KACON RXT Series 1-Channel Relay Interface Terminals

KACON RXT Series 1-Channel Relay Interface Terminals

Slim DIN-rail relay interface terminals with one relay output for isolating and amplifying PLC signals in control panels.

Key features

  • One relay channel per module in a slim DIN-rail housing
  • Choice of bolt (screw) or quick (pin) terminal versions with TF-1C relay
  • Slim 10 mm / 15 mm versions with TA-1a or HR96A relay
  • LED operation lamp
  • Common terminals can be linked with the RXT-QS short bar (RXT-F01/Q01)

Specifications

Mounting DIN rail
Coil voltage 24VDC (relay coil 12V/24V)
TF-1C relay rating 6A 250VAC / 6A 30VDC, 1C, silver alloy
TA-1a / HR96A relay rating 5A 250VAC / 5A 30VDC
Ambient temperature -40 to +85°C (TF-1C relay)
Certification cULus (relay)
KACON RXT Series 1-Channel Relay Interface Terminals - reference 2
RXT-F01 Relay: TF-1C (KACON) | Contact: 1C | Rating: 6A 250VAC, 6A 30VDC | Terminal: bolt (screw) | Channels: 1 | Size: 89 x 76.5 x 6 mm
RXT-Q01 Relay: TF-1C (KACON) | Contact: 1C | Rating: 6A 250VAC, 6A 30VDC | Terminal: quick (pin) | Channels: 1 | Size: 102 x 79.5 x 6 mm
RXT-A01 Relay: TA-1a (KACON) | Contact: 1a | Rating: 5A 250VAC, 5A 30VDC | Channels: 1 | Size: 10 x 81.3 x 32 mm
RXT-B01 Relay: HR96A (Hankuk Relay) | Contact: 1a | Rating: 5A 250VAC, 5A 30VDC | Channels: 1 | Size: 15 x 81.3 x 32 mm
Relay Interface TerminalsKACON
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KACON RXT Series 1-Channel Relay Interface Terminals

Brand KACON·Relay Interface Terminals

Available part numbers (4)

RXT-F01, RXT-Q01, RXT-A01, RXT-B01

How to order

Send the KACON part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
KACON RXT Series 1-Channel Relay Interface Terminals - reference 2
0 selected
RFQ List (0)
Product codeSpec
RXT-F01Relay: TF-1C (KACON) | Contact: 1C | Rating: 6A 250VAC, 6A 30VDC | Terminal: bolt (screw) | Channels: 1 | Size: 89 x 76.5 x 6 mm
RXT-Q01Relay: TF-1C (KACON) | Contact: 1C | Rating: 6A 250VAC, 6A 30VDC | Terminal: quick (pin) | Channels: 1 | Size: 102 x 79.5 x 6 mm
RXT-A01Relay: TA-1a (KACON) | Contact: 1a | Rating: 5A 250VAC, 5A 30VDC | Channels: 1 | Size: 10 x 81.3 x 32 mm
RXT-B01Relay: HR96A (Hankuk Relay) | Contact: 1a | Rating: 5A 250VAC, 5A 30VDC | Channels: 1 | Size: 15 x 81.3 x 32 mm
