CKD VSP-P Vacuum Pad, Thin Workpiece Type (dia. 8-20)

CKD VSP-P Vacuum Pad, Thin Workpiece Type (dia. 8-20)

Thin-lip vacuum pad for picking thin workpieces such as copy paper and vinyl film.

Key features

  • Thin lip improves adhesion to thin sheets and reduces double-sheet pick-up
  • Pad diameters 8, 10, 15 and 20 mm
  • 6 materials incl. fluorosilicone and conductive NBR
  • 11 holder shapes incl. direct-mount E/F and compact ME with M5x0.5 thread
  • Compact holders with 1.8 mm one-touch or 4 mm barb connection

Specifications

Pad type P = thin workpiece
Order format VSP-<holder><dia>P<material>-<port>
Holders A, B, C, D, E, F, MA, MB, MC, MD, ME
Ports 1.8/4 mm one-touch, 4 mm barb, M5 (ME)
Options No drop prevention valve or free holder options
Source CKD Korea catalog CC-796K-5, p. 487-500
VSP-A8PN-4 Holder: Fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A8PS-4 Holder: Fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A8PU-4 Holder: Fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A8PF-4 Holder: Fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A8PFS-4 Holder: Fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A8PNE-4 Holder: Fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A8PN-4T Holder: Fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A8PS-4T Holder: Fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A8PU-4T Holder: Fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A8PF-4T Holder: Fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A8PFS-4T Holder: Fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A8PNE-4T Holder: Fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-A10PN-4 Holder: Fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A10PS-4 Holder: Fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A10PU-4 Holder: Fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A10PF-4 Holder: Fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A10PFS-4 Holder: Fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A10PNE-4 Holder: Fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A10PN-4T Holder: Fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A10PS-4T Holder: Fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A10PU-4T Holder: Fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A10PF-4T Holder: Fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A10PFS-4T Holder: Fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A10PNE-4T Holder: Fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-A15PN-4 Holder: Fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A15PS-4 Holder: Fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A15PU-4 Holder: Fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A15PF-4 Holder: Fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A15PFS-4 Holder: Fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A15PNE-4 Holder: Fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A15PN-4T Holder: Fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A15PS-4T Holder: Fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A15PU-4T Holder: Fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A15PF-4T Holder: Fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A15PFS-4T Holder: Fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A15PNE-4T Holder: Fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-A20PN-4 Holder: Fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A20PS-4 Holder: Fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A20PU-4 Holder: Fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A20PF-4 Holder: Fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A20PFS-4 Holder: Fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A20PNE-4 Holder: Fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A20PN-4T Holder: Fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A20PS-4T Holder: Fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A20PU-4T Holder: Fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A20PF-4T Holder: Fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A20PFS-4T Holder: Fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A20PNE-4T Holder: Fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B8PN-4 Holder: Fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B8PS-4 Holder: Fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B8PU-4 Holder: Fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B8PF-4 Holder: Fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B8PFS-4 Holder: Fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B8PNE-4 Holder: Fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B8PN-4T Holder: Fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B8PS-4T Holder: Fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B8PU-4T Holder: Fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B8PF-4T Holder: Fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B8PFS-4T Holder: Fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B8PNE-4T Holder: Fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B10PN-4 Holder: Fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B10PS-4 Holder: Fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B10PU-4 Holder: Fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B10PF-4 Holder: Fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B10PFS-4 Holder: Fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B10PNE-4 Holder: Fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B10PN-4T Holder: Fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B10PS-4T Holder: Fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B10PU-4T Holder: Fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B10PF-4T Holder: Fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B10PFS-4T Holder: Fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B10PNE-4T Holder: Fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B15PN-4 Holder: Fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B15PS-4 Holder: Fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B15PU-4 Holder: Fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B15PF-4 Holder: Fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B15PFS-4 Holder: Fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B15PNE-4 Holder: Fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B15PN-4T Holder: Fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B15PS-4T Holder: Fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B15PU-4T Holder: Fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B15PF-4T Holder: Fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B15PFS-4T Holder: Fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B15PNE-4T Holder: Fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B20PN-4 Holder: Fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B20PS-4 Holder: Fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B20PU-4 Holder: Fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B20PF-4 Holder: Fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B20PFS-4 Holder: Fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B20PNE-4 Holder: Fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B20PN-4T Holder: Fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B20PS-4T Holder: Fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B20PU-4T Holder: Fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B20PF-4T Holder: Fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B20PFS-4T Holder: Fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B20PNE-4T Holder: Fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C8PN-4 Holder: Buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C8PS-4 Holder: Buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C8PU-4 Holder: Buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C8PF-4 Holder: Buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C8PFS-4 Holder: Buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C8PNE-4 Holder: Buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C8PN-4T Holder: Buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C8PS-4T Holder: Buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C8PU-4T Holder: Buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C8PF-4T Holder: Buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C8PFS-4T Holder: Buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C8PNE-4T Holder: Buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C10PN-4 Holder: Buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C10PS-4 Holder: Buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C10PU-4 Holder: Buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C10PF-4 Holder: Buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C10PFS-4 Holder: Buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C10PNE-4 Holder: Buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C10PN-4T Holder: Buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C10PS-4T Holder: Buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C10PU-4T Holder: Buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C10PF-4T Holder: Buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C10PFS-4T Holder: Buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C10PNE-4T Holder: Buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C15PN-4 Holder: Buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C15PS-4 Holder: Buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C15PU-4 Holder: Buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C15PF-4 Holder: Buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C15PFS-4 