CKD W4GB4/W4GZ4 5-Port Solenoid Valve (Single Unit)

CKD W4GB4/W4GZ4 5-Port Solenoid Valve (Single Unit)

CKD W4GB4/W4GZ4 pilot-operated 5-port soft-spool solenoid valves on a single subplate with side (W4GB4) or bottom (W4GZ4) piping for 63-125 mm cylinders.

Key features

  • Single-unit valve with subplate: W4GB4 side-ported (Rc/G/NPT 1/4, 3/8), W4GZ4 bottom-ported (Rc/G/NPT 1/4, Rc 3/8)
  • 2-position single/double and 3-position all-ports-blocked, A/B/R and P/A/B centre functions
  • Terminal block (AC100/110V, DC12/24V) or M12 4-pin I/O connector R1 (DC only, 500 mm); lamp and surge suppressor standard
  • Subplate-only (W4GB4-SP / W4GZ4-SP) and base-mount valve only (W4GB4[ ]9-00) codes listed
  • Options not expanded: M7 pilot-air OFF lock, K external pilot, A coolant-resistant, F A/B port filter; suffix -P40 secondary battery, -ST CE
  • Flow C = 7.7 dm3/(s.bar) (2-position, Rc3/8); response 30 ms ON / 38 ms OFF (single)

