KACON KTS 9 Series Touch Screen HMI

KACON KTS 9 Series Touch Screen HMI

Industrial touch screen HMIs from 4.3 to 15 inch with aluminium/steel housing and RISC ARM processor.

Key features

  • Drawing data, OS and recipe/log transfer via USB flash drive without a PC
  • Supports 1:1, 1:N serial and N:M Ethernet HMI-PLC configurations
  • Free drawing software with 3D graphics library
  • Broad PLC driver support (Mitsubishi, Siemens, Omron, LS, Delta, Keyence, Modbus and more)

Specifications

Colors 65,536
Rated voltage 24VDC
USB USB host and USB slave
Display TFT LCD
Memory 128MB Flash + 64MB
Material Aluminium, steel
KTS92043W Display: 4.3" | Resolution: 480 x 272 | Brightness: 300 cd/m² | Touch: capacitive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 2 channels | Interfaces: USB host, USB slave
KTS92070 Display: 7" | Resolution: 800 x 480 | Brightness: 450 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: SD card, USB host, USB slave
KTS92070E Display: 7" | Resolution: 800 x 480 | Brightness: 450 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
KTS92070V Display: 7" | Resolution: 800 x 480 | Brightness: 450 cd/m² | Touch: resistive | CPU: 32-bit 600MHz RISC Cortex-A8 | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave | Video input: Yes
KTS92080S Display: 8" 4:3 | Resolution: 800 x 600 | Brightness: 300 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, USB host, USB slave
KTS92097X Display: 9.7" 4:3 | Resolution: 1024 x 768 | Brightness: 420 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
KTS92104S Display: 10.4" 4:3 | Resolution: 800 x 600 | Brightness: 300 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, USB host, USB slave
KTS92121X Display: 12.1" 4:3 | Resolution: 1024 x 768 | Brightness: 500 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
KTS92150X Display: 15" 4:3 | Resolution: 1024 x 768 | Brightness: 400 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
HMIsKACON
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KACON KTS 9 Series Touch Screen HMI

Brand KACON·HMIs

Available part numbers (9)

KTS92043W, KTS92070, KTS92070E, KTS92070V, KTS92080S, KTS92097X, KTS92104S, KTS92121X, KTS92150X

How to order

Send the KACON part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KTS92043WDisplay: 4.3" | Resolution: 480 x 272 | Brightness: 300 cd/m² | Touch: capacitive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 2 channels | Interfaces: USB host, USB slave
KTS92070Display: 7" | Resolution: 800 x 480 | Brightness: 450 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: SD card, USB host, USB slave
KTS92070EDisplay: 7" | Resolution: 800 x 480 | Brightness: 450 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
KTS92070VDisplay: 7" | Resolution: 800 x 480 | Brightness: 450 cd/m² | Touch: resistive | CPU: 32-bit 600MHz RISC Cortex-A8 | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave | Video input: Yes
KTS92080SDisplay: 8" 4:3 | Resolution: 800 x 600 | Brightness: 300 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, USB host, USB slave
KTS92097XDisplay: 9.7" 4:3 | Resolution: 1024 x 768 | Brightness: 420 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
KTS92104SDisplay: 10.4" 4:3 | Resolution: 800 x 600 | Brightness: 300 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, USB host, USB slave
KTS92121XDisplay: 12.1" 4:3 | Resolution: 1024 x 768 | Brightness: 500 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
KTS92150XDisplay: 15" 4:3 | Resolution: 1024 x 768 | Brightness: 400 cd/m² | Touch: resistive | CPU: 32-bit 400MHz RISC ARM926EJ | COM: 4 channels | Interfaces: Ethernet, SD card, USB host, USB slave