Holder: Buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C15PNE-4 Holder: Buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C15PN-4T Holder: Buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C15PS-4T Holder: Buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C15PU-4T Holder: Buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C15PF-4T Holder: Buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C15PFS-4T Holder: Buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C15PNE-4T Holder: Buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C20PN-4 Holder: Buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C20PS-4 Holder: Buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C20PU-4 Holder: Buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C20PF-4 Holder: Buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C20PFS-4 Holder: Buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C20PNE-4 Holder: Buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C20PN-4T Holder: Buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C20PS-4T Holder: Buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C20PU-4T Holder: Buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C20PF-4T Holder: Buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C20PFS-4T Holder: Buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C20PNE-4T Holder: Buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D8PN-4 Holder: Buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D8PS-4 Holder: Buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D8PU-4 Holder: Buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D8PF-4 Holder: Buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D8PFS-4 Holder: Buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D8PNE-4 Holder: Buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D8PN-4T Holder: Buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D8PS-4T Holder: Buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D8PU-4T Holder: Buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D8PF-4T Holder: Buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D8PFS-4T Holder: Buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D8PNE-4T Holder: Buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D10PN-4 Holder: Buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D10PS-4 Holder: Buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D10PU-4 Holder: Buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D10PF-4 Holder: Buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D10PFS-4 Holder: Buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D10PNE-4 Holder: Buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D10PN-4T Holder: Buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D10PS-4T Holder: Buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D10PU-4T Holder: Buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D10PF-4T Holder: Buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D10PFS-4T Holder: Buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D10PNE-4T Holder: Buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D15PN-4 Holder: Buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D15PS-4 Holder: Buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D15PU-4 Holder: Buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D15PF-4 Holder: Buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D15PFS-4 Holder: Buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D15PNE-4 Holder: Buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D15PN-4T Holder: Buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D15PS-4T Holder: Buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D15PU-4T Holder: Buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D15PF-4T Holder: Buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D15PFS-4T Holder: Buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D15PNE-4T Holder: Buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D20PN-4 Holder: Buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D20PS-4 Holder: Buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D20PU-4 Holder: Buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D20PF-4 Holder: Buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D20PFS-4 Holder: Buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D20PNE-4 Holder: Buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D20PN-4T Holder: Buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D20PS-4T Holder: Buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D20PU-4T Holder: Buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D20PF-4T Holder: Buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D20PFS-4T Holder: Buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D20PNE-4T Holder: Buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-F8PN Holder: Direct mount, buffer | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F8PS Holder: Direct mount, buffer | Pad size: 8 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F8PU Holder: Direct mount, buffer | Pad size: 8 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F8PF Holder: Direct mount, buffer | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F8PFS Holder: Direct mount, buffer | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F8PNE Holder: Direct mount, buffer | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-F10PN Holder: Direct mount, buffer | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F10PS Holder: Direct mount, buffer | Pad size: 10 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F10PU Holder: Direct mount, buffer | Pad size: 10 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F10PF Holder: Direct mount, buffer | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F10PFS Holder: Direct mount, buffer | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F10PNE Holder: Direct mount, buffer | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-F15PN Holder: Direct mount, buffer | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F15PS Holder: Direct mount, buffer | Pad size: 15 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F15PU Holder: Direct mount, buffer | Pad size: 15 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F15PF Holder: Direct mount, buffer | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F15PFS Holder: Direct mount, buffer | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F15PNE Holder: Direct mount, buffer | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-F20PN Holder: Direct mount, buffer | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F20PS Holder: Direct mount, buffer | Pad size: 20 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F20PU Holder: Direct mount, buffer | Pad size: 20 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F20PF Holder: Direct mount, buffer | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F20PFS Holder: Direct mount, buffer | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F20PNE Holder: Direct mount, buffer | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E8PN Holder: Direct mount, fixed | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E8PS Holder: Direct mount, fixed | Pad size: 8 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E8PU Holder: Direct mount, fixed | Pad size: 8 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E8PF Holder: Direct mount, fixed | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E8PFS Holder: Direct mount, fixed | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E8PNE Holder: Direct mount, fixed | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E10PN Holder: Direct mount, fixed | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E10PS Holder: Direct mount, fixed | Pad size: 10 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E10PU Holder: Direct mount, fixed | Pad size: 10 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E10PF Holder: Direct mount, fixed | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E10PFS Holder: Direct mount, fixed | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E10PNE Holder: Direct mount, fixed | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E15PN Holder: Direct mount, fixed | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E15PS Holder: Direct mount, fixed | Pad size: 15 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E15PU Holder: Direct mount, fixed | Pad size: 15 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E15PF Holder: Direct mount, fixed | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E15PFS Holder: Direct mount, fixed | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E15PNE Holder: Direct mount, fixed | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E20PN Holder: Direct mount, fixed | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E20PS Holder: Direct mount, fixed | Pad size: 20 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E20PU Holder: Direct mount, fixed | Pad size: 20 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E20PF Holder: Direct mount, fixed | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E20PFS Holder: Direct mount, fixed | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E20PNE Holder: Direct mount, fixed | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-MA8PN-2 Holder: Compact fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA8PS-2 Holder: Compact fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA8PU-2 Holder: Compact fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA8PF-2 