Specifications

Valve type Pilot-operated soft spool, 5-port
Media Compressed air
Operating pressure 0.2 to 1.0 MPa (ext. pilot 0 to 1.0)
Proof pressure 1.5 MPa
Ambient / fluid temp. -5 to 55 C / 5 to 55 C
Lubrication Not required (ISO VG32 if used)
Protection IP65 dust/jet-proof
Applicable cylinder bore 63 to 125 mm
Power consumption DC 1.2 W; AC 1.8/1.5 VA (holding)
Source CKD Korea catalog CB-023SK-9, p. 1187-1199
W4GB410-08-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-08-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-08-M-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-08-M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08-M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08-M-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-08-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-10-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-10-M-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-10-M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10-M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10-M-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-10-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08G-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-08G-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08G-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08G-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-08G-M-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-08G-M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08G-M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08G-M-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-08G-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08G-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08G-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08G-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10G-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-10G-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10G-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10G-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-10G-M-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-10G-M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10G-M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10G-M-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-10G-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10G-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10G-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10G-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08N-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-08N-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08N-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08N-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-08N-M-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-08N-M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08N-M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08N-M-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-08N-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08N-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08N-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08N-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10N-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-10N-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10N-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10N-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-10N-M-1 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-10N-M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10N-M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10N-M-5 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-10N-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10N-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10N-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10N-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-08-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-08-M-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-08-M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08-M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08-M-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-08-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-10-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-10-M-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-10-M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10-M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10-M-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-10-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08G-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-08G-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08G-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08G-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-08G-M-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-08G-M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08G-M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08G-M-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-08G-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08G-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08G-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08G-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10G-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-10G-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10G-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10G-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-10G-M-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-10G-M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10G-M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10G-M-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-10G-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10G-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10G-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10G-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08N-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-08N-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08N-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08N-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-08N-M-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-08N-M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08N-M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08N-M-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-08N-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08N-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08N-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08N-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10N-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-10N-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10N-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10N-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-10N-M-1 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-10N-M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10N-M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10N-M-5 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-10N-R1-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10N-R1-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10N-R1M-3 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10N-R1M-4 Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-08-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-08-M-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-08-M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08-M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08-M-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-08-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-10-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-10-M-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-10-M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10-M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10-M-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-10-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08G-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-08G-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08G-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08G-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-08G-M-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-08G-M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08G-M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08G-M-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-08G-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08G-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08G-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08G-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10G-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-10G-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10G-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10G-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-10G-M-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-10G-M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10G-M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10G-M-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-10G-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10G-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10G-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10G-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08N-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-08N-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08N-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08N-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-08N-M-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-08N-M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08N-M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08N-M-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-08N-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08N-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08N-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08N-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10N-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-10N-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10N-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10N-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-10N-M-1 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-10N-M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10N-M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10N-M-5 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-10N-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10N-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10N-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10N-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-08-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-08-M-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-08-M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08-M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08-M-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-08-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-10-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-10-M-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-10-M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10-M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10-M-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-10-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08G-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-08G-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08G-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08G-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-08G-M-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-08G-M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08G-M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08G-M-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-08G-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08G-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08G-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08G-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10G-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-10G-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10G-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10G-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-10G-M-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-10G-M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10G-M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10G-M-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-10G-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10G-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10G-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10G-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08N-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-08N-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08N-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08N-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-08N-M-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-08N-M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08N-M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08N-M-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-08N-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08N-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08N-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08N-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10N-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-10N-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10N-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10N-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-10N-M-1 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-10N-M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10N-M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10N-M-5 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-10N-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10N-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10N-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10N-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-08-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-08-M-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-08-M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08-M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08-M-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-08-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-10-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-10-M-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-10-M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10-M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10-M-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-10-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08G-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-08G-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08G-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08G-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-08G-M-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-08G-M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08G-M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08G-M-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-08G-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08G-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08G-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08G-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10G-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-10G-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10G-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10G-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-10G-M-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-10G-M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10G-M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10G-M-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-10G-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10G-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10G-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10G-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08N-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-08N-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08N-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08N-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-08N-M-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-08N-M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08N-M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08N-M-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-08N-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08N-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08N-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08N-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10N-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-10N-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10N-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10N-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-10N-M-1 