KCC B10-AFK/ADFK Non-Rotating Thin Cylinder (Battery Industry Version) - Part 2

KCC B10-AFK/ADFK series thin pneumatic cylinder with non-rotating rod in the battery-industry B10 version, single or double rod, bore ø16 to ø63 mm.

Key features

B10 battery-industry version of the KCC AFK/ADFK non-rotating thin cylinder
Rod anti-rotation accuracy ±0.8° (ø16) to ±0.5° (ø40-ø63); avoid applying rotational torque to the rod
AFK/AFWK without magnet, ADFK/ADFWK with built-in magnet for auto switches ordered as a suffix
Mounting: standard (ø16-ø63); foot LB, rod flange FA, head flange FB, double clevis CB for ø40, ø50, ø63; mounting holes A tapped or B through
Options as code suffixes: male rod end N, knuckle joints I/Y, switch quantity, multi-stage TS/TW and adjustable-stroke ASJ/BSJ

Specifications

Action	Double acting
Fluid	Air
Proof pressure	1.5 MPa
Max. operating pressure	1.0 MPa
Min. operating pressure	0.07 MPa (ø16), 0.05 MPa (ø20 to ø63)
Ambient and fluid temperature	-10 to 70°C without switch, -10 to 60°C with switch
Piston speed	50 to 500 mm/s
Lubrication	Not required (non-lube)
Allowable rotation torque	0.15 / 0.2 / 0.25 / 0.44 N·m max. by bore
Stroke tolerance	+1.0/0 mm
Source	KCC catalog Book01_B10-AF,ADF.pdf, p. 24-28