Holder: Compact fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA8PFS-2 Holder: Compact fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA8PNE-2 Holder: Compact fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA8PN-4T Holder: Compact fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA8PS-4T Holder: Compact fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA8PU-4T Holder: Compact fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA8PF-4T Holder: Compact fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA8PFS-4T Holder: Compact fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA8PNE-4T Holder: Compact fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MA10PN-2 Holder: Compact fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA10PS-2 Holder: Compact fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA10PU-2 Holder: Compact fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA10PF-2 Holder: Compact fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA10PFS-2 Holder: Compact fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA10PNE-2 Holder: Compact fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA10PN-4T Holder: Compact fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA10PS-4T Holder: Compact fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA10PU-4T Holder: Compact fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA10PF-4T Holder: Compact fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA10PFS-4T Holder: Compact fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA10PNE-4T Holder: Compact fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MA15PN-2 Holder: Compact fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA15PS-2 Holder: Compact fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA15PU-2 Holder: Compact fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA15PF-2 Holder: Compact fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA15PFS-2 Holder: Compact fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA15PNE-2 Holder: Compact fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA15PN-4T Holder: Compact fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA15PS-4T Holder: Compact fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA15PU-4T Holder: Compact fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA15PF-4T Holder: Compact fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA15PFS-4T Holder: Compact fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA15PNE-4T Holder: Compact fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MA20PN-2 Holder: Compact fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA20PS-2 Holder: Compact fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA20PU-2 Holder: Compact fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA20PF-2 Holder: Compact fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA20PFS-2 Holder: Compact fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA20PNE-2 Holder: Compact fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA20PN-4T Holder: Compact fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA20PS-4T Holder: Compact fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA20PU-4T Holder: Compact fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA20PF-4T Holder: Compact fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA20PFS-4T Holder: Compact fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA20PNE-4T Holder: Compact fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB8PN-2 Holder: Compact fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB8PS-2 Holder: Compact fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB8PU-2 Holder: Compact fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB8PF-2 Holder: Compact fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB8PFS-2 Holder: Compact fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB8PNE-2 Holder: Compact fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB8PN-4T Holder: Compact fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB8PS-4T Holder: Compact fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB8PU-4T Holder: Compact fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB8PF-4T Holder: Compact fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB8PFS-4T Holder: Compact fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB8PNE-4T Holder: Compact fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB10PN-2 Holder: Compact fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB10PS-2 Holder: Compact fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB10PU-2 Holder: Compact fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB10PF-2 Holder: Compact fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB10PFS-2 Holder: Compact fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB10PNE-2 Holder: Compact fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB10PN-4T Holder: Compact fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB10PS-4T Holder: Compact fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB10PU-4T Holder: Compact fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB10PF-4T Holder: Compact fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB10PFS-4T Holder: Compact fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB10PNE-4T Holder: Compact fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB15PN-2 Holder: Compact fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB15PS-2 Holder: Compact fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB15PU-2 Holder: Compact fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB15PF-2 Holder: Compact fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB15PFS-2 Holder: Compact fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB15PNE-2 Holder: Compact fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB15PN-4T Holder: Compact fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB15PS-4T Holder: Compact fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB15PU-4T Holder: Compact fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB15PF-4T Holder: Compact fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB15PFS-4T Holder: Compact fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB15PNE-4T Holder: Compact fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB20PN-2 Holder: Compact fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB20PS-2 Holder: Compact fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB20PU-2 Holder: Compact fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB20PF-2 Holder: Compact fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB20PFS-2 Holder: Compact fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB20PNE-2 Holder: Compact fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB20PN-4T Holder: Compact fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB20PS-4T Holder: Compact fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB20PU-4T Holder: Compact fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB20PF-4T Holder: Compact fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB20PFS-4T Holder: Compact fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB20PNE-4T Holder: Compact fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC8PN-2 Holder: Compact buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC8PS-2 Holder: Compact buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC8PU-2 Holder: Compact buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC8PF-2 Holder: Compact buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC8PFS-2 Holder: Compact buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC8PNE-2 Holder: Compact buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC8PN-4T Holder: Compact buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC8PS-4T Holder: Compact buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC8PU-4T Holder: Compact buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC8PF-4T Holder: Compact buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC8PFS-4T Holder: Compact buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC8PNE-4T Holder: Compact buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC10PN-2 Holder: Compact buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC10PS-2 Holder: Compact buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC10PU-2 Holder: Compact buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC10PF-2 Holder: Compact buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC10PFS-2 Holder: Compact buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC10PNE-2 Holder: Compact buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC10PN-4T Holder: Compact buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC10PS-4T Holder: Compact buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC10PU-4T Holder: Compact buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC10PF-4T Holder: Compact buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC10PFS-4T Holder: Compact buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC10PNE-4T Holder: Compact buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC15PN-2 Holder: Compact buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC15PS-2 Holder: Compact buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC15PU-2 Holder: Compact buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC15PF-2 Holder: Compact buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC15PFS-2 Holder: Compact buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC15PNE-2 Holder: Compact buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC15PN-4T Holder: Compact buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC15PS-4T Holder: Compact buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC15PU-4T Holder: Compact buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC15PF-4T Holder: Compact buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC15PFS-4T Holder: Compact buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC15PNE-4T Holder: Compact buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC20PN-2 Holder: Compact buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC20PS-2 Holder: Compact buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC20PU-2 Holder: Compact buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC20PF-2 Holder: Compact buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC20PFS-2 Holder: Compact buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC20PNE-2 Holder: Compact buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC20PN-4T Holder: Compact buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC20PS-4T Holder: Compact buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC20PU-4T Holder: Compact buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC20PF-4T Holder: Compact buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC20PFS-4T Holder: Compact buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC20PNE-4T Holder: Compact buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD8PN-2 Holder: Compact buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD8PS-2 Holder: Compact buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD8PU-2 Holder: Compact buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD8PF-2 Holder: Compact buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD8PFS-2 Holder: Compact buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD8PNE-2 Holder: Compact buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD8PN-4T Holder: Compact buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD8PS-4T Holder: Compact buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD8PU-4T Holder: Compact buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD8PF-4T Holder: Compact buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD8PFS-4T Holder: Compact buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD8PNE-4T Holder: Compact buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD10PN-2 Holder: Compact buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD10PS-2 Holder: Compact buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD10PU-2 Holder: Compact buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD10PF-2 Holder: Compact buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD10PFS-2 Holder: Compact buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD10PNE-2 Holder: Compact buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD10PN-4T Holder: Compact buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD10PS-4T Holder: Compact buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD10PU-4T Holder: Compact buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD10PF-4T Holder: Compact buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD10PFS-4T Holder: Compact buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD10PNE-4T Holder: Compact buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD15PN-2 Holder: Compact buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD15PS-2 Holder: Compact buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD15PU-2 Holder: Compact buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD15PF-2 Holder: Compact buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD15PFS-2 Holder: Compact buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD15PNE-2 Holder: Compact buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD15PN-4T Holder: Compact buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD15PS-4T Holder: Compact buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD15PU-4T Holder: Compact buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD15PF-4T Holder: Compact buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD15PFS-4T Holder: Compact buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD15PNE-4T Holder: Compact buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD20PN-2 Holder: Compact buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD20PS-2 Holder: Compact buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD20PU-2 Holder: Compact buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD20PF-2 Holder: Compact buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD20PFS-2 Holder: Compact buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD20PNE-2 Holder: Compact buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD20PN-4T Holder: Compact buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD20PS-4T Holder: Compact buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD20PU-4T Holder: Compact buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD20PF-4T Holder: Compact buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD20PFS-4T Holder: Compact buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD20PNE-4T Holder: Compact buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-ME8PN-M5 Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME8PS-M5 Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME8PU-M5 Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME8PF-M5 Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME8PFS-M5 Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME8PNE-M5 Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSP-ME10PN-M5 Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME10PS-M5 Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME10PU-M5 Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME10PF-M5 Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME10PFS-M5 Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME10PNE-M5 Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSP-ME15PN-M5 Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME15PS-M5 Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME15PU-M5 Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME15PF-M5 Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME15PFS-M5 Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME15PNE-M5 Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSP-ME20PN-M5 Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME20PS-M5 Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME20PU-M5 Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME20PF-M5 Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME20PFS-M5 Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME20PNE-M5 Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSPG-8PN Holder: Pad only | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-8PS Holder: Pad only | Pad size: 8 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-8PU Holder: Pad only | Pad size: 8 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-8PF Holder: Pad only | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-8PFS Holder: Pad only | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-8PNE Holder: Pad only | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)
VSPG-10PN Holder: Pad only | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-10PS Holder: Pad only | Pad size: 10 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-10PU Holder: Pad only | Pad size: 10 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-10PF Holder: Pad only | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-10PFS Holder: Pad only | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-10PNE Holder: Pad only | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)
VSPG-15PN Holder: Pad only | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-15PS Holder: Pad only | Pad size: 15 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-15PU Holder: Pad only | Pad size: 15 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-15PF Holder: Pad only | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-15PFS Holder: Pad only | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-15PNE Holder: Pad only | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)
VSPG-20PN Holder: Pad only | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-20PS Holder: Pad only | Pad size: 20 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-20PU Holder: Pad only | Pad size: 20 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-20PF Holder: Pad only | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-20PFS Holder: Pad only | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-20PNE Holder: Pad only | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)
Vacuum PadsCKD
480 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD VSP-P Vacuum Pad, Thin Workpiece Type (dia. 8-20)

Brand CKD·Vacuum Pads

Available part numbers (480)

VSP-A8PN-4, VSP-A8PS-4, VSP-A8PU-4, VSP-A8PF-4, VSP-A8PFS-4, VSP-A8PNE-4, VSP-A8PN-4T, VSP-A8PS-4T, VSP-A8PU-4T, VSP-A8PF-4T + 470 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
