KCC ACTW ISO 15552 Cylinder (Tie-Rod, Double Rod, Ø32-200)

KCC ACTW ISO 15552 Cylinder (Tie-Rod, Double Rod, Ø32-200)

KCC ACTW series double-rod ISO 15552 cylinder, tie-rod type, double acting with adjustable air cushions, bore 32 to 200 mm.

Key features

  • ISO 15552 (formerly ISO 6431) standard dimensions, interchangeable with other ISO cylinders
  • Tie-rod construction with aluminium alloy covers and tube
  • Long-life wear ring construction with low breakaway pressure; smooth adjustable cushioning
  • Mountings in code: B, LB, FA, TC, TA (double rod has no FB/CA/CB); KA2 and TCM2 trunnion supports ordered separately
  • Tie-rod mounted auto switches D-A54K/A93(V)K/F9N(V)K etc. ordered separately
  • Rod material, heat-resistant seal (H), bellows (J/K), knuckle joints (I/Y) and stroke adjustment (ASJ/BSJ) are option suffixes

Specifications

Standard ISO 15552 (formerly ISO 6431)
Action Double acting
Fluid Air
Operating pressure 0.15 to 1.0 MPa
Proof pressure 1.5 MPa
Ambient temperature -20 to 70°C
Piston speed 30 to 500 mm/s
Cushion Adjustable air cushion both ends
Stroke tolerance 0-250: +1.0; 251-1000: +1.5; 1001-1500: +2.0 mm
Max. stroke 1800 mm (Ø160-200: 2000 mm); std. strokes to 1000 mm
Rod Double rod
Source KCC catalog aci,act.pdf, p. 1-3
ACTW-B32-S25 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-B32-S50 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-B32-S75 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-B32-S100 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-B32-S125 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-B32-S175 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-B32-S200 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-B32-S250 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-B32-S300 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-B32-S350 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-B32-S400 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-B32-S450 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-B32-S500 Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-LB32-S25 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-LB32-S50 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-LB32-S75 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-LB32-S100 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-LB32-S125 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-LB32-S175 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-LB32-S200 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-LB32-S250 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-LB32-S300 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-LB32-S350 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-LB32-S400 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-LB32-S450 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-LB32-S500 Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-FA32-S25 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-FA32-S50 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-FA32-S75 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-FA32-S100 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-FA32-S125 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-FA32-S175 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-FA32-S200 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-FA32-S250 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-FA32-S300 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-FA32-S350 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-FA32-S400 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-FA32-S450 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-FA32-S500 Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-TC32-S25 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-TC32-S50 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-TC32-S75 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-TC32-S100 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-TC32-S125 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-TC32-S175 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-TC32-S200 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-TC32-S250 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-TC32-S300 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-TC32-S350 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-TC32-S400 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-TC32-S450 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-TC32-S500 Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-TA32-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-TA32-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-TA32-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-TA32-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-TA32-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-TA32-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-TA32-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-TA32-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-TA32-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-TA32-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-TA32-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-TA32-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-TA32-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-B40-S25 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-B40-S50 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-B40-S75 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-B40-S100 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-B40-S125 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-B40-S175 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-B40-S200 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-B40-S250 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-B40-S300 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-B40-S350 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-B40-S400 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-B40-S450 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-B40-S500 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-B40-S600 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-B40-S700 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-B40-S800 Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-LB40-S25 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-LB40-S50 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-LB40-S75 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-LB40-S100 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-LB40-S125 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-LB40-S175 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-LB40-S200 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-LB40-S250 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-LB40-S300 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-LB40-S350 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-LB40-S400 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-LB40-S450 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-LB40-S500 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-LB40-S600 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-LB40-S700 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-LB40-S800 Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-FA40-S25 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-FA40-S50 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-FA40-S75 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-FA40-S100 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-FA40-S125 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-FA40-S175 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-FA40-S200 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-FA40-S250 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-FA40-S300 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-FA40-S350 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-FA40-S400 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-FA40-S450 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-FA40-S500 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-FA40-S600 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-FA40-S700 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-FA40-S800 Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-TC40-S25 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-TC40-S50 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-TC40-S75 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-TC40-S100 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-TC40-S125 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-TC40-S175 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-TC40-S200 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-TC40-S250 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-TC40-S300 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-TC40-S350 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-TC40-S400 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-TC40-S450 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-TC40-S500 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-TC40-S600 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-TC40-S700 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-TC40-S800 Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-TA40-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-TA40-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-TA40-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-TA40-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-TA40-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-TA40-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-TA40-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-TA40-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-TA40-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-TA40-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-TA40-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-TA40-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-TA40-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-TA40-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-TA40-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-TA40-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-B50-S25 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-B50-S50 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-B50-S75 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-B50-S100 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-B50-S125 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-B50-S175 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-B50-S200 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-B50-S250 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-B50-S300 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-B50-S350 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-B50-S400 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-B50-S450 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-B50-S500 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-B50-S600 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-B50-S700 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-B50-S800 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-B50-S900 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-B50-S1000 Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-LB50-S25 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-LB50-S50 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-LB50-S75 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-LB50-S100 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-LB50-S125 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-LB50-S175 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-LB50-S200 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-LB50-S250 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-LB50-S300 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-LB50-S350 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-LB50-S400 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-LB50-S450 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-LB50-S500 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-LB50-S600 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-LB50-S700 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-LB50-S800 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-LB50-S900 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-LB50-S1000 Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-FA50-S25 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-FA50-S50 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-FA50-S75 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-FA50-S100 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-FA50-S125 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-FA50-S175 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-FA50-S200 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-FA50-S250 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-FA50-S300 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-FA50-S350 