KCC ACMW Medium-Bore Cylinder (Double Rod, Ø40-100)

KCC ACMW Medium-Bore Cylinder (Double Rod, Ø40-100)

KCC ACMW series double-rod medium-bore tie-rod cylinder with built-in magnet, bore 40 to 100 mm.

Key features

  • Magnet and non-lube packing built in as standard (lubrication symbol N)
  • Improved cushion rings absorb more kinetic energy; cushion needles are retained against falling out
  • Mountings in code: B, LB, FA, TC, TA (double rod)
  • Low-hydraulic (L/G) and low-friction (Q) types, bellows (J/K), knuckle joints (I/Y), KA2 trunnion support, auto switches and TS/TW/TD/ASJ/BSJ/MS specials on order
  • Brackets LB/FA-FB/CA/CB, knuckle joints I/Y and KA2 trunnion supports also sold separately

Specifications

Action Double acting
Fluid Air
Operating pressure 0.05 to 0.97 MPa
Proof pressure 1.44 MPa
Ambient and fluid temperature 5 to 60°C
Piston speed 50 to 500 mm/s
Cushion Air cushion both ends
Lubrication Not required (N, non-lube standard)
Magnet Built-in (standard)
Max. stroke 2950 mm (std. strokes to 1000 mm)
Rod Double rod
Source KCC catalog acm.pdf, p. 1-2, 11
ACMW-N-B40-S25 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-B40-S50 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-B40-S75 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-B40-S100 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-B40-S125 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-B40-S150 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-B40-S175 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-B40-S200 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-B40-S250 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-B40-S300 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-B40-S350 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-B40-S400 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-B40-S450 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-B40-S500 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-B40-S550 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-B40-S600 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-B40-S650 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-B40-S700 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-B40-S750 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-B40-S800 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-B40-S850 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-B40-S900 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-B40-S950 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-B40-S1000 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-LB40-S25 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-LB40-S50 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-LB40-S75 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-LB40-S100 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-LB40-S125 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-LB40-S150 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-LB40-S175 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-LB40-S200 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-LB40-S250 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-LB40-S300 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-LB40-S350 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-LB40-S400 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-LB40-S450 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-LB40-S500 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-LB40-S550 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-LB40-S600 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-LB40-S650 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-LB40-S700 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-LB40-S750 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-LB40-S800 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-LB40-S850 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-LB40-S900 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-LB40-S950 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-LB40-S1000 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-FA40-S25 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-FA40-S50 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-FA40-S75 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-FA40-S100 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-FA40-S125 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-FA40-S150 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-FA40-S175 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-FA40-S200 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-FA40-S250 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-FA40-S300 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-FA40-S350 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-FA40-S400 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-FA40-S450 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-FA40-S500 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-FA40-S550 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-FA40-S600 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-FA40-S650 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-FA40-S700 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-FA40-S750 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-FA40-S800 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-FA40-S850 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-FA40-S900 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-FA40-S950 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-FA40-S1000 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-TC40-S25 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-TC40-S50 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-TC40-S75 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-TC40-S100 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-TC40-S125 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-TC40-S150 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-TC40-S175 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-TC40-S200 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-TC40-S250 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-TC40-S300 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-TC40-S350 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-TC40-S400 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-TC40-S450 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-TC40-S500 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-TC40-S550 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-TC40-S600 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-TC40-S650 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-TC40-S700 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-TC40-S750 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-TC40-S800 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-TC40-S850 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-TC40-S900 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-TC40-S950 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-TC40-S1000 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-TA40-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-TA40-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-TA40-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-TA40-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-TA40-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-TA40-S150 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-TA40-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-TA40-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-TA40-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-TA40-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-TA40-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-TA40-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-TA40-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-TA40-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-TA40-S550 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-TA40-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-TA40-S650 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-TA40-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-TA40-S750 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-TA40-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-TA40-S850 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-TA40-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-TA40-S950 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-TA40-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-B50-S25 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-B50-S50 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-B50-S75 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-B50-S100 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-B50-S125 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-B50-S150 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-B50-S175 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-B50-S200 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-B50-S250 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-B50-S300 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-B50-S350 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-B50-S400 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-B50-S450 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-B50-S500 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-B50-S550 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-B50-S600 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-B50-S650 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-B50-S700 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-B50-S750 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-B50-S800 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-B50-S850 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-B50-S900 