CKD SCPD3-D Pencil Cylinder (Double-Acting, Double Rod)

CKD SCPD3-D Pencil Cylinder (Double-Acting, Double Rod)

CKD SCPD3-D double-acting double-rod pencil cylinder, bores 6/10/16 mm, including the switch-ready SCPD3-DL and the made-to-order heat resistant SCPD3-DT.

Key features

  • Bores 6/10/16 mm, standard strokes 15/30/45/60 mm (max. 60 mm bore 6, 120 mm bore 10/16)
  • Mounting: 00, LS, LB (both-side axial foot), FA
  • SCPD3-DT: heat resistant 5 to 120°C, made to order, no switch
  • Auto switches T0H/T0V, T5H/T5V (reed), T2H/T2V, T3H/T3V, T2WH/T2WV, T3WH/T3WV (solid state) are added after the stroke on switch-ready (-L) models with switch quantity R/H/D/T; lead 1 m standard, 3 m/5 m optional
  • Rod-end knuckle I/Y as suffix (bore 10/16)

Specifications

Fluid Compressed air
Max. operating pressure 1.0 MPa
Proof pressure 1.6 MPa
Port size M5
Stroke tolerance +1.0/0 mm
Min. operating pressure 0.2 MPa (bore 6), 0.1 MPa (bore 10/16)
Ambient temperature -10 to 60°C (DT 5 to 120°C)
Piston speed 50 to 750 mm/s
Cushion Rubber cushion
Source CKD Korea catalog CB-029SK-9, p. 132-137
SCPD3-D-00-6-15 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-00-6-30 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-00-6-45 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-00-6-60 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-00-10-15 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-00-10-30 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-00-10-45 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-00-10-60 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-00-16-15 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-00-16-30 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-00-16-45 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-00-16-60 Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 60 mm
SCPD3-D-LS-6-15 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-LS-6-30 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-LS-6-45 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-LS-6-60 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-LS-10-15 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-LS-10-30 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-LS-10-45 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-LS-10-60 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-LS-16-15 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-LS-16-30 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-LS-16-45 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-LS-16-60 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 60 mm
SCPD3-D-LB-6-15 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-LB-6-30 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-LB-6-45 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-LB-6-60 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-LB-10-15 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-LB-10-30 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-LB-10-45 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-LB-10-60 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-LB-16-15 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-LB-16-30 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-LB-16-45 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-LB-16-60 Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 60 mm
SCPD3-D-FA-6-15 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-FA-6-30 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-FA-6-45 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-FA-6-60 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-FA-10-15 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-FA-10-30 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-FA-10-45 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-FA-10-60 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-FA-16-15 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-FA-16-30 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-FA-16-45 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-FA-16-60 Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-00-6-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-00-6-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-00-6-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-00-6-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-00-10-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-00-10-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-00-10-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-00-10-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-00-16-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-00-16-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-00-16-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-00-16-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-LS-6-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-LS-6-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-LS-6-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-LS-6-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-LS-10-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-LS-10-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-LS-10-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-LS-10-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-LS-16-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-LS-16-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-LS-16-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-LS-16-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-LB-6-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-LB-6-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-LB-6-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-LB-6-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-LB-10-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-LB-10-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-LB-10-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-LB-10-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-LB-16-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-LB-16-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-LB-16-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-LB-16-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-FA-6-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-FA-6-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-FA-6-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-FA-6-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-FA-10-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-FA-10-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-FA-10-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-FA-10-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-FA-16-15 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-FA-16-30 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-FA-16-45 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-FA-16-60 Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-00-6-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-00-6-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-00-6-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-00-6-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-00-10-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-00-10-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-00-10-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-00-10-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-00-16-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-00-16-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-00-16-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-00-16-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-LS-6-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-LS-6-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-LS-6-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-LS-6-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-LS-10-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-LS-10-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-LS-10-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-LS-10-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-LS-16-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-LS-16-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-LS-16-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-LS-16-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-LB-6-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-LB-6-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-LB-6-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-LB-6-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-LB-10-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-LB-10-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-LB-10-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-LB-10-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-LB-16-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-LB-16-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-LB-16-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-LB-16-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-FA-6-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-FA-6-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-FA-6-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-FA-6-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-FA-10-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-FA-10-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-FA-10-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-FA-10-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-FA-16-15 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-FA-16-30 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-FA-16-45 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-FA-16-60 Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 60 mm
Pneumatic CylindersCKD
144 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD SCPD3-D Pencil Cylinder (Double-Acting, Double Rod)

Brand CKD·Pneumatic Cylinders

Available part numbers (144)