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-FA50-S400 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-FA50-S450 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-FA50-S500 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-FA50-S600 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-FA50-S700 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-FA50-S800 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-FA50-S900 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-FA50-S1000 Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-TC50-S25 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-TC50-S50 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-TC50-S75 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-TC50-S100 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-TC50-S125 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-TC50-S175 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-TC50-S200 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-TC50-S250 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-TC50-S300 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-TC50-S350 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-TC50-S400 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-TC50-S450 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-TC50-S500 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-TC50-S600 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-TC50-S700 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-TC50-S800 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-TC50-S900 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-TC50-S1000 Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-TA50-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-TA50-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-TA50-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-TA50-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-TA50-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-TA50-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-TA50-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-TA50-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-TA50-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-TA50-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-TA50-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-TA50-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-TA50-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-TA50-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-TA50-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-TA50-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-TA50-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-TA50-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-B63-S25 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-B63-S50 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-B63-S75 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-B63-S100 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-B63-S125 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-B63-S175 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-B63-S200 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-B63-S250 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-B63-S300 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-B63-S350 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-B63-S400 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-B63-S450 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-B63-S500 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-B63-S600 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-B63-S700 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-B63-S800 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-B63-S900 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-B63-S1000 Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-LB63-S25 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-LB63-S50 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-LB63-S75 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-LB63-S100 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-LB63-S125 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-LB63-S175 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-LB63-S200 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-LB63-S250 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-LB63-S300 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-LB63-S350 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-LB63-S400 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-LB63-S450 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-LB63-S500 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-LB63-S600 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-LB63-S700 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-LB63-S800 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-LB63-S900 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-LB63-S1000 Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-FA63-S25 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-FA63-S50 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-FA63-S75 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-FA63-S100 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-FA63-S125 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-FA63-S175 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-FA63-S200 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-FA63-S250 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-FA63-S300 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-FA63-S350 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-FA63-S400 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-FA63-S450 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-FA63-S500 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-FA63-S600 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-FA63-S700 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-FA63-S800 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-FA63-S900 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-FA63-S1000 Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TC63-S25 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-TC63-S50 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-TC63-S75 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-TC63-S100 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-TC63-S125 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-TC63-S175 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-TC63-S200 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-TC63-S250 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-TC63-S300 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-TC63-S350 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-TC63-S400 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-TC63-S450 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-TC63-S500 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-TC63-S600 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-TC63-S700 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-TC63-S800 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-TC63-S900 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-TC63-S1000 Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TA63-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-TA63-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-TA63-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-TA63-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-TA63-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-TA63-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-TA63-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-TA63-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-TA63-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-TA63-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-TA63-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-TA63-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-TA63-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-TA63-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-TA63-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-TA63-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-TA63-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-TA63-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-B80-S25 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-B80-S50 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-B80-S75 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-B80-S100 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-B80-S125 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-B80-S175 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-B80-S200 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-B80-S250 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-B80-S300 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-B80-S350 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-B80-S400 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-B80-S450 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-B80-S500 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-B80-S600 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-B80-S700 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-B80-S800 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-B80-S900 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-B80-S1000 Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-LB80-S25 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-LB80-S50 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-LB80-S75 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-LB80-S100 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-LB80-S125 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-LB80-S175 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-LB80-S200 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-LB80-S250 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-LB80-S300 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-LB80-S350 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-LB80-S400 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-LB80-S450 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-LB80-S500 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-LB80-S600 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-LB80-S700 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-LB80-S800 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-LB80-S900 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-LB80-S1000 Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-FA80-S25 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-FA80-S50 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-FA80-S75 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-FA80-S100 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-FA80-S125 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-FA80-S175 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-FA80-S200 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-FA80-S250 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-FA80-S300 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-FA80-S350 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-FA80-S400 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-FA80-S450 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-FA80-S500 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-FA80-S600 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-FA80-S700 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-FA80-S800 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-FA80-S900 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-FA80-S1000 Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TC80-S25 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-TC80-S50 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-TC80-S75 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-TC80-S100 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-TC80-S125 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-TC80-S175 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-TC80-S200 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-TC80-S250 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-TC80-S300 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-TC80-S350 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-TC80-S400 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-TC80-S450 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-TC80-S500 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-TC80-S600 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-TC80-S700 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-TC80-S800 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-TC80-S900 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-TC80-S1000 Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TA80-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-TA80-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-TA80-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-TA80-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-TA80-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-TA80-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-TA80-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-TA80-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-TA80-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-TA80-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-TA80-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-TA80-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-TA80-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-TA80-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-TA80-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-TA80-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-TA80-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-TA80-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-B100-S25 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-B100-S50 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-B100-S75 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-B100-S100 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-B100-S125 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-B100-S175 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-B100-S200 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-B100-S250 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-B100-S300 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-B100-S350 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-B100-S400 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-B100-S450 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-B100-S500 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-B100-S600 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-B100-S700 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-B100-S800 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-B100-S900 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-B100-S1000 Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-LB100-S25 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-LB100-S50 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-LB100-S75 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-LB100-S100 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-LB100-S125 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-LB100-S175 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-LB100-S200 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-LB100-S250 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-LB100-S300 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-LB100-S350 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-LB100-S400 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-LB100-S450 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-LB100-S500 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-LB100-S600 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-LB100-S700 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-LB100-S800 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-LB100-S900 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-LB100-S1000 Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-FA100-S25 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-FA100-S50 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-FA100-S75 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-FA100-S100 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-FA100-S125 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-FA100-S175 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-FA100-S200 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-FA100-S250 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-FA100-S300 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-FA100-S350 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-FA100-S400 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-FA100-S450 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-FA100-S500 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-FA100-S600 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-FA100-S700 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-FA100-S800 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-FA100-S900 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-FA100-S1000 Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TC100-S25 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-TC100-S50 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-TC100-S75 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-TC100-S100 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-TC100-S125 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-TC100-S175 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-TC100-S200 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-TC100-S250 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-TC100-S300 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-TC100-S350 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-TC100-S400 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-TC100-S450 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-TC100-S500 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-TC100-S600 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-TC100-S700 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-TC100-S800 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-TC100-S900 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-TC100-S1000 Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TA100-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-TA100-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-TA100-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-TA100-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-TA100-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-TA100-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-TA100-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-TA100-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-TA100-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-TA100-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-TA100-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-TA100-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-TA100-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-TA100-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-TA100-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-TA100-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-TA100-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-TA100-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-B125-S25 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-B125-S50 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-B125-S75 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-B125-S100 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-B125-S125 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-B125-S175 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-B125-S200 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-B125-S250 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-B125-S300 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-B125-S350 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-B125-S400 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-B125-S450 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-B125-S500 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-B125-S600 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-B125-S700 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-B125-S800 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-B125-S900 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-B125-S1000 Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-LB125-S25 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-LB125-S50 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-LB125-S75 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-LB125-S100 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-LB125-S125 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-LB125-S175 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-LB125-S200 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-LB125-S250 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-LB125-S300 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-LB125-S350 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-LB125-S400 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-LB125-S450 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-LB125-S500 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-LB125-S600 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-LB125-S700 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-LB125-S800 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-LB125-S900 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-LB125-S1000 Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-FA125-S25 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-FA125-S50 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-FA125-S75 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-FA125-S100 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-FA125-S125 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-FA125-S175 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-FA125-S200 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-FA125-S250 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-FA125-S300 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-FA125-S350 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-FA125-S400 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-FA125-S450 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-FA125-S500 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-FA125-S600 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-FA125-S700 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-FA125-S800 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-FA125-S900 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-FA125-S1000 Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TC125-S25 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-TC125-S50 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-TC125-S75 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-TC125-S100 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-TC125-S125 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-TC125-S175 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-TC125-S200 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-TC125-S250 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-TC125-S300 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-TC125-S350 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-TC125-S400 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-TC125-S450 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-TC125-S500 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-TC125-S600 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-TC125-S700 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-TC125-S800 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-TC125-S900 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-TC125-S1000 Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TA125-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-TA125-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-TA125-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-TA125-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-TA125-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-TA125-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-TA125-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-TA125-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-TA125-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-TA125-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-TA125-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-TA125-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-TA125-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-TA125-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-TA125-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-TA125-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-TA125-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-TA125-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-B160-S25 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-B160-S50 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-B160-S75 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-B160-S100 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-B160-S125 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-B160-S175 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-B160-S200 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-B160-S250 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-B160-S300 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-B160-S350 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-B160-S400 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-B160-S450 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-B160-S500 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-B160-S600 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-B160-S700 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-B160-S800 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-B160-S900 