B10-ADFK-CB40A-S75		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 75 mm
B10-ADFK-CB40A-S100		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 100 mm
B10-ADFK-CB40B-S5		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFK-CB40B-S10		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFK-CB40B-S15		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFK-CB40B-S20		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFK-CB40B-S25		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFK-CB40B-S30		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFK-CB40B-S35		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFK-CB40B-S40		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFK-CB40B-S45		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFK-CB40B-S50		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFK-CB40B-S75		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 75 mm
B10-ADFK-CB40B-S100		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 100 mm
B10-ADFK-CB50A-S5		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFK-CB50A-S10		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFK-CB50A-S15		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFK-CB50A-S20		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFK-CB50A-S25		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFK-CB50A-S30		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFK-CB50A-S35		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFK-CB50A-S40		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFK-CB50A-S45		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFK-CB50A-S50		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFK-CB50A-S75		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 75 mm
B10-ADFK-CB50A-S100		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 100 mm
B10-ADFK-CB50B-S5		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFK-CB50B-S10		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFK-CB50B-S15		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFK-CB50B-S20		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFK-CB50B-S25		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFK-CB50B-S30		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFK-CB50B-S35		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFK-CB50B-S40		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFK-CB50B-S45		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFK-CB50B-S50		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFK-CB50B-S75		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 75 mm
B10-ADFK-CB50B-S100		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 100 mm
B10-ADFK-CB63A-S5		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFK-CB63A-S10		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFK-CB63A-S15		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFK-CB63A-S20		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFK-CB63A-S25		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFK-CB63A-S30		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFK-CB63A-S35		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFK-CB63A-S40		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFK-CB63A-S45		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFK-CB63A-S50		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFK-CB63A-S75		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 75 mm
B10-ADFK-CB63A-S100		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 100 mm
B10-ADFK-CB63B-S5		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFK-CB63B-S10		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFK-CB63B-S15		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFK-CB63B-S20		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFK-CB63B-S25		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFK-CB63B-S30		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFK-CB63B-S35		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFK-CB63B-S40		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFK-CB63B-S45		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFK-CB63B-S50		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFK-CB63B-S75		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 75 mm
B10-ADFK-CB63B-S100		Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 100 mm
B10-AFWK-20A-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-20A-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-20A-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-20A-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-20A-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-20A-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-20A-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-20A-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-20A-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-20A-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-20B-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-20B-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-20B-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-20B-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-20B-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-20B-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-20B-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-20B-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-20B-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-20B-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-25A-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-25A-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-25A-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-25A-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-25A-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-25A-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-25A-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-25A-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-25A-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-25A-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-25B-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-25B-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-25B-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-25B-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-25B-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-25B-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-25B-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-25B-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-25B-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-25B-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-32A-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-32A-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-32A-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-32A-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-32A-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-32A-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-32A-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-32A-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-32A-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-32A-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-32B-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-32B-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-32B-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-32B-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-32B-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-32B-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-32B-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-32B-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-32B-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-32B-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-40A-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-40A-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-40A-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-40A-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-40A-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-40A-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-40A-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-40A-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-40A-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-40A-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-40B-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-40B-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-40B-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-40B-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-40B-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-40B-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-40B-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-40B-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-40B-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-40B-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-50A-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-50A-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-50A-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-50A-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-50A-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-50A-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-50A-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-50A-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-50A-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-50A-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-50B-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-50B-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-50B-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-50B-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-50B-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-50B-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-50B-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-50B-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-50B-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-50B-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-63A-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-63A-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-63A-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-63A-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-63A-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-63A-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-63A-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-63A-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-63A-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-63A-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-63B-S5		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-63B-S10		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-63B-S15		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-63B-S20		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-63B-S25		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-63B-S30		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-63B-S35		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-63B-S40		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-63B-S45		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-63B-S50		Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-LB40A-S5		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-LB40A-S10		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-LB40A-S15		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-LB40A-S20		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-LB40A-S25		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-LB40A-S30		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-LB40A-S35		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-LB40A-S40		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-LB40A-S45		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-LB40A-S50		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-LB40B-S5		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-LB40B-S10		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-LB40B-S15		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-LB40B-S20		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-LB40B-S25		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-LB40B-S30		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-LB40B-S35		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-LB40B-S40		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-LB40B-S45		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-LB40B-S50		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-LB50A-S5		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-LB50A-S10		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-LB50A-S15		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-LB50A-S20		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-LB50A-S25		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-LB50A-S30		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-LB50A-S35		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-LB50A-S40		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-LB50A-S45		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-LB50A-S50		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-LB50B-S5		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-LB50B-S10		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-LB50B-S15		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-LB50B-S20		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-LB50B-S25		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-LB50B-S30		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-LB50B-S35		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-LB50B-S40		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-LB50B-S45		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-LB50B-S50		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-LB63A-S5		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-LB63A-S10		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-LB63A-S15		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-LB63A-S20		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-LB63A-S25		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-LB63A-S30		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-LB63A-S35		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-LB63A-S40		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-LB63A-S45		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-LB63A-S50		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-LB63B-S5		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-LB63B-S10		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-LB63B-S15		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-LB63B-S20		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-LB63B-S25		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-LB63B-S30		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-LB63B-S35		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-LB63B-S40		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-LB63B-S45		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-LB63B-S50		Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-FA40A-S5		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-FA40A-S10		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-FA40A-S15		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-FA40A-S20		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-FA40A-S25		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-FA40A-S30		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-FA40A-S35		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-FA40A-S40		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-FA40A-S45		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-FA40A-S50		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-FA40B-S5		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-FA40B-S10		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-FA40B-S15		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-FA40B-S20		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-FA40B-S25		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-FA40B-S30		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-FA40B-S35		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-FA40B-S40		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-FA40B-S45		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-FA40B-S50		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-FA50A-S5		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-FA50A-S10		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-FA50A-S15		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-FA50A-S20		