CKD SMG-M Super Mount Cylinder (Double Acting, Non-Rotating)

CKD SMG-M Super Mount Cylinder (Double Acting, Non-Rotating)

CKD SMG-M double acting non-rotating super mount cylinder with guide bar anti-rotation, bore 6 to 32 mm.

Key features

  • Anti-rotation guide: non-rotating accuracy ±0.8° (bore 6-16) / ±0.5° (bore 20-32)
  • Allowable rotating torque 0.008 N·m (bore 6) to 0.67 N·m (bore 32)
  • Standard strokes 5-60 mm (bore 6-16) and 5-100 mm (bore 20-32)
  • NPT (NN) and G (GN) port threads for bore 32 are made to order
  • Auto switches (order separately or appended to the code): reed K0H/K0V, K5H/K5V; solid state K2H/K2V, K3H/K3V, K2YH/K2YV, K3YH/K3YV (2-colour); lead 1/3/5 m; switch qty R/H/D

Specifications

Fluid Compressed air
Action Double acting, non-rotating
Min. working pressure 0.15 MPa (6), 0.10 MPa (10-16), 0.08 MPa (20-32)
Max. working pressure 0.7 MPa
Proof pressure 1.05 MPa
Ambient temperature -10 to 60°C (no freezing)
Piston speed 50 to 500 mm/s
Stroke tolerance +1.5/0 mm
Cushion Rubber cushion
Source CKD Korea catalog CB-029SK-9, p. 1492-1497
SMG-M-6-5 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 5 mm | Port: M5
SMG-M-6-10 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 10 mm | Port: M5
SMG-M-6-15 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 15 mm | Port: M5
SMG-M-6-20 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 20 mm | Port: M5
SMG-M-6-25 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 25 mm | Port: M5
SMG-M-6-30 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 30 mm | Port: M5
SMG-M-6-40 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 40 mm | Port: M5
SMG-M-6-50 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 50 mm | Port: M5
SMG-M-6-60 Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 60 mm | Port: M5
SMG-M-10-5 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 5 mm | Port: M5
SMG-M-10-10 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 10 mm | Port: M5
SMG-M-10-15 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 15 mm | Port: M5
SMG-M-10-20 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 20 mm | Port: M5
SMG-M-10-25 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 25 mm | Port: M5
SMG-M-10-30 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 30 mm | Port: M5
SMG-M-10-40 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 40 mm | Port: M5
SMG-M-10-50 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 50 mm | Port: M5
SMG-M-10-60 Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 60 mm | Port: M5
SMG-M-16-5 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SMG-M-16-10 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SMG-M-16-15 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SMG-M-16-20 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SMG-M-16-25 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SMG-M-16-30 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SMG-M-16-40 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 40 mm | Port: M5
SMG-M-16-50 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 50 mm | Port: M5
SMG-M-16-60 Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 60 mm | Port: M5
SMG-M-20-5 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SMG-M-20-10 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SMG-M-20-15 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SMG-M-20-20 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SMG-M-20-25 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SMG-M-20-30 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SMG-M-20-40 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 40 mm | Port: M5
SMG-M-20-50 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 50 mm | Port: M5
SMG-M-20-60 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 60 mm | Port: M5
SMG-M-20-70 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 70 mm | Port: M5
SMG-M-20-80 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 80 mm | Port: M5
SMG-M-20-90 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 90 mm | Port: M5
SMG-M-20-100 Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 100 mm | Port: M5
SMG-M-25-5 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SMG-M-25-10 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SMG-M-25-15 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SMG-M-25-20 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SMG-M-25-25 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SMG-M-25-30 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SMG-M-25-40 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SMG-M-25-50 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SMG-M-25-60 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 60 mm | Port: M5
SMG-M-25-70 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 70 mm | Port: M5
SMG-M-25-80 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 80 mm | Port: M5
SMG-M-25-90 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 90 mm | Port: M5
SMG-M-25-100 Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 100 mm | Port: M5
SMG-M-32-5 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SMG-M-32-10 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SMG-M-32-15 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SMG-M-32-20 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SMG-M-32-25 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SMG-M-32-30 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SMG-M-32-40 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SMG-M-32-50 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SMG-M-32-60 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 60 mm | Port: Rc1/8