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-B160-S1000 Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-LB160-S25 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-LB160-S50 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-LB160-S75 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-LB160-S100 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-LB160-S125 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-LB160-S175 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-LB160-S200 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-LB160-S250 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-LB160-S300 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-LB160-S350 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-LB160-S400 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-LB160-S450 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-LB160-S500 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-LB160-S600 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-LB160-S700 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-LB160-S800 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-LB160-S900 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-LB160-S1000 Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-FA160-S25 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-FA160-S50 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-FA160-S75 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-FA160-S100 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-FA160-S125 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-FA160-S175 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-FA160-S200 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-FA160-S250 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-FA160-S300 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-FA160-S350 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-FA160-S400 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-FA160-S450 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-FA160-S500 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-FA160-S600 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-FA160-S700 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-FA160-S800 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-FA160-S900 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-FA160-S1000 Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TC160-S25 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-TC160-S50 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-TC160-S75 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-TC160-S100 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-TC160-S125 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-TC160-S175 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-TC160-S200 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-TC160-S250 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-TC160-S300 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-TC160-S350 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-TC160-S400 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-TC160-S450 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-TC160-S500 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-TC160-S600 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-TC160-S700 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-TC160-S800 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-TC160-S900 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-TC160-S1000 Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TA160-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-TA160-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-TA160-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-TA160-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-TA160-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-TA160-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-TA160-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-TA160-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-TA160-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-TA160-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-TA160-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-TA160-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-TA160-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-TA160-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-TA160-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-TA160-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-TA160-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-TA160-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-B200-S25 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-B200-S50 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-B200-S75 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-B200-S100 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-B200-S125 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-B200-S175 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-B200-S200 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-B200-S250 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-B200-S300 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-B200-S350 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-B200-S400 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-B200-S450 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-B200-S500 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-B200-S600 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-B200-S700 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-B200-S800 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-B200-S900 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-B200-S1000 Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-LB200-S25 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-LB200-S50 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-LB200-S75 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-LB200-S100 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-LB200-S125 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-LB200-S175 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-LB200-S200 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-LB200-S250 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-LB200-S300 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-LB200-S350 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-LB200-S400 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-LB200-S450 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-LB200-S500 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-LB200-S600 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-LB200-S700 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-LB200-S800 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-LB200-S900 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-LB200-S1000 Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-FA200-S25 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-FA200-S50 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-FA200-S75 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-FA200-S100 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-FA200-S125 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-FA200-S175 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-FA200-S200 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-FA200-S250 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-FA200-S300 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-FA200-S350 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-FA200-S400 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-FA200-S450 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-FA200-S500 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-FA200-S600 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-FA200-S700 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-FA200-S800 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-FA200-S900 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-FA200-S1000 Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TC200-S25 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-TC200-S50 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-TC200-S75 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-TC200-S100 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-TC200-S125 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-TC200-S175 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-TC200-S200 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-TC200-S250 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-TC200-S300 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-TC200-S350 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-TC200-S400 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-TC200-S450 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-TC200-S500 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-TC200-S600 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-TC200-S700 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-TC200-S800 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-TC200-S900 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-TC200-S1000 Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TA200-S25 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-TA200-S50 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-TA200-S75 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-TA200-S100 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-TA200-S125 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-TA200-S175 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-TA200-S200 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-TA200-S250 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-TA200-S300 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-TA200-S350 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-TA200-S400 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-TA200-S450 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-TA200-S500 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-TA200-S600 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-TA200-S700 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-TA200-S800 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-TA200-S900 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-TA200-S1000 Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-32 Legacy code, base model (add mounting and stroke) | Bore: Ø32 mm | Port: 1/8
ACTW-40 Legacy code, base model (add mounting and stroke) | Bore: Ø40 mm | Port: 1/4
ACTW-50 Legacy code, base model (add mounting and stroke) | Bore: Ø50 mm | Port: 1/4
ACTW-63 Legacy code, base model (add mounting and stroke) | Bore: Ø63 mm | Port: 3/8
ACTW-80 Legacy code, base model (add mounting and stroke) | Bore: Ø80 mm | Port: 3/8
ACTW-100 Legacy code, base model (add mounting and stroke) | Bore: Ø100 mm | Port: 1/2
ACTW-125 Legacy code, base model (add mounting and stroke) | Bore: Ø125 mm | Port: 1/2
ACTW-160 Legacy code, base model (add mounting and stroke) | Bore: Ø160 mm | Port: 3/4
ACTW-200 Legacy code, base model (add mounting and stroke) | Bore: Ø200 mm | Port: 3/4
Pneumatic CylindersKCC
784 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KCC ACTW ISO 15552 Cylinder (Tie-Rod, Double Rod, Ø32-200)

Brand KCC·Pneumatic Cylinders

Available part numbers (784)

ACTW-B32-S25, ACTW-B32-S50, ACTW-B32-S75, ACTW-B32-S100, ACTW-B32-S125, ACTW-B32-S175, ACTW-B32-S200, ACTW-B32-S250, ACTW-B32-S300, ACTW-B32-S350 + 774 more — see full table ↓

How to order