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-FA50A-S25		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-FA50A-S30		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-FA50A-S35		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-FA50A-S40		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-FA50A-S45		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-FA50A-S50		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-FA50B-S5		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-FA50B-S10		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-FA50B-S15		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-FA50B-S20		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-FA50B-S25		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-FA50B-S30		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-FA50B-S35		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-FA50B-S40		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-FA50B-S45		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-FA50B-S50		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-FA63A-S5		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-FA63A-S10		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-FA63A-S15		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-FA63A-S20		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-FA63A-S25		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-FA63A-S30		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-FA63A-S35		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-FA63A-S40		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-FA63A-S45		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-FA63A-S50		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-FA63B-S5		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-FA63B-S10		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-FA63B-S15		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-FA63B-S20		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-FA63B-S25		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-FA63B-S30		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-FA63B-S35		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-FA63B-S40		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-FA63B-S45		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-FA63B-S50		Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-FB40A-S5		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-FB40A-S10		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-FB40A-S15		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-FB40A-S20		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-FB40A-S25		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-FB40A-S30		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-FB40A-S35		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-FB40A-S40		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-FB40A-S45		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-FB40A-S50		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-FB40B-S5		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-FB40B-S10		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-FB40B-S15		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-FB40B-S20		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-FB40B-S25		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-FB40B-S30		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-FB40B-S35		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-FB40B-S40		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-FB40B-S45		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-FB40B-S50		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-FB50A-S5		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-FB50A-S10		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-FB50A-S15		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-FB50A-S20		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-FB50A-S25		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-FB50A-S30		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-FB50A-S35		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-FB50A-S40		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-FB50A-S45		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-FB50A-S50		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-FB50B-S5		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-FB50B-S10		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-FB50B-S15		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-FB50B-S20		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-FB50B-S25		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-FB50B-S30		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-FB50B-S35		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-FB50B-S40		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-FB50B-S45		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-FB50B-S50		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-FB63A-S5		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-FB63A-S10		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-FB63A-S15		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-FB63A-S20		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-FB63A-S25		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-FB63A-S30		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-FB63A-S35		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-FB63A-S40		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-FB63A-S45		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-FB63A-S50		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-FB63B-S5		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-FB63B-S10		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-FB63B-S15		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-FB63B-S20		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-FB63B-S25		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-FB63B-S30		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-FB63B-S35		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-FB63B-S40		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-FB63B-S45		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-FB63B-S50		Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-CB40A-S5		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-CB40A-S10		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-CB40A-S15		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-CB40A-S20		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-CB40A-S25		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-CB40A-S30		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-CB40A-S35		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-CB40A-S40		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-CB40A-S45		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-CB40A-S50		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-CB40B-S5		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-CB40B-S10		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-CB40B-S15		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-CB40B-S20		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-CB40B-S25		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-CB40B-S30		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-CB40B-S35		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-CB40B-S40		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-CB40B-S45		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-CB40B-S50		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-CB50A-S5		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-CB50A-S10		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-CB50A-S15		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-CB50A-S20		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-CB50A-S25		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-CB50A-S30		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-CB50A-S35		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-CB50A-S40		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-CB50A-S45		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-CB50A-S50		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-CB50B-S5		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-CB50B-S10		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-CB50B-S15		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-CB50B-S20		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-CB50B-S25		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-CB50B-S30		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-CB50B-S35		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-CB50B-S40		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-CB50B-S45		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-CB50B-S50		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFWK-CB63A-S5		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-AFWK-CB63A-S10		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-AFWK-CB63A-S15		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-AFWK-CB63A-S20		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-AFWK-CB63A-S25		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-AFWK-CB63A-S30		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-AFWK-CB63A-S35		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-AFWK-CB63A-S40		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-AFWK-CB63A-S45		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-AFWK-CB63A-S50		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-AFWK-CB63B-S5		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-AFWK-CB63B-S10		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-AFWK-CB63B-S15		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-AFWK-CB63B-S20		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-AFWK-CB63B-S25		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-AFWK-CB63B-S30		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-AFWK-CB63B-S35		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-AFWK-CB63B-S40		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-AFWK-CB63B-S45		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-AFWK-CB63B-S50		Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-20A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-20A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-20A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-20A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-20A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-20A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-20A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-20A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-20A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-20A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-20B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-20B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-20B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-20B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-20B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-20B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-20B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-20B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-20B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-20B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-25A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-25A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-25A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-25A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-25A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-25A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-25A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-25A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-25A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-25A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-25B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-25B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-25B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-25B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-25B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-25B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-25B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-25B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-25B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-25B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-32A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-32A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-32A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-32A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-32A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-32A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-32A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-32A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-32A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-32A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-32B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-32B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-32B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-32B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-32B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-32B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-32B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-32B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-32B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-32B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-40A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-40A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-40A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-40A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-40A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-40A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-40A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-40A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-40A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-40A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-40B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-40B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-40B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-40B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-40B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-40B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-40B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-40B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-40B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-40B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-50A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-50A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-50A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-50A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-50A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-50A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-50A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-50A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-50A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-50A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-50B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-50B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-50B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-50B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-50B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-50B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-50B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-50B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-50B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-50B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-63A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-63A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-63A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-63A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-63A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-63A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-63A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-63A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-63A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-63A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-63B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-63B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-63B