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-B50-S950 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-B50-S1000 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-LB50-S25 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-LB50-S50 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-LB50-S75 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-LB50-S100 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-LB50-S125 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-LB50-S150 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-LB50-S175 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-LB50-S200 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-LB50-S250 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-LB50-S300 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-LB50-S350 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-LB50-S400 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-LB50-S450 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-LB50-S500 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-LB50-S550 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-LB50-S600 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-LB50-S650 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-LB50-S700 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-LB50-S750 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-LB50-S800 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-LB50-S850 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-LB50-S900 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-LB50-S950 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-LB50-S1000 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-FA50-S25 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-FA50-S50 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-FA50-S75 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-FA50-S100 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-FA50-S125 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-FA50-S150 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-FA50-S175 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-FA50-S200 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-FA50-S250 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-FA50-S300 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-FA50-S350 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-FA50-S400 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-FA50-S450 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-FA50-S500 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-FA50-S550 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-FA50-S600 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-FA50-S650 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-FA50-S700 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-FA50-S750 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-FA50-S800 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-FA50-S850 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-FA50-S900 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-FA50-S950 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-FA50-S1000 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TC50-S25 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TC50-S50 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TC50-S75 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TC50-S100 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TC50-S125 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TC50-S150 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TC50-S175 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TC50-S200 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TC50-S250 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TC50-S300 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TC50-S350 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TC50-S400 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TC50-S450 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TC50-S500 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TC50-S550 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TC50-S600 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TC50-S650 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TC50-S700 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TC50-S750 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TC50-S800 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TC50-S850 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TC50-S900 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TC50-S950 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TC50-S1000 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TA50-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TA50-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TA50-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TA50-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TA50-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TA50-S150 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TA50-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TA50-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TA50-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TA50-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TA50-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TA50-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TA50-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TA50-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TA50-S550 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TA50-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TA50-S650 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TA50-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TA50-S750 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TA50-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TA50-S850 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TA50-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TA50-S950 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TA50-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-B63-S25 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-B63-S50 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-B63-S75 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-B63-S100 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-B63-S125 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-B63-S150 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-B63-S175 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-B63-S200 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-B63-S250 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-B63-S300 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-B63-S350 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-B63-S400 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-B63-S450 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-B63-S500 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-B63-S550 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-B63-S600 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-B63-S650 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-B63-S700 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-B63-S750 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-B63-S800 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-B63-S850 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-B63-S900 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-B63-S950 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-B63-S1000 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-LB63-S25 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-LB63-S50 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-LB63-S75 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-LB63-S100 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-LB63-S125 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-LB63-S150 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-LB63-S175 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-LB63-S200 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-LB63-S250 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-LB63-S300 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-LB63-S350 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-LB63-S400 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-LB63-S450 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-LB63-S500 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-LB63-S550 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-LB63-S600 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-LB63-S650 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-LB63-S700 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-LB63-S750 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-LB63-S800 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-LB63-S850 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-LB63-S900 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-LB63-S950 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-LB63-S1000 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-FA63-S25 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-FA63-S50 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-FA63-S75 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-FA63-S100 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-FA63-S125 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-FA63-S150 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-FA63-S175 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-FA63-S200 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-FA63-S250 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-FA63-S300 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-FA63-S350 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-FA63-S400 