Send the KCC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ACTW-B32-S25Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-B32-S50Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-B32-S75Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-B32-S100Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-B32-S125Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-B32-S175Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-B32-S200Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-B32-S250Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-B32-S300Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-B32-S350Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-B32-S400Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-B32-S450Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-B32-S500Mounting: Basic (no bracket) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-LB32-S25Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-LB32-S50Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-LB32-S75Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-LB32-S100Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-LB32-S125Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-LB32-S175Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-LB32-S200Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-LB32-S250Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-LB32-S300Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-LB32-S350Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-LB32-S400Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-LB32-S450Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-LB32-S500Mounting: Foot (LB) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-FA32-S25Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-FA32-S50Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-FA32-S75Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-FA32-S100Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-FA32-S125Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-FA32-S175Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-FA32-S200Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-FA32-S250Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-FA32-S300Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-FA32-S350Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-FA32-S400Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-FA32-S450Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-FA32-S500Mounting: Rod-side flange (FA) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-TC32-S25Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-TC32-S50Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-TC32-S75Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-TC32-S100Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-TC32-S125Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-TC32-S175Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-TC32-S200Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-TC32-S250Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-TC32-S300Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-TC32-S350Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-TC32-S400Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-TC32-S450Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-TC32-S500Mounting: Centre trunnion (TC) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-TA32-S25Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 25 mm | Port: 1/8
ACTW-TA32-S50Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 50 mm | Port: 1/8
ACTW-TA32-S75Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 75 mm | Port: 1/8
ACTW-TA32-S100Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 100 mm | Port: 1/8
ACTW-TA32-S125Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 125 mm | Port: 1/8
ACTW-TA32-S175Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 175 mm | Port: 1/8
ACTW-TA32-S200Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 200 mm | Port: 1/8
ACTW-TA32-S250Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 250 mm | Port: 1/8
ACTW-TA32-S300Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 300 mm | Port: 1/8
ACTW-TA32-S350Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 350 mm | Port: 1/8
ACTW-TA32-S400Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 400 mm | Port: 1/8
ACTW-TA32-S450Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 450 mm | Port: 1/8
ACTW-TA32-S500Mounting: Rod-side trunnion (TA) | Bore: Ø32 mm | Stroke: 500 mm | Port: 1/8
ACTW-B40-S25Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-B40-S50Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-B40-S75Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-B40-S100Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-B40-S125Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-B40-S175Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-B40-S200Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-B40-S250Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-B40-S300Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-B40-S350Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-B40-S400Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-B40-S450Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-B40-S500Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-B40-S600Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-B40-S700Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-B40-S800Mounting: Basic (no bracket) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-LB40-S25Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-LB40-S50Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-LB40-S75Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-LB40-S100Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-LB40-S125Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-LB40-S175Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-LB40-S200Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-LB40-S250Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-LB40-S300Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-LB40-S350Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-LB40-S400Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-LB40-S450Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-LB40-S500Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-LB40-S600Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-LB40-S700Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-LB40-S800Mounting: Foot (LB) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-FA40-S25Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-FA40-S50Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-FA40-S75Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-FA40-S100Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-FA40-S125Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-FA40-S175Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-FA40-S200Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-FA40-S250Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-FA40-S300Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-FA40-S350Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-FA40-S400Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-FA40-S450Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-FA40-S500Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-FA40-S600Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-FA40-S700Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-FA40-S800Mounting: Rod-side flange (FA) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-TC40-S25Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-TC40-S50Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-TC40-S75Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-TC40-S100Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-TC40-S125Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-TC40-S175Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-TC40-S200Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-TC40-S250Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-TC40-S300Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-TC40-S350Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-TC40-S400Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-TC40-S450Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-TC40-S500Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-TC40-S600Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-TC40-S700Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-TC40-S800Mounting: Centre trunnion (TC) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-TA40-S25Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 25 mm | Port: 1/4
ACTW-TA40-S50Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 50 mm | Port: 1/4
ACTW-TA40-S75Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 75 mm | Port: 1/4
ACTW-TA40-S100Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 100 mm | Port: 1/4
ACTW-TA40-S125Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 125 mm | Port: 1/4
ACTW-TA40-S175Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 175 mm | Port: 1/4
ACTW-TA40-S200Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 200 mm | Port: 1/4
ACTW-TA40-S250Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 250 mm | Port: 1/4
ACTW-TA40-S300Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 300 mm | Port: 1/4
ACTW-TA40-S350Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 350 mm | Port: 1/4
ACTW-TA40-S400Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 400 mm | Port: 1/4
ACTW-TA40-S450Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 450 mm | Port: 1/4
ACTW-TA40-S500Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 500 mm | Port: 1/4
ACTW-TA40-S600Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 600 mm | Port: 1/4
ACTW-TA40-S700Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 700 mm | Port: 1/4
ACTW-TA40-S800Mounting: Rod-side trunnion (TA) | Bore: Ø40 mm | Stroke: 800 mm | Port: 1/4
ACTW-B50-S25Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-B50-S50Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-B50-S75Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-B50-S100Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-B50-S125Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-B50-S175Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-B50-S200Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-B50-S250Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-B50-S300Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-B50-S350Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-B50-S400Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-B50-S450Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-B50-S500Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-B50-S600Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-B50-S700Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-B50-S800Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-B50-S900Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-B50-S1000Mounting: Basic (no bracket) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-LB50-S25Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-LB50-S50Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-LB50-S75Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-LB50-S100Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-LB50-S125Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-LB50-S175Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-LB50-S200Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-LB50-S250Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-LB50-S300Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-LB50-S350Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-LB50-S400Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-LB50-S450Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-LB50-S500Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-LB50-S600Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-LB50-S700Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-LB50-S800Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-LB50-S900Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-LB50-S1000Mounting: Foot (LB) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-FA50-S25Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-FA50-S50Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-FA50-S75Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-FA50-S100Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-FA50-S125Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-FA50-S175Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-FA50-S200Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-FA50-S250Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-FA50-S300Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-FA50-S350Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-FA50-S400Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-FA50-S450Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-FA50-S500Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-FA50-S600Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-FA50-S700Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-FA50-S800Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-FA50-S900Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-FA50-S1000Mounting: Rod-side flange (FA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-TC50-S25Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-TC50-S50Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-TC50-S75Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-TC50-S100Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-TC50-S125Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-TC50-S175Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-TC50-S200Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-TC50-S250Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-TC50-S300Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-TC50-S350Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-TC50-S400Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-TC50-S450Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-TC50-S500Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-TC50-S600Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-TC50-S700Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-TC50-S800Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-TC50-S900Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-TC50-S1000Mounting: Centre trunnion (TC) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-TA50-S25Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 25 mm | Port: 1/4
