KCC AFW/ADFW Thin Cylinder (Double Rod, Bore 20-200)

KCC AFW/ADFW series double-acting double-rod (through-rod) thin pneumatic cylinder, bore 20 to 200 mm, without magnet (AFW) or with built-in auto switch magnet (ADFW).

Key features

Through-rod design with equal rod extension on both ends; same compact square body as the AF/ADF series
Bolts directly to the machine without brackets; special anodized square aluminium body
Standard type has tapped mounting holes on both ends (A) or through-holes (B); foot (LB), rod/head flange (FA/FB) and double clevis (CB) brackets for bore 12-100, head-end spigot (HI) for bore 50/63
Rod end female thread as standard; male thread (N), knuckle joints (I, Y), rubber (C) or air (A) cushion, low hydraulic-pressure type (L) and auto switches (A-7x/A-9x reed, F-7x/F-9x solid state) are ordered as suffixes
Intermediate strokes 55-100 mm are built from the next standard stroke with an internal spacer; specials TS/TW (multi-stage), ASJ/BSJ (adjustable stroke), SV (heat resistant), E (side load), MS (scraper), SS (stainless rod) and single acting S/T on request

Specifications

Action	Double acting
Fluid	Air
Proof pressure	1.44 MPa
Max. operating pressure	0.97 MPa
Min. operating pressure	0.07 MPa (bore 12/16), 0.05 MPa (bore 20 to 200)
Ambient and fluid temperature	-10 to 70°C (no freezing)
Piston speed	50 to 500 mm/s
Cushion	None (rubber cushion option C; air cushion A for bore 32-80)
Stroke tolerance	+1.0/0 mm (+1.4/0 mm for bore 125-200)
Thread tolerance	KS class 2
Source	KCC catalog 2039239615_vIdDNj7z_6af84da342e1788723816e2300d4783ce8e172d4+1.pdf, p. 1-105 to 1-122 (PDF p. 1-18)