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-FA63-S450 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-FA63-S500 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-FA63-S550 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-FA63-S600 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-FA63-S650 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-FA63-S700 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-FA63-S750 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-FA63-S800 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-FA63-S850 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-FA63-S900 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-FA63-S950 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-FA63-S1000 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TC63-S25 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TC63-S50 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TC63-S75 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TC63-S100 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TC63-S125 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TC63-S150 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TC63-S175 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TC63-S200 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TC63-S250 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TC63-S300 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TC63-S350 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TC63-S400 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TC63-S450 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TC63-S500 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TC63-S550 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TC63-S600 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TC63-S650 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TC63-S700 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TC63-S750 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TC63-S800 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TC63-S850 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TC63-S900 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TC63-S950 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TC63-S1000 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TA63-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TA63-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TA63-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TA63-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TA63-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TA63-S150 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TA63-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TA63-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TA63-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TA63-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TA63-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TA63-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TA63-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TA63-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TA63-S550 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TA63-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TA63-S650 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TA63-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TA63-S750 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TA63-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TA63-S850 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TA63-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TA63-S950 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TA63-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-B80-S25 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-B80-S50 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-B80-S75 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-B80-S100 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-B80-S125 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-B80-S150 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-B80-S175 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-B80-S200 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-B80-S250 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-B80-S300 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-B80-S350 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-B80-S400 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-B80-S450 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-B80-S500 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-B80-S550 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-B80-S600 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-B80-S650 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-B80-S700 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-B80-S750 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-B80-S800 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-B80-S850 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-B80-S900 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-B80-S950 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-B80-S1000 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-LB80-S25 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-LB80-S50 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-LB80-S75 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-LB80-S100 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-LB80-S125 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-LB80-S150 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-LB80-S175 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-LB80-S200 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-LB80-S250 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-LB80-S300 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-LB80-S350 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-LB80-S400 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-LB80-S450 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-LB80-S500 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-LB80-S550 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-LB80-S600 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-LB80-S650 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-LB80-S700 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-LB80-S750 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-LB80-S800 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-LB80-S850 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-LB80-S900 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-LB80-S950 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-LB80-S1000 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-FA80-S25 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-FA80-S50 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-FA80-S75 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-FA80-S100 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-FA80-S125 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-FA80-S150 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-FA80-S175 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-FA80-S200 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-FA80-S250 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-FA80-S300 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-FA80-S350 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-FA80-S400 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-FA80-S450 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-FA80-S500 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-FA80-S550 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-FA80-S600 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-FA80-S650 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-FA80-S700 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-FA80-S750 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-FA80-S800 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-FA80-S850 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-FA80-S900 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-FA80-S950 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-FA80-S1000 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TC80-S25 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TC80-S50 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TC80-S75 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TC80-S100 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TC80-S125 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TC80-S150 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TC80-S175 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TC80-S200 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TC80-S250 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TC80-S300 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TC80-S350 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TC80-S400 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TC80-S450 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TC80-S500 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TC80-S550 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TC80-S600 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TC80-S650 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TC80-S700 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TC80-S750 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TC80-S800 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TC80-S850 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TC80-S900 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TC80-S950 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TC80-S1000 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TA80-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TA80-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TA80-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TA80-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TA80-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TA80-S150 