CKD ZW Stainless Steel New Joint Push-in Fittings (P80 Oil-Free)

CKD ZW Stainless Steel New Joint Push-in Fittings (P80 Oil-Free)

CKD ZW stainless steel New Joint push-in fittings in P80 oil-free specification for ø4 to ø12 tube with M5 to R1/2 connections.

Key features

  • Male straight, male elbow and union straight/elbow/tee shapes
  • Metal parts stainless steel; NBR seals; no grease; no PTFE thread sealant (identical to P84)
  • Release ring light blue; P70/P74 not offered for this series
  • Vacuum use with U-92/U-95/NU tube requires an insert ring (made to order)

Specifications

Fluid Compressed air
Max. operating pressure 1.0 MPa
Vacuum -100 kPa
Ambient temperature -10 to 60°C (no freezing)
Body material Stainless steel
Clean spec P80 oil-free
Sales unit 1 pc
Source CKD Korea catalog CB-033S-4, p. 973-974
ZW-S4-M5-P80 Shape: Straight | Variant: Male thread | Tube OD: ø4 | Connection: M5x0.8
ZW-S4-6-P80 Shape: Straight | Variant: Male thread | Tube OD: ø4 | Connection: R1/8
ZW-S4-8-P80 Shape: Straight | Variant: Male thread | Tube OD: ø4 | Connection: R1/4
ZW-S6-M5-P80 Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: M5x0.8
ZW-S6-6-P80 Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: R1/8
ZW-S6-8-P80 Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: R1/4
ZW-S6-10-P80 Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: R3/8
ZW-S8-6-P80 Shape: Straight | Variant: Male thread | Tube OD: ø8 | Connection: R1/8
ZW-S8-8-P80 Shape: Straight | Variant: Male thread | Tube OD: ø8 | Connection: R1/4
ZW-S8-10-P80 Shape: Straight | Variant: Male thread | Tube OD: ø8 | Connection: R3/8
ZW-S10-8-P80 Shape: Straight | Variant: Male thread | Tube OD: ø10 | Connection: R1/4
ZW-S10-10-P80 Shape: Straight | Variant: Male thread | Tube OD: ø10 | Connection: R3/8
ZW-S10-15-P80 Shape: Straight | Variant: Male thread | Tube OD: ø10 | Connection: R1/2
ZW-S12-10-P80 Shape: Straight | Variant: Male thread | Tube OD: ø12 | Connection: R3/8
ZW-S12-15-P80 Shape: Straight | Variant: Male thread | Tube OD: ø12 | Connection: R1/2
ZW-L4-0-P80 Shape: Elbow | Variant: Union | Tube OD: ø4 | Connection: None (union)
ZW-L6-0-P80 Shape: Elbow | Variant: Union | Tube OD: ø6 | Connection: None (union)
ZW-L8-0-P80 Shape: Elbow | Variant: Union | Tube OD: ø8 | Connection: None (union)
ZW-L10-0-P80 Shape: Elbow | Variant: Union | Tube OD: ø10 | Connection: None (union)
ZW-L12-0-P80 Shape: Elbow | Variant: Union | Tube OD: ø12 | Connection: None (union)
ZW-L4-M5-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø4 | Connection: M5x0.8
ZW-L4-6-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø4 | Connection: R1/8
ZW-L4-8-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø4 | Connection: R1/4
ZW-L6-M5-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: M5x0.8
ZW-L6-6-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: R1/8
ZW-L6-8-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: R1/4
ZW-L6-10-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: R3/8
ZW-L8-6-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø8 | Connection: R1/8
ZW-L8-8-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø8 | Connection: R1/4
ZW-L8-10-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø8 | Connection: R3/8
ZW-L10-8-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø10 | Connection: R1/4
ZW-L10-10-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø10 | Connection: R3/8
ZW-L10-15-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø10 | Connection: R1/2
ZW-L12-10-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø12 | Connection: R3/8
ZW-L12-15-P80 Shape: Elbow | Variant: Male thread | Tube OD: ø12 | Connection: R1/2
ZW-T4-0-P80 Shape: Tee | Variant: Union | Tube OD: ø4 | Connection: None (union)
ZW-T6-0-P80 Shape: Tee | Variant: Union | Tube OD: ø6 | Connection: None (union)
ZW-T8-0-P80 Shape: Tee | Variant: Union | Tube OD: ø8 | Connection: None (union)
ZW-T10-0-P80 Shape: Tee | Variant: Union | Tube OD: ø10 | Connection: None (union)
ZW-T12-0-P80 Shape: Tee | Variant: Union | Tube OD: ø12 | Connection: None (union)
ZW-S4-0-P80 Shape: Straight | Variant: Union | Tube OD: ø4 | Connection: None (union)
ZW-S6-0-P80 Shape: Straight | Variant: Union | Tube OD: ø6 | Connection: None (union)
ZW-S8-0-P80 Shape: Straight | Variant: Union | Tube OD: ø8 | Connection: None (union)
ZW-S10-0-P80 Shape: Straight | Variant: Union | Tube OD: ø10 | Connection: None (union)
ZW-S12-0-P80 Shape: Straight | Variant: Union | Tube OD: ø12 | Connection: None (union)
Pneumatic FittingsCKD
45 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD ZW Stainless Steel New Joint Push-in Fittings (P80 Oil-Free)

