CKD SMW2-FP1 Metering Valve with Silencer (Food Grade, R1/8-1/4)

CKD SMW2-FP1 Metering Valve with Silencer (Food Grade, R1/8-1/4)

CKD SMW2-FP1 compact all-plastic exhaust metering valves with sintered PP silencer element.

Key features

  • FP1 food-processing series using NSF H1 registered grease
  • 50% smaller and 80% lighter than previous series
  • Push-lock needle knob
  • All-plastic construction, no separation needed for disposal

Specifications

Fluid Compressed air
Max. operating pressure 0.7 MPa
Proof pressure 1.05 MPa
Needle turns 9
Element Sintered PP
Source CKD Korea catalog CC-1271K-5, p. 309
SMW2-6A-FP1 Port: R1/8 | Flow: 370 L/min | Noise reduction: 23 dB(A)
SMW2-8A-FP1 Port: R1/4 | Flow: 660 L/min | Noise reduction: 28 dB(A)
Speed ControllersCKD
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD SMW2-FP1 Metering Valve with Silencer (Food Grade, R1/8-1/4)

Brand CKD·Speed Controllers

Available part numbers (2)

SMW2-6A-FP1, SMW2-8A-FP1

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SMW2-6A-FP1Port: R1/8 | Flow: 370 L/min | Noise reduction: 23 dB(A)
SMW2-8A-FP1Port: R1/4 | Flow: 660 L/min | Noise reduction: 28 dB(A)