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TA80-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TA80-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TA80-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TA80-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TA80-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TA80-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TA80-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TA80-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TA80-S550 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TA80-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TA80-S650 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TA80-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TA80-S750 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TA80-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TA80-S850 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TA80-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TA80-S950 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TA80-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-B100-S25 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-B100-S50 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-B100-S75 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-B100-S100 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-B100-S125 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-B100-S150 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-B100-S175 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-B100-S200 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-B100-S250 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-B100-S300 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-B100-S350 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-B100-S400 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-B100-S450 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-B100-S500 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-B100-S550 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-B100-S600 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-B100-S650 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-B100-S700 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-B100-S750 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-B100-S800 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-B100-S850 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-B100-S900 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-B100-S950 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-B100-S1000 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-LB100-S25 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-LB100-S50 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-LB100-S75 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-LB100-S100 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-LB100-S125 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-LB100-S150 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-LB100-S175 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-LB100-S200 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-LB100-S250 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-LB100-S300 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-LB100-S350 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-LB100-S400 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-LB100-S450 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-LB100-S500 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-LB100-S550 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-LB100-S600 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-LB100-S650 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-LB100-S700 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-LB100-S750 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-LB100-S800 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-LB100-S850 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-LB100-S900 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-LB100-S950 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-LB100-S1000 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-FA100-S25 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-FA100-S50 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-FA100-S75 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-FA100-S100 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-FA100-S125 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-FA100-S150 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-FA100-S175 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-FA100-S200 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-FA100-S250 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-FA100-S300 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-FA100-S350 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-FA100-S400 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-FA100-S450 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-FA100-S500 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-FA100-S550 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-FA100-S600 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-FA100-S650 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-FA100-S700 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-FA100-S750 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-FA100-S800 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-FA100-S850 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-FA100-S900 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-FA100-S950 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-FA100-S1000 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TC100-S25 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TC100-S50 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TC100-S75 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TC100-S100 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TC100-S125 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TC100-S150 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TC100-S175 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TC100-S200 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TC100-S250 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TC100-S300 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TC100-S350 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TC100-S400 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TC100-S450 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TC100-S500 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TC100-S550 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TC100-S600 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TC100-S650 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TC100-S700 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TC100-S750 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TC100-S800 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TC100-S850 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TC100-S900 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TC100-S950 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TC100-S1000 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TA100-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TA100-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TA100-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TA100-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TA100-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TA100-S150 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TA100-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TA100-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TA100-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TA100-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TA100-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TA100-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TA100-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TA100-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TA100-S550 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TA100-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TA100-S650 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TA100-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TA100-S750 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TA100-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TA100-S850 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TA100-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TA100-S950 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TA100-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-40 Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø40 mm | Port: Rc1/4
ACMW-50 Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø50 mm | Port: Rc3/8
ACMW-63 Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø63 mm | Port: Rc3/8
ACMW-80 Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø80 mm | Port: Rc1/2
ACMW-100 Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø100 mm | Port: Rc1/2
Pneumatic CylindersKCC
605 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KCC ACMW Medium-Bore Cylinder (Double Rod, Ø40-100)

Brand KCC·Pneumatic Cylinders

Available part numbers (605)

ACMW-N-B40-S25, ACMW-N-B40-S50, ACMW-N-B40-S75, ACMW-N-B40-S100, ACMW-N-B40-S125, ACMW-N-B40-S150, ACMW-N-B40-S175, ACMW-N-B40-S200, ACMW-N-B40-S250, ACMW-N-B40-S300 + 595 more — see full table ↓

How to order