Brand CKD·Pneumatic Fittings

Available part numbers (45)

ZW-S4-M5-P80, ZW-S4-6-P80, ZW-S4-8-P80, ZW-S6-M5-P80, ZW-S6-6-P80, ZW-S6-8-P80, ZW-S6-10-P80, ZW-S8-6-P80, ZW-S8-8-P80, ZW-S8-10-P80 + 35 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ZW-S4-M5-P80Shape: Straight | Variant: Male thread | Tube OD: ø4 | Connection: M5x0.8
ZW-S4-6-P80Shape: Straight | Variant: Male thread | Tube OD: ø4 | Connection: R1/8
ZW-S4-8-P80Shape: Straight | Variant: Male thread | Tube OD: ø4 | Connection: R1/4
ZW-S6-M5-P80Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: M5x0.8
ZW-S6-6-P80Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: R1/8
ZW-S6-8-P80Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: R1/4
ZW-S6-10-P80Shape: Straight | Variant: Male thread | Tube OD: ø6 | Connection: R3/8
ZW-S8-6-P80Shape: Straight | Variant: Male thread | Tube OD: ø8 | Connection: R1/8
ZW-S8-8-P80Shape: Straight | Variant: Male thread | Tube OD: ø8 | Connection: R1/4
ZW-S8-10-P80Shape: Straight | Variant: Male thread | Tube OD: ø8 | Connection: R3/8
ZW-S10-8-P80Shape: Straight | Variant: Male thread | Tube OD: ø10 | Connection: R1/4
ZW-S10-10-P80Shape: Straight | Variant: Male thread | Tube OD: ø10 | Connection: R3/8
ZW-S10-15-P80Shape: Straight | Variant: Male thread | Tube OD: ø10 | Connection: R1/2
ZW-S12-10-P80Shape: Straight | Variant: Male thread | Tube OD: ø12 | Connection: R3/8
ZW-S12-15-P80Shape: Straight | Variant: Male thread | Tube OD: ø12 | Connection: R1/2
ZW-L4-0-P80Shape: Elbow | Variant: Union | Tube OD: ø4 | Connection: None (union)
ZW-L6-0-P80Shape: Elbow | Variant: Union | Tube OD: ø6 | Connection: None (union)
ZW-L8-0-P80Shape: Elbow | Variant: Union | Tube OD: ø8 | Connection: None (union)
ZW-L10-0-P80Shape: Elbow | Variant: Union | Tube OD: ø10 | Connection: None (union)
ZW-L12-0-P80Shape: Elbow | Variant: Union | Tube OD: ø12 | Connection: None (union)
ZW-L4-M5-P80Shape: Elbow | Variant: Male thread | Tube OD: ø4 | Connection: M5x0.8
ZW-L4-6-P80Shape: Elbow | Variant: Male thread | Tube OD: ø4 | Connection: R1/8
ZW-L4-8-P80Shape: Elbow | Variant: Male thread | Tube OD: ø4 | Connection: R1/4
ZW-L6-M5-P80Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: M5x0.8
ZW-L6-6-P80Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: R1/8
ZW-L6-8-P80Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: R1/4
ZW-L6-10-P80Shape: Elbow | Variant: Male thread | Tube OD: ø6 | Connection: R3/8
ZW-L8-6-P80Shape: Elbow | Variant: Male thread | Tube OD: ø8 | Connection: R1/8
ZW-L8-8-P80Shape: Elbow | Variant: Male thread | Tube OD: ø8 | Connection: R1/4
ZW-L8-10-P80Shape: Elbow | Variant: Male thread | Tube OD: ø8 | Connection: R3/8
ZW-L10-8-P80Shape: Elbow | Variant: Male thread | Tube OD: ø10 | Connection: R1/4
ZW-L10-10-P80Shape: Elbow | Variant: Male thread | Tube OD: ø10 | Connection: R3/8
ZW-L10-15-P80Shape: Elbow | Variant: Male thread | Tube OD: ø10 | Connection: R1/2
ZW-L12-10-P80Shape: Elbow | Variant: Male thread | Tube OD: ø12 | Connection: R3/8
ZW-L12-15-P80Shape: Elbow | Variant: Male thread | Tube OD: ø12 | Connection: R1/2
ZW-T4-0-P80Shape: Tee | Variant: Union | Tube OD: ø4 | Connection: None (union)
ZW-T6-0-P80Shape: Tee | Variant: Union | Tube OD: ø6 | Connection: None (union)
ZW-T8-0-P80Shape: Tee | Variant: Union | Tube OD: ø8 | Connection: None (union)
ZW-T10-0-P80Shape: Tee | Variant: Union | Tube OD: ø10 | Connection: None (union)
ZW-T12-0-P80Shape: Tee | Variant: Union | Tube OD: ø12 | Connection: None (union)
ZW-S4-0-P80Shape: Straight | Variant: Union | Tube OD: ø4 | Connection: None (union)
ZW-S6-0-P80Shape: Straight | Variant: Union | Tube OD: ø6 | Connection: None (union)
ZW-S8-0-P80Shape: Straight | Variant: Union | Tube OD: ø8 | Connection: None (union)
ZW-S10-0-P80Shape: Straight | Variant: Union | Tube OD: ø10 | Connection: None (union)
ZW-S12-0-P80Shape: Straight | Variant: Union | Tube OD: ø12 | Connection: None (union)