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-10N-M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10N-M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10N-M-5 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-10N-R1-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10N-R1-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10N-R1M-3 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10N-R1M-4 Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-08-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-08-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-08-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-08-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-10-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-10-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-10-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-10-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-10-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-10-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-10-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-10-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-10-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-10-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-10-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-10-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08G-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-08G-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08G-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08G-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-08G-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-08G-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08G-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08G-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-08G-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08G-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08G-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08G-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08N-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-08N-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08N-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08N-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-08N-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-08N-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08N-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08N-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-08N-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08N-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08N-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08N-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-08-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-08-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-08-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-08-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-10-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-10-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-10-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-10-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-10-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-10-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-10-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-10-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-10-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-10-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-10-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-10-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08G-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-08G-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08G-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08G-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-08G-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-08G-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08G-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08G-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-08G-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08G-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08G-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08G-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08N-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-08N-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08N-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08N-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-08N-M-1 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-08N-M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08N-M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08N-M-5 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-08N-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08N-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08N-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08N-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-08-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-08-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-08-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-08-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-10-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-10-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-10-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-10-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-10-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-10-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-10-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-10-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-10-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-10-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-10-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-10-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08G-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-08G-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08G-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08G-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-08G-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-08G-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08G-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08G-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-08G-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08G-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08G-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08G-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08N-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-08N-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08N-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08N-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-08N-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-08N-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08N-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08N-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-08N-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08N-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08N-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08N-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-08-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-08-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-08-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-08-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-10-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-10-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-10-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-10-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-10-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-10-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-10-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-10-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-10-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-10-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-10-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-10-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08G-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-08G-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08G-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08G-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-08G-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-08G-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08G-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08G-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-08G-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08G-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08G-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08G-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08N-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-08N-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08N-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08N-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-08N-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-08N-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08N-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08N-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-08N-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08N-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08N-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08N-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-08-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-08-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-08-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-08-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-10-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-10-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-10-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-10-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-10-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-10-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-10-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-10-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-10-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-10-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-10-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-10-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08G-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-08G-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08G-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08G-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-08G-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-08G-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08G-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08G-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-08G-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08G-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08G-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08G-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08N-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-08N-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08N-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08N-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-08N-M-1 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-08N-M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08N-M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08N-M-5 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-08N-R1-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08N-R1-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08N-R1M-3 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08N-R1M-4 Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB4-SP-08 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-08-R1 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-10 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-10-R1 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-08G Body: W4GB4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-08G-R1 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-10G Body: W4GB4 subplate only | Function: None (subplate) | A/B port: G3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-10G-R1 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-08N Body: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-08N-R1 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-10N Body: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-10N-R1 Body: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-08 Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-08-R1 Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-10 Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-10-R1 Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-08G Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-08G-R1 Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-08N Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-08N-R1 Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB419-00-1 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB419-00-3 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB419-00-4 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB419-00-5 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB419-00-M-1 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB419-00-M-3 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB419-00-M-4 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB419-00-M-5 Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB429-00-1 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB429-00-3 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB429-00-4 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB429-00-5 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB429-00-M-1 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB429-00-M-3 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB429-00-M-4 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB429-00-M-5 Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB439-00-1 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB439-00-3 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB439-00-4 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB439-00-5 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB439-00-M-1 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB439-00-M-3 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB439-00-M-4 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB439-00-M-5 Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB449-00-1 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB449-00-3 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB449-00-4 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB449-00-5 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB449-00-M-1 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB449-00-M-3 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB449-00-M-4 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB449-00-M-5 Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB459-00-1 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB459-00-3 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB459-00-4 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB459-00-5 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB459-00-M-1 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB459-00-M-3 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB459-00-M-4 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB459-00-M-5 Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
Solenoid ValvesCKD
660 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD W4GB4/W4GZ4 5-Port Solenoid Valve (Single Unit)