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-63B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-63B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-63B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-63B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-63B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-63B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-63B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-LB40A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-LB40A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-LB40A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-LB40A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-LB40A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-LB40A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-LB40A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-LB40A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-LB40A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-LB40A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-LB40B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-LB40B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-LB40B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-LB40B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-LB40B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-LB40B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-LB40B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-LB40B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-LB40B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-LB40B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-LB50A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-LB50A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-LB50A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-LB50A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-LB50A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-LB50A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-LB50A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-LB50A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-LB50A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-LB50A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-LB50B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-LB50B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-LB50B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-LB50B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-LB50B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-LB50B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-LB50B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-LB50B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-LB50B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-LB50B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-LB63A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-LB63A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-LB63A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-LB63A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-LB63A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-LB63A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-LB63A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-LB63A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-LB63A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-LB63A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-LB63B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-LB63B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-LB63B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-LB63B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-LB63B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-LB63B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-LB63B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-LB63B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-LB63B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-LB63B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-FA40A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-FA40A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-FA40A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-FA40A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-FA40A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-FA40A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-FA40A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-FA40A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-FA40A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-FA40A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-FA40B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-FA40B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-FA40B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-FA40B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-FA40B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-FA40B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-FA40B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-FA40B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-FA40B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-FA40B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-FA50A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-FA50A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-FA50A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-FA50A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-FA50A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-FA50A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-FA50A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-FA50A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-FA50A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-FA50A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-FA50B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-FA50B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-FA50B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-FA50B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-FA50B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-FA50B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-FA50B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-FA50B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-FA50B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-FA50B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-FA63A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-FA63A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-FA63A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-FA63A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-FA63A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-FA63A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-FA63A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-FA63A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-FA63A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-FA63A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-FA63B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-FA63B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-FA63B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-FA63B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-FA63B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-FA63B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-FA63B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-FA63B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-FA63B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-FA63B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-FB40A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-FB40A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-FB40A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-FB40A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-FB40A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-FB40A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-FB40A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-FB40A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-FB40A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-FB40A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-FB40B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-FB40B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-FB40B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-FB40B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-FB40B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-FB40B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-FB40B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-FB40B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-FB40B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-FB40B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-FB50A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-FB50A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-FB50A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-FB50A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-FB50A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-FB50A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-FB50A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-FB50A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-FB50A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-FB50A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-FB50B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-FB50B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-FB50B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-FB50B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-FB50B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-FB50B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-FB50B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-FB50B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-FB50B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-FB50B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-FB63A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-FB63A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-FB63A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-FB63A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-FB63A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-FB63A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-FB63A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-FB63A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-FB63A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-FB63A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-FB63B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-FB63B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-FB63B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-FB63B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-FB63B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-FB63B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-FB63B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-FB63B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-FB63B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-FB63B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-CB40A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-CB40A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-CB40A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-CB40A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-CB40A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-CB40A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-CB40A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-CB40A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-CB40A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-CB40A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-CB40B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-CB40B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-CB40B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-CB40B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-CB40B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-CB40B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-CB40B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-CB40B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-CB40B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-CB40B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-CB50A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-CB50A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-CB50A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-CB50A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-CB50A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-CB50A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-CB50A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-CB50A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-CB50A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-CB50A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-CB50B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-CB50B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-CB50B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-CB50B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-CB50B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-CB50B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-CB50B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-CB50B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-CB50B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-CB50B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-ADFWK-CB63A-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
B10-ADFWK-CB63A-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
B10-ADFWK-CB63A-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
B10-ADFWK-CB63A-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
B10-ADFWK-CB63A-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
B10-ADFWK-CB63A-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
B10-ADFWK-CB63A-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
B10-ADFWK-CB63A-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
B10-ADFWK-CB63A-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
B10-ADFWK-CB63A-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
B10-ADFWK-CB63B-S5		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
B10-ADFWK-CB63B-S10		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
B10-ADFWK-CB63B-S15		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
B10-ADFWK-CB63B-S20		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
B10-ADFWK-CB63B-S25		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
B10-ADFWK-CB63B-S30		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
B10-ADFWK-CB63B-S35		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
B10-ADFWK-CB63B-S40		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
B10-ADFWK-CB63B-S45		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
B10-ADFWK-CB63B-S50		Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
B10-AFK-16		Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFK-20		Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFK-25		Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFK-32		Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFK-40		Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFK-50		Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFK-63		Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFWK-16		Legacy code, base model (ø16 double rod not in standard stroke table) \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFWK-20		Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFWK-25		Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFWK-32		Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFWK-40		Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFWK-50		Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
B10-AFWK-63		Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFK-16		Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFK-20		Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFK-25		Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFK-32		Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFK-40		Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFK-50		Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFK-63		Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFWK-16		Legacy code, base model (ø16 double rod not in standard stroke table) \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFWK-20		Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFWK-25		Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFWK-32		Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFWK-40		Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFWK-50		Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
B10-ADFWK-63		Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify

Compact CylindersKCC

810 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KCC B10-AFK/ADFK Non-Rotating Thin Cylinder (Battery Industry Version) - Part 2

Brand KCC·Compact Cylinders

Available part numbers (810)

B10-ADFK-CB40A-S75, B10-ADFK-CB40A-S100, B10-ADFK-CB40B-S5, B10-ADFK-CB40B-S10, B10-ADFK-CB40B-S15, B10-ADFK-CB40B-S20, B10-ADFK-CB40B-S25, B10-ADFK-CB40B-S30, B10-ADFK-CB40B-S35, B10-ADFK-CB40B-S40 + 800 more — see full table ↓

How to order

Send the KCC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	B10-ADFK-CB40A-S75	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 75 mm
	B10-ADFK-CB40A-S100	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 100 mm
	B10-ADFK-CB40B-S5	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFK-CB40B-S10	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFK-CB40B-S15	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFK-CB40B-S20	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFK-CB40B-S25	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFK-CB40B-S30	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFK-CB40B-S35	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFK-CB40B-S40	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFK-CB40B-S45	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFK-CB40B-S50	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFK-CB40B-S75	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 75 mm
	B10-ADFK-CB40B-S100	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 100 mm
	B10-ADFK-CB50A-S5	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFK-CB50A-S10	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFK-CB50A-S15	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFK-CB50A-S20	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFK-CB50A-S25	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFK-CB50A-S30	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFK-CB50A-S35	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFK-CB50A-S40	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFK-CB50A-S45	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFK-CB50A-S50	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFK-CB50A-S75	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 75 mm
	B10-ADFK-CB50A-S100	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 100 mm
	B10-ADFK-CB50B-S5	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFK-CB50B-S10	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFK-CB50B-S15	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFK-CB50B-S20	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFK-CB50B-S25	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFK-CB50B-S30	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFK-CB50B-S35	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFK-CB50B-S40	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFK-CB50B-S45	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFK-CB50B-S50	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFK-CB50B-S75	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 75 mm
	B10-ADFK-CB50B-S100	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 100 mm
	B10-ADFK-CB63A-S5	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFK-CB63A-S10	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFK-CB63A-S15	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFK-CB63A-S20	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFK-CB63A-S25	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFK-CB63A-S30	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFK-CB63A-S35	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFK-CB63A-S40	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFK-CB63A-S45	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFK-CB63A-S50	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFK-CB63A-S75	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 75 mm
	B10-ADFK-CB63A-S100	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 100 mm
	B10-ADFK-CB63B-S5	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFK-CB63B-S10	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFK-CB63B-S15	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFK-CB63B-S20	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFK-CB63B-S25	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFK-CB63B-S30	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFK-CB63B-S35	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFK-CB63B-S40	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFK-CB63B-S45	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFK-CB63B-S50	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFK-CB63B-S75	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 75 mm
	B10-ADFK-CB63B-S100	Rod: Single rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 100 mm
	B10-AFWK-20A-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-20A-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-20A-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-20A-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-20A-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-20A-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-20A-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-20A-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-20A-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-20A-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-20B-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-20B-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-20B-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-20B-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-20B-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-20B-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-20B-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-20B-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-20B-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-20B-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-25A-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-25A-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-25A-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-25A-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-25A-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-25A-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-25A-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-25A-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-25A-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-25A-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-25B-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-25B-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-25B-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-25B-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-25B-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-25B-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-25B-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-25B-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-25B-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-25B-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-32A-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-32A-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-32A-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-32A-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-32A-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-32A-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-32A-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-32A-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-32A-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-32A-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-32B-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-32B-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-32B-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-32B-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-32B-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-32B-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-32B-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-32B-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-32B-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-32B-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-40A-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-40A-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-40A-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-40A-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-40A-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-40A-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-40A-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-40A-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-40A-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-40A-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-40B-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-40B-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-40B-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-40B-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-40B-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-40B-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-40B-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-40B-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-40B-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-40B-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-50A-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-50A-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-50A-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-50A-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-50A-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-50A-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-50A-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-50A-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-50A-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-50A-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-50B-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-50B-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-50B-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-50B-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-50B-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-50B-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-50B-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-50B-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-50B-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-50B-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-63A-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-63A-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-63A-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-63A-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-63A-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-63A-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-63A-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-63A-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-63A-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-63A-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-63B-S5	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-63B-S10	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-63B-S15	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-63B-S20	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-63B-S25	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-63B-S30	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-63B-S35	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-63B-S40	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-63B-S45	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-63B-S50	Rod: Double rod \| Magnet: No \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-LB40A-S5	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-LB40A-S10	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-LB40A-S15	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-LB40A-S20	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-LB40A-S25	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-LB40A-S30	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-LB40A-S35	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-LB40A-S40	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-LB40A-S45	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-LB40A-S50	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-LB40B-S5	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-LB40B-S10	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-LB40B-S15	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-LB40B-S20	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-LB40B-S25	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-LB40B-S30	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-LB40B-S35	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-LB40B-S40	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-LB40B-S45	