SMG-M-32-70 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 70 mm | Port: Rc1/8
SMG-M-32-80 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 80 mm | Port: Rc1/8
SMG-M-32-90 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 90 mm | Port: Rc1/8
SMG-M-32-100 Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 100 mm | Port: Rc1/8
SMG-ML-6-5 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 5 mm | Port: M5
SMG-ML-6-10 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 10 mm | Port: M5
SMG-ML-6-15 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 15 mm | Port: M5
SMG-ML-6-20 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 20 mm | Port: M5
SMG-ML-6-25 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 25 mm | Port: M5
SMG-ML-6-30 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 30 mm | Port: M5
SMG-ML-6-40 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 40 mm | Port: M5
SMG-ML-6-50 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 50 mm | Port: M5
SMG-ML-6-60 Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 60 mm | Port: M5
SMG-ML-10-5 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 5 mm | Port: M5
SMG-ML-10-10 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 10 mm | Port: M5
SMG-ML-10-15 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 15 mm | Port: M5
SMG-ML-10-20 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 20 mm | Port: M5
SMG-ML-10-25 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 25 mm | Port: M5
SMG-ML-10-30 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 30 mm | Port: M5
SMG-ML-10-40 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 40 mm | Port: M5
SMG-ML-10-50 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 50 mm | Port: M5
SMG-ML-10-60 Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 60 mm | Port: M5
SMG-ML-16-5 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SMG-ML-16-10 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SMG-ML-16-15 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SMG-ML-16-20 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SMG-ML-16-25 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SMG-ML-16-30 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SMG-ML-16-40 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 40 mm | Port: M5
SMG-ML-16-50 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 50 mm | Port: M5
SMG-ML-16-60 Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 60 mm | Port: M5
SMG-ML-20-5 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SMG-ML-20-10 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SMG-ML-20-15 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SMG-ML-20-20 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SMG-ML-20-25 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SMG-ML-20-30 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SMG-ML-20-40 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 40 mm | Port: M5
SMG-ML-20-50 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 50 mm | Port: M5
SMG-ML-20-60 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 60 mm | Port: M5
SMG-ML-20-70 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 70 mm | Port: M5
SMG-ML-20-80 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 80 mm | Port: M5
SMG-ML-20-90 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 90 mm | Port: M5
SMG-ML-20-100 Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 100 mm | Port: M5
SMG-ML-25-5 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SMG-ML-25-10 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SMG-ML-25-15 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SMG-ML-25-20 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SMG-ML-25-25 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SMG-ML-25-30 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SMG-ML-25-40 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SMG-ML-25-50 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SMG-ML-25-60 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 60 mm | Port: M5
SMG-ML-25-70 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 70 mm | Port: M5
SMG-ML-25-80 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 80 mm | Port: M5
SMG-ML-25-90 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 90 mm | Port: M5
SMG-ML-25-100 Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 100 mm | Port: M5
SMG-ML-32-5 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SMG-ML-32-10 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SMG-ML-32-15 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SMG-ML-32-20 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SMG-ML-32-25 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SMG-ML-32-30 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SMG-ML-32-40 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SMG-ML-32-50 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SMG-ML-32-60 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 60 mm | Port: Rc1/8
SMG-ML-32-70 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 70 mm | Port: Rc1/8
SMG-ML-32-80 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 80 mm | Port: Rc1/8
SMG-ML-32-90 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 90 mm | Port: Rc1/8
SMG-ML-32-100 Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 100 mm | Port: Rc1/8
Compact CylindersCKD
132 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD SMG-M Super Mount Cylinder (Double Acting, Non-Rotating)