Brand CKD·Solenoid Valves

Available part numbers (660)

W4GB410-08-1, W4GB410-08-3, W4GB410-08-4, W4GB410-08-5, W4GB410-08-M-1, W4GB410-08-M-3, W4GB410-08-M-4, W4GB410-08-M-5, W4GB410-08-R1-3, W4GB410-08-R1-4 + 650 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
W4GB410-08-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-08-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-08-M-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-08-M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08-M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08-M-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-08-R1-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08-R1-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-10-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-10-M-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-10-M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10-M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10-M-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-10-R1-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10-R1-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08G-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-08G-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08G-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08G-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-08G-M-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-08G-M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08G-M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08G-M-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-08G-R1-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08G-R1-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08G-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08G-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10G-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-10G-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10G-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10G-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-10G-M-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-10G-M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10G-M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10G-M-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-10G-R1-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10G-R1-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10G-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10G-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08N-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-08N-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08N-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08N-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-08N-M-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-08N-M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08N-M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-08N-M-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-08N-R1-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-08N-R1-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-08N-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-08N-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10N-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB410-10N-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10N-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10N-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB410-10N-M-1Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB410-10N-M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10N-M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB410-10N-M-5Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB410-10N-R1-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB410-10N-R1-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB410-10N-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB410-10N-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position single | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-08-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-08-M-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-08-M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08-M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08-M-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-08-R1-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08-R1-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-10-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-10-M-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-10-M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10-M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10-M-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-10-R1-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10-R1-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08G-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-08G-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08G-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08G-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-08G-M-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-08G-M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08G-M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08G-M-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-08G-R1-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08G-R1-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08G-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08G-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10G-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-10G-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10G-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10G-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-10G-M-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-10G-M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10G-M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10G-M-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-10G-R1-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10G-R1-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10G-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10G-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08N-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-08N-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08N-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08N-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-08N-M-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-08N-M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08N-M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-08N-M-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-08N-R1-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-08N-R1-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-08N-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-08N-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10N-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB420-10N-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10N-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10N-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB420-10N-M-1Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB420-10N-M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10N-M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB420-10N-M-5Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB420-10N-R1-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB420-10N-R1-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB420-10N-R1M-3Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB420-10N-R1M-4Body: W4GB4 Side ported (base) | Function: 2-position double | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-08-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-08-M-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-08-M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08-M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08-M-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-08-R1-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08-R1-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-10-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-10-M-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-10-M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10-M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10-M-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-10-R1-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10-R1-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08G-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-08G-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08G-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08G-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-08G-M-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-08G-M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08G-M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08G-M-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-08G-R1-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08G-R1-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08G-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08G-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10G-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-10G-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10G-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10G-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-10G-M-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-10G-M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10G-M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10G-M-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-10G-R1-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10G-R1-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10G-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10G-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08N-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-08N-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08N-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08N-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-08N-M-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-08N-M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08N-M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-08N-M-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-08N-R1-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-08N-R1-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-08N-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-08N-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10N-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB430-10N-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10N-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10N-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB430-10N-M-1Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB430-10N-M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10N-M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB430-10N-M-5Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB430-10N-R1-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB430-10N-R1-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB430-10N-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB430-10N-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position all ports blocked | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-08-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-08-M-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-08-M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08-M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08-M-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-08-R1-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08-R1-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-10-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-10-M-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-10-M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10-M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10-M-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-10-R1-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10-R1-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08G-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-08G-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08G-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08G-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-08G-M-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-08G-M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08G-M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08G-M-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-08G-R1-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08G-R1-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08G-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08G-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10G-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-10G-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10G-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10G-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-10G-M-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-10G-M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10G-M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10G-M-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-10G-R1-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10G-R1-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10G-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10G-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08N-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-08N-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08N-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08N-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-08N-M-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-08N-M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08N-M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-08N-M-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-08N-R1-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-08N-R1-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-08N-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-08N-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10N-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB440-10N-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10N-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10N-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB440-10N-M-1Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB440-10N-M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10N-M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB440-10N-M-5Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB440-10N-R1-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB440-10N-R1-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB440-10N-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB440-10N-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position A/B/R connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-08-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-08-M-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-08-M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08-M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08-M-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-08-R1-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08-R1-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-10-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-10-M-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-10-M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10-M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10-M-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-10-R1-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10-R1-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08G-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-08G-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08G-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08G-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-08G-M-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-08G-M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08G-M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08G-M-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-08G-R1-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08G-R1-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08G-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08G-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10G-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-10G-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10G-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10G-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-10G-M-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-10G-M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10G-M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10G-M-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-10G-R1-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10G-R1-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10G-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10G-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08N-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-08N-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08N-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08N-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-08N-M-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-08N-M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08N-M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-08N-M-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-08N-R1-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-08N-R1-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-08N-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-08N-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10N-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB450-10N-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10N-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10N-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB450-10N-M-1Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GB450-10N-M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10N-M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GB450-10N-M-5Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GB450-10N-R1-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB450-10N-R1-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB450-10N-R1M-3Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB450-10N-R1M-4Body: W4GB4 Side ported (base) | Function: 3-position P/A/B connection | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-08-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-08-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-08-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-08-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-10-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-10-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-10-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-10-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-10-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-10-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-10-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-10-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-10-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-10-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-10-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-10-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08G-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-08G-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08G-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08G-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-08G-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-08G-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08G-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08G-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-08G-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08G-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08G-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08G-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08N-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ410-08N-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08N-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08N-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ410-08N-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ410-08N-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08N-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ410-08N-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ410-08N-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ410-08N-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ410-08N-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ410-08N-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position single | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-08-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-08-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-08-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-08-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-10-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-10-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-10-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-10-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-10-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-10-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-10-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-10-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-10-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-10-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-10-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-10-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08G-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-08G-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08G-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08G-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-08G-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-08G-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08G-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08G-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-08G-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08G-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08G-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08G-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08N-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ420-08N-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08N-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08N-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ420-08N-M-1Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ420-08N-M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08N-M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ420-08N-M-5Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ420-08N-R1-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ420-08N-R1-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ420-08N-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ420-08N-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 2-position double | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-08-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-08-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-08-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-08-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-10-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-10-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-10-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-10-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-10-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-10-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-10-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-10-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-10-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-10-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-10-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-10-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08G-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-08G-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08G-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08G-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-08G-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-08G-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08G-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08G-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-08G-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08G-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08G-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08G-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08N-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ430-08N-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08N-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08N-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ430-08N-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ430-08N-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08N-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ430-08N-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ430-08N-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ430-08N-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ430-08N-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ430-08N-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position all ports blocked | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-08-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-08-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-08-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-08-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-10-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-10-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-10-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-10-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-10-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-10-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-10-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-10-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-10-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-10-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-10-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-10-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08G-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-08G-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08G-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08G-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-08G-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-08G-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08G-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08G-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-08G-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08G-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08G-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08G-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08N-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ440-08N-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08N-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08N-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ440-08N-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ440-08N-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08N-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ440-08N-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ440-08N-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ440-08N-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ440-08N-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ440-08N-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position A/B/R connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-08-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-08-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-08-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-08-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-10-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-10-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-10-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-10-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-10-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-10-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-10-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-10-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-10-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-10-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-10-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-10-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08G-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-08G-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08G-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08G-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-08G-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-08G-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08G-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08G-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-08G-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08G-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08G-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08G-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08N-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC100V
W4GZ450-08N-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08N-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08N-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock/lock common | Voltage: AC110V
W4GZ450-08N-M-1Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC100V
W4GZ450-08N-M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08N-M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: DC12V
W4GZ450-08N-M-5Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: Non-lock (M) | Voltage: AC110V
W4GZ450-08N-R1-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GZ450-08N-R1-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GZ450-08N-R1M-3Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC24V
W4GZ450-08N-R1M-4Body: W4GZ4 Bottom ported (base) | Function: 3-position P/A/B connection | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB4-SP-08Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-08-R1Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-10Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-10-R1Body: W4GB4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-08GBody: W4GB4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-08G-R1Body: W4GB4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-10GBody: W4GB4 subplate only | Function: None (subplate) | A/B port: G3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-10G-R1Body: W4GB4 subplate only | Function: None (subplate) | A/B port: G3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-08NBody: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-08N-R1Body: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB4-SP-10NBody: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GB4-SP-10N-R1Body: W4GB4 subplate only | Function: None (subplate) | A/B port: NPT3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-08Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-08-R1Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-10Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-10-R1Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: Rc3/8 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-08GBody: W4GZ4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-08G-R1Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: G1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GZ4-SP-08NBody: W4GZ4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: Terminal block | Manual override: None | Voltage: None
W4GZ4-SP-08N-R1Body: W4GZ4 subplate only | Function: None (subplate) | A/B port: NPT1/4 | Wiring: M12 I/O connector (R1) | Manual override: None | Voltage: None
W4GB419-00-1Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB419-00-3Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB419-00-4Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB419-00-5Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB419-00-M-1Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB419-00-M-3Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB419-00-M-4Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB419-00-M-5Body: W4GB4 valve only (base mount) | Function: 2-position single | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB429-00-1Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB429-00-3Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB429-00-4Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB429-00-5Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB429-00-M-1Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB429-00-M-3Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB429-00-M-4Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB429-00-M-5Body: W4GB4 valve only (base mount) | Function: 2-position double | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB439-00-1Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB439-00-3Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB439-00-4Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB439-00-5Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB439-00-M-1Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB439-00-M-3Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB439-00-M-4Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB439-00-M-5Body: W4GB4 valve only (base mount) | Function: 3-position all ports blocked | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB449-00-1Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB449-00-3Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB449-00-4Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB449-00-5Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB449-00-M-1Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB449-00-M-3Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB449-00-M-4Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB449-00-M-5Body: W4GB4 valve only (base mount) | Function: 3-position A/B/R connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V
W4GB459-00-1Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC100V
W4GB459-00-3Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC24V
W4GB459-00-4Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: DC12V
W4GB459-00-5Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock/lock common | Voltage: AC110V
W4GB459-00-M-1Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC100V
W4GB459-00-M-3Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC24V
W4GB459-00-M-4Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: DC12V
W4GB459-00-M-5Body: W4GB4 valve only (base mount) | Function: 3-position P/A/B connection | A/B port: None (base) | Wiring: Plug-in (base) | Manual override: Non-lock (M) | Voltage: AC110V

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