AFW20A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW20A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW20A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW20A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW20A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW20A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW20A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW20A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW20A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW20A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW20B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW20B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW20B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW20B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW20B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW20B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW20B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW20B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW20B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW20B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW25A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW25A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW25A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW25A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW25A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW25A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW25A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW25A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW25A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW25A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW25B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW25B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW25B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW25B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW25B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW25B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW25B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW25B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW25B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW25B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW32A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW32A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW32A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW32A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW32A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW32A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW32A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW32A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW32A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW32A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW32B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW32B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW32B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW32B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW32B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW32B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW32B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW32B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW32B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW32B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW40A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW40A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW40A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW40A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW40A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW40A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW40A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW40A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW40A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW40A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW40B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW40B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW40B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW40B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW40B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW40B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW40B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW40B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW40B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW40B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW50A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW50A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW50A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW50A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW50A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW50A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW50A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW50A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW50A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW50A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW50B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW50B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW50B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW50B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW50B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW50B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW50B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW50B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW50B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW50B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW63A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW63A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW63A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW63A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW63A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW63A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW63A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW63A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW63A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW63A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW63B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW63B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW63B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW63B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW63B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW63B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW63B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW63B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW63B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW63B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW80A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW80A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW80A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW80A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW80A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW80A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW80A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW80A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW80A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW80A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW80B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW80B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW80B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW80B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW80B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW80B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW80B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW80B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW80B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW80B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW100A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW100A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW100A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW100A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW100A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW100A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW100A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW100A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW100A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW100A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW100B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW100B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW100B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW100B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW100B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW100B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW100B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW100B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW100B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW100B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW125A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW125A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW125A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW125A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW125A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW125A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW125A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW125A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW125A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW125A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW125B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW125B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW125B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW125B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW125B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW125B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW125B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW125B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW125B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW125B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW140A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW140A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW140A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW140A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW140A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW140A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW140A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW140A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW140A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW140A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW140B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW140B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW140B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW140B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW140B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW140B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW140B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW140B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW140B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW140B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW160A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW160A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW160A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW160A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW160A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW160A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW160A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW160A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW160A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW160A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW160B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW160B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW160B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW160B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW160B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW160B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW160B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW160B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW160B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW160B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW200A-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW200A-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW200A-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW200A-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW200A-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW200A-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW200A-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW200A-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW200A-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW200A-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW200B-S5		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
AFW200B-S10		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
AFW200B-S15		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
AFW200B-S20		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
AFW200B-S25		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
AFW200B-S30		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
AFW200B-S35		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
AFW200B-S40		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
AFW200B-S45		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
AFW200B-S50		Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
AFW-LB20A-S5		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB20A-S10		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB20A-S15		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB20A-S20		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB20A-S25		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB20A-S30		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB20A-S35		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB20A-S40		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB20A-S45		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB20A-S50		Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-LB25A-S5		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB25A-S10		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB25A-S15		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB25A-S20		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB25A-S25		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB25A-S30		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB25A-S35		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB25A-S40		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB25A-S45		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB25A-S50		Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-LB32A-S5		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB32A-S10		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB32A-S15		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB32A-S20		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB32A-S25		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB32A-S30		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB32A-S35		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB32A-S40		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB32A-S45		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB32A-S50		Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-LB40A-S5		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB40A-S10		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB40A-S15		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB40A-S20		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB40A-S25		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB40A-S30		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB40A-S35		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB40A-S40		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB40A-S45		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB40A-S50		Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-LB50A-S5		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB50A-S10		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB50A-S15		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB50A-S20		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB50A-S25		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB50A-S30		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB50A-S35		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB50A-S40		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB50A-S45		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB50A-S50		Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-LB63A-S5		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB63A-S10		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB63A-S15		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB63A-S20		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB63A-S25		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB63A-S30		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB63A-S35		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB63A-S40		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB63A-S45		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB63A-S50		Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-LB80A-S5		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB80A-S10		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB80A-S15		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB80A-S20		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB80A-S25		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB80A-S30		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB80A-S35		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB80A-S40		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB80A-S45		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB80A-S50		Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-LB100A-S5		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-LB100A-S10		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-LB100A-S15		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-LB100A-S20		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-LB100A-S25		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-LB100A-S30		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-LB100A-S35		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-LB100A-S40		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-LB100A-S45		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-LB100A-S50		Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA20A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA20A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA20A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA20A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA20A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA20A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA20A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA20A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA20A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA20A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA25A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA25A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA25A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA25A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA25A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA25A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA25A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA25A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA25A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA25A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA32A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA32A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA32A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA32A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA32A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA32A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA32A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA32A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA32A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA32A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA40A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA40A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA40A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA40A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA40A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA40A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA40A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA40A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA40A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA40A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA50A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA50A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA50A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA50A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA50A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA50A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA50A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA50A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA50A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA50A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA63A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA63A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA63A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA63A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA63A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA63A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA63A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA63A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA63A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA63A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA80A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA80A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA80A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA80A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA80A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA80A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA80A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA80A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA80A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA80A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FA100A-S5		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FA100A-S10		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FA100A-S15		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FA100A-S20		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FA100A-S25		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FA100A-S30		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FA100A-S35		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FA100A-S40		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FA100A-S45		