VSP-A8PN-4Holder: Fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A8PS-4Holder: Fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A8PU-4Holder: Fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A8PF-4Holder: Fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A8PFS-4Holder: Fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A8PNE-4Holder: Fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A8PN-4THolder: Fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A8PS-4THolder: Fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A8PU-4THolder: Fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A8PF-4THolder: Fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A8PFS-4THolder: Fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A8PNE-4THolder: Fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-A10PN-4Holder: Fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A10PS-4Holder: Fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A10PU-4Holder: Fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A10PF-4Holder: Fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A10PFS-4Holder: Fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A10PNE-4Holder: Fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A10PN-4THolder: Fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A10PS-4THolder: Fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A10PU-4THolder: Fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A10PF-4THolder: Fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A10PFS-4THolder: Fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A10PNE-4THolder: Fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-A15PN-4Holder: Fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A15PS-4Holder: Fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A15PU-4Holder: Fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A15PF-4Holder: Fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A15PFS-4Holder: Fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A15PNE-4Holder: Fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A15PN-4THolder: Fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A15PS-4THolder: Fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A15PU-4THolder: Fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A15PF-4THolder: Fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A15PFS-4THolder: Fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A15PNE-4THolder: Fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-A20PN-4Holder: Fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-A20PS-4Holder: Fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-A20PU-4Holder: Fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-A20PF-4Holder: Fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-A20PFS-4Holder: Fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-A20PNE-4Holder: Fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-A20PN-4THolder: Fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-A20PS-4THolder: Fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-A20PU-4THolder: Fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-A20PF-4THolder: Fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-A20PFS-4THolder: Fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-A20PNE-4THolder: Fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B8PN-4Holder: Fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B8PS-4Holder: Fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B8PU-4Holder: Fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B8PF-4Holder: Fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B8PFS-4Holder: Fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B8PNE-4Holder: Fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B8PN-4THolder: Fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B8PS-4THolder: Fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B8PU-4THolder: Fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B8PF-4THolder: Fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B8PFS-4THolder: Fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B8PNE-4THolder: Fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B10PN-4Holder: Fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B10PS-4Holder: Fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B10PU-4Holder: Fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B10PF-4Holder: Fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B10PFS-4Holder: Fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B10PNE-4Holder: Fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B10PN-4THolder: Fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B10PS-4THolder: Fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B10PU-4THolder: Fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B10PF-4THolder: Fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B10PFS-4THolder: Fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B10PNE-4THolder: Fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B15PN-4Holder: Fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B15PS-4Holder: Fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B15PU-4Holder: Fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B15PF-4Holder: Fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B15PFS-4Holder: Fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B15PNE-4Holder: Fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B15PN-4THolder: Fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B15PS-4THolder: Fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B15PU-4THolder: Fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B15PF-4THolder: Fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B15PFS-4THolder: Fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B15PNE-4THolder: Fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-B20PN-4Holder: Fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-B20PS-4Holder: Fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-B20PU-4Holder: Fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-B20PF-4Holder: Fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-B20PFS-4Holder: Fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-B20PNE-4Holder: Fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-B20PN-4THolder: Fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-B20PS-4THolder: Fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-B20PU-4THolder: Fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-B20PF-4THolder: Fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-B20PFS-4THolder: Fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-B20PNE-4THolder: Fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C8PN-4Holder: Buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C8PS-4Holder: Buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C8PU-4Holder: Buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C8PF-4Holder: Buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C8PFS-4Holder: Buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C8PNE-4Holder: Buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C8PN-4THolder: Buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C8PS-4THolder: Buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C8PU-4THolder: Buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C8PF-4THolder: Buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C8PFS-4THolder: Buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C8PNE-4THolder: Buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C10PN-4Holder: Buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C10PS-4Holder: Buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C10PU-4Holder: Buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C10PF-4Holder: Buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C10PFS-4Holder: Buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C10PNE-4Holder: Buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C10PN-4THolder: Buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C10PS-4THolder: Buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C10PU-4THolder: Buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C10PF-4THolder: Buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C10PFS-4THolder: Buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C10PNE-4THolder: Buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C15PN-4Holder: Buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C15PS-4Holder: Buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C15PU-4Holder: Buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C15PF-4Holder: Buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C15PFS-4Holder: Buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C15PNE-4Holder: Buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C15PN-4THolder: Buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C15PS-4THolder: Buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C15PU-4THolder: Buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C15PF-4THolder: Buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C15PFS-4THolder: Buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C15PNE-4THolder: Buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-C20PN-4Holder: Buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-C20PS-4Holder: Buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-C20PU-4Holder: Buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-C20PF-4Holder: Buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-C20PFS-4Holder: Buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-C20PNE-4Holder: Buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-C20PN-4THolder: Buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-C20PS-4THolder: Buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-C20PU-4THolder: Buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-C20PF-4THolder: Buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-C20PFS-4THolder: Buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-C20PNE-4THolder: Buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D8PN-4Holder: Buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D8PS-4Holder: Buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D8PU-4Holder: Buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D8PF-4Holder: Buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D8PFS-4Holder: Buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D8PNE-4Holder: Buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D8PN-4THolder: Buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D8PS-4THolder: Buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D8PU-4THolder: Buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D8PF-4THolder: Buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D8PFS-4THolder: Buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D8PNE-4THolder: Buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D10PN-4Holder: Buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D10PS-4Holder: Buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D10PU-4Holder: Buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D10PF-4Holder: Buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D10PFS-4Holder: Buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D10PNE-4Holder: Buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D10PN-4THolder: Buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D10PS-4THolder: Buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D10PU-4THolder: Buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D10PF-4THolder: Buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D10PFS-4THolder: Buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D10PNE-4THolder: Buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D15PN-4Holder: Buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D15PS-4Holder: Buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D15PU-4Holder: Buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D15PF-4Holder: Buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D15PFS-4Holder: Buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D15PNE-4Holder: Buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D15PN-4THolder: Buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D15PS-4THolder: Buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D15PU-4THolder: Buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D15PF-4THolder: Buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D15PFS-4THolder: Buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D15PNE-4THolder: Buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-D20PN-4Holder: Buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm one-touch
VSP-D20PS-4Holder: Buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm one-touch
VSP-D20PU-4Holder: Buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm one-touch
VSP-D20PF-4Holder: Buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm one-touch
VSP-D20PFS-4Holder: Buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm one-touch
VSP-D20PNE-4Holder: Buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm one-touch
VSP-D20PN-4THolder: Buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-D20PS-4THolder: Buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-D20PU-4THolder: Buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-D20PF-4THolder: Buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-D20PFS-4THolder: Buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-D20PNE-4THolder: Buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-F8PNHolder: Direct mount, buffer | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F8PSHolder: Direct mount, buffer | Pad size: 8 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F8PUHolder: Direct mount, buffer | Pad size: 8 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F8PFHolder: Direct mount, buffer | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F8PFSHolder: Direct mount, buffer | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F8PNEHolder: Direct mount, buffer | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-F10PNHolder: Direct mount, buffer | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F10PSHolder: Direct mount, buffer | Pad size: 10 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F10PUHolder: Direct mount, buffer | Pad size: 10 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F10PFHolder: Direct mount, buffer | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F10PFSHolder: Direct mount, buffer | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F10PNEHolder: Direct mount, buffer | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-F15PNHolder: Direct mount, buffer | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F15PSHolder: Direct mount, buffer | Pad size: 15 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F15PUHolder: Direct mount, buffer | Pad size: 15 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F15PFHolder: Direct mount, buffer | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F15PFSHolder: Direct mount, buffer | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F15PNEHolder: Direct mount, buffer | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-F20PNHolder: Direct mount, buffer | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-F20PSHolder: Direct mount, buffer | Pad size: 20 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-F20PUHolder: Direct mount, buffer | Pad size: 20 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-F20PFHolder: Direct mount, buffer | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-F20PFSHolder: Direct mount, buffer | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-F20PNEHolder: Direct mount, buffer | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E8PNHolder: Direct mount, fixed | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E8PSHolder: Direct mount, fixed | Pad size: 8 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E8PUHolder: Direct mount, fixed | Pad size: 8 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E8PFHolder: Direct mount, fixed | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E8PFSHolder: Direct mount, fixed | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E8PNEHolder: Direct mount, fixed | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E10PNHolder: Direct mount, fixed | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E10PSHolder: Direct mount, fixed | Pad size: 10 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E10PUHolder: Direct mount, fixed | Pad size: 10 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E10PFHolder: Direct mount, fixed | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E10PFSHolder: Direct mount, fixed | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E10PNEHolder: Direct mount, fixed | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E15PNHolder: Direct mount, fixed | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E15PSHolder: Direct mount, fixed | Pad size: 15 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E15PUHolder: Direct mount, fixed | Pad size: 15 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E15PFHolder: Direct mount, fixed | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E15PFSHolder: Direct mount, fixed | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E15PNEHolder: Direct mount, fixed | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-E20PNHolder: Direct mount, fixed | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: None (direct mount)
VSP-E20PSHolder: Direct mount, fixed | Pad size: 20 mm | Material: Silicone rubber | Port: None (direct mount)
VSP-E20PUHolder: Direct mount, fixed | Pad size: 20 mm | Material: Urethane rubber | Port: None (direct mount)
VSP-E20PFHolder: Direct mount, fixed | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: None (direct mount)
VSP-E20PFSHolder: Direct mount, fixed | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: None (direct mount)
VSP-E20PNEHolder: Direct mount, fixed | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: None (direct mount)