Send the KCC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ACMW-N-B40-S25Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-B40-S50Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-B40-S75Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-B40-S100Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-B40-S125Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-B40-S150Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-B40-S175Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-B40-S200Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-B40-S250Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-B40-S300Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-B40-S350Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-B40-S400Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-B40-S450Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-B40-S500Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-B40-S550Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-B40-S600Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-B40-S650Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-B40-S700Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-B40-S750Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-B40-S800Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-B40-S850Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-B40-S900Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-B40-S950Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-B40-S1000Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-LB40-S25Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-LB40-S50Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-LB40-S75Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-LB40-S100Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-LB40-S125Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-LB40-S150Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-LB40-S175Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-LB40-S200Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-LB40-S250Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-LB40-S300Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-LB40-S350Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-LB40-S400Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-LB40-S450Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-LB40-S500Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-LB40-S550Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-LB40-S600Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-LB40-S650Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-LB40-S700Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-LB40-S750Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-LB40-S800Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-LB40-S850Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-LB40-S900Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-LB40-S950Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-LB40-S1000Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-FA40-S25Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-FA40-S50Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-FA40-S75Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-FA40-S100Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-FA40-S125Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-FA40-S150Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-FA40-S175Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-FA40-S200Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-FA40-S250Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-FA40-S300Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-FA40-S350Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-FA40-S400Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-FA40-S450Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-FA40-S500Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-FA40-S550Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-FA40-S600Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-FA40-S650Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-FA40-S700Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-FA40-S750Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-FA40-S800Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-FA40-S850Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-FA40-S900Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-FA40-S950Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-FA40-S1000Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-TC40-S25Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-TC40-S50Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-TC40-S75Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-TC40-S100Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-TC40-S125Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-TC40-S150Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-TC40-S175Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-TC40-S200Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-TC40-S250Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-TC40-S300Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-TC40-S350Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-TC40-S400Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-TC40-S450Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-TC40-S500Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-TC40-S550Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-TC40-S600Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-TC40-S650Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-TC40-S700Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-TC40-S750Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-TC40-S800Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-TC40-S850Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-TC40-S900Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-TC40-S950Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-TC40-S1000Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-TA40-S25Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 25 mm | Port: Rc1/4
ACMW-N-TA40-S50Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 50 mm | Port: Rc1/4
ACMW-N-TA40-S75Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 75 mm | Port: Rc1/4
ACMW-N-TA40-S100Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 100 mm | Port: Rc1/4
ACMW-N-TA40-S125Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 125 mm | Port: Rc1/4
ACMW-N-TA40-S150Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 150 mm | Port: Rc1/4
ACMW-N-TA40-S175Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 175 mm | Port: Rc1/4
ACMW-N-TA40-S200Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 200 mm | Port: Rc1/4
ACMW-N-TA40-S250Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 250 mm | Port: Rc1/4
ACMW-N-TA40-S300Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 300 mm | Port: Rc1/4
ACMW-N-TA40-S350Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 350 mm | Port: Rc1/4
ACMW-N-TA40-S400Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 400 mm | Port: Rc1/4
ACMW-N-TA40-S450Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 450 mm | Port: Rc1/4
ACMW-N-TA40-S500Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 500 mm | Port: Rc1/4
ACMW-N-TA40-S550Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 550 mm | Port: Rc1/4
ACMW-N-TA40-S600Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 600 mm | Port: Rc1/4
ACMW-N-TA40-S650Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 650 mm | Port: Rc1/4
ACMW-N-TA40-S700Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 700 mm | Port: Rc1/4
ACMW-N-TA40-S750Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 750 mm | Port: Rc1/4
ACMW-N-TA40-S800Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 800 mm | Port: Rc1/4
ACMW-N-TA40-S850Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 850 mm | Port: Rc1/4
ACMW-N-TA40-S900Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 900 mm | Port: Rc1/4
ACMW-N-TA40-S950Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 950 mm | Port: Rc1/4
ACMW-N-TA40-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 1000 mm | Port: Rc1/4
ACMW-N-B50-S25Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-B50-S50Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-B50-S75Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-B50-S100Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-B50-S125Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-B50-S150Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-B50-S175Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-B50-S200Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-B50-S250Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-B50-S300Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-B50-S350Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-B50-S400Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-B50-S450Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-B50-S500Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-B50-S550Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-B50-S600Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-B50-S650Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-B50-S700Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-B50-S750Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-B50-S800Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-B50-S850Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-B50-S900Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-B50-S950Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-B50-S1000Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-LB50-S25Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-LB50-S50Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-LB50-S75Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-LB50-S100Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-LB50-S125Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-LB50-S150Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-LB50-S175Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-LB50-S200Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-LB50-S250Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-LB50-S300Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-LB50-S350Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-LB50-S400Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-LB50-S450Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-LB50-S500Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-LB50-S550Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-LB50-S600Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-LB50-S650Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-LB50-S700Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-LB50-S750Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-LB50-S800Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-LB50-S850Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-LB50-S900Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-LB50-S950Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-LB50-S1000Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-FA50-S25Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-FA50-S50Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-FA50-S75Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-FA50-S100Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-FA50-S125Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-FA50-S150Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-FA50-S175Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-FA50-S200Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-FA50-S250Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-FA50-S300Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-FA50-S350Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-FA50-S400Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-FA50-S450Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-FA50-S500Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-FA50-S550Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-FA50-S600Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-FA50-S650Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-FA50-S700Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-FA50-S750Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-FA50-S800Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-FA50-S850Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-FA50-S900Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-FA50-S950Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-FA50-S1000Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TC50-S25Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TC50-S50Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TC50-S75Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TC50-S100Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TC50-S125Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TC50-S150Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TC50-S175Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TC50-S200Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TC50-S250Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TC50-S300Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TC50-S350Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TC50-S400Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TC50-S450Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TC50-S500Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TC50-S550Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TC50-S600Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TC50-S650Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TC50-S700Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TC50-S750Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TC50-S800Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TC50-S850Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TC50-S900Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TC50-S950Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TC50-S1000Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TA50-S25Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TA50-S50Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TA50-S75Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TA50-S100Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TA50-S125Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TA50-S150Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TA50-S175Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TA50-S200Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TA50-S250Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TA50-S300Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TA50-S350Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TA50-S400Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TA50-S450Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TA50-S500Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TA50-S550Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TA50-S600Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TA50-S650Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TA50-S700Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TA50-S750Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TA50-S800Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TA50-S850Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TA50-S900Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TA50-S950Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TA50-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-B63-S25Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-B63-S50Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-B63-S75Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-B63-S100Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-B63-S125Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-B63-S150Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-B63-S175Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-B63-S200Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-B63-S250Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-B63-S300Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-B63-S350Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-B63-S400Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-B63-S450Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-B63-S500Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-B63-S550Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-B63-S600Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-B63-S650Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-B63-S700Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-B63-S750Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-B63-S800Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-B63-S850Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-B63-S900Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-B63-S950Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-B63-S1000Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-LB63-S25Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-LB63-S50Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-LB63-S75Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-LB63-S100Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-LB63-S125Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-LB63-S150Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-LB63-S175Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-LB63-S200Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-LB63-S250Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-LB63-S300Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-LB63-S350Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-LB63-S400Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-LB63-S450Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-LB63-S500Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-LB63-S550Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-LB63-S600Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-LB63-S650Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-LB63-S700Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-LB63-S750Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-LB63-S800Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-LB63-S850Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-LB63-S900Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-LB63-S950Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-LB63-S1000Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-FA63-S25Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-FA63-S50Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-FA63-S75Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-FA63-S100Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-FA63-S125Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-FA63-S150Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-FA63-S175Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-FA63-S200Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-FA63-S250Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-FA63-S300Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-FA63-S350Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-FA63-S400Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-FA63-S450Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-FA63-S500Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-FA63-S550Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-FA63-S600Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-FA63-S650Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-FA63-S700Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-FA63-S750Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-FA63-S800Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-FA63-S850Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-FA63-S900Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-FA63-S950Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