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FA100A-S50		Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB20A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB20A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB20A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB20A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB20A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB20A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB20A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB20A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB20A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB20A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB25A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB25A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB25A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB25A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB25A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB25A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB25A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB25A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB25A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB25A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB32A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB32A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB32A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB32A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB32A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB32A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB32A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB32A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB32A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB32A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB40A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB40A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB40A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB40A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB40A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB40A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB40A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB40A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB40A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB40A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB50A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB50A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB50A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB50A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB50A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB50A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB50A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB50A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB50A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB50A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB63A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB63A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB63A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB63A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB63A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB63A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB63A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB63A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB63A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB63A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB80A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB80A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB80A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB80A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB80A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB80A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB80A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB80A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB80A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB80A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-FB100A-S5		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-FB100A-S10		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-FB100A-S15		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-FB100A-S20		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-FB100A-S25		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-FB100A-S30		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-FB100A-S35		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-FB100A-S40		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-FB100A-S45		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-FB100A-S50		Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB20A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB20A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB20A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB20A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB20A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB20A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB20A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB20A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB20A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB20A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB25A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB25A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB25A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB25A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB25A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB25A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB25A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB25A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB25A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB25A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB32A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB32A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB32A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB32A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB32A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB32A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB32A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB32A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB32A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB32A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB40A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB40A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB40A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB40A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB40A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB40A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB40A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB40A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB40A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB40A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB50A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB50A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB50A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB50A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB50A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB50A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB50A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB50A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB50A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB50A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB63A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB63A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB63A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB63A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB63A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB63A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB63A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB63A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB63A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB63A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB80A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB80A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB80A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB80A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB80A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB80A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB80A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB80A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB80A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB80A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-CB100A-S5		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-CB100A-S10		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-CB100A-S15		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-CB100A-S20		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-CB100A-S25		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-CB100A-S30		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-CB100A-S35		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-CB100A-S40		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-CB100A-S45		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-CB100A-S50		Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-HI50A-S5		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-HI50A-S10		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-HI50A-S15		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-HI50A-S20		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-HI50A-S25		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-HI50A-S30		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-HI50A-S35		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-HI50A-S40		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-HI50A-S45		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-HI50A-S50		Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW-HI63A-S5		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
AFW-HI63A-S10		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
AFW-HI63A-S15		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
AFW-HI63A-S20		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
AFW-HI63A-S25		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
AFW-HI63A-S30		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
AFW-HI63A-S35		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
AFW-HI63A-S40		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
AFW-HI63A-S45		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
AFW-HI63A-S50		Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW20A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW20A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW20A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW20A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW20A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW20A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW20A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW20A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW20A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW20A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW20B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW20B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW20B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW20B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW20B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW20B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW20B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW20B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW20B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW20B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW25A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW25A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW25A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW25A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW25A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW25A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW25A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW25A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW25A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW25A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW25B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW25B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW25B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW25B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW25B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW25B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW25B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW25B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW25B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW25B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW32A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW32A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW32A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW32A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW32A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW32A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW32A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW32A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW32A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW32A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW32B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW32B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW32B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW32B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW32B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW32B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW32B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW32B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW32B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW32B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW40A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW40A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW40A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW40A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW40A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW40A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW40A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW40A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW40A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW40A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW40B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW40B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW40B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW40B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW40B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW40B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW40B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW40B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW40B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW40B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW50A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW50A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW50A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW50A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW50A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW50A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW50A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW50A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW50A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW50A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW50B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW50B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW50B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW50B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW50B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW50B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW50B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW50B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW50B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW50B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW63A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW63A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW63A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW63A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW63A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW63A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW63A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW63A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW63A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW63A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW63B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW63B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW63B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW63B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW63B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW63B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW63B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW63B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW63B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW63B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW80A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW80A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW80A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW80A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW80A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW80A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW80A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW80A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW80A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW80A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW80B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW80B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW80B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW80B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW80B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW80B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW80B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW80B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW80B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW80B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW100A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW100A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW100A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW100A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW100A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW100A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW100A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW100A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW100A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW100A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW100B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW100B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW100B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW100B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW100B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW100B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW100B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW100B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW100B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW100B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW125A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW125A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW125A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW125A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW125A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW125A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW125A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW125A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW125A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW125A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW125B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW125B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW125B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW125B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW125B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW125B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW125B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW125B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW125B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW125B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW140A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW140A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW140A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW140A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW140A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW140A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW140A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW140A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW140A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW140A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW140B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW140B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW140B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW140B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW140B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW140B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW140B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW140B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW140B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW140B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW160A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW160A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW160A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW160A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW160A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW160A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW160A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW160A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW160A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW160A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW160B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW160B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW160B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW160B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW160B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW160B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW160B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW160B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW160B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW160B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW200A-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW200A-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW200A-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW200A-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW200A-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW200A-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW200A-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW200A-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW200A-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW200A-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW200B-S5		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