VSP-MA8PN-2Holder: Compact fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA8PS-2Holder: Compact fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA8PU-2Holder: Compact fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA8PF-2Holder: Compact fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA8PFS-2Holder: Compact fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA8PNE-2Holder: Compact fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA8PN-4THolder: Compact fixed, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA8PS-4THolder: Compact fixed, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA8PU-4THolder: Compact fixed, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA8PF-4THolder: Compact fixed, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA8PFS-4THolder: Compact fixed, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA8PNE-4THolder: Compact fixed, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MA10PN-2Holder: Compact fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA10PS-2Holder: Compact fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA10PU-2Holder: Compact fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA10PF-2Holder: Compact fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA10PFS-2Holder: Compact fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA10PNE-2Holder: Compact fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA10PN-4THolder: Compact fixed, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA10PS-4THolder: Compact fixed, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA10PU-4THolder: Compact fixed, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA10PF-4THolder: Compact fixed, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA10PFS-4THolder: Compact fixed, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA10PNE-4THolder: Compact fixed, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MA15PN-2Holder: Compact fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA15PS-2Holder: Compact fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA15PU-2Holder: Compact fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA15PF-2Holder: Compact fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA15PFS-2Holder: Compact fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA15PNE-2Holder: Compact fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA15PN-4THolder: Compact fixed, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA15PS-4THolder: Compact fixed, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA15PU-4THolder: Compact fixed, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA15PF-4THolder: Compact fixed, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA15PFS-4THolder: Compact fixed, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA15PNE-4THolder: Compact fixed, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MA20PN-2Holder: Compact fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MA20PS-2Holder: Compact fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MA20PU-2Holder: Compact fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MA20PF-2Holder: Compact fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MA20PFS-2Holder: Compact fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MA20PNE-2Holder: Compact fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MA20PN-4THolder: Compact fixed, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MA20PS-4THolder: Compact fixed, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MA20PU-4THolder: Compact fixed, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MA20PF-4THolder: Compact fixed, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MA20PFS-4THolder: Compact fixed, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MA20PNE-4THolder: Compact fixed, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB8PN-2Holder: Compact fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB8PS-2Holder: Compact fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB8PU-2Holder: Compact fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB8PF-2Holder: Compact fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB8PFS-2Holder: Compact fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB8PNE-2Holder: Compact fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB8PN-4THolder: Compact fixed, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB8PS-4THolder: Compact fixed, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB8PU-4THolder: Compact fixed, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB8PF-4THolder: Compact fixed, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB8PFS-4THolder: Compact fixed, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB8PNE-4THolder: Compact fixed, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB10PN-2Holder: Compact fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB10PS-2Holder: Compact fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB10PU-2Holder: Compact fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB10PF-2Holder: Compact fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB10PFS-2Holder: Compact fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB10PNE-2Holder: Compact fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB10PN-4THolder: Compact fixed, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB10PS-4THolder: Compact fixed, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB10PU-4THolder: Compact fixed, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB10PF-4THolder: Compact fixed, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB10PFS-4THolder: Compact fixed, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB10PNE-4THolder: Compact fixed, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB15PN-2Holder: Compact fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB15PS-2Holder: Compact fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB15PU-2Holder: Compact fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB15PF-2Holder: Compact fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB15PFS-2Holder: Compact fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB15PNE-2Holder: Compact fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB15PN-4THolder: Compact fixed, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB15PS-4THolder: Compact fixed, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB15PU-4THolder: Compact fixed, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB15PF-4THolder: Compact fixed, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB15PFS-4THolder: Compact fixed, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB15PNE-4THolder: Compact fixed, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MB20PN-2Holder: Compact fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MB20PS-2Holder: Compact fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MB20PU-2Holder: Compact fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MB20PF-2Holder: Compact fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MB20PFS-2Holder: Compact fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MB20PNE-2Holder: Compact fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MB20PN-4THolder: Compact fixed, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MB20PS-4THolder: Compact fixed, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MB20PU-4THolder: Compact fixed, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MB20PF-4THolder: Compact fixed, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MB20PFS-4THolder: Compact fixed, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MB20PNE-4THolder: Compact fixed, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC8PN-2Holder: Compact buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC8PS-2Holder: Compact buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC8PU-2Holder: Compact buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC8PF-2Holder: Compact buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC8PFS-2Holder: Compact buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC8PNE-2Holder: Compact buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC8PN-4THolder: Compact buffer, port top | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC8PS-4THolder: Compact buffer, port top | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC8PU-4THolder: Compact buffer, port top | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC8PF-4THolder: Compact buffer, port top | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC8PFS-4THolder: Compact buffer, port top | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC8PNE-4THolder: Compact buffer, port top | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC10PN-2Holder: Compact buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC10PS-2Holder: Compact buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC10PU-2Holder: Compact buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC10PF-2Holder: Compact buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC10PFS-2Holder: Compact buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC10PNE-2Holder: Compact buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC10PN-4THolder: Compact buffer, port top | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC10PS-4THolder: Compact buffer, port top | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC10PU-4THolder: Compact buffer, port top | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC10PF-4THolder: Compact buffer, port top | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC10PFS-4THolder: Compact buffer, port top | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC10PNE-4THolder: Compact buffer, port top | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC15PN-2Holder: Compact buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC15PS-2Holder: Compact buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC15PU-2Holder: Compact buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC15PF-2Holder: Compact buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC15PFS-2Holder: Compact buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC15PNE-2Holder: Compact buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC15PN-4THolder: Compact buffer, port top | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC15PS-4THolder: Compact buffer, port top | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC15PU-4THolder: Compact buffer, port top | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC15PF-4THolder: Compact buffer, port top | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC15PFS-4THolder: Compact buffer, port top | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC15PNE-4THolder: Compact buffer, port top | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MC20PN-2Holder: Compact buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MC20PS-2Holder: Compact buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MC20PU-2Holder: Compact buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MC20PF-2Holder: Compact buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MC20PFS-2Holder: Compact buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MC20PNE-2Holder: Compact buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MC20PN-4THolder: Compact buffer, port top | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MC20PS-4THolder: Compact buffer, port top | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MC20PU-4THolder: Compact buffer, port top | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MC20PF-4THolder: Compact buffer, port top | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MC20PFS-4THolder: Compact buffer, port top | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MC20PNE-4THolder: Compact buffer, port top | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD8PN-2Holder: Compact buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD8PS-2Holder: Compact buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD8PU-2Holder: Compact buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD8PF-2Holder: Compact buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD8PFS-2Holder: Compact buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD8PNE-2Holder: Compact buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD8PN-4THolder: Compact buffer, port side | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD8PS-4THolder: Compact buffer, port side | Pad size: 8 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD8PU-4THolder: Compact buffer, port side | Pad size: 8 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD8PF-4THolder: Compact buffer, port side | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD8PFS-4THolder: Compact buffer, port side | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD8PNE-4THolder: Compact buffer, port side | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD10PN-2Holder: Compact buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD10PS-2Holder: Compact buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD10PU-2Holder: Compact buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD10PF-2Holder: Compact buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD10PFS-2Holder: Compact buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD10PNE-2Holder: Compact buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD10PN-4THolder: Compact buffer, port side | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD10PS-4THolder: Compact buffer, port side | Pad size: 10 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD10PU-4THolder: Compact buffer, port side | Pad size: 10 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD10PF-4THolder: Compact buffer, port side | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD10PFS-4THolder: Compact buffer, port side | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD10PNE-4THolder: Compact buffer, port side | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD15PN-2Holder: Compact buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD15PS-2Holder: Compact buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD15PU-2Holder: Compact buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD15PF-2Holder: Compact buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD15PFS-2Holder: Compact buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD15PNE-2Holder: Compact buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD15PN-4THolder: Compact buffer, port side | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD15PS-4THolder: Compact buffer, port side | Pad size: 15 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD15PU-4THolder: Compact buffer, port side | Pad size: 15 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD15PF-4THolder: Compact buffer, port side | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD15PFS-4THolder: Compact buffer, port side | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD15PNE-4THolder: Compact buffer, port side | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-MD20PN-2Holder: Compact buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 1.8 mm one-touch
VSP-MD20PS-2Holder: Compact buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 1.8 mm one-touch
VSP-MD20PU-2Holder: Compact buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 1.8 mm one-touch
VSP-MD20PF-2Holder: Compact buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 1.8 mm one-touch
VSP-MD20PFS-2Holder: Compact buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 1.8 mm one-touch
VSP-MD20PNE-2Holder: Compact buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 1.8 mm one-touch
VSP-MD20PN-4THolder: Compact buffer, port side | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: 4 mm barb
VSP-MD20PS-4THolder: Compact buffer, port side | Pad size: 20 mm | Material: Silicone rubber | Port: 4 mm barb
VSP-MD20PU-4THolder: Compact buffer, port side | Pad size: 20 mm | Material: Urethane rubber | Port: 4 mm barb
VSP-MD20PF-4THolder: Compact buffer, port side | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: 4 mm barb
VSP-MD20PFS-4THolder: Compact buffer, port side | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: 4 mm barb
VSP-MD20PNE-4THolder: Compact buffer, port side | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: 4 mm barb
VSP-ME8PN-M5Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME8PS-M5Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME8PU-M5Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME8PF-M5Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME8PFS-M5Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME8PNE-M5Holder: Compact direct mount, fixed | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSP-ME10PN-M5Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME10PS-M5Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME10PU-M5Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME10PF-M5Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME10PFS-M5Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME10PNE-M5Holder: Compact direct mount, fixed | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSP-ME15PN-M5Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME15PS-M5Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME15PU-M5Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME15PF-M5Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME15PFS-M5Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME15PNE-M5Holder: Compact direct mount, fixed | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSP-ME20PN-M5Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: M5x0.5 male thread
VSP-ME20PS-M5Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Silicone rubber | Port: M5x0.5 male thread
VSP-ME20PU-M5Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Urethane rubber | Port: M5x0.5 male thread
VSP-ME20PF-M5Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: M5x0.5 male thread
VSP-ME20PFS-M5Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: M5x0.5 male thread
VSP-ME20PNE-M5Holder: Compact direct mount, fixed | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: M5x0.5 male thread
VSPG-8PNHolder: Pad only | Pad size: 8 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-8PSHolder: Pad only | Pad size: 8 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-8PUHolder: Pad only | Pad size: 8 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-8PFHolder: Pad only | Pad size: 8 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-8PFSHolder: Pad only | Pad size: 8 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-8PNEHolder: Pad only | Pad size: 8 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)
VSPG-10PNHolder: Pad only | Pad size: 10 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-10PSHolder: Pad only | Pad size: 10 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-10PUHolder: Pad only | Pad size: 10 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-10PFHolder: Pad only | Pad size: 10 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-10PFSHolder: Pad only | Pad size: 10 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-10PNEHolder: Pad only | Pad size: 10 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)
VSPG-15PNHolder: Pad only | Pad size: 15 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-15PSHolder: Pad only | Pad size: 15 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-15PUHolder: Pad only | Pad size: 15 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-15PFHolder: Pad only | Pad size: 15 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-15PFSHolder: Pad only | Pad size: 15 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-15PNEHolder: Pad only | Pad size: 15 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)
VSPG-20PNHolder: Pad only | Pad size: 20 mm | Material: Nitrile rubber (NBR) | Port: None (pad only)
VSPG-20PSHolder: Pad only | Pad size: 20 mm | Material: Silicone rubber | Port: None (pad only)
VSPG-20PUHolder: Pad only | Pad size: 20 mm | Material: Urethane rubber | Port: None (pad only)
VSPG-20PFHolder: Pad only | Pad size: 20 mm | Material: Fluoro rubber (FKM) | Port: None (pad only)
VSPG-20PFSHolder: Pad only | Pad size: 20 mm | Material: Fluorosilicone rubber | Port: None (pad only)
VSPG-20PNEHolder: Pad only | Pad size: 20 mm | Material: Conductive NBR (low resistance) | Port: None (pad only)

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