ACTW-TA50-S50Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 50 mm | Port: 1/4
ACTW-TA50-S75Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 75 mm | Port: 1/4
ACTW-TA50-S100Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 100 mm | Port: 1/4
ACTW-TA50-S125Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 125 mm | Port: 1/4
ACTW-TA50-S175Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 175 mm | Port: 1/4
ACTW-TA50-S200Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 200 mm | Port: 1/4
ACTW-TA50-S250Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 250 mm | Port: 1/4
ACTW-TA50-S300Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 300 mm | Port: 1/4
ACTW-TA50-S350Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 350 mm | Port: 1/4
ACTW-TA50-S400Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 400 mm | Port: 1/4
ACTW-TA50-S450Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 450 mm | Port: 1/4
ACTW-TA50-S500Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 500 mm | Port: 1/4
ACTW-TA50-S600Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 600 mm | Port: 1/4
ACTW-TA50-S700Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 700 mm | Port: 1/4
ACTW-TA50-S800Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 800 mm | Port: 1/4
ACTW-TA50-S900Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 900 mm | Port: 1/4
ACTW-TA50-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø50 mm | Stroke: 1000 mm | Port: 1/4
ACTW-B63-S25Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-B63-S50Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-B63-S75Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-B63-S100Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-B63-S125Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-B63-S175Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-B63-S200Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-B63-S250Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-B63-S300Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-B63-S350Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-B63-S400Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-B63-S450Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-B63-S500Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-B63-S600Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-B63-S700Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-B63-S800Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-B63-S900Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-B63-S1000Mounting: Basic (no bracket) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-LB63-S25Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-LB63-S50Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-LB63-S75Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-LB63-S100Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-LB63-S125Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-LB63-S175Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-LB63-S200Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-LB63-S250Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-LB63-S300Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-LB63-S350Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-LB63-S400Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-LB63-S450Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-LB63-S500Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-LB63-S600Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-LB63-S700Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-LB63-S800Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-LB63-S900Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-LB63-S1000Mounting: Foot (LB) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-FA63-S25Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-FA63-S50Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-FA63-S75Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-FA63-S100Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-FA63-S125Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-FA63-S175Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-FA63-S200Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-FA63-S250Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-FA63-S300Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-FA63-S350Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-FA63-S400Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-FA63-S450Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-FA63-S500Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-FA63-S600Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-FA63-S700Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-FA63-S800Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-FA63-S900Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-FA63-S1000Mounting: Rod-side flange (FA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TC63-S25Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-TC63-S50Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-TC63-S75Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-TC63-S100Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-TC63-S125Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-TC63-S175Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-TC63-S200Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-TC63-S250Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-TC63-S300Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-TC63-S350Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-TC63-S400Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-TC63-S450Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-TC63-S500Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-TC63-S600Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-TC63-S700Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-TC63-S800Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-TC63-S900Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-TC63-S1000Mounting: Centre trunnion (TC) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TA63-S25Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 25 mm | Port: 3/8
ACTW-TA63-S50Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 50 mm | Port: 3/8
ACTW-TA63-S75Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 75 mm | Port: 3/8
ACTW-TA63-S100Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 100 mm | Port: 3/8
ACTW-TA63-S125Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 125 mm | Port: 3/8
ACTW-TA63-S175Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 175 mm | Port: 3/8
ACTW-TA63-S200Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 200 mm | Port: 3/8
ACTW-TA63-S250Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 250 mm | Port: 3/8
ACTW-TA63-S300Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 300 mm | Port: 3/8
ACTW-TA63-S350Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 350 mm | Port: 3/8
ACTW-TA63-S400Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 400 mm | Port: 3/8
ACTW-TA63-S450Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 450 mm | Port: 3/8
ACTW-TA63-S500Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 500 mm | Port: 3/8
ACTW-TA63-S600Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 600 mm | Port: 3/8
ACTW-TA63-S700Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 700 mm | Port: 3/8
ACTW-TA63-S800Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 800 mm | Port: 3/8
ACTW-TA63-S900Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 900 mm | Port: 3/8
ACTW-TA63-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø63 mm | Stroke: 1000 mm | Port: 3/8
ACTW-B80-S25Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-B80-S50Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-B80-S75Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-B80-S100Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-B80-S125Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-B80-S175Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-B80-S200Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-B80-S250Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-B80-S300Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-B80-S350Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-B80-S400Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-B80-S450Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-B80-S500Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-B80-S600Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-B80-S700Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-B80-S800Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-B80-S900Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-B80-S1000Mounting: Basic (no bracket) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-LB80-S25Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-LB80-S50Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-LB80-S75Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-LB80-S100Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-LB80-S125Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-LB80-S175Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-LB80-S200Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-LB80-S250Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-LB80-S300Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-LB80-S350Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-LB80-S400Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-LB80-S450Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-LB80-S500Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-LB80-S600Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-LB80-S700Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-LB80-S800Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-LB80-S900Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-LB80-S1000Mounting: Foot (LB) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-FA80-S25Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-FA80-S50Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-FA80-S75Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-FA80-S100Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-FA80-S125Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-FA80-S175Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-FA80-S200Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-FA80-S250Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-FA80-S300Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-FA80-S350Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-FA80-S400Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-FA80-S450Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-FA80-S500Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-FA80-S600Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-FA80-S700Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-FA80-S800Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-FA80-S900Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-FA80-S1000Mounting: Rod-side flange (FA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TC80-S25Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-TC80-S50Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-TC80-S75Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-TC80-S100Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-TC80-S125Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-TC80-S175Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-TC80-S200Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-TC80-S250Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-TC80-S300Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-TC80-S350Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-TC80-S400Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-TC80-S450Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-TC80-S500Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-TC80-S600Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-TC80-S700Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-TC80-S800Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-TC80-S900Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-TC80-S1000Mounting: Centre trunnion (TC) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-TA80-S25Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 25 mm | Port: 3/8
ACTW-TA80-S50Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 50 mm | Port: 3/8
ACTW-TA80-S75Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 75 mm | Port: 3/8
ACTW-TA80-S100Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 100 mm | Port: 3/8
ACTW-TA80-S125Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 125 mm | Port: 3/8
ACTW-TA80-S175Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 175 mm | Port: 3/8
ACTW-TA80-S200Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 200 mm | Port: 3/8
ACTW-TA80-S250Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 250 mm | Port: 3/8
ACTW-TA80-S300Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 300 mm | Port: 3/8
ACTW-TA80-S350Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 350 mm | Port: 3/8
ACTW-TA80-S400Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 400 mm | Port: 3/8
ACTW-TA80-S450Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 450 mm | Port: 3/8