SCPD3-D-00-6-15, SCPD3-D-00-6-30, SCPD3-D-00-6-45, SCPD3-D-00-6-60, SCPD3-D-00-10-15, SCPD3-D-00-10-30, SCPD3-D-00-10-45, SCPD3-D-00-10-60, SCPD3-D-00-16-15, SCPD3-D-00-16-30 + 134 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SCPD3-D-00-6-15Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-00-6-30Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-00-6-45Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-00-6-60Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-00-10-15Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-00-10-30Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-00-10-45Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-00-10-60Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-00-16-15Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-00-16-30Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-00-16-45Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-00-16-60Model: SCPD3-D (no switch magnet) | Mounting: Basic | Bore: 16 mm | Stroke: 60 mm
SCPD3-D-LS-6-15Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-LS-6-30Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-LS-6-45Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-LS-6-60Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-LS-10-15Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-LS-10-30Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-LS-10-45Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-LS-10-60Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-LS-16-15Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-LS-16-30Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-LS-16-45Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-LS-16-60Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 60 mm
SCPD3-D-LB-6-15Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-LB-6-30Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-LB-6-45Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-LB-6-60Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-LB-10-15Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-LB-10-30Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-LB-10-45Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-LB-10-60Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-LB-16-15Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-LB-16-30Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-LB-16-45Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-LB-16-60Model: SCPD3-D (no switch magnet) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 60 mm
SCPD3-D-FA-6-15Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 15 mm
SCPD3-D-FA-6-30Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 30 mm
SCPD3-D-FA-6-45Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 45 mm
SCPD3-D-FA-6-60Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 60 mm
SCPD3-D-FA-10-15Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 15 mm
SCPD3-D-FA-10-30Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 30 mm
SCPD3-D-FA-10-45Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 45 mm
SCPD3-D-FA-10-60Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 60 mm
SCPD3-D-FA-16-15Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 15 mm
SCPD3-D-FA-16-30Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 30 mm
SCPD3-D-FA-16-45Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 45 mm
SCPD3-D-FA-16-60Model: SCPD3-D (no switch magnet) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-00-6-15Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-00-6-30Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-00-6-45Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-00-6-60Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-00-10-15Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-00-10-30Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-00-10-45Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-00-10-60Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-00-16-15Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-00-16-30Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-00-16-45Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-00-16-60Model: SCPD3-DL (switch magnet built in) | Mounting: Basic | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-LS-6-15Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-LS-6-30Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-LS-6-45Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-LS-6-60Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-LS-10-15Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-LS-10-30Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-LS-10-45Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-LS-10-60Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-LS-16-15Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-LS-16-30Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-LS-16-45Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-LS-16-60Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-LB-6-15Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-LB-6-30Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-LB-6-45Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-LB-6-60Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-LB-10-15Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-LB-10-30Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-LB-10-45Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-LB-10-60Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-LB-16-15Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-LB-16-30Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-LB-16-45Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-LB-16-60Model: SCPD3-DL (switch magnet built in) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 60 mm
SCPD3-DL-FA-6-15Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 15 mm
SCPD3-DL-FA-6-30Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 30 mm
SCPD3-DL-FA-6-45Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 45 mm
SCPD3-DL-FA-6-60Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 60 mm
SCPD3-DL-FA-10-15Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 15 mm
SCPD3-DL-FA-10-30Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 30 mm
SCPD3-DL-FA-10-45Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 45 mm
SCPD3-DL-FA-10-60Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 60 mm
SCPD3-DL-FA-16-15Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 15 mm
SCPD3-DL-FA-16-30Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 30 mm
SCPD3-DL-FA-16-45Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 45 mm
SCPD3-DL-FA-16-60Model: SCPD3-DL (switch magnet built in) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-00-6-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-00-6-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-00-6-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-00-6-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-00-10-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-00-10-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-00-10-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-00-10-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-00-16-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-00-16-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-00-16-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-00-16-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Basic | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-LS-6-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-LS-6-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-LS-6-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-LS-6-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-LS-10-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-LS-10-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-LS-10-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-LS-10-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-LS-16-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-LS-16-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-LS-16-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-LS-16-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, one side | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-LB-6-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-LB-6-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-LB-6-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-LB-6-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-LB-10-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-LB-10-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-LB-10-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-LB-10-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-LB-16-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-LB-16-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-LB-16-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-LB-16-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Axial foot, both sides | Bore: 16 mm | Stroke: 60 mm
SCPD3-DT-FA-6-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 15 mm
SCPD3-DT-FA-6-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 30 mm
SCPD3-DT-FA-6-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 45 mm
SCPD3-DT-FA-6-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 6 mm | Stroke: 60 mm
SCPD3-DT-FA-10-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 15 mm
SCPD3-DT-FA-10-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 30 mm
SCPD3-DT-FA-10-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 45 mm
SCPD3-DT-FA-10-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 10 mm | Stroke: 60 mm
SCPD3-DT-FA-16-15Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 15 mm
SCPD3-DT-FA-16-30Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 30 mm
SCPD3-DT-FA-16-45Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 45 mm
SCPD3-DT-FA-16-60Model: SCPD3-DT heat resistant (MTO) | Mounting: Rod-end flange | Bore: 16 mm | Stroke: 60 mm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