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-LB40B-S50	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-LB50A-S5	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-LB50A-S10	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-LB50A-S15	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-LB50A-S20	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-LB50A-S25	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-LB50A-S30	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-LB50A-S35	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-LB50A-S40	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-LB50A-S45	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-LB50A-S50	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-LB50B-S5	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-LB50B-S10	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-LB50B-S15	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-LB50B-S20	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-LB50B-S25	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-LB50B-S30	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-LB50B-S35	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-LB50B-S40	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-LB50B-S45	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-LB50B-S50	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-LB63A-S5	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-LB63A-S10	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-LB63A-S15	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-LB63A-S20	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-LB63A-S25	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-LB63A-S30	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-LB63A-S35	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-LB63A-S40	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-LB63A-S45	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-LB63A-S50	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-LB63B-S5	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-LB63B-S10	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-LB63B-S15	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-LB63B-S20	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-LB63B-S25	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-LB63B-S30	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-LB63B-S35	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-LB63B-S40	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-LB63B-S45	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-LB63B-S50	Rod: Double rod \| Magnet: No \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-FA40A-S5	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-FA40A-S10	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-FA40A-S15	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-FA40A-S20	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-FA40A-S25	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-FA40A-S30	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-FA40A-S35	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-FA40A-S40	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-FA40A-S45	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-FA40A-S50	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-FA40B-S5	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-FA40B-S10	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-FA40B-S15	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-FA40B-S20	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-FA40B-S25	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-FA40B-S30	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-FA40B-S35	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-FA40B-S40	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-FA40B-S45	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-FA40B-S50	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-FA50A-S5	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-FA50A-S10	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-FA50A-S15	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-FA50A-S20	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-FA50A-S25	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-FA50A-S30	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-FA50A-S35	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-FA50A-S40	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-FA50A-S45	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-FA50A-S50	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-FA50B-S5	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-FA50B-S10	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-FA50B-S15	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-FA50B-S20	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-FA50B-S25	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-FA50B-S30	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-FA50B-S35	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-FA50B-S40	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-FA50B-S45	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-FA50B-S50	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-FA63A-S5	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-FA63A-S10	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-FA63A-S15	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-FA63A-S20	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-FA63A-S25	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-FA63A-S30	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-FA63A-S35	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-FA63A-S40	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-FA63A-S45	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-FA63A-S50	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-FA63B-S5	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-FA63B-S10	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-FA63B-S15	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-FA63B-S20	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-FA63B-S25	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-FA63B-S30	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-FA63B-S35	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-FA63B-S40	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-FA63B-S45	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-FA63B-S50	Rod: Double rod \| Magnet: No \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-FB40A-S5	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-FB40A-S10	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-FB40A-S15	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-FB40A-S20	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-FB40A-S25	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-FB40A-S30	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-FB40A-S35	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-FB40A-S40	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-FB40A-S45	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-FB40A-S50	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-FB40B-S5	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-FB40B-S10	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-FB40B-S15	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-FB40B-S20	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-FB40B-S25	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-FB40B-S30	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-FB40B-S35	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-FB40B-S40	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-FB40B-S45	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-FB40B-S50	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-FB50A-S5	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-FB50A-S10	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-FB50A-S15	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-FB50A-S20	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-FB50A-S25	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-FB50A-S30	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-FB50A-S35	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-FB50A-S40	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-FB50A-S45	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-FB50A-S50	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-FB50B-S5	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-FB50B-S10	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-FB50B-S15	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-FB50B-S20	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-FB50B-S25	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-FB50B-S30	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-FB50B-S35	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-FB50B-S40	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-FB50B-S45	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-FB50B-S50	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-FB63A-S5	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-FB63A-S10	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-FB63A-S15	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-FB63A-S20	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-FB63A-S25	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-FB63A-S30	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-FB63A-S35	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-FB63A-S40	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-FB63A-S45	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-FB63A-S50	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-FB63B-S5	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-FB63B-S10	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-FB63B-S15	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-FB63B-S20	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-FB63B-S25	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-FB63B-S30	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-FB63B-S35	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-FB63B-S40	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-FB63B-S45	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-FB63B-S50	Rod: Double rod \| Magnet: No \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-CB40A-S5	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-CB40A-S10	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-CB40A-S15	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-CB40A-S20	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-CB40A-S25	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-CB40A-S30	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-CB40A-S35	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-CB40A-S40	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-CB40A-S45	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-CB40A-S50	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-CB40B-S5	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-CB40B-S10	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-CB40B-S15	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-CB40B-S20	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-CB40B-S25	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-CB40B-S30	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-CB40B-S35	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-CB40B-S40	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-CB40B-S45	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-CB40B-S50	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-CB50A-S5	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-CB50A-S10	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-CB50A-S15	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-CB50A-S20	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-CB50A-S25	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-CB50A-S30	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-CB50A-S35	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-CB50A-S40	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-CB50A-S45	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-CB50A-S50	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-CB50B-S5	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-CB50B-S10	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-CB50B-S15	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-CB50B-S20	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-CB50B-S25	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-CB50B-S30	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-CB50B-S35	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-CB50B-S40	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-CB50B-S45	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-CB50B-S50	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFWK-CB63A-S5	