ACTW-TA80-S500Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 500 mm | Port: 3/8
ACTW-TA80-S600Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 600 mm | Port: 3/8
ACTW-TA80-S700Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 700 mm | Port: 3/8
ACTW-TA80-S800Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 800 mm | Port: 3/8
ACTW-TA80-S900Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 900 mm | Port: 3/8
ACTW-TA80-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø80 mm | Stroke: 1000 mm | Port: 3/8
ACTW-B100-S25Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-B100-S50Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-B100-S75Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-B100-S100Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-B100-S125Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-B100-S175Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-B100-S200Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-B100-S250Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-B100-S300Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-B100-S350Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-B100-S400Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-B100-S450Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-B100-S500Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-B100-S600Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-B100-S700Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-B100-S800Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-B100-S900Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-B100-S1000Mounting: Basic (no bracket) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-LB100-S25Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-LB100-S50Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-LB100-S75Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-LB100-S100Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-LB100-S125Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-LB100-S175Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-LB100-S200Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-LB100-S250Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-LB100-S300Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-LB100-S350Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-LB100-S400Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-LB100-S450Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-LB100-S500Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-LB100-S600Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-LB100-S700Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-LB100-S800Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-LB100-S900Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-LB100-S1000Mounting: Foot (LB) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-FA100-S25Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-FA100-S50Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-FA100-S75Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-FA100-S100Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-FA100-S125Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-FA100-S175Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-FA100-S200Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-FA100-S250Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-FA100-S300Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-FA100-S350Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-FA100-S400Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-FA100-S450Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-FA100-S500Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-FA100-S600Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-FA100-S700Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-FA100-S800Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-FA100-S900Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-FA100-S1000Mounting: Rod-side flange (FA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TC100-S25Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-TC100-S50Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-TC100-S75Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-TC100-S100Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-TC100-S125Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-TC100-S175Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-TC100-S200Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-TC100-S250Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-TC100-S300Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-TC100-S350Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-TC100-S400Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-TC100-S450Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-TC100-S500Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-TC100-S600Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-TC100-S700Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-TC100-S800Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-TC100-S900Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-TC100-S1000Mounting: Centre trunnion (TC) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TA100-S25Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 25 mm | Port: 1/2
ACTW-TA100-S50Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 50 mm | Port: 1/2
ACTW-TA100-S75Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 75 mm | Port: 1/2
ACTW-TA100-S100Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 100 mm | Port: 1/2
ACTW-TA100-S125Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 125 mm | Port: 1/2
ACTW-TA100-S175Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 175 mm | Port: 1/2
ACTW-TA100-S200Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 200 mm | Port: 1/2
ACTW-TA100-S250Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 250 mm | Port: 1/2
ACTW-TA100-S300Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 300 mm | Port: 1/2
ACTW-TA100-S350Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 350 mm | Port: 1/2
ACTW-TA100-S400Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 400 mm | Port: 1/2
ACTW-TA100-S450Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 450 mm | Port: 1/2
ACTW-TA100-S500Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 500 mm | Port: 1/2
ACTW-TA100-S600Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 600 mm | Port: 1/2
ACTW-TA100-S700Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 700 mm | Port: 1/2
ACTW-TA100-S800Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 800 mm | Port: 1/2
ACTW-TA100-S900Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 900 mm | Port: 1/2
ACTW-TA100-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø100 mm | Stroke: 1000 mm | Port: 1/2
ACTW-B125-S25Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-B125-S50Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-B125-S75Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-B125-S100Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-B125-S125Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-B125-S175Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-B125-S200Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-B125-S250Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-B125-S300Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-B125-S350Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-B125-S400Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-B125-S450Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-B125-S500Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-B125-S600Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-B125-S700Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-B125-S800Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-B125-S900Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-B125-S1000Mounting: Basic (no bracket) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-LB125-S25Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-LB125-S50Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-LB125-S75Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-LB125-S100Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-LB125-S125Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-LB125-S175Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-LB125-S200Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-LB125-S250Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-LB125-S300Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-LB125-S350Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-LB125-S400Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-LB125-S450Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-LB125-S500Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-LB125-S600Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-LB125-S700Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-LB125-S800Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-LB125-S900Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-LB125-S1000Mounting: Foot (LB) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-FA125-S25Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-FA125-S50Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-FA125-S75Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-FA125-S100Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-FA125-S125Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-FA125-S175Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-FA125-S200Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-FA125-S250Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-FA125-S300Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-FA125-S350Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-FA125-S400Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-FA125-S450Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-FA125-S500Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-FA125-S600Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-FA125-S700Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-FA125-S800Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-FA125-S900Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-FA125-S1000Mounting: Rod-side flange (FA) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TC125-S25Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-TC125-S50Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-TC125-S75Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-TC125-S100Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-TC125-S125Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-TC125-S175Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-TC125-S200Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-TC125-S250Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-TC125-S300Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-TC125-S350Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-TC125-S400Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-TC125-S450Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-TC125-S500Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-TC125-S600Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-TC125-S700Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-TC125-S800Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-TC125-S900Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-TC125-S1000Mounting: Centre trunnion (TC) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-TA125-S25Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 25 mm | Port: 1/2
ACTW-TA125-S50Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 50 mm | Port: 1/2
ACTW-TA125-S75Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 75 mm | Port: 1/2
ACTW-TA125-S100Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 100 mm | Port: 1/2
ACTW-TA125-S125Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 125 mm | Port: 1/2
ACTW-TA125-S175Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 175 mm | Port: 1/2
ACTW-TA125-S200Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 200 mm | Port: 1/2
ACTW-TA125-S250Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 250 mm | Port: 1/2
ACTW-TA125-S300Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 300 mm | Port: 1/2
ACTW-TA125-S350Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 350 mm | Port: 1/2
ACTW-TA125-S400Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 400 mm | Port: 1/2
ACTW-TA125-S450Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 450 mm | Port: 1/2
ACTW-TA125-S500Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 500 mm | Port: 1/2
ACTW-TA125-S600Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 600 mm | Port: 1/2
ACTW-TA125-S700Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 700 mm | Port: 1/2
ACTW-TA125-S800Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 800 mm | Port: 1/2
ACTW-TA125-S900Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 900 mm | Port: 1/2
ACTW-TA125-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø125 mm | Stroke: 1000 mm | Port: 1/2