ADFW200B-S10		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
ADFW200B-S15		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
ADFW200B-S20		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
ADFW200B-S25		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
ADFW200B-S30		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
ADFW200B-S35		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
ADFW200B-S40		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
ADFW200B-S45		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
ADFW200B-S50		Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
ADFW-LB20A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB20A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB20A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB20A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB20A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB20A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB20A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB20A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB20A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB20A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-LB25A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB25A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB25A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB25A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB25A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB25A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB25A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB25A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB25A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB25A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-LB32A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB32A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB32A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB32A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB32A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB32A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB32A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB32A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB32A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB32A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-LB40A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB40A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB40A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB40A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB40A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB40A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB40A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB40A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB40A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB40A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-LB50A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB50A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB50A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB50A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB50A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB50A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB50A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB50A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB50A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB50A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-LB63A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB63A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB63A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB63A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB63A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB63A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB63A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB63A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB63A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB63A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-LB80A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB80A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB80A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB80A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB80A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB80A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB80A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB80A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB80A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB80A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-LB100A-S5		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-LB100A-S10		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-LB100A-S15		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-LB100A-S20		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-LB100A-S25		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-LB100A-S30		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-LB100A-S35		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-LB100A-S40		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-LB100A-S45		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-LB100A-S50		Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA20A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA20A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA20A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA20A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA20A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA20A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA20A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA20A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA20A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA20A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA25A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA25A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA25A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA25A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA25A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA25A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA25A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA25A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA25A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA25A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA32A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA32A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA32A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA32A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA32A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA32A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA32A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA32A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA32A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA32A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA40A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA40A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA40A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA40A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA40A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA40A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA40A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA40A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA40A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA40A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA50A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA50A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA50A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA50A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA50A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA50A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA50A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA50A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA50A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA50A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA63A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA63A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA63A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA63A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA63A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA63A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA63A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA63A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA63A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA63A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA80A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA80A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA80A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA80A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA80A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA80A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA80A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA80A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA80A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA80A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FA100A-S5		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FA100A-S10		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FA100A-S15		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FA100A-S20		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FA100A-S25		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FA100A-S30		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FA100A-S35		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FA100A-S40		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FA100A-S45		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FA100A-S50		Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB20A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB20A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB20A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB20A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB20A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB20A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB20A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB20A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB20A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB20A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB25A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB25A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB25A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB25A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB25A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB25A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB25A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB25A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB25A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB25A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB32A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB32A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB32A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB32A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB32A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB32A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB32A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB32A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB32A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB32A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB40A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB40A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB40A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB40A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB40A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB40A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB40A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB40A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB40A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB40A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB50A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB50A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB50A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB50A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB50A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB50A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB50A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB50A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB50A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB50A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB63A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB63A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB63A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB63A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB63A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB63A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB63A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB63A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB63A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB63A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB80A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB80A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB80A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB80A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB80A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB80A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB80A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB80A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB80A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB80A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-FB100A-S5		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-FB100A-S10		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-FB100A-S15		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-FB100A-S20		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-FB100A-S25		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-FB100A-S30		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-FB100A-S35		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-FB100A-S40		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-FB100A-S45		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-FB100A-S50		Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB20A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB20A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB20A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB20A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB20A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB20A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB20A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB20A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB20A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB20A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB25A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB25A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB25A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB25A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB25A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB25A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB25A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB25A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB25A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB25A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB32A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB32A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB32A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB32A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB32A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB32A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB32A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB32A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB32A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB32A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB40A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB40A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB40A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB40A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB40A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB40A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB40A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB40A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB40A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB40A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB50A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB50A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB50A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB50A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB50A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB50A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB50A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB50A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB50A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB50A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB63A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB63A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB63A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB63A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB63A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB63A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB63A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB63A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB63A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB63A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB80A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB80A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB80A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB80A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB80A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB80A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB80A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB80A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB80A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB80A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-CB100A-S5		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-CB100A-S10		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-CB100A-S15		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-CB100A-S20		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-CB100A-S25		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-CB100A-S30		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-CB100A-S35		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-CB100A-S40		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-CB100A-S45		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-CB100A-S50		Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-HI50A-S5		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-HI50A-S10		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-HI50A-S15		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-HI50A-S20		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-HI50A-S25		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-HI50A-S30		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-HI50A-S35		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-HI50A-S40		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-HI50A-S45		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-HI50A-S50		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
ADFW-HI63A-S5		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
ADFW-HI63A-S10		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
ADFW-HI63A-S15		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
ADFW-HI63A-S20		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
ADFW-HI63A-S25		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
ADFW-HI63A-S30		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
ADFW-HI63A-S35		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
ADFW-HI63A-S40		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
ADFW-HI63A-S45		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
ADFW-HI63A-S50		Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
AFW20		Legacy code (base model), order as AFW20A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW25		Legacy code (base model), order as AFW25A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW32		Legacy code (base model), order as AFW32A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW40		Legacy code (base model), order as AFW40A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW50		Legacy code (base model), order as AFW50A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW63		Legacy code (base model), order as AFW63A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW80		Legacy code (base model), order as AFW80A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW100		Legacy code (base model), order as AFW100A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW125		Legacy code (base model), order as AFW125A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW140		Legacy code (base model), order as AFW140A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW160		Legacy code (base model), order as AFW160A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
AFW200		Legacy code (base model), order as AFW200A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW20		Legacy code (base model), order as ADFW20A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW25		Legacy code (base model), order as ADFW25A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW32		Legacy code (base model), order as ADFW32A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW40		Legacy code (base model), order as ADFW40A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW50		Legacy code (base model), order as ADFW50A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW63		Legacy code (base model), order as ADFW63A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW80		Legacy code (base model), order as ADFW80A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW100		Legacy code (base model), order as ADFW100A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW125		Legacy code (base model), order as ADFW125A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW140		Legacy code (base model), order as ADFW140A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW160		Legacy code (base model), order as ADFW160A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
ADFW200		Legacy code (base model), order as ADFW200A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table

