CKD SMG-F Super Mount Cylinder (Double Acting, Low Speed)

CKD SMG-F Super Mount Cylinder (Double Acting, Low Speed)

CKD SMG-F double acting low-speed super mount cylinder for smooth operation from 1 mm/s, bore 6 to 32 mm.

Key features

  • Low-speed type: stable piston speed 1 to 200 mm/s, lubrication not allowed
  • Integrated mounting block; dimensions and mass identical to standard SMG
  • Standard strokes 5-30 mm (bore 6-16) and 5-50 mm (bore 20-32); intermediate strokes in 5 mm steps
  • Port thread Rc standard; NPT (NN) and G (GN) for bore 32
  • Auto switches (order separately or appended to the code): reed K0H/K0V, K5H/K5V; solid state K2H/K2V, K3H/K3V, K2YH/K2YV, K3YH/K3YV (2-colour); lead 1/3/5 m; switch qty R/H/D

Specifications

Fluid Compressed air
Action Double acting, low speed
Min. working pressure 0.12 MPa (6), 0.06 MPa (10-16), 0.05 MPa (20-32)
Max. working pressure 0.7 MPa
Proof pressure 1.05 MPa
Port size M5 (bore 6-25), Rc1/8 (bore 32)
Piston speed 1 to 200 mm/s
Ambient temperature 5 to 60°C
Cushion Rubber cushion
Source CKD Korea catalog CB-029SK-9, p. 1488-1490
SMG-F-6-5 Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-6-10 Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-6-15 Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-6-20 Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-6-25 Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-6-30 Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-10-5 Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-10-10 Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-10-15 Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-10-20 Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-10-25 Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-10-30 Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-16-5 Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-16-10 Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-16-15 Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-16-20 Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-16-25 Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-16-30 Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-20-5 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-20-10 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-20-15 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-20-20 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-20-25 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-20-30 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-20-40 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 40 mm
SMG-F-20-50 Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 50 mm
SMG-F-25-5 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-25-10 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-25-15 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-25-20 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-25-25 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-25-30 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-25-40 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 40 mm
SMG-F-25-50 Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 50 mm
SMG-F-32-5 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-32-10 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-32-15 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-32-20 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-32-25 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-32-30 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-32-40 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 40 mm
SMG-F-32-50 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 50 mm
SMG-F-32NN-5 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 5 mm
SMG-F-32NN-10 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 10 mm
SMG-F-32NN-15 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 15 mm
SMG-F-32NN-20 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 20 mm
SMG-F-32NN-25 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 25 mm
SMG-F-32NN-30 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 30 mm
SMG-F-32NN-40 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 40 mm
SMG-F-32NN-50 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 50 mm
SMG-F-32GN-5 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 5 mm
SMG-F-32GN-10 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 10 mm
SMG-F-32GN-15 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 15 mm
SMG-F-32GN-20 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 20 mm
SMG-F-32GN-25 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 25 mm
SMG-F-32GN-30 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 30 mm
SMG-F-32GN-40 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 40 mm
SMG-F-32GN-50 Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 50 mm
SMG-LF-6-5 Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-6-10 Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-6-15 Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-6-20 Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-6-25 Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-6-30 Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-10-5 Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-10-10 Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-10-15 Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-10-20 Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-10-25 Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-10-30 Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-16-5 Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-16-10 Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-16-15 Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-16-20 Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-16-25 Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-16-30 Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-20-5 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-20-10 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-20-15 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-20-20 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-20-25 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-20-30 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-20-40 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 40 mm
SMG-LF-20-50 Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 50 mm
SMG-LF-25-5 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-25-10 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-25-15 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-25-20 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-25-25 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-25-30 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-25-40 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 40 mm
SMG-LF-25-50 Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 50 mm
SMG-LF-32-5 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-32-10 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-32-15 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-32-20 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-32-25 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-32-30 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-32-40 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 40 mm
SMG-LF-32-50 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 50 mm
SMG-LF-32NN-5 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 5 mm
SMG-LF-32NN-10 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 10 mm
SMG-LF-32NN-15 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 15 mm
SMG-LF-32NN-20 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 20 mm
SMG-LF-32NN-25 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 25 mm
SMG-LF-32NN-30 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 30 mm
SMG-LF-32NN-40 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 40 mm
SMG-LF-32NN-50 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 50 mm
SMG-LF-32GN-5 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 5 mm
SMG-LF-32GN-10 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 10 mm
SMG-LF-32GN-15 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 15 mm
SMG-LF-32GN-20 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 20 mm
SMG-LF-32GN-25 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 25 mm
SMG-LF-32GN-30 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 30 mm
SMG-LF-32GN-40 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 40 mm
SMG-LF-32GN-50 Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 50 mm
Compact CylindersCKD
116 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD SMG-F Super Mount Cylinder (Double Acting, Low Speed)

