CKD VSP-S Vacuum Pad, Sponge Type (ø10 to ø100)

CKD VSP-S Vacuum Pad, Sponge Type (ø10 to ø100)

CKD VSP sponge type vacuum pad for work with uneven surfaces such as building exterior panels, stones and shells, ø10 to ø100 mm, in chloroprene or silicone sponge.

Key features

  • Sponge pad conforms to rough and uneven work surfaces
  • Nine pad diameters: ø10, 15, 20, 25, 30, 35, 50, 70, 100 mm
  • Materials: chloroprene rubber (no symbol) or silicone rubber (S)
  • Holders A, B, C, D, F and small holders MA-MD; ø6 push-in/barb, ø4 push-in/barb, Rp1/8
  • Pad only VSPG-<d>S<material>A; free holder (F1/F2) and drop prevention valve (V) options not multiplied

Specifications

Pad diameter range ø10 to ø100 mm
Pad shape Sponge (S)
Pad materials Chloroprene (standard), silicone (S)
Holder types 9 (5 standard, 4 small)
Free holder F1 30° / F2 15° neck rotation, all sizes
Drop prevention valve V, all sizes
Ordering example VSP-A30S-6T; pad only VSPG-30SA
Source CKD Korea catalog CC-796K-5, p. 365-378
VSP-A10S-6 Holder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A10SS-6 Holder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A15S-6 Holder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A15SS-6 Holder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A20S-6 Holder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A20SS-6 Holder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A25S-6 Holder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A25SS-6 Holder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A30S-6 Holder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A30SS-6 Holder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A35S-6 Holder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A35SS-6 Holder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A50S-6 Holder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A50SS-6 Holder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A70S-6A Holder: A Fixed, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-A70SS-6A Holder: A Fixed, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-A100S-6A Holder: A Fixed, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-A100SS-6A Holder: A Fixed, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-A10S-6T Holder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A10SS-6T Holder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A15S-6T Holder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A15SS-6T Holder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A20S-6T Holder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A20SS-6T Holder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A25S-6T Holder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A25SS-6T Holder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A30S-6T Holder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A30SS-6T Holder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A35S-6T Holder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A35SS-6T Holder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A50S-6T Holder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A50SS-6T Holder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B10S-6 Holder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B10SS-6 Holder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B15S-6 Holder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B15SS-6 Holder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B20S-6 Holder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B20SS-6 Holder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B25S-6 Holder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B25SS-6 Holder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B30S-6 Holder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B30SS-6 Holder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B35S-6 Holder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B35SS-6 Holder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B50S-6 Holder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B50SS-6 Holder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B70S-6A Holder: B Fixed, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-B70SS-6A Holder: B Fixed, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-B100S-6A Holder: B Fixed, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-B100SS-6A Holder: B Fixed, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-B10S-6T Holder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B10SS-6T Holder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B15S-6T Holder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B15SS-6T Holder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B20S-6T Holder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B20SS-6T Holder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B25S-6T Holder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B25SS-6T Holder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B30S-6T Holder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B30SS-6T Holder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B35S-6T Holder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B35SS-6T Holder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B50S-6T Holder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B50SS-6T Holder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C10S-6 Holder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C10SS-6 Holder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C15S-6 Holder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C15SS-6 Holder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C20S-6 Holder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C20SS-6 Holder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C25S-6 Holder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C25SS-6 Holder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C30S-6 Holder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C30SS-6 Holder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C35S-6 Holder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C35SS-6 Holder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C50S-6 Holder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C50SS-6 Holder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C70S-6A Holder: C Buffer, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-C70SS-6A Holder: C Buffer, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-C100S-6A Holder: C Buffer, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-C100SS-6A Holder: C Buffer, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-C10S-6T Holder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C10SS-6T Holder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C15S-6T Holder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C15SS-6T Holder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C20S-6T Holder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C20SS-6T Holder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C25S-6T Holder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C25SS-6T Holder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C30S-6T Holder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C30SS-6T Holder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C35S-6T Holder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C35SS-6T Holder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C50S-6T Holder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C50SS-6T Holder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D10S-6 Holder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D10SS-6 Holder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D15S-6 Holder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D15SS-6 Holder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D20S-6 Holder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D20SS-6 Holder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D25S-6 Holder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D25SS-6 Holder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D30S-6 Holder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D30SS-6 Holder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D35S-6 Holder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D35SS-6 Holder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D50S-6 Holder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D50SS-6 Holder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D70S-6A Holder: D Buffer, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-D70SS-6A Holder: D Buffer, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-D100S-6A Holder: D Buffer, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-D100SS-6A Holder: D Buffer, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-D10S-6T Holder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D10SS-6T Holder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D15S-6T Holder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D15SS-6T Holder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D20S-6T Holder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D20SS-6T Holder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D25S-6T Holder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D25SS-6T Holder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D30S-6T Holder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D30SS-6T Holder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D35S-6T Holder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D35SS-6T Holder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D50S-6T Holder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D50SS-6T Holder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-F10S Holder: F Direct mount, buffer | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F10SS Holder: F Direct mount, buffer | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F15S Holder: F Direct mount, buffer | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F15SS Holder: F Direct mount, buffer | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F20S Holder: F Direct mount, buffer | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F20SS Holder: F Direct mount, buffer | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F25S Holder: F Direct mount, buffer | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F25SS Holder: F Direct mount, buffer | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F30S Holder: F Direct mount, buffer | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F30SS Holder: F Direct mount, buffer | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F35S Holder: F Direct mount, buffer | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F35SS Holder: F Direct mount, buffer | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F50S Holder: F Direct mount, buffer | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F50SS Holder: F Direct mount, buffer | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-MA10S-4 Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA10SS-4 Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA15S-4 Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA15SS-4 Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA20S-4 Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA20SS-4 Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA25S-4 Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA25SS-4 Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA30S-4 Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA30SS-4 Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA10S-4T Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA10SS-4T Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA10S-6T Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA10SS-6T Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA15S-4T Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA15SS-4T Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA15S-6T Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA15SS-6T Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA20S-4T Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA20SS-4T Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA20S-6T Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA20SS-6T Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA25S-4T Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA25SS-4T Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA25S-6T Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA25SS-6T Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA30S-4T Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA30SS-4T Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA30S-6T Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA30SS-6T Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB10S-4 Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB10SS-4 Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB15S-4 Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB15SS-4 Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB20S-4 Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB20SS-4 Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB25S-4 Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB25SS-4 Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB30S-4 Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB30SS-4 Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB10S-4T Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB10SS-4T Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB10S-6T Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB10SS-6T Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB15S-4T Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB15SS-4T Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB15S-6T Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB15SS-6T Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB20S-4T Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB20SS-4T Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB20S-6T Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB20SS-6T Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB25S-4T Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB25SS-4T Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB25S-6T Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB25SS-6T Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB30S-4T Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB30SS-4T Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB30S-6T Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB30SS-6T Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC10S-4 Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC10SS-4 Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC15S-4 Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC15SS-4 Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC20S-4 Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC20SS-4 Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC25S-4 Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC25SS-4 Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC30S-4 Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC30SS-4 Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC10S-4T Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC10SS-4T Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC10S-6T Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC10SS-6T Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC15S-4T Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC15SS-4T Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC15S-6T Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC15SS-6T Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC20S-4T Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC20SS-4T Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC20S-6T Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC20SS-6T Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC25S-4T Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC25SS-4T Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC25S-6T Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC25SS-6T Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC30S-4T Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC30SS-4T Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC30S-6T Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC30SS-6T Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD10S-4 Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD10SS-4 Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD15S-4 Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD15SS-4 Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD20S-4 Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD20SS-4 Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD25S-4 Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD25SS-4 Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD30S-4 Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD30SS-4 Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD10S-4T Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD10SS-4T Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD10S-6T Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD10SS-6T Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD15S-4T Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD15SS-4T Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD15S-6T Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD15SS-6T Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD20S-4T Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD20SS-4T Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD20S-6T Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD20SS-6T Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD25S-4T Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD25SS-4T Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD25S-6T Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD25SS-6T Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD30S-4T Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD30SS-4T Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD30S-6T Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD30SS-6T Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSPG-10SA Holder: None (pad only) | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-10SSA Holder: None (pad only) | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-15SA Holder: None (pad only) | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-15SSA Holder: None (pad only) | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-20SA Holder: None (pad only) | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-20SSA Holder: None (pad only) | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-25SA Holder: None (pad only) | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-25SSA Holder: None (pad only) | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-30SA Holder: None (pad only) | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-30SSA Holder: None (pad only) | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-35SA Holder: None (pad only) | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-35SSA Holder: None (pad only) | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-50SA Holder: None (pad only) | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-50SSA Holder: None (pad only) | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-70SA Holder: None (pad only) | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-70SSA Holder: None (pad only) | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-100SA Holder: None (pad only) | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-100SSA Holder: None (pad only) | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
Vacuum PadsCKD
280 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD VSP-S Vacuum Pad, Sponge Type (ø10 to ø100)

Brand CKD·Vacuum Pads

Available part numbers (280)