-FA63-S1000Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TC63-S25Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TC63-S50Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TC63-S75Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TC63-S100Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TC63-S125Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TC63-S150Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TC63-S175Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TC63-S200Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TC63-S250Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TC63-S300Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TC63-S350Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TC63-S400Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TC63-S450Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TC63-S500Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TC63-S550Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TC63-S600Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TC63-S650Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TC63-S700Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TC63-S750Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TC63-S800Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TC63-S850Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TC63-S900Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TC63-S950Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TC63-S1000Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-TA63-S25Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 25 mm | Port: Rc3/8
ACMW-N-TA63-S50Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 50 mm | Port: Rc3/8
ACMW-N-TA63-S75Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 75 mm | Port: Rc3/8
ACMW-N-TA63-S100Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 100 mm | Port: Rc3/8
ACMW-N-TA63-S125Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 125 mm | Port: Rc3/8
ACMW-N-TA63-S150Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 150 mm | Port: Rc3/8
ACMW-N-TA63-S175Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 175 mm | Port: Rc3/8
ACMW-N-TA63-S200Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 200 mm | Port: Rc3/8
ACMW-N-TA63-S250Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 250 mm | Port: Rc3/8
ACMW-N-TA63-S300Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 300 mm | Port: Rc3/8
ACMW-N-TA63-S350Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 350 mm | Port: Rc3/8
ACMW-N-TA63-S400Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 400 mm | Port: Rc3/8
ACMW-N-TA63-S450Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 450 mm | Port: Rc3/8
ACMW-N-TA63-S500Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 500 mm | Port: Rc3/8
ACMW-N-TA63-S550Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 550 mm | Port: Rc3/8
ACMW-N-TA63-S600Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 600 mm | Port: Rc3/8
ACMW-N-TA63-S650Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 650 mm | Port: Rc3/8
ACMW-N-TA63-S700Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 700 mm | Port: Rc3/8
ACMW-N-TA63-S750Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 750 mm | Port: Rc3/8
ACMW-N-TA63-S800Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 800 mm | Port: Rc3/8
ACMW-N-TA63-S850Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 850 mm | Port: Rc3/8
ACMW-N-TA63-S900Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 900 mm | Port: Rc3/8
ACMW-N-TA63-S950Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 950 mm | Port: Rc3/8
ACMW-N-TA63-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: Rc3/8
ACMW-N-B80-S25Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-B80-S50Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-B80-S75Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-B80-S100Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-B80-S125Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-B80-S150Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-B80-S175Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-B80-S200Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-B80-S250Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-B80-S300Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-B80-S350Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-B80-S400Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-B80-S450Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-B80-S500Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-B80-S550Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-B80-S600Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-B80-S650Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-B80-S700Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-B80-S750Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-B80-S800Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-B80-S850Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-B80-S900Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-B80-S950Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-B80-S1000Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-LB80-S25Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-LB80-S50Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-LB80-S75Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-LB80-S100Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-LB80-S125Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-LB80-S150Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-LB80-S175Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-LB80-S200Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-LB80-S250Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-LB80-S300Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-LB80-S350Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-LB80-S400Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-LB80-S450Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-LB80-S500Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-LB80-S550Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-LB80-S600Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-LB80-S650Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-LB80-S700Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-LB80-S750Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-LB80-S800Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-LB80-S850Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-LB80-S900Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-LB80-S950Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-LB80-S1000Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-FA80-S25Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-FA80-S50Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-FA80-S75Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-FA80-S100Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-FA80-S125Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-FA80-S150Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-FA80-S175Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-FA80-S200Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-FA80-S250Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-FA80-S300Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-FA80-S350Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-FA80-S400Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-FA80-S450Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-FA80-S500Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-FA80-S550Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-FA80-S600Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-FA80-S650Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-FA80-S700Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-FA80-S750Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-FA80-S800Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-FA80-S850Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-FA80-S900Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-FA80-S950Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-FA80-S1000Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TC80-S25Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TC80-S50Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TC80-S75Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TC80-S100Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TC80-S125Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TC80-S150Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TC80-S175Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TC80-S200Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TC80-S250Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TC80-S300Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TC80-S350Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TC80-S400Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TC80-S450Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TC80-S500Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TC80-S550Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TC80-S600Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TC80-S650Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TC80-S700Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TC80-S750Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TC80-S800Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TC80-S850Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TC80-S900Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TC80-S950Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TC80-S1000Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TA80-S25Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TA80-S50Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TA80-S75Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TA80-S100Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TA80-S125Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TA80-S150Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TA80-S175Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TA80-S200Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TA80-S250Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TA80-S300Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TA80-S350Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TA80-S400Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TA80-S450Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TA80-S500Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TA80-S550Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TA80-S600Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TA80-S650Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TA80-S700Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TA80-S750Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TA80-S800Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TA80-S850Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TA80-S900Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TA80-S950Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TA80-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-B100-S25Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-B100-S50Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-B100-S75Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-B100-S100Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-B100-S125Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-B100-S150Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-B100-S175Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-B100-S200Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-B100-S250Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-B100-S300Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-B100-S350Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-B100-S400Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-B100-S450Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-B100-S500Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-B100-S550Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-B100-S600Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-B100-S650Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-B100-S700Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-B100-S750Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-B100-S800Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-B100-S850Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-B100-S900Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-B100-S950Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-B100-S1000Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-LB100-S25Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-LB100-S50Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-LB100-S75Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-LB100-S100Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-LB100-S125Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-LB100-S150Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-LB100-S175Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-LB100-S200Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-LB100-S250Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-LB100-S300Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-LB100-S350Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-LB100-S400Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-LB100-S450Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-LB100-S500Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-LB100-S550Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-LB100-S600Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-LB100-S650Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-LB100-S700Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-LB100-S750Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-LB100-S800Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-LB100-S850Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-LB100-S900Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-LB100-S950Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-LB100-S1000Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-FA100-S25Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-FA100-S50Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-FA100-S75Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-FA100-S100Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-FA100-S125Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-FA100-S150Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-FA100-S175Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-FA100-S200Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-FA100-S250Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-FA100-S300Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-FA100-S350Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-FA100-S400Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-FA100-S450Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-FA100-S500Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-FA100-S550Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-FA100-S600Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-FA100-S650Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-FA100-S700Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-FA100-S750Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-FA100-S800Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-FA100-S850Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-FA100-S900Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-FA100-S950Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-FA100-S1000Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TC100-S25Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TC100-S50Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TC100-S75Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TC100-S100Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TC100-S125Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TC100-S150Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TC100-S175Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TC100-S200Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TC100-S250Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TC100-S300Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TC100-S350Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TC100-S400Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TC100-S450Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TC100-S500Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TC100-S550Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TC100-S600Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TC100-S650Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TC100-S700Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TC100-S750Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TC100-S800Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TC100-S850Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TC100-S900Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TC100-S950Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TC100-S1000Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-N-TA100-S25Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 25 mm | Port: Rc1/2
ACMW-N-TA100-S50Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 50 mm | Port: Rc1/2
ACMW-N-TA100-S75Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 75 mm | Port: Rc1/2
ACMW-N-TA100-S100Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 100 mm | Port: Rc1/2
ACMW-N-TA100-S125Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 125 mm | Port: Rc1/2
ACMW-N-TA100-S150Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 150 mm | Port: Rc1/2
ACMW-N-TA100-S175Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 175 mm | Port: Rc1/2
ACMW-N-TA100-S200Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 200 mm | Port: Rc1/2
ACMW-N-TA100-S250Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 250 mm | Port: Rc1/2
ACMW-N-TA100-S300Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 300 mm | Port: Rc1/2
ACMW-N-TA100-S350Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 350 mm | Port: Rc1/2
ACMW-N-TA100-S400Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 400 mm | Port: Rc1/2
ACMW-N-TA100-S450Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 450 mm | Port: Rc1/2
ACMW-N-TA100-S500Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 500 mm | Port: Rc1/2
ACMW-N-TA100-S550Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 550 mm | Port: Rc1/2
ACMW-N-TA100-S600Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 600 mm | Port: Rc1/2
ACMW-N-TA100-S650Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 650 mm | Port: Rc1/2
ACMW-N-TA100-S700Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 700 mm | Port: Rc1/2
ACMW-N-TA100-S750Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 750 mm | Port: Rc1/2
ACMW-N-TA100-S800Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 800 mm | Port: Rc1/2
ACMW-N-TA100-S850Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 850 mm | Port: Rc1/2
ACMW-N-TA100-S900Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 900 mm | Port: Rc1/2
ACMW-N-TA100-S950Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 950 mm | Port: Rc1/2
ACMW-N-TA100-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: Rc1/2
ACMW-40Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø40 mm | Port: Rc1/4
ACMW-50Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø50 mm | Port: Rc3/8
ACMW-63Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø63 mm | Port: Rc3/8
ACMW-80Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø80 mm | Port: Rc1/2
ACMW-100Legacy code, base model (add lubrication, mounting, stroke) | Bore: Ø100 mm | Port: Rc1/2

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
