CKD SSD-D Super Compact Cylinder (Double Acting, Double Rod)

CKD SSD-D Super Compact Cylinder (Double Acting, Double Rod)

CKD SSD-D super compact cylinder, double acting double-rod type with equal thrust and speed in both directions, bore 12 to 160 mm.

Key features

  • Through rod on both ends; equal effective area on both sides
  • Switch-ready version (L) has a built-in magnet for T-type auto switches (T0H, T2H, T2YH, T3H etc.)
  • Standard strokes 5 to 50 mm (bore 12-100) and 10 to 100 mm (bore 125-160)
  • No cushion (12-100), rubber cushion (125-160)
  • Foot (LB, LB2) and flange (FA) mounting; LB and CB only for bore 125-160

Specifications

Action Double acting, double rod
Fluid Compressed air
Max. operating pressure 1.0 MPa
Min. operating pressure 0.15 MPa (12-50), 0.1 (63-100), 0.05 (125-160)
Proof pressure 1.6 MPa
Ambient temperature -10 to 60°C (no freezing)
Piston speed 50-500 mm/s (12-50), 50-300 mm/s (63-160)
Stroke tolerance +1.0/0 mm (12-100), +2.0/0 mm (125-160)
Source CKD Korea catalog CB-029SK-9, p. 1276-1287
SSD-D-12-5 Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 5 mm | Port: M5
SSD-D-12-10 Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 10 mm | Port: M5
SSD-D-12-15 Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 15 mm | Port: M5
SSD-D-12-20 Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 20 mm | Port: M5
SSD-D-12-25 Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 25 mm | Port: M5
SSD-D-12-30 Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 30 mm | Port: M5
SSD-D-16-5 Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SSD-D-16-10 Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SSD-D-16-15 Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SSD-D-16-20 Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SSD-D-16-25 Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SSD-D-16-30 Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SSD-D-20-5 Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SSD-D-20-10 Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SSD-D-20-15 Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SSD-D-20-20 Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SSD-D-20-25 Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SSD-D-20-30 Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SSD-D-25-5 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SSD-D-25-10 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SSD-D-25-15 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SSD-D-25-20 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SSD-D-25-25 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SSD-D-25-30 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SSD-D-25-40 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SSD-D-25-50 Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SSD-D-32-5 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SSD-D-32-10 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SSD-D-32-15 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SSD-D-32-20 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SSD-D-32-25 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SSD-D-32-30 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SSD-D-32-40 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SSD-D-32-50 Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SSD-D-40-5 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 5 mm | Port: Rc1/8
SSD-D-40-10 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 10 mm | Port: Rc1/8
SSD-D-40-15 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 15 mm | Port: Rc1/8
SSD-D-40-20 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 20 mm | Port: Rc1/8
SSD-D-40-25 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 25 mm | Port: Rc1/8
SSD-D-40-30 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 30 mm | Port: Rc1/8
SSD-D-40-40 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 40 mm | Port: Rc1/8
SSD-D-40-50 Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 50 mm | Port: Rc1/8
SSD-D-50-5 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 5 mm | Port: Rc1/4
SSD-D-50-10 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 10 mm | Port: Rc1/4
SSD-D-50-15 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 15 mm | Port: Rc1/4
SSD-D-50-20 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 20 mm | Port: Rc1/4
SSD-D-50-25 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 25 mm | Port: Rc1/4
SSD-D-50-30 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 30 mm | Port: Rc1/4
SSD-D-50-40 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 40 mm | Port: Rc1/4
SSD-D-50-50 Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 50 mm | Port: Rc1/4
SSD-D-63-5 Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 5 mm | Port: Rc1/4
SSD-D-63-10 Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 10 mm | Port: Rc1/4
SSD-D-63-20 Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 20 mm | Port: Rc1/4
SSD-D-63-30 Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 30 mm | Port: Rc1/4
SSD-D-63-40 Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 40 mm | Port: Rc1/4
SSD-D-63-50 Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 50 mm | Port: Rc1/4
SSD-D-80-5 Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 5 mm | Port: Rc3/8
SSD-D-80-10 Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-80-20 Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-80-30 Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-80-40 Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-80-50 Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-100-5 Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 5 mm | Port: Rc3/8
SSD-D-100-10 Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-100-20 Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-100-30 Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-100-40 Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-100-50 Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-125-10 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-125-20 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-125-30 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-125-40 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-125-50 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-125-60 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 60 mm | Port: Rc3/8
SSD-D-125-70 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 70 mm | Port: Rc3/8
SSD-D-125-80 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 80 mm | Port: Rc3/8
SSD-D-125-90 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 90 mm | Port: Rc3/8
SSD-D-125-100 Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 100 mm | Port: Rc3/8
SSD-D-140-10 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-140-20 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-140-30 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-140-40 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-140-50 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-140-60 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 60 mm | Port: Rc3/8
SSD-D-140-70 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 70 mm | Port: Rc3/8
SSD-D-140-80 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 80 mm | Port: Rc3/8
SSD-D-140-90 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 90 mm | Port: Rc3/8
SSD-D-140-100 Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 100 mm | Port: Rc3/8
SSD-D-160-10 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-160-20 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-160-30 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-160-40 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-160-50 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-160-60 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 60 mm | Port: Rc3/8
SSD-D-160-70 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 70 mm | Port: Rc3/8
SSD-D-160-80 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 80 mm | Port: Rc3/8
SSD-D-160-90 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 90 mm | Port: Rc3/8
SSD-D-160-100 Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 100 mm | Port: Rc3/8
SSD-DL-12-5 Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 5 mm | Port: M5
SSD-DL-12-10 Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 10 mm | Port: M5
SSD-DL-12-15 Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 15 mm | Port: M5
SSD-DL-12-20 Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 20 mm | Port: M5
SSD-DL-12-25 Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 25 mm | Port: M5
SSD-DL-12-30 Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 30 mm | Port: M5
SSD-DL-16-5 Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SSD-DL-16-10 Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SSD-DL-16-15 Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SSD-DL-16-20 Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SSD-DL-16-25 Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SSD-DL-16-30 Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SSD-DL-20-5 Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SSD-DL-20-10 Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SSD-DL-20-15 Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SSD-DL-20-20 Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SSD-DL-20-25 Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SSD-DL-20-30 Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SSD-DL-25-5 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SSD-DL-25-10 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SSD-DL-25-15 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SSD-DL-25-20 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SSD-DL-25-25 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SSD-DL-25-30 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SSD-DL-25-40 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SSD-DL-25-50 Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SSD-DL-32-5 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SSD-DL-32-10 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SSD-DL-32-15 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SSD-DL-32-20 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SSD-DL-32-25 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SSD-DL-32-30 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SSD-DL-32-40 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SSD-DL-32-50 Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SSD-DL-40-5 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 5 mm | Port: Rc1/8
SSD-DL-40-10 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 10 mm | Port: Rc1/8
SSD-DL-40-15 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 15 mm | Port: Rc1/8
SSD-DL-40-20 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 20 mm | Port: Rc1/8
SSD-DL-40-25 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 25 mm | Port: Rc1/8
SSD-DL-40-30 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 30 mm | Port: Rc1/8
SSD-DL-40-40 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 40 mm | Port: Rc1/8
SSD-DL-40-50 Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 50 mm | Port: Rc1/8
SSD-DL-50-5 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 5 mm | Port: Rc1/4
SSD-DL-50-10 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 10 mm | Port: Rc1/4
SSD-DL-50-15 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 15 mm | Port: Rc1/4
SSD-DL-50-20 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 20 mm | Port: Rc1/4
SSD-DL-50-25 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 25 mm | Port: Rc1/4
SSD-DL-50-30 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 30 mm | Port: Rc1/4
SSD-DL-50-40 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 40 mm | Port: Rc1/4
SSD-DL-50-50 Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 50 mm | Port: Rc1/4
SSD-DL-63-5 Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 5 mm | Port: Rc1/4
SSD-DL-63-10 Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 10 mm | Port: Rc1/4
SSD-DL-63-20 Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 20 mm | Port: Rc1/4
SSD-DL-63-30 Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 30 mm | Port: Rc1/4
SSD-DL-63-40 Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 40 mm | Port: Rc1/4
SSD-DL-63-50 Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 50 mm | Port: Rc1/4
SSD-DL-80-5 Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 5 mm | Port: Rc3/8
SSD-DL-80-10 Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-80-20 Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-80-30 Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-80-40 Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-80-50 Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-100-5 Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 5 mm | Port: Rc3/8
SSD-DL-100-10 Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-100-20 Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-100-30 Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-100-40 Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-100-50 Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-125-10 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-125-20 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-125-30 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-125-40 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-125-50 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-125-60 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 60 mm | Port: Rc3/8
SSD-DL-125-70 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 70 mm | Port: Rc3/8
SSD-DL-125-80 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 80 mm | Port: Rc3/8
SSD-DL-125-90 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 90 mm | Port: Rc3/8
SSD-DL-125-100 Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 100 mm | Port: Rc3/8
SSD-DL-140-10 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-140-20 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-140-30 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-140-40 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-140-50 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-140-60 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 60 mm | Port: Rc3/8
SSD-DL-140-70 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 70 mm | Port: Rc3/8
SSD-DL-140-80 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 80 mm | Port: Rc3/8
SSD-DL-140-90 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 90 mm | Port: Rc3/8
SSD-DL-140-100 Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 100 mm | Port: Rc3/8
SSD-DL-160-10 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-160-20 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-160-30 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-160-40 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-160-50 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-160-60 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 60 mm | Port: Rc3/8
SSD-DL-160-70 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 70 mm | Port: Rc3/8
SSD-DL-160-80 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 80 mm | Port: Rc3/8
SSD-DL-160-90 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 90 mm | Port: Rc3/8
SSD-DL-160-100 Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 100 mm | Port: Rc3/8
Compact CylindersCKD
196 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD SSD-D Super Compact Cylinder (Double Acting, Double Rod)

Brand CKD·Compact Cylinders

Available part numbers (196)

SSD-D-12-5, SSD-D-12-10, SSD-D-12-15, SSD-D-12-20, SSD-D-12-25, SSD-D-12-30, SSD-D-16-5, SSD-D-16-10, SSD-D-16-15, SSD-D-16-20 + 186 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SSD-D-12-5Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 5 mm | Port: M5
SSD-D-12-10Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 10 mm | Port: M5
SSD-D-12-15Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 15 mm | Port: M5
SSD-D-12-20Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 20 mm | Port: M5
SSD-D-12-25Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 25 mm | Port: M5
SSD-D-12-30Model: SSD-D (no magnet) | Bore: 12 mm | Stroke: 30 mm | Port: M5
SSD-D-16-5Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SSD-D-16-10Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SSD-D-16-15Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SSD-D-16-20Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SSD-D-16-25Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SSD-D-16-30Model: SSD-D (no magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SSD-D-20-5Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SSD-D-20-10Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SSD-D-20-15Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SSD-D-20-20Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SSD-D-20-25Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SSD-D-20-30Model: SSD-D (no magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SSD-D-25-5Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SSD-D-25-10Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SSD-D-25-15Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SSD-D-25-20Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SSD-D-25-25Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SSD-D-25-30Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SSD-D-25-40Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SSD-D-25-50Model: SSD-D (no magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SSD-D-32-5Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SSD-D-32-10Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SSD-D-32-15Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SSD-D-32-20Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SSD-D-32-25Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SSD-D-32-30Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SSD-D-32-40Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SSD-D-32-50Model: SSD-D (no magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SSD-D-40-5Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 5 mm | Port: Rc1/8
SSD-D-40-10Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 10 mm | Port: Rc1/8
SSD-D-40-15Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 15 mm | Port: Rc1/8
SSD-D-40-20Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 20 mm | Port: Rc1/8
SSD-D-40-25Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 25 mm | Port: Rc1/8
SSD-D-40-30Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 30 mm | Port: Rc1/8
SSD-D-40-40Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 40 mm | Port: Rc1/8
SSD-D-40-50Model: SSD-D (no magnet) | Bore: 40 mm | Stroke: 50 mm | Port: Rc1/8
SSD-D-50-5Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 5 mm | Port: Rc1/4
SSD-D-50-10Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 10 mm | Port: Rc1/4
SSD-D-50-15Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 15 mm | Port: Rc1/4
SSD-D-50-20Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 20 mm | Port: Rc1/4
SSD-D-50-25Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 25 mm | Port: Rc1/4
SSD-D-50-30Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 30 mm | Port: Rc1/4
SSD-D-50-40Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 40 mm | Port: Rc1/4
SSD-D-50-50Model: SSD-D (no magnet) | Bore: 50 mm | Stroke: 50 mm | Port: Rc1/4
SSD-D-63-5Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 5 mm | Port: Rc1/4
SSD-D-63-10Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 10 mm | Port: Rc1/4
SSD-D-63-20Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 20 mm | Port: Rc1/4
SSD-D-63-30Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 30 mm | Port: Rc1/4
SSD-D-63-40Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 40 mm | Port: Rc1/4
SSD-D-63-50Model: SSD-D (no magnet) | Bore: 63 mm | Stroke: 50 mm | Port: Rc1/4
SSD-D-80-5Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 5 mm | Port: Rc3/8
SSD-D-80-10Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-80-20Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-80-30Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-80-40Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-80-50Model: SSD-D (no magnet) | Bore: 80 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-100-5Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 5 mm | Port: Rc3/8
SSD-D-100-10Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-100-20Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-100-30Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-100-40Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-100-50Model: SSD-D (no magnet) | Bore: 100 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-125-10Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-125-20Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-125-30Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-125-40Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-125-50Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-125-60Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 60 mm | Port: Rc3/8
SSD-D-125-70Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 70 mm | Port: Rc3/8
SSD-D-125-80Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 80 mm | Port: Rc3/8
SSD-D-125-90Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 90 mm | Port: Rc3/8
SSD-D-125-100Model: SSD-D (no magnet) | Bore: 125 mm | Stroke: 100 mm | Port: Rc3/8
SSD-D-140-10Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-140-20Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-140-30Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-140-40Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-140-50Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-140-60Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 60 mm | Port: Rc3/8
SSD-D-140-70Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 70 mm | Port: Rc3/8
SSD-D-140-80Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 80 mm | Port: Rc3/8
SSD-D-140-90Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 90 mm | Port: Rc3/8
SSD-D-140-100Model: SSD-D (no magnet) | Bore: 140 mm | Stroke: 100 mm | Port: Rc3/8
SSD-D-160-10Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 10 mm | Port: Rc3/8
SSD-D-160-20Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 20 mm | Port: Rc3/8
SSD-D-160-30Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 30 mm | Port: Rc3/8
SSD-D-160-40Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 40 mm | Port: Rc3/8
SSD-D-160-50Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 50 mm | Port: Rc3/8
SSD-D-160-60Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 60 mm | Port: Rc3/8
SSD-D-160-70Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 70 mm | Port: Rc3/8
SSD-D-160-80Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 80 mm | Port: Rc3/8
SSD-D-160-90Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 90 mm | Port: Rc3/8
SSD-D-160-100Model: SSD-D (no magnet) | Bore: 160 mm | Stroke: 100 mm | Port: Rc3/8
SSD-DL-12-5Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 5 mm | Port: M5
SSD-DL-12-10Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 10 mm | Port: M5
SSD-DL-12-15Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 15 mm | Port: M5
SSD-DL-12-20Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 20 mm | Port: M5
SSD-DL-12-25Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 25 mm | Port: M5
SSD-DL-12-30Model: SSD-DL (switch magnet) | Bore: 12 mm | Stroke: 30 mm | Port: M5
SSD-DL-16-5Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 5 mm | Port: M5
SSD-DL-16-10Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 10 mm | Port: M5
SSD-DL-16-15Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 15 mm | Port: M5
SSD-DL-16-20Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 20 mm | Port: M5
SSD-DL-16-25Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 25 mm | Port: M5
SSD-DL-16-30Model: SSD-DL (switch magnet) | Bore: 16 mm | Stroke: 30 mm | Port: M5
SSD-DL-20-5Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 5 mm | Port: M5
SSD-DL-20-10Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 10 mm | Port: M5
SSD-DL-20-15Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 15 mm | Port: M5
SSD-DL-20-20Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 20 mm | Port: M5
SSD-DL-20-25Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 25 mm | Port: M5
SSD-DL-20-30Model: SSD-DL (switch magnet) | Bore: 20 mm | Stroke: 30 mm | Port: M5
SSD-DL-25-5Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 5 mm | Port: M5
SSD-DL-25-10Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 10 mm | Port: M5
SSD-DL-25-15Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 15 mm | Port: M5
SSD-DL-25-20Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 20 mm | Port: M5
SSD-DL-25-25Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 25 mm | Port: M5
SSD-DL-25-30Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 30 mm | Port: M5
SSD-DL-25-40Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 40 mm | Port: M5
SSD-DL-25-50Model: SSD-DL (switch magnet) | Bore: 25 mm | Stroke: 50 mm | Port: M5
SSD-DL-32-5Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 5 mm | Port: Rc1/8
SSD-DL-32-10Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 10 mm | Port: Rc1/8
SSD-DL-32-15Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 15 mm | Port: Rc1/8
SSD-DL-32-20Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 20 mm | Port: Rc1/8
SSD-DL-32-25Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 25 mm | Port: Rc1/8
SSD-DL-32-30Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 30 mm | Port: Rc1/8
SSD-DL-32-40Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 40 mm | Port: Rc1/8
SSD-DL-32-50Model: SSD-DL (switch magnet) | Bore: 32 mm | Stroke: 50 mm | Port: Rc1/8
SSD-DL-40-5Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 5 mm | Port: Rc1/8
SSD-DL-40-10Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 10 mm | Port: Rc1/8
SSD-DL-40-15Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 15 mm | Port: Rc1/8
SSD-DL-40-20Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 20 mm | Port: Rc1/8
SSD-DL-40-25Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 25 mm | Port: Rc1/8
SSD-DL-40-30Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 30 mm | Port: Rc1/8
SSD-DL-40-40Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 40 mm | Port: Rc1/8
SSD-DL-40-50Model: SSD-DL (switch magnet) | Bore: 40 mm | Stroke: 50 mm | Port: Rc1/8
SSD-DL-50-5Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 5 mm | Port: Rc1/4
SSD-DL-50-10Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 10 mm | Port: Rc1/4
SSD-DL-50-15Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 15 mm | Port: Rc1/4
SSD-DL-50-20Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 20 mm | Port: Rc1/4
SSD-DL-50-25Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 25 mm | Port: Rc1/4
SSD-DL-50-30Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 30 mm | Port: Rc1/4
SSD-DL-50-40Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 40 mm | Port: Rc1/4
SSD-DL-50-50Model: SSD-DL (switch magnet) | Bore: 50 mm | Stroke: 50 mm | Port: Rc1/4
SSD-DL-63-5Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 5 mm | Port: Rc1/4
SSD-DL-63-10Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 10 mm | Port: Rc1/4
SSD-DL-63-20Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 20 mm | Port: Rc1/4
SSD-DL-63-30Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 30 mm | Port: Rc1/4
SSD-DL-63-40Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 40 mm | Port: Rc1/4
SSD-DL-63-50Model: SSD-DL (switch magnet) | Bore: 63 mm | Stroke: 50 mm | Port: Rc1/4
SSD-DL-80-5Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 5 mm | Port: Rc3/8
SSD-DL-80-10Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-80-20Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-80-30Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-80-40Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-80-50Model: SSD-DL (switch magnet) | Bore: 80 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-100-5Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 5 mm | Port: Rc3/8
SSD-DL-100-10Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-100-20Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-100-30Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-100-40Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-100-50Model: SSD-DL (switch magnet) | Bore: 100 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-125-10Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-125-20Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-125-30Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-125-40Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-125-50Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-125-60Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 60 mm | Port: Rc3/8
SSD-DL-125-70Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 70 mm | Port: Rc3/8
SSD-DL-125-80Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 80 mm | Port: Rc3/8
SSD-DL-125-90Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 90 mm | Port: Rc3/8
SSD-DL-125-100Model: SSD-DL (switch magnet) | Bore: 125 mm | Stroke: 100 mm | Port: Rc3/8
SSD-DL-140-10Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-140-20Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-140-30Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-140-40Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-140-50Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-140-60Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 60 mm | Port: Rc3/8
SSD-DL-140-70Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 70 mm | Port: Rc3/8
SSD-DL-140-80Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 80 mm | Port: Rc3/8
SSD-DL-140-90Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 90 mm | Port: Rc3/8
SSD-DL-140-100Model: SSD-DL (switch magnet) | Bore: 140 mm | Stroke: 100 mm | Port: Rc3/8
SSD-DL-160-10Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 10 mm | Port: Rc3/8
SSD-DL-160-20Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 20 mm | Port: Rc3/8
SSD-DL-160-30Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 30 mm | Port: Rc3/8
SSD-DL-160-40Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 40 mm | Port: Rc3/8
SSD-DL-160-50Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 50 mm | Port: Rc3/8
SSD-DL-160-60Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 60 mm | Port: Rc3/8
SSD-DL-160-70Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 70 mm | Port: Rc3/8
SSD-DL-160-80Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 80 mm | Port: Rc3/8
SSD-DL-160-90Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 90 mm | Port: Rc3/8
SSD-DL-160-100Model: SSD-DL (switch magnet) | Bore: 160 mm | Stroke: 100 mm | Port: Rc3/8

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