VSP-A10S-6, VSP-A10SS-6, VSP-A15S-6, VSP-A15SS-6, VSP-A20S-6, VSP-A20SS-6, VSP-A25S-6, VSP-A25SS-6, VSP-A30S-6, VSP-A30SS-6 + 270 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
VSP-A10S-6Holder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A10SS-6Holder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A15S-6Holder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A15SS-6Holder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A20S-6Holder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A20SS-6Holder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A25S-6Holder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A25SS-6Holder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A30S-6Holder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A30SS-6Holder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A35S-6Holder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A35SS-6Holder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A50S-6Holder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-A50SS-6Holder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-A70S-6AHolder: A Fixed, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-A70SS-6AHolder: A Fixed, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-A100S-6AHolder: A Fixed, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-A100SS-6AHolder: A Fixed, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-A10S-6THolder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A10SS-6THolder: A Fixed, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A15S-6THolder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A15SS-6THolder: A Fixed, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A20S-6THolder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A20SS-6THolder: A Fixed, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A25S-6THolder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A25SS-6THolder: A Fixed, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A30S-6THolder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A30SS-6THolder: A Fixed, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A35S-6THolder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A35SS-6THolder: A Fixed, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-A50S-6THolder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-A50SS-6THolder: A Fixed, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B10S-6Holder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B10SS-6Holder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B15S-6Holder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B15SS-6Holder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B20S-6Holder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B20SS-6Holder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B25S-6Holder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B25SS-6Holder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B30S-6Holder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B30SS-6Holder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B35S-6Holder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B35SS-6Holder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B50S-6Holder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-B50SS-6Holder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-B70S-6AHolder: B Fixed, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-B70SS-6AHolder: B Fixed, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-B100S-6AHolder: B Fixed, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-B100SS-6AHolder: B Fixed, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-B10S-6THolder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B10SS-6THolder: B Fixed, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B15S-6THolder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B15SS-6THolder: B Fixed, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B20S-6THolder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B20SS-6THolder: B Fixed, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B25S-6THolder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B25SS-6THolder: B Fixed, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B30S-6THolder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B30SS-6THolder: B Fixed, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B35S-6THolder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B35SS-6THolder: B Fixed, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-B50S-6THolder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-B50SS-6THolder: B Fixed, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C10S-6Holder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C10SS-6Holder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C15S-6Holder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C15SS-6Holder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C20S-6Holder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C20SS-6Holder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C25S-6Holder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C25SS-6Holder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C30S-6Holder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C30SS-6Holder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C35S-6Holder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C35SS-6Holder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C50S-6Holder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-C50SS-6Holder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-C70S-6AHolder: C Buffer, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-C70SS-6AHolder: C Buffer, top vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-C100S-6AHolder: C Buffer, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-C100SS-6AHolder: C Buffer, top vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-C10S-6THolder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C10SS-6THolder: C Buffer, top vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C15S-6THolder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C15SS-6THolder: C Buffer, top vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C20S-6THolder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C20SS-6THolder: C Buffer, top vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C25S-6THolder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C25SS-6THolder: C Buffer, top vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C30S-6THolder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C30SS-6THolder: C Buffer, top vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C35S-6THolder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C35SS-6THolder: C Buffer, top vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-C50S-6THolder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-C50SS-6THolder: C Buffer, top vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D10S-6Holder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D10SS-6Holder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D15S-6Holder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D15SS-6Holder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D20S-6Holder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D20SS-6Holder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D25S-6Holder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D25SS-6Holder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D30S-6Holder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D30SS-6Holder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D35S-6Holder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D35SS-6Holder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D50S-6Holder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 push-in
VSP-D50SS-6Holder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 push-in
VSP-D70S-6AHolder: D Buffer, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-D70SS-6AHolder: D Buffer, side vacuum port | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-D100S-6AHolder: D Buffer, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Rp1/8 female
VSP-D100SS-6AHolder: D Buffer, side vacuum port | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Rp1/8 female
VSP-D10S-6THolder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D10SS-6THolder: D Buffer, side vacuum port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D15S-6THolder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D15SS-6THolder: D Buffer, side vacuum port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D20S-6THolder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D20SS-6THolder: D Buffer, side vacuum port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D25S-6THolder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D25SS-6THolder: D Buffer, side vacuum port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D30S-6THolder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D30SS-6THolder: D Buffer, side vacuum port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D35S-6THolder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D35SS-6THolder: D Buffer, side vacuum port | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-D50S-6THolder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-D50SS-6THolder: D Buffer, side vacuum port | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-F10SHolder: F Direct mount, buffer | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F10SSHolder: F Direct mount, buffer | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F15SHolder: F Direct mount, buffer | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F15SSHolder: F Direct mount, buffer | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F20SHolder: F Direct mount, buffer | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F20SSHolder: F Direct mount, buffer | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F25SHolder: F Direct mount, buffer | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F25SSHolder: F Direct mount, buffer | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F30SHolder: F Direct mount, buffer | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F30SSHolder: F Direct mount, buffer | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F35SHolder: F Direct mount, buffer | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F35SSHolder: F Direct mount, buffer | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-F50SHolder: F Direct mount, buffer | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Male thread (direct)