Brand CKD·Compact Cylinders

Available part numbers (116)

SMG-F-6-5, SMG-F-6-10, SMG-F-6-15, SMG-F-6-20, SMG-F-6-25, SMG-F-6-30, SMG-F-10-5, SMG-F-10-10, SMG-F-10-15, SMG-F-10-20 + 106 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SMG-F-6-5Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-6-10Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-6-15Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-6-20Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-6-25Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-6-30Model: SMG-F (no switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-10-5Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-10-10Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-10-15Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-10-20Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-10-25Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-10-30Model: SMG-F (no switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-16-5Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-16-10Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-16-15Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-16-20Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-16-25Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-16-30Model: SMG-F (no switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-20-5Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-20-10Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-20-15Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-20-20Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-20-25Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-20-30Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-20-40Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 40 mm
SMG-F-20-50Model: SMG-F (no switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 50 mm
SMG-F-25-5Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-25-10Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-25-15Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-25-20Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-25-25Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-25-30Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-25-40Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 40 mm
SMG-F-25-50Model: SMG-F (no switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 50 mm
SMG-F-32-5Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 5 mm
SMG-F-32-10Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 10 mm
SMG-F-32-15Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 15 mm
SMG-F-32-20Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 20 mm
SMG-F-32-25Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 25 mm
SMG-F-32-30Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 30 mm
SMG-F-32-40Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 40 mm
SMG-F-32-50Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 50 mm
SMG-F-32NN-5Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 5 mm
SMG-F-32NN-10Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 10 mm
SMG-F-32NN-15Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 15 mm
SMG-F-32NN-20Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 20 mm
SMG-F-32NN-25Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 25 mm
SMG-F-32NN-30Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 30 mm
SMG-F-32NN-40Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 40 mm
SMG-F-32NN-50Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 50 mm
SMG-F-32GN-5Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 5 mm
SMG-F-32GN-10Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 10 mm
SMG-F-32GN-15Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 15 mm
SMG-F-32GN-20Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 20 mm
SMG-F-32GN-25Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 25 mm
SMG-F-32GN-30Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 30 mm
SMG-F-32GN-40Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 40 mm
SMG-F-32GN-50Model: SMG-F (no switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 50 mm
SMG-LF-6-5Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-6-10Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-6-15Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-6-20Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-6-25Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-6-30Model: SMG-LF (switch magnet) | Bore: 6 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-10-5Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-10-10Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-10-15Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-10-20Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-10-25Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-10-30Model: SMG-LF (switch magnet) | Bore: 10 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-16-5Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-16-10Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-16-15Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-16-20Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-16-25Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-16-30Model: SMG-LF (switch magnet) | Bore: 16 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-20-5Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-20-10Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-20-15Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-20-20Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-20-25Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-20-30Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-20-40Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 40 mm
SMG-LF-20-50Model: SMG-LF (switch magnet) | Bore: 20 mm | Port thread: Rc | Stroke: 50 mm
SMG-LF-25-5Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-25-10Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-25-15Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-25-20Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-25-25Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-25-30Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-25-40Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 40 mm
SMG-LF-25-50Model: SMG-LF (switch magnet) | Bore: 25 mm | Port thread: Rc | Stroke: 50 mm
SMG-LF-32-5Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 5 mm
SMG-LF-32-10Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 10 mm
SMG-LF-32-15Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 15 mm
SMG-LF-32-20Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 20 mm
SMG-LF-32-25Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 25 mm
SMG-LF-32-30Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 30 mm
SMG-LF-32-40Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 40 mm
SMG-LF-32-50Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: Rc | Stroke: 50 mm
SMG-LF-32NN-5Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 5 mm
SMG-LF-32NN-10Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 10 mm
SMG-LF-32NN-15Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 15 mm
SMG-LF-32NN-20Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 20 mm
SMG-LF-32NN-25Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 25 mm
SMG-LF-32NN-30Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 30 mm
SMG-LF-32NN-40Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 40 mm
SMG-LF-32NN-50Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: NPT | Stroke: 50 mm
SMG-LF-32GN-5Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 5 mm
SMG-LF-32GN-10Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 10 mm
SMG-LF-32GN-15Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 15 mm
SMG-LF-32GN-20Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 20 mm
SMG-LF-32GN-25Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 25 mm
SMG-LF-32GN-30Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 30 mm
SMG-LF-32GN-40Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 40 mm
SMG-LF-32GN-50Model: SMG-LF (switch magnet) | Bore: 32 mm | Port thread: G | Stroke: 50 mm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
