Fuji Electric MONITOUCH HMI Option Units (Video, RGB, Audio)

Fuji Electric MONITOUCH HMI Option Units (Video, RGB, Audio)

Rear-mounted option units for MONITOUCH V8 and V9 displays that add video camera input, PC RGB input or output, audio output, or an extra serial port and CF slot on compact models.

Key features

  • Display camera video directly on the HMI screen
  • Show a PC screen via RGB input or mirror the HMI to a monitor
  • Play sound files through external speakers (GU series)
  • DU/DUN/DUR units add a D-sub9 port to compact models
  • Mounted in the option unit connector (CN7)

Specifications

Product family MONITOUCH option units
Mounting HMI rear option connector
V8 units GU-xx, DU-10, DUN-10
V9 units GUR-xx, DUR-00
Note GUR-00/-10/-11 listed as 2016 releases
Source Fuji Electric MONITOUCH V8 Series catalogue (KR ed.) / MONITOUCH V9 Series catalogue (KR ed., 2016), p. 15 (V8); 9, 13 (V9)
GU-00 Category: Video / RGB / audio | Function: Video input 4ch + audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-01 Category: Video / RGB / audio | Function: RGB input + audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-02 Category: Video / RGB / audio | Function: RGB output + audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-03 Category: Video / RGB / audio | Function: Audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-10 Category: Video / RGB / audio | Function: Video 2ch + RGB input | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-11 Category: Video / RGB / audio | Function: RGB input 2ch | Compatible HMI: V8 high-performance (iX/iS/iT)
DU-10 Category: Serial port / CF | Function: Adds D-sub9 port + CF card slot | Compatible HMI: V806 (2008 models)
DUN-10 Category: Serial port / CF | Function: Adds D-sub9 port + CF card slot | Compatible HMI: V806 N models
GUR-00 Category: Video / RGB / audio | Function: Video input 4ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-01 Category: Video / RGB / audio | Function: RGB input 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-02 Category: Video / RGB / audio | Function: RGB output 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-04 Category: Video / RGB / audio | Function: Video input 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-10 Category: Video / RGB / audio | Function: Video input 2ch + RGB input 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-11 Category: Video / RGB / audio | Function: RGB input 2ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
DUR-00 Category: Serial port / CF | Function: D-sub9 serial port option | Compatible HMI: V9071iW, V9060iTD
HMI Touch PanelsFuji Electric
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Fuji Electric MONITOUCH HMI Option Units (Video, RGB, Audio)

Brand Fuji Electric·HMI Touch Panels

Available part numbers (15)

GU-00, GU-01, GU-02, GU-03, GU-10, GU-11, DU-10, DUN-10, GUR-00, GUR-01 + 5 more — see full table ↓

How to order

Send the Fuji Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GU-00Category: Video / RGB / audio | Function: Video input 4ch + audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-01Category: Video / RGB / audio | Function: RGB input + audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-02Category: Video / RGB / audio | Function: RGB output + audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-03Category: Video / RGB / audio | Function: Audio output | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-10Category: Video / RGB / audio | Function: Video 2ch + RGB input | Compatible HMI: V8 high-performance (iX/iS/iT)
GU-11Category: Video / RGB / audio | Function: RGB input 2ch | Compatible HMI: V8 high-performance (iX/iS/iT)
DU-10Category: Serial port / CF | Function: Adds D-sub9 port + CF card slot | Compatible HMI: V806 (2008 models)
DUN-10Category: Serial port / CF | Function: Adds D-sub9 port + CF card slot | Compatible HMI: V806 N models
GUR-00Category: Video / RGB / audio | Function: Video input 4ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-01Category: Video / RGB / audio | Function: RGB input 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-02Category: Video / RGB / audio | Function: RGB output 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-04Category: Video / RGB / audio | Function: Video input 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-10Category: Video / RGB / audio | Function: Video input 2ch + RGB input 1ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
GUR-11Category: Video / RGB / audio | Function: RGB input 2ch | Compatible HMI: V9 Advanced 10.1 in / V9 Standard
DUR-00Category: Serial port / CF | Function: D-sub9 serial port option | Compatible HMI: V9071iW, V9060iTD