VSP-F50SSHolder: F Direct mount, buffer | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Male thread (direct)
VSP-MA10S-4Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA10SS-4Holder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA15S-4Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA15SS-4Holder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA20S-4Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA20SS-4Holder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA25S-4Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA25SS-4Holder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA30S-4Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MA30SS-4Holder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MA10S-4THolder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA10SS-4THolder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA10S-6THolder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA10SS-6THolder: MA Small fixed, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA15S-4THolder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA15SS-4THolder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA15S-6THolder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA15SS-6THolder: MA Small fixed, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA20S-4THolder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA20SS-4THolder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA20S-6THolder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA20SS-6THolder: MA Small fixed, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA25S-4THolder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA25SS-4THolder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA25S-6THolder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA25SS-6THolder: MA Small fixed, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MA30S-4THolder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MA30SS-4THolder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MA30S-6THolder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MA30SS-6THolder: MA Small fixed, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB10S-4Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB10SS-4Holder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB15S-4Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB15SS-4Holder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB20S-4Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB20SS-4Holder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB25S-4Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB25SS-4Holder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB30S-4Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MB30SS-4Holder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MB10S-4THolder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB10SS-4THolder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB10S-6THolder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB10SS-6THolder: MB Small fixed, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB15S-4THolder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB15SS-4THolder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB15S-6THolder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB15SS-6THolder: MB Small fixed, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB20S-4THolder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB20SS-4THolder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB20S-6THolder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB20SS-6THolder: MB Small fixed, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB25S-4THolder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB25SS-4THolder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB25S-6THolder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB25SS-6THolder: MB Small fixed, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MB30S-4THolder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MB30SS-4THolder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MB30S-6THolder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MB30SS-6THolder: MB Small fixed, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC10S-4Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC10SS-4Holder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC15S-4Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC15SS-4Holder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC20S-4Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC20SS-4Holder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC25S-4Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC25SS-4Holder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC30S-4Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MC30SS-4Holder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MC10S-4THolder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC10SS-4THolder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC10S-6THolder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC10SS-6THolder: MC Small buffer, top port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC15S-4THolder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC15SS-4THolder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC15S-6THolder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC15SS-6THolder: MC Small buffer, top port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC20S-4THolder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC20SS-4THolder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC20S-6THolder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC20SS-6THolder: MC Small buffer, top port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC25S-4THolder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC25SS-4THolder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC25S-6THolder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC25SS-6THolder: MC Small buffer, top port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MC30S-4THolder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MC30SS-4THolder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MC30S-6THolder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MC30SS-6THolder: MC Small buffer, top port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD10S-4Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD10SS-4Holder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD15S-4Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD15SS-4Holder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD20S-4Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD20SS-4Holder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD25S-4Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD25SS-4Holder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD30S-4Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 push-in
VSP-MD30SS-4Holder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 push-in
VSP-MD10S-4THolder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD10SS-4THolder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD10S-6THolder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD10SS-6THolder: MD Small buffer, side port | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD15S-4THolder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD15SS-4THolder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD15S-6THolder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD15SS-6THolder: MD Small buffer, side port | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD20S-4THolder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD20SS-4THolder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD20S-6THolder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD20SS-6THolder: MD Small buffer, side port | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD25S-4THolder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD25SS-4THolder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD25S-6THolder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD25SS-6THolder: MD Small buffer, side port | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSP-MD30S-4THolder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø4 barb
VSP-MD30SS-4THolder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø4 barb
VSP-MD30S-6THolder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: ø6 barb
VSP-MD30SS-6THolder: MD Small buffer, side port | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: ø6 barb
VSPG-10SAHolder: None (pad only) | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-10SSAHolder: None (pad only) | Pad diameter: ø10 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-15SAHolder: None (pad only) | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-15SSAHolder: None (pad only) | Pad diameter: ø15 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-20SAHolder: None (pad only) | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-20SSAHolder: None (pad only) | Pad diameter: ø20 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-25SAHolder: None (pad only) | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-25SSAHolder: None (pad only) | Pad diameter: ø25 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-30SAHolder: None (pad only) | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-30SSAHolder: None (pad only) | Pad diameter: ø30 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-35SAHolder: None (pad only) | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-35SSAHolder: None (pad only) | Pad diameter: ø35 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-50SAHolder: None (pad only) | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-50SSAHolder: None (pad only) | Pad diameter: ø50 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-70SAHolder: None (pad only) | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-70SSAHolder: None (pad only) | Pad diameter: ø70 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame
VSPG-100SAHolder: None (pad only) | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Chloroprene rubber (CR) | Connection: Pad only, with frame
VSPG-100SSAHolder: None (pad only) | Pad diameter: ø100 mm | Pad shape: Sponge | Material: Silicone rubber | Connection: Pad only, with frame

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