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-AFWK-CB63A-S10	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-AFWK-CB63A-S15	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-AFWK-CB63A-S20	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-AFWK-CB63A-S25	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-AFWK-CB63A-S30	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-AFWK-CB63A-S35	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-AFWK-CB63A-S40	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-AFWK-CB63A-S45	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-AFWK-CB63A-S50	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-AFWK-CB63B-S5	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-AFWK-CB63B-S10	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-AFWK-CB63B-S15	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-AFWK-CB63B-S20	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-AFWK-CB63B-S25	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-AFWK-CB63B-S30	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-AFWK-CB63B-S35	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-AFWK-CB63B-S40	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-AFWK-CB63B-S45	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-AFWK-CB63B-S50	Rod: Double rod \| Magnet: No \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-20A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-20A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-20A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-20A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-20A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-20A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-20A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-20A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-20A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-20A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-20B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-20B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-20B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-20B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-20B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-20B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-20B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-20B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-20B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-20B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø20 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-25A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-25A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-25A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-25A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-25A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-25A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-25A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-25A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-25A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-25A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-25B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-25B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-25B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-25B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-25B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-25B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-25B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-25B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-25B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-25B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø25 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-32A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-32A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-32A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-32A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-32A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-32A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-32A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-32A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-32A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-32A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-32B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-32B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-32B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-32B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-32B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-32B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-32B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-32B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-32B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-32B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø32 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-40A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-40A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-40A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-40A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-40A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-40A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-40A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-40A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-40A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-40A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-40B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-40B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-40B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-40B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-40B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-40B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-40B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-40B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-40B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-40B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-50A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-50A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-50A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-50A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-50A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-50A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-50A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-50A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-50A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-50A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-50B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-50B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-50B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-50B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-50B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-50B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-50B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-50B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-50B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-50B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-63A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-63A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-63A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-63A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-63A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-63A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-63A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-63A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-63A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-63A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-63B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-63B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-63B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-63B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-63B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-63B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-63B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-63B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-63B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-63B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Standard \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-LB40A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-LB40A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-LB40A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-LB40A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-LB40A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-LB40A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-LB40A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-LB40A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-LB40A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-LB40A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-LB40B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-LB40B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-LB40B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-LB40B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-LB40B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-LB40B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-LB40B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-LB40B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-LB40B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-LB40B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-LB50A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-LB50A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-LB50A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-LB50A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-LB50A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-LB50A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-LB50A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-LB50A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-LB50A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-LB50A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-LB50B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-LB50B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-LB50B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-LB50B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-LB50B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-LB50B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-LB50B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-LB50B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-LB50B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-LB50B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-LB63A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-LB63A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-LB63A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-LB63A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-LB63A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-LB63A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-LB63A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-LB63A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-LB63A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-LB63A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-LB63B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-LB63B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-LB63B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-LB63B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-LB63B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-LB63B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-LB63B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-LB63B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-LB63B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-LB63B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Foot \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-FA40A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-FA40A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-FA40A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-FA40A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-FA40A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-FA40A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-FA40A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-FA40A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-FA40A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-FA40A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-FA40B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-FA40B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-FA40B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-FA40B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-FA40B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-FA40B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-FA40B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-FA40B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-FA40B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-FA40B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-FA50A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-FA50A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-FA50A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-FA50A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-FA50A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-FA50A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-FA50A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-FA50A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-FA50A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-FA50A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-FA50B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-FA50B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-FA50B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-FA50B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-FA50B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-FA50B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-FA50B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-FA50B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-FA50B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-FA50B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-FA63A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-FA63A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-FA63A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-FA63A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-FA63A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-FA63A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-FA63A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-FA63A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-FA63A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-FA63A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-FA63B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-FA63B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-FA63B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-FA63B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-FA63B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-FA63B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-FA63B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-FA63B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-FA63B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-FA63B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Rod flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-FB40A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-FB40A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-FB40A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-FB40A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-FB40A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-FB40A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-FB40A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-FB40A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-FB40A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-FB40A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-FB40B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-FB40B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-FB40B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-FB40B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-FB40B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-FB40B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-FB40B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-FB40B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-FB40B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-FB40B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-FB50A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-FB50A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-FB50A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-FB50A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-FB50A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-FB50A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-FB50A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-FB50A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-FB50A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-FB50A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-FB50B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-FB50B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-FB50B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-FB50B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-FB50B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-FB50B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-FB50B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-FB50B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-FB50B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-FB50B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-FB63A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-FB63A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-FB63A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-FB63A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-FB63A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-FB63A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-FB63A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-FB63A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-FB63A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-FB63A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-FB63B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-FB63B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-FB63B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-FB63B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-FB63B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-FB63B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-FB63B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-FB63B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-FB63B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-FB63B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Head flange \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-CB40A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-CB40A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-CB40A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-CB40A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-CB40A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-CB40A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-CB40A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-CB40A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-CB40A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-CB40A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-CB40B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-CB40B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-CB40B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-CB40B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-CB40B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-CB40B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-CB40B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-CB40B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-CB40B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-CB40B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø40 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-CB50A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-CB50A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-CB50A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-CB50A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-CB50A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-CB50A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-CB50A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-CB50A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-CB50A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-CB50A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-CB50B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-CB50B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-CB50B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-CB50B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-CB50B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-CB50B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-CB50B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-CB50B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-CB50B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-CB50B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø50 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-ADFWK-CB63A-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 5 mm
	B10-ADFWK-CB63A-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 10 mm
	B10-ADFWK-CB63A-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 15 mm
	B10-ADFWK-CB63A-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 20 mm
	B10-ADFWK-CB63A-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 25 mm
	B10-ADFWK-CB63A-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 30 mm
	B10-ADFWK-CB63A-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 35 mm
	B10-ADFWK-CB63A-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 40 mm
	B10-ADFWK-CB63A-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 45 mm
	B10-ADFWK-CB63A-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Both ends tapped \| Stroke: 50 mm
	B10-ADFWK-CB63B-S5	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 5 mm
	B10-ADFWK-CB63B-S10	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 10 mm
	B10-ADFWK-CB63B-S15	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 15 mm
	B10-ADFWK-CB63B-S20	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 20 mm
	B10-ADFWK-CB63B-S25	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 25 mm
	B10-ADFWK-CB63B-S30	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 30 mm
	B10-ADFWK-CB63B-S35	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 35 mm
	B10-ADFWK-CB63B-S40	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 40 mm
	B10-ADFWK-CB63B-S45	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 45 mm
	B10-ADFWK-CB63B-S50	Rod: Double rod \| Magnet: Yes \| Mounting: Double clevis \| Bore: ø63 mm \| Mounting holes: Through hole \| Stroke: 50 mm
	B10-AFK-16	Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFK-20	Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFK-25	Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFK-32	Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFK-40	Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFK-50	Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFK-63	Legacy code, base model \| Rod: Single rod \| Magnet: No \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFWK-16	Legacy code, base model (ø16 double rod not in standard stroke table) \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFWK-20	Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFWK-25	Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFWK-32	Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFWK-40	Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFWK-50	Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-AFWK-63	Legacy code, base model \| Rod: Double rod \| Magnet: No \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFK-16	Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFK-20	Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFK-25	Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFK-32	Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFK-40	Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFK-50	Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFK-63	Legacy code, base model \| Rod: Single rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFWK-16	Legacy code, base model (ø16 double rod not in standard stroke table) \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø16 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFWK-20	Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø20 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFWK-25	Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø25 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFWK-32	Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø32 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFWK-40	Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø40 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFWK-50	Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø50 mm \| Mounting holes: Specify \| Stroke: Specify
	B10-ADFWK-63	Legacy code, base model \| Rod: Double rod \| Magnet: Yes \| Mounting: Specify \| Bore: ø63 mm \| Mounting holes: Specify \| Stroke: Specify

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →

Item added to your cart

KCC B10-AFK/ADFK Non-Rotating Thin Cylinder (Battery Industry Version) - Part 2
