SCM-LD-20D-50 Bore: 20 mm | Stroke: 50 mm | Port: Rc1/8
SCM-LD-20D-75 Bore: 20 mm | Stroke: 75 mm | Port: Rc1/8
SCM-LD-20D-100 Bore: 20 mm | Stroke: 100 mm | Port: Rc1/8
SCM-LD-20D-125 Bore: 20 mm | Stroke: 125 mm | Port: Rc1/8
SCM-LD-20D-150 Bore: 20 mm | Stroke: 150 mm | Port: Rc1/8
SCM-LD-20D-200 Bore: 20 mm | Stroke: 200 mm | Port: Rc1/8
SCM-LD-20D-250 Bore: 20 mm | Stroke: 250 mm | Port: Rc1/8
SCM-LD-20D-300 Bore: 20 mm | Stroke: 300 mm | Port: Rc1/8
SCM-LD-25D-25 Bore: 25 mm | Stroke: 25 mm | Port: Rc1/8
SCM-LD-25D-50 Bore: 25 mm | Stroke: 50 mm | Port: Rc1/8
SCM-LD-25D-75 Bore: 25 mm | Stroke: 75 mm | Port: Rc1/8
SCM-LD-25D-100 Bore: 25 mm | Stroke: 100 mm | Port: Rc1/8
SCM-LD-25D-125 Bore: 25 mm | Stroke: 125 mm | Port: Rc1/8
SCM-LD-25D-150 Bore: 25 mm | Stroke: 150 mm | Port: Rc1/8
SCM-LD-25D-200 Bore: 25 mm | Stroke: 200 mm | Port: Rc1/8
SCM-LD-25D-250 Bore: 25 mm | Stroke: 250 mm | Port: Rc1/8
SCM-LD-25D-300 Bore: 25 mm | Stroke: 300 mm | Port: Rc1/8
SCM-LD-32D-25 Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SCM-LD-32D-50 Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SCM-LD-32D-75 Bore: 32 mm | Stroke: 75 mm | Port: Rc1/8
SCM-LD-32D-100 Bore: 32 mm | Stroke: 100 mm | Port: Rc1/8
SCM-LD-32D-125 Bore: 32 mm | Stroke: 125 mm | Port: Rc1/8
SCM-LD-32D-150 Bore: 32 mm | Stroke: 150 mm | Port: Rc1/8
SCM-LD-32D-200 Bore: 32 mm | Stroke: 200 mm | Port: Rc1/8
SCM-LD-32D-250 Bore: 32 mm | Stroke: 250 mm | Port: Rc1/8
SCM-LD-32D-300 Bore: 32 mm | Stroke: 300 mm | Port: Rc1/8
SCM-LD-40D-25 Bore: 40 mm | Stroke: 25 mm | Port: Rc1/8
SCM-LD-40D-50 Bore: 40 mm | Stroke: 50 mm | Port: Rc1/8
SCM-LD-40D-75 Bore: 40 mm | Stroke: 75 mm | Port: Rc1/8
SCM-LD-40D-100 Bore: 40 mm | Stroke: 100 mm | Port: Rc1/8
SCM-LD-40D-125 Bore: 40 mm | Stroke: 125 mm | Port: Rc1/8
SCM-LD-40D-150 Bore: 40 mm | Stroke: 150 mm | Port: Rc1/8
SCM-LD-40D-200 Bore: 40 mm | Stroke: 200 mm | Port: Rc1/8
SCM-LD-40D-250 Bore: 40 mm | Stroke: 250 mm | Port: Rc1/8
SCM-LD-40D-300 Bore: 40 mm | Stroke: 300 mm | Port: Rc1/8
SCM-LD-50D-25 Bore: 50 mm | Stroke: 25 mm | Port: Rc1/4
SCM-LD-50D-50 Bore: 50 mm | Stroke: 50 mm | Port: Rc1/4
SCM-LD-50D-75 Bore: 50 mm | Stroke: 75 mm | Port: Rc1/4
SCM-LD-50D-100 Bore: 50 mm | Stroke: 100 mm | Port: Rc1/4
SCM-LD-50D-125 Bore: 50 mm | Stroke: 125 mm | Port: Rc1/4
SCM-LD-50D-150 Bore: 50 mm | Stroke: 150 mm | Port: Rc1/4
SCM-LD-50D-200 Bore: 50 mm | Stroke: 200 mm | Port: Rc1/4
SCM-LD-50D-250 Bore: 50 mm | Stroke: 250 mm | Port: Rc1/4
SCM-LD-50D-300 Bore: 50 mm | Stroke: 300 mm | Port: Rc1/4
SCM-LD-63D-25 Bore: 63 mm | Stroke: 25 mm | Port: Rc1/4
SCM-LD-63D-50 Bore: 63 mm | Stroke: 50 mm | Port: Rc1/4
SCM-LD-63D-75 Bore: 63 mm | Stroke: 75 mm | Port: Rc1/4
SCM-LD-63D-100 Bore: 63 mm | Stroke: 100 mm | Port: Rc1/4
SCM-LD-63D-125 Bore: 63 mm | Stroke: 125 mm | Port: Rc1/4
SCM-LD-63D-150 Bore: 63 mm | Stroke: 150 mm | Port: Rc1/4
SCM-LD-63D-200 Bore: 63 mm | Stroke: 200 mm | Port: Rc1/4
SCM-LD-63D-250 Bore: 63 mm | Stroke: 250 mm | Port: Rc1/4
SCM-LD-63D-300 Bore: 63 mm | Stroke: 300 mm | Port: Rc1/4
Pneumatic CylindersCKD
54 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →
