CKD UP-9102 Air Fiber Tube and PTN2 Barb Fittings (Anti-Static, P80)

CKD UP-9102 Air Fiber Tube and PTN2 Barb Fittings (Anti-Static, P80)

CKD air fiber: 1.8 mm OD anti-static conductive urethane micro tube UP-9102 with dedicated PTN2 barb fittings in P80 oil-free specification.

Key features

  • Tube 1.8 x 1.0 mm, 20 m roll, conductive urethane (volume resistivity 1x10^8 Ω·cm black)
  • Colours black, white, clear, clear blue, clear green; yellow and red made to order
  • PTN2 straight (M3, M5, R1/8), PTNL2 elbow (M3, M5) and barb nipples to ø3.2/ø4/ø6 urethane tube
  • P80 fittings: brass, electroless nickel, NBR seals, no grease (P70/P74/P84 identical; order P80)
  • Min. mounting radius 4 mm; fitting flow 20 L/min (straight), 13 L/min (elbow) at 0.5 MPa

Specifications

Fluid Compressed air
Operating pressure -100 kPa to 0.7 MPa (20°C)
Ambient temperature -10 to 60°C (no freezing)
Tube burst pressure 2.1 MPa (reference)
Clean spec P80 oil-free
Fitting sales unit 10 pcs/set
Source CKD Korea catalog CB-033S-4, p. 979-983
UP-9102-20-F1-P80 Item: Air fiber tube, 20 m | Size / port: ø1.8 x ø1.0 | Color: Black
UP-9102-20-W-F1-P80 Item: Air fiber tube, 20 m | Size / port: ø1.8 x ø1.0 | Color: White
UP-9102-20-C-F1-P80 Item: Air fiber tube, 20 m | Size / port: ø1.8 x ø1.0 | Color: Clear
UP-9102-20-CB-F1-P80 Item: Air fiber tube, 20 m | Size / port: ø1.8 x ø1.0 | Color: Clear blue
UP-9102-20-CG-F1-P80 Item: Air fiber tube, 20 m | Size / port: ø1.8 x ø1.0 | Color: Clear green
UP-9102-20-Y-F1-P80 Item: Air fiber tube, 20 m | Size / port: ø1.8 x ø1.0 | Color: Yellow (MTO)
UP-9102-20-R-F1-P80 Item: Air fiber tube, 20 m | Size / port: ø1.8 x ø1.0 | Color: Red (MTO)
PTN2-M3-P80 Item: Barb fitting, straight | Size / port: M3x0.5 | Color: Brass, nickel plated
PTN2-M5-P80 Item: Barb fitting, straight | Size / port: M5x0.8 | Color: Brass, nickel plated
PTN2-6-P80 Item: Barb fitting, straight | Size / port: R1/8 | Color: Brass, nickel plated
PTNL2-M3-P80 Item: Barb fitting, elbow | Size / port: M3x0.5 | Color: Brass, nickel plated
PTNL2-M5-P80 Item: Barb fitting, elbow | Size / port: M5x0.8 | Color: Brass, nickel plated
PTN24-0-P80 Item: Barb nipple | Size / port: To ø3.2/ø4 tube | Color: Brass, nickel plated
PTN26-0-P80 Item: Barb nipple | Size / port: To ø6 tube | Color: Brass, nickel plated
