KACON K7SC Series DIN-Rail Safety Relay Socket with LED

KACON K7SC Series DIN-Rail Safety Relay Socket with LED

Screw-terminal DIN-rail socket with LED indicator for mounting K7SR safety relays in control panels.

Key features

  • Accepts K7SR 4-pole (10FL) or 6-pole (14FL) safety relays
  • Built-in operation LED (the indicator is on the socket, not the relay)
  • M3 screw terminals, 1.5mm² / 16AWG wire
  • DIN-rail or screw mounting
  • Retaining hooks lock the relay against vibration

Specifications

Switching voltage 250VAC, 30VDC
Max. conduction current 6A
Applicable relay coil voltage 6-24VDC
Ambient temperature -25 to +55°C
Terminal torque 1.0N·m
Wire size 1.5mm² (16AWG), strip length 7mm
Indicator LED
KACON K7SC Series DIN-Rail Safety Relay Socket with LED - reference 2
K7SC-10FL-24VDC Terminals: 10 | Relay poles: 4P | Rated voltage: 24VDC | Applied relays: K7SR-2A2B-24VDC, K7SR-3A1B-24VDC | Size: 22.5 x 72 x 60 mm
K7SC-14FL-24VDC Terminals: 14 | Relay poles: 6P | Rated voltage: 24VDC | Applied relays: K7SR-5A1B-24VDC, K7SR-4A2B-24VDC, K7SR-3A3B-24VDC | Size: 30 x 72 x 60 mm
Safety Relay SocketsKACON
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KACON K7SC Series DIN-Rail Safety Relay Socket with LED

Brand KACON·Safety Relay Sockets

Available part numbers (2)

K7SC-10FL-24VDC, K7SC-14FL-24VDC

How to order

Send the KACON part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
KACON K7SC Series DIN-Rail Safety Relay Socket with LED - reference 2
0 selected
RFQ List (0)
Product codeSpec
K7SC-10FL-24VDCTerminals: 10 | Relay poles: 4P | Rated voltage: 24VDC | Applied relays: K7SR-2A2B-24VDC, K7SR-3A1B-24VDC | Size: 22.5 x 72 x 60 mm
K7SC-14FL-24VDCTerminals: 14 | Relay poles: 6P | Rated voltage: 24VDC | Applied relays: K7SR-5A1B-24VDC, K7SR-4A2B-24VDC, K7SR-3A3B-24VDC | Size: 30 x 72 x 60 mm