Compact CylindersKCC

1184 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KCC AFW/ADFW Thin Cylinder (Double Rod, Bore 20-200)

Brand KCC·Compact Cylinders

Available part numbers (1184)

AFW20A-S5, AFW20A-S10, AFW20A-S15, AFW20A-S20, AFW20A-S25, AFW20A-S30, AFW20A-S35, AFW20A-S40, AFW20A-S45, AFW20A-S50 + 1174 more — see full table ↓

How to order

Send the KCC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	AFW20A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW20A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW20A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW20A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW20A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW20A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW20A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW20A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW20A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW20A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW20B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW20B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW20B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW20B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW20B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW20B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW20B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW20B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW20B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW20B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW25A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW25A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW25A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW25A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW25A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW25A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW25A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW25A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW25A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW25A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW25B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW25B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW25B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW25B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW25B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW25B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW25B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW25B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW25B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW25B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW32A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW32A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW32A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW32A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW32A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW32A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW32A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW32A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW32A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW32A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW32B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW32B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW32B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW32B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW32B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW32B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW32B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW32B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW32B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW32B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW40A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW40A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW40A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW40A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW40A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW40A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW40A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW40A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW40A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW40A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW40B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW40B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW40B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW40B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW40B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW40B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW40B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW40B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW40B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW40B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW50A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW50A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW50A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW50A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW50A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW50A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW50A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW50A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW50A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW50A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW50B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW50B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW50B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW50B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW50B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW50B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW50B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW50B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW50B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW50B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW63A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW63A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW63A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW63A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW63A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW63A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW63A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW63A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW63A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW63A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW63B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW63B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW63B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW63B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW63B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW63B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW63B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW63B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW63B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW63B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW80A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW80A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW80A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW80A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW80A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW80A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW80A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW80A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW80A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW80A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW80B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW80B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW80B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW80B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW80B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW80B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW80B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW80B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW80B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW80B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW100A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW100A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW100A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW100A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW100A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW100A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW100A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW100A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW100A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW100A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW100B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW100B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW100B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW100B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW100B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW100B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW100B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW100B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW100B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW100B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW125A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW125A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW125A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW125A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW125A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW125A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW125A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW125A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW125A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW125A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW125B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW125B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW125B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW125B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW125B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW125B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW125B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW125B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW125B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW125B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW140A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW140A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW140A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW140A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW140A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW140A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW140A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW140A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW140A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW140A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW140B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW140B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW140B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW140B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW140B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW140B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW140B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW140B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW140B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW140B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW160A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW160A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW160A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW160A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW160A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW160A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW160A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW160A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW160A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW160A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW160B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW160B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW160B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW160B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW160B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW160B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW160B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW160B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW160B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW160B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW200A-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW200A-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW200A-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW200A-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW200A-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW200A-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW200A-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW200A-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW200A-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW200A-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW200B-S5	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	AFW200B-S10	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	AFW200B-S15	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	AFW200B-S20	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	AFW200B-S25	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	AFW200B-S30	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	AFW200B-S35	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	AFW200B-S40	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	AFW200B-S45	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	AFW200B-S50	Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	AFW-LB20A-S5	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB20A-S10	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB20A-S15	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB20A-S20	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB20A-S25	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB20A-S30	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB20A-S35	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB20A-S40	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB20A-S45	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB20A-S50	Magnet: No \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-LB25A-S5	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB25A-S10	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB25A-S15	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB25A-S20	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB25A-S25	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB25A-S30	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB25A-S35	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB25A-S40	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB25A-S45	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB25A-S50	Magnet: No \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-LB32A-S5	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB32A-S10	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB32A-S15	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB32A-S20	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB32A-S25	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB32A-S30	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB32A-S35	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB32A-S40	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB32A-S45	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB32A-S50	Magnet: No \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-LB40A-S5	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB40A-S10	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB40A-S15	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB40A-S20	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB40A-S25	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB40A-S30	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB40A-S35	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB40A-S40	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB40A-S45	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB40A-S50	Magnet: No \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-LB50A-S5	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB50A-S10	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB50A-S15	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB50A-S20	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB50A-S25	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB50A-S30	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB50A-S35	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB50A-S40	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB50A-S45	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB50A-S50	Magnet: No \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-LB63A-S5	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB63A-S10	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB63A-S15	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB63A-S20	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB63A-S25	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB63A-S30	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB63A-S35	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB63A-S40	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB63A-S45	