ACTW-B160-S25Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-B160-S50Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-B160-S75Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-B160-S100Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-B160-S125Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-B160-S175Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-B160-S200Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-B160-S250Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-B160-S300Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-B160-S350Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-B160-S400Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-B160-S450Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-B160-S500Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-B160-S600Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-B160-S700Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-B160-S800Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-B160-S900Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-B160-S1000Mounting: Basic (no bracket) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-LB160-S25Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-LB160-S50Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-LB160-S75Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-LB160-S100Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-LB160-S125Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-LB160-S175Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-LB160-S200Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-LB160-S250Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-LB160-S300Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-LB160-S350Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-LB160-S400Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-LB160-S450Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-LB160-S500Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-LB160-S600Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-LB160-S700Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-LB160-S800Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-LB160-S900Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-LB160-S1000Mounting: Foot (LB) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-FA160-S25Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-FA160-S50Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-FA160-S75Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-FA160-S100Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-FA160-S125Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-FA160-S175Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-FA160-S200Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-FA160-S250Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-FA160-S300Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-FA160-S350Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-FA160-S400Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-FA160-S450Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-FA160-S500Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-FA160-S600Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-FA160-S700Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-FA160-S800Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-FA160-S900Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-FA160-S1000Mounting: Rod-side flange (FA) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TC160-S25Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-TC160-S50Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-TC160-S75Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-TC160-S100Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-TC160-S125Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-TC160-S175Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-TC160-S200Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-TC160-S250Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-TC160-S300Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-TC160-S350Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-TC160-S400Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-TC160-S450Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-TC160-S500Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-TC160-S600Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-TC160-S700Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-TC160-S800Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-TC160-S900Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-TC160-S1000Mounting: Centre trunnion (TC) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TA160-S25Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 25 mm | Port: 3/4
ACTW-TA160-S50Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 50 mm | Port: 3/4
ACTW-TA160-S75Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 75 mm | Port: 3/4
ACTW-TA160-S100Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 100 mm | Port: 3/4
ACTW-TA160-S125Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 125 mm | Port: 3/4
ACTW-TA160-S175Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 175 mm | Port: 3/4
ACTW-TA160-S200Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 200 mm | Port: 3/4
ACTW-TA160-S250Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 250 mm | Port: 3/4
ACTW-TA160-S300Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 300 mm | Port: 3/4
ACTW-TA160-S350Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 350 mm | Port: 3/4
ACTW-TA160-S400Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 400 mm | Port: 3/4
ACTW-TA160-S450Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 450 mm | Port: 3/4
ACTW-TA160-S500Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 500 mm | Port: 3/4
ACTW-TA160-S600Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 600 mm | Port: 3/4
ACTW-TA160-S700Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 700 mm | Port: 3/4
ACTW-TA160-S800Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 800 mm | Port: 3/4
ACTW-TA160-S900Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 900 mm | Port: 3/4
ACTW-TA160-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø160 mm | Stroke: 1000 mm | Port: 3/4
ACTW-B200-S25Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-B200-S50Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-B200-S75Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-B200-S100Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-B200-S125Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-B200-S175Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-B200-S200Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-B200-S250Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-B200-S300Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-B200-S350Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-B200-S400Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-B200-S450Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-B200-S500Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-B200-S600Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-B200-S700Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-B200-S800Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-B200-S900Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-B200-S1000Mounting: Basic (no bracket) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-LB200-S25Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-LB200-S50Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-LB200-S75Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-LB200-S100Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-LB200-S125Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-LB200-S175Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-LB200-S200Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-LB200-S250Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-LB200-S300Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-LB200-S350Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-LB200-S400Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-LB200-S450Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-LB200-S500Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-LB200-S600Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-LB200-S700Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-LB200-S800Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-LB200-S900Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-LB200-S1000Mounting: Foot (LB) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-FA200-S25Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-FA200-S50Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-FA200-S75Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-FA200-S100Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-FA200-S125Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-FA200-S175Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-FA200-S200Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-FA200-S250Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-FA200-S300Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-FA200-S350Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-FA200-S400Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-FA200-S450Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-FA200-S500Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-FA200-S600Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-FA200-S700Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-FA200-S800Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-FA200-S900Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-FA200-S1000Mounting: Rod-side flange (FA) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TC200-S25Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-TC200-S50Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-TC200-S75Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-TC200-S100Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-TC200-S125Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-TC200-S175Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-TC200-S200Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-TC200-S250Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-TC200-S300Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-TC200-S350Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-TC200-S400Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-TC200-S450Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-TC200-S500Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-TC200-S600Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-TC200-S700Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-TC200-S800Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-TC200-S900Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-TC200-S1000Mounting: Centre trunnion (TC) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-TA200-S25Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 25 mm | Port: 3/4
ACTW-TA200-S50Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 50 mm | Port: 3/4
ACTW-TA200-S75Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 75 mm | Port: 3/4
ACTW-TA200-S100Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 100 mm | Port: 3/4
ACTW-TA200-S125Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 125 mm | Port: 3/4
ACTW-TA200-S175Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 175 mm | Port: 3/4
ACTW-TA200-S200Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 200 mm | Port: 3/4
ACTW-TA200-S250Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 250 mm | Port: 3/4
ACTW-TA200-S300Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 300 mm | Port: 3/4
ACTW-TA200-S350Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 350 mm | Port: 3/4
ACTW-TA200-S400Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 400 mm | Port: 3/4
ACTW-TA200-S450Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 450 mm | Port: 3/4
ACTW-TA200-S500Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 500 mm | Port: 3/4
ACTW-TA200-S600Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 600 mm | Port: 3/4
ACTW-TA200-S700Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 700 mm | Port: 3/4
ACTW-TA200-S800Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 800 mm | Port: 3/4
ACTW-TA200-S900Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 900 mm | Port: 3/4
ACTW-TA200-S1000Mounting: Rod-side trunnion (TA) | Bore: Ø200 mm | Stroke: 1000 mm | Port: 3/4
ACTW-32Legacy code, base model (add mounting and stroke) | Bore: Ø32 mm | Port: 1/8
ACTW-40Legacy code, base model (add mounting and stroke) | Bore: Ø40 mm | Port: 1/4
ACTW-50Legacy code, base model (add mounting and stroke) | Bore: Ø50 mm | Port: 1/4
ACTW-63Legacy code, base model (add mounting and stroke) | Bore: Ø63 mm | Port: 3/8
ACTW-80Legacy code, base model (add mounting and stroke) | Bore: Ø80 mm | Port: 3/8
ACTW-100Legacy code, base model (add mounting and stroke) | Bore: Ø100 mm | Port: 1/2
ACTW-125Legacy code, base model (add mounting and stroke) | Bore: Ø125 mm | Port: 1/2
ACTW-160Legacy code, base model (add mounting and stroke) | Bore: Ø160 mm | Port: 3/4
ACTW-200Legacy code, base model (add mounting and stroke) | Bore: Ø200 mm | Port: 3/4

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
