KACON KAF-HD3TF Series Heavy-Duty Foot Switch with Pedal Guard
KACON KAF-HD3TF Series Heavy-Duty Foot Switch with Pedal Guard
Heavy-duty aluminum die-cast foot switch with protective pedal guard against accidental operation, IP65, for presses and machine tools.
Key features
- Pedal guard (cover) prevents unintentional actuation
- Single, double and triple pedal versions
- Choice of Z15G basic switch (15A), V type micro switch (16A) or bolt-terminal V type micro switch
- Rugged aluminum die-cast body, IP65
- 1/2 inch conduit entry for flexible cable
Specifications
| Housing | Aluminum die-casting |
|---|---|
| Degree of protection | IP65 |
| Cable entry | PF 1/2 inch tapped hole per pedal, for flexible conduit (zinc connector 10-16) |
| Certification | CE, CCC, KC; built-in switch UL/cUL |
| KAF-HD3TF(L) | Pedals: 1 | Contact: 1a+1b | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | |
| KAF-HD3TF(L)2C | Pedals: 2 | Contact: (2a+2b) x2 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | |
| KAF-HD3TF2 | Pedals: 2 | Contact: (1a+1b) x2 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | |
| KAF-HD3TF22C | Pedals: 2 | Contact: (2a+2b) x2 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | |
| KAF-HD3TF3 | Pedals: 3 | Contact: (1a+1b) x3 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | |
| KAF-HD3TF32C | Pedals: 3 | Contact: (2a+2b) x3 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | |
| KAF-HD3TF(L)V | Pedals: 1 | Contact: 1a+1b | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF(L)V2C | Pedals: 1 | Contact: 2a+2b | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF2V | Pedals: 2 | Contact: (1a+1b) x2 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF2V2C | Pedals: 2 | Contact: (2a+2b) x2 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF3V | Pedals: 3 | Contact: (1a+1b) x3 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF3V2C | Pedals: 3 | Contact: (2a+2b) x3 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF(L)VB | Pedals: 1 | Contact: 1a+1b | Built-in switch: V type micro switch, bolt terminal | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF2VB | Pedals: 2 | Contact: (1a+1b) x2 | Built-in switch: V type micro switch, bolt terminal | Rated load: 16A 250VAC (resistive) | |
| KAF-HD3TF3VB | Pedals: 3 | Contact: (1a+1b) x3 | Built-in switch: V type micro switch, bolt terminal | Rated load: 16A 250VAC (resistive) |
Foot SwitchesKACON
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
Need a different model, or a part not listed here? Send us your parts list →
KACON KAF-HD3TF Series Heavy-Duty Foot Switch with Pedal Guard
Available part numbers (15)
KAF-HD3TF(L), KAF-HD3TF(L)2C, KAF-HD3TF2, KAF-HD3TF22C, KAF-HD3TF3, KAF-HD3TF32C, KAF-HD3TF(L)V, KAF-HD3TF(L)V2C, KAF-HD3TF2V, KAF-HD3TF2V2C + 5 more — see full table ↓
How to order
Send the KACON part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
KACON
Foot Switches
Photo on request
Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| KAF-HD3TF(L) | Pedals: 1 | Contact: 1a+1b | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | ||
| KAF-HD3TF(L)2C | Pedals: 2 | Contact: (2a+2b) x2 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | ||
| KAF-HD3TF2 | Pedals: 2 | Contact: (1a+1b) x2 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | ||
| KAF-HD3TF22C | Pedals: 2 | Contact: (2a+2b) x2 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | ||
| KAF-HD3TF3 | Pedals: 3 | Contact: (1a+1b) x3 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | ||
| KAF-HD3TF32C | Pedals: 3 | Contact: (2a+2b) x3 | Built-in switch: Z15G-10B | Rated load: 15A 250VAC (resistive) | ||
| KAF-HD3TF(L)V | Pedals: 1 | Contact: 1a+1b | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF(L)V2C | Pedals: 1 | Contact: 2a+2b | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF2V | Pedals: 2 | Contact: (1a+1b) x2 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF2V2C | Pedals: 2 | Contact: (2a+2b) x2 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF3V | Pedals: 3 | Contact: (1a+1b) x3 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF3V2C | Pedals: 3 | Contact: (2a+2b) x3 | Built-in switch: V type micro switch | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF(L)VB | Pedals: 1 | Contact: 1a+1b | Built-in switch: V type micro switch, bolt terminal | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF2VB | Pedals: 2 | Contact: (1a+1b) x2 | Built-in switch: V type micro switch, bolt terminal | Rated load: 16A 250VAC (resistive) | ||
| KAF-HD3TF3VB | Pedals: 3 | Contact: (1a+1b) x3 | Built-in switch: V type micro switch, bolt terminal | Rated load: 16A 250VAC (resistive) |