Brand CKD·Compact Cylinders

Available part numbers (132)

SMG-M-6-5, SMG-M-6-10, SMG-M-6-15, SMG-M-6-20, SMG-M-6-25, SMG-M-6-30, SMG-M-6-40, SMG-M-6-50, SMG-M-6-60, SMG-M-10-5 + 122 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SMG-M-6-5Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 5 mm | Port: M5
SMG-M-6-10Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 10 mm | Port: M5
SMG-M-6-15Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 15 mm | Port: M5
SMG-M-6-20Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 20 mm | Port: M5
SMG-M-6-25Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 25 mm | Port: M5
SMG-M-6-30Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 30 mm | Port: M5
SMG-M-6-40Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 40 mm | Port: M5
SMG-M-6-50Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 50 mm | Port: M5
SMG-M-6-60Model: SMG-M (no switch magnet) | Bore: 6 mm | Stroke: 60 mm | Port: M5
SMG-M-10-5Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 5 mm | Port: M5
SMG-M-10-10Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 10 mm | Port: M5
SMG-M-10-15Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 15 mm | Port: M5
SMG-M-10-20Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 20 mm | Port: M5
SMG-M-10-25Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 25 mm | Port: M5
SMG-M-10-30Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 30 mm | Port: M5
SMG-M-10-40Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 40 mm | Port: M5
SMG-M-10-50Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 50 mm | Port: M5
SMG-M-10-60Model: SMG-M (no switch magnet) | Bore: 10 mm | Stroke: 60 mm | Port: M5
SMG-M-16-5Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SMG-M-16-10Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SMG-M-16-15Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SMG-M-16-20Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SMG-M-16-25Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SMG-M-16-30Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SMG-M-16-40Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 40 mm | Port: M5
SMG-M-16-50Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 50 mm | Port: M5
SMG-M-16-60Model: SMG-M (no switch magnet) | Bore: 16 mm | Stroke: 60 mm | Port: M5
SMG-M-20-5Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SMG-M-20-10Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SMG-M-20-15Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SMG-M-20-20Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SMG-M-20-25Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SMG-M-20-30Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SMG-M-20-40Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 40 mm | Port: M5
SMG-M-20-50Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 50 mm | Port: M5
SMG-M-20-60Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 60 mm | Port: M5
SMG-M-20-70Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 70 mm | Port: M5
SMG-M-20-80Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 80 mm | Port: M5
SMG-M-20-90Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 90 mm | Port: M5
SMG-M-20-100Model: SMG-M (no switch magnet) | Bore: 20 mm | Stroke: 100 mm | Port: M5
SMG-M-25-5Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SMG-M-25-10Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SMG-M-25-15Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SMG-M-25-20Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SMG-M-25-25Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SMG-M-25-30Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SMG-M-25-40Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SMG-M-25-50Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SMG-M-25-60Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 60 mm | Port: M5
SMG-M-25-70Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 70 mm | Port: M5
SMG-M-25-80Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 80 mm | Port: M5
SMG-M-25-90Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 90 mm | Port: M5
SMG-M-25-100Model: SMG-M (no switch magnet) | Bore: 25 mm | Stroke: 100 mm | Port: M5
SMG-M-32-5Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SMG-M-32-10Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SMG-M-32-15Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SMG-M-32-20Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SMG-M-32-25Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SMG-M-32-30Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SMG-M-32-40Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SMG-M-32-50Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SMG-M-32-60Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 60 mm | Port: Rc1/8
SMG-M-32-70Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 70 mm | Port: Rc1/8
SMG-M-32-80Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 80 mm | Port: Rc1/8
SMG-M-32-90Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 90 mm | Port: Rc1/8
SMG-M-32-100Model: SMG-M (no switch magnet) | Bore: 32 mm | Stroke: 100 mm | Port: Rc1/8
SMG-ML-6-5Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 5 mm | Port: M5
SMG-ML-6-10Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 10 mm | Port: M5
SMG-ML-6-15Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 15 mm | Port: M5
SMG-ML-6-20Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 20 mm | Port: M5
SMG-ML-6-25Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 25 mm | Port: M5
SMG-ML-6-30Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 30 mm | Port: M5
SMG-ML-6-40Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 40 mm | Port: M5
SMG-ML-6-50Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 50 mm | Port: M5
SMG-ML-6-60Model: SMG-ML (switch magnet) | Bore: 6 mm | Stroke: 60 mm | Port: M5
SMG-ML-10-5Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 5 mm | Port: M5
SMG-ML-10-10Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 10 mm | Port: M5
SMG-ML-10-15Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 15 mm | Port: M5
SMG-ML-10-20Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 20 mm | Port: M5
SMG-ML-10-25Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 25 mm | Port: M5
SMG-ML-10-30Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 30 mm | Port: M5
SMG-ML-10-40Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 40 mm | Port: M5
SMG-ML-10-50Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 50 mm | Port: M5
SMG-ML-10-60Model: SMG-ML (switch magnet) | Bore: 10 mm | Stroke: 60 mm | Port: M5
SMG-ML-16-5Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SMG-ML-16-10Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SMG-ML-16-15Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SMG-ML-16-20Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SMG-ML-16-25Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SMG-ML-16-30Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SMG-ML-16-40Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 40 mm | Port: M5
SMG-ML-16-50Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 50 mm | Port: M5
SMG-ML-16-60Model: SMG-ML (switch magnet) | Bore: 16 mm | Stroke: 60 mm | Port: M5
SMG-ML-20-5Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SMG-ML-20-10Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SMG-ML-20-15Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SMG-ML-20-20Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SMG-ML-20-25Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SMG-ML-20-30Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SMG-ML-20-40Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 40 mm | Port: M5
SMG-ML-20-50Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 50 mm | Port: M5
SMG-ML-20-60Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 60 mm | Port: M5
SMG-ML-20-70Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 70 mm | Port: M5
SMG-ML-20-80Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 80 mm | Port: M5
SMG-ML-20-90Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 90 mm | Port: M5
SMG-ML-20-100Model: SMG-ML (switch magnet) | Bore: 20 mm | Stroke: 100 mm | Port: M5
SMG-ML-25-5Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SMG-ML-25-10Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SMG-ML-25-15Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SMG-ML-25-20Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SMG-ML-25-25Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SMG-ML-25-30Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SMG-ML-25-40Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SMG-ML-25-50Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SMG-ML-25-60Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 60 mm | Port: M5
SMG-ML-25-70Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 70 mm | Port: M5
SMG-ML-25-80Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 80 mm | Port: M5
SMG-ML-25-90Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 90 mm | Port: M5
SMG-ML-25-100Model: SMG-ML (switch magnet) | Bore: 25 mm | Stroke: 100 mm | Port: M5
SMG-ML-32-5Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SMG-ML-32-10Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SMG-ML-32-15Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SMG-ML-32-20Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SMG-ML-32-25Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SMG-ML-32-30Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SMG-ML-32-40Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SMG-ML-32-50Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SMG-ML-32-60Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 60 mm | Port: Rc1/8
SMG-ML-32-70Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 70 mm | Port: Rc1/8
SMG-ML-32-80Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 80 mm | Port: Rc1/8
SMG-ML-32-90Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 90 mm | Port: Rc1/8
SMG-ML-32-100Model: SMG-ML (switch magnet) | Bore: 32 mm | Stroke: 100 mm | Port: Rc1/8

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