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB63A-S50	Magnet: No \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-LB80A-S5	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB80A-S10	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB80A-S15	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB80A-S20	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB80A-S25	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB80A-S30	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB80A-S35	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB80A-S40	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB80A-S45	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB80A-S50	Magnet: No \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-LB100A-S5	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-LB100A-S10	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-LB100A-S15	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-LB100A-S20	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-LB100A-S25	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-LB100A-S30	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-LB100A-S35	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-LB100A-S40	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-LB100A-S45	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-LB100A-S50	Magnet: No \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA20A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA20A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA20A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA20A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA20A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA20A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA20A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA20A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA20A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA20A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA25A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA25A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA25A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA25A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA25A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA25A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA25A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA25A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA25A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA25A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA32A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA32A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA32A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA32A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA32A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA32A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA32A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA32A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA32A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA32A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA40A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA40A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA40A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA40A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA40A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA40A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA40A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA40A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA40A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA40A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA50A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA50A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA50A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA50A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA50A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA50A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA50A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA50A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA50A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA50A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA63A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA63A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA63A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA63A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA63A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA63A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA63A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA63A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA63A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA63A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA80A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA80A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA80A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA80A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA80A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA80A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA80A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA80A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA80A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA80A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FA100A-S5	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FA100A-S10	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FA100A-S15	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FA100A-S20	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FA100A-S25	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FA100A-S30	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FA100A-S35	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FA100A-S40	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FA100A-S45	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FA100A-S50	Magnet: No \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB20A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB20A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB20A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB20A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB20A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB20A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB20A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB20A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB20A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB20A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB25A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB25A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB25A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB25A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB25A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB25A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB25A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB25A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB25A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB25A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB32A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB32A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB32A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB32A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB32A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB32A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB32A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB32A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB32A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB32A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB40A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB40A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB40A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB40A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB40A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB40A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB40A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB40A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB40A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB40A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB50A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB50A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB50A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB50A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB50A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB50A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB50A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB50A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB50A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB50A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB63A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB63A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB63A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB63A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB63A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB63A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB63A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB63A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB63A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB63A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB80A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB80A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB80A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB80A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB80A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB80A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB80A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB80A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB80A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB80A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-FB100A-S5	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-FB100A-S10	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-FB100A-S15	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-FB100A-S20	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-FB100A-S25	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-FB100A-S30	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-FB100A-S35	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-FB100A-S40	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-FB100A-S45	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-FB100A-S50	Magnet: No \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB20A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB20A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB20A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB20A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB20A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB20A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB20A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB20A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB20A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB20A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB25A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB25A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB25A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB25A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB25A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB25A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB25A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB25A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB25A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB25A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB32A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB32A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB32A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB32A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB32A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB32A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB32A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB32A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB32A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB32A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB40A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB40A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB40A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB40A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB40A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB40A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB40A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB40A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB40A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB40A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB50A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB50A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB50A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB50A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB50A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB50A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB50A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB50A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB50A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB50A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB63A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB63A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB63A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB63A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB63A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB63A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB63A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB63A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB63A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB63A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB80A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB80A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB80A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB80A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB80A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB80A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB80A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB80A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB80A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB80A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-CB100A-S5	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-CB100A-S10	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-CB100A-S15	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-CB100A-S20	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-CB100A-S25	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-CB100A-S30	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-CB100A-S35	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-CB100A-S40	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-CB100A-S45	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-CB100A-S50	Magnet: No \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-HI50A-S5	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-HI50A-S10	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-HI50A-S15	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-HI50A-S20	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-HI50A-S25	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-HI50A-S30	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-HI50A-S35	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-HI50A-S40	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-HI50A-S45	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-HI50A-S50	Magnet: No \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW-HI63A-S5	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	AFW-HI63A-S10	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	AFW-HI63A-S15	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	AFW-HI63A-S20	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	AFW-HI63A-S25	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	AFW-HI63A-S30	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	AFW-HI63A-S35	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	AFW-HI63A-S40	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	AFW-HI63A-S45	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	AFW-HI63A-S50	Magnet: No \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW20A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW20A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW20A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW20A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW20A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW20A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW20A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW20A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW20A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW20A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW20B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW20B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW20B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW20B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW20B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW20B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW20B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW20B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW20B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW20B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW25A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW25A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW25A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW25A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW25A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW25A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW25A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW25A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW25A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW25A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW25B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW25B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW25B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW25B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW25B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW25B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW25B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW25B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW25B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW25B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW32A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW32A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW32A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW32A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW32A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW32A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW32A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW32A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW32A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW32A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW32B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW32B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW32B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW32B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW32B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW32B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW32B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW32B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW32B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW32B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW40A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW40A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW40A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW40A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW40A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW40A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW40A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW40A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW40A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW40A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW40B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW40B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW40B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW40B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW40B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW40B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW40B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW40B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW40B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW40B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW50A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW50A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW50A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW50A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW50A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW50A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW50A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW50A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW50A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW50A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW50B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW50B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW50B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW50B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW50B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW50B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW50B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW50B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW50B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW50B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW63A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW63A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW63A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW63A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW63A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW63A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW63A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW63A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW63A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW63A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW63B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW63B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW63B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW63B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW63B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW63B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW63B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW63B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW63B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW63B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW80A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW80A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW80A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW80A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW80A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW80A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW80A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW80A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW80A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW80A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW80B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW80B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW80B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW80B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW80B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW80B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW80B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW80B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW80B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW80B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW100A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW100A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW100A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW100A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW100A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW100A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW100A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW100A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW100A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW100A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW100B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW100B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW100B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW100B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW100B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW100B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW100B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW100B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW100B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW100B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW125A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW125A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW125A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW125A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW125A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW125A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW125A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW125A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW125A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW125A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW125B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW125B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW125B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW125B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW125B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW125B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW125B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW125B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW125B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW125B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW140A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW140A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW140A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW140A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW140A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW140A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW140A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW140A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW140A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW140A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW140B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW140B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW140B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW140B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW140B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW140B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW140B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW140B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW140B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW140B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW160A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW160A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW160A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW160A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW160A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW160A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW160A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW160A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW160A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW160A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW160B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW160B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW160B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW160B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW160B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW160B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW160B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW160B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW160B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW160B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW200A-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW200A-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW200A-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW200A-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW200A-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW200A-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW200A-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW200A-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW200A-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW200A-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW200B-S5	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 5 mm
	ADFW200B-S10	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 10 mm
	ADFW200B-S15	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 15 mm
	ADFW200B-S20	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 20 mm
	ADFW200B-S25	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 25 mm
	ADFW200B-S30	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 30 mm
	ADFW200B-S35	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 35 mm
	ADFW200B-S40	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 40 mm
	ADFW200B-S45	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 45 mm
	ADFW200B-S50	Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Through-hole \| Stroke: 50 mm
	ADFW-LB20A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB20A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB20A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB20A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB20A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB20A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB20A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB20A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB20A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB20A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-LB25A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB25A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB25A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB25A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB25A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB25A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB25A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB25A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB25A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB25A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-LB32A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB32A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB32A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB32A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB32A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB32A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB32A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB32A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB32A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB32A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-LB40A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB40A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB40A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB40A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB40A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB40A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB40A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB40A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB40A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB40A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-LB50A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB50A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB50A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB50A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB50A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB50A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB50A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB50A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB50A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB50A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-LB63A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB63A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB63A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB63A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB63A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB63A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB63A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB63A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB63A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB63A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-LB80A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB80A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB80A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB80A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB80A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB80A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB80A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB80A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB80A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB80A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-LB100A-S5	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-LB100A-S10	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-LB100A-S15	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-LB100A-S20	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-LB100A-S25	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-LB100A-S30	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-LB100A-S35	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-LB100A-S40	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-LB100A-S45	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-LB100A-S50	Magnet: Yes \| Mounting: Foot \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA20A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA20A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA20A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA20A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA20A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA20A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA20A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA20A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA20A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA20A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA25A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA25A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA25A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA25A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA25A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA25A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA25A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA25A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA25A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA25A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA32A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA32A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA32A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA32A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA32A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA32A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA32A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA32A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA32A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA32A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA40A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA40A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA40A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA40A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA40A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA40A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA40A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA40A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA40A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA40A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA50A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA50A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA50A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA50A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA50A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA50A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA50A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA50A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA50A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA50A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA63A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA63A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA63A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA63A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA63A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA63A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA63A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA63A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA63A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA63A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA80A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA80A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA80A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA80A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA80A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA80A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA80A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA80A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA80A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA80A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FA100A-S5	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FA100A-S10	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FA100A-S15	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FA100A-S20	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FA100A-S25	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FA100A-S30	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FA100A-S35	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FA100A-S40	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FA100A-S45	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FA100A-S50	Magnet: Yes \| Mounting: Rod-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB20A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB20A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB20A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB20A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB20A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB20A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB20A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB20A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB20A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB20A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB25A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB25A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB25A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB25A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB25A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB25A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB25A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB25A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB25A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB25A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB32A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB32A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB32A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB32A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB32A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB32A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB32A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB32A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB32A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB32A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB40A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB40A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB40A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB40A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB40A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB40A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB40A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB40A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB40A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB40A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB50A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB50A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB50A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB50A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB50A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB50A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB50A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB50A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB50A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB50A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB63A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB63A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB63A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB63A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB63A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB63A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB63A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB63A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB63A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB63A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB80A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB80A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB80A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB80A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB80A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB80A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB80A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB80A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB80A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB80A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-FB100A-S5	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-FB100A-S10	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-FB100A-S15	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-FB100A-S20	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-FB100A-S25	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-FB100A-S30	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-FB100A-S35	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-FB100A-S40	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-FB100A-S45	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-FB100A-S50	Magnet: Yes \| Mounting: Head-end flange \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB20A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB20A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB20A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB20A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB20A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB20A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB20A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB20A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB20A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB20A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB25A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB25A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB25A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB25A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB25A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB25A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB25A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB25A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB25A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB25A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB32A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB32A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB32A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB32A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB32A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB32A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB32A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB32A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB32A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB32A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB40A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB40A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB40A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB40A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB40A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB40A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB40A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB40A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB40A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB40A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB50A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB50A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB50A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB50A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB50A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB50A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB50A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB50A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB50A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB50A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB63A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB63A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB63A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB63A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB63A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB63A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB63A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB63A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB63A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB63A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB80A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB80A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB80A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB80A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB80A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB80A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB80A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB80A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB80A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB80A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-CB100A-S5	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-CB100A-S10	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-CB100A-S15	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-CB100A-S20	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-CB100A-S25	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-CB100A-S30	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-CB100A-S35	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-CB100A-S40	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-CB100A-S45	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-CB100A-S50	Magnet: Yes \| Mounting: Double clevis \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-HI50A-S5	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-HI50A-S10	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-HI50A-S15	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-HI50A-S20	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-HI50A-S25	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-HI50A-S30	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-HI50A-S35	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-HI50A-S40	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-HI50A-S45	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-HI50A-S50	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	ADFW-HI63A-S5	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	ADFW-HI63A-S10	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	ADFW-HI63A-S15	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	ADFW-HI63A-S20	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	ADFW-HI63A-S25	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	ADFW-HI63A-S30	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	ADFW-HI63A-S35	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	ADFW-HI63A-S40	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	ADFW-HI63A-S45	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	ADFW-HI63A-S50	Magnet: Yes \| Mounting: Head-end spigot \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	AFW20	Legacy code (base model), order as AFW20A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW25	Legacy code (base model), order as AFW25A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW32	Legacy code (base model), order as AFW32A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW40	Legacy code (base model), order as AFW40A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW50	Legacy code (base model), order as AFW50A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW63	Legacy code (base model), order as AFW63A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW80	Legacy code (base model), order as AFW80A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW100	Legacy code (base model), order as AFW100A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW125	Legacy code (base model), order as AFW125A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW140	Legacy code (base model), order as AFW140A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW160	Legacy code (base model), order as AFW160A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	AFW200	Legacy code (base model), order as AFW200A-S<stroke> \| Magnet: No \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW20	Legacy code (base model), order as ADFW20A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 20 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW25	Legacy code (base model), order as ADFW25A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 25 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW32	Legacy code (base model), order as ADFW32A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 32 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW40	Legacy code (base model), order as ADFW40A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 40 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW50	Legacy code (base model), order as ADFW50A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 50 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW63	Legacy code (base model), order as ADFW63A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 63 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW80	Legacy code (base model), order as ADFW80A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 80 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW100	Legacy code (base model), order as ADFW100A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 100 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW125	Legacy code (base model), order as ADFW125A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 125 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW140	Legacy code (base model), order as ADFW140A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 140 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW160	Legacy code (base model), order as ADFW160A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 160 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table
	ADFW200	Legacy code (base model), order as ADFW200A-S<stroke> \| Magnet: Yes \| Mounting: Standard (no bracket) \| Bore: 200 mm \| Mounting holes: Both ends tapped \| Stroke: See stroke table

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

KCC AFW/ADFW Thin Cylinder (Double Rod, Bore 20-200)
