KOINO KH-2204EB / KH-2204ER Ø22 Illuminated Mushroom Push Button Switches

KOINO KH-2204EB / KH-2204ER Ø22 Illuminated Mushroom Push Button Switches

Ø22 mm illuminated mushroom-head push button switches in momentary or push-lock turn-release versions with filament or LED lamp.

Key features

  • KC, CE, UL/cUL and CCC certified
  • Easy maintenance; contact blocks can be added
  • Wiring from both directions; terminals with protective cover

Specifications

Mounting Hole Ø22 mm
Contact Rating 125 VAC 10 A, 250 VAC 6 A (resistive)
Terminal Screw M3.5
Operating Temperature -15 to +50 °C (no icing)
Electrical Life 100,000 operations min.
Mechanical Life 500,000 operations
Transformer Secondary 6 V
Button Colours R/G/Y
Material Body: ABS, Contact block: Nylon
KH-2204EB-1 Operation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: 110 VAC (transformer) | Protection: IP56
KH-2204EB-2 Operation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: 220 VAC (transformer) | Protection: IP56
KH-2204EB-3 Operation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: 230 VAC (transformer) | Protection: IP56
KH-2204LEB-1 Operation: Mushroom momentary push button | Light Source: LED | Voltage: 110 VAC (transformer) | Protection: IP56
KH-2204LEB-2 Operation: Mushroom momentary push button | Light Source: LED | Voltage: 220 VAC (transformer) | Protection: IP56
KH-2204LEB-3 Operation: Mushroom momentary push button | Light Source: LED | Voltage: 230 VAC (transformer) | Protection: IP56
KH-2204EB-TL Operation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: Full voltage | Protection: IP56
KH-2204LEB-TL Operation: Mushroom momentary push button | Light Source: LED | Voltage: Full voltage | Protection: IP56
KH-2204ER-1 Operation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: 110 VAC (transformer) | Protection: IP50
KH-2204ER-2 Operation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: 220 VAC (transformer) | Protection: IP50
KH-2204ER-3 Operation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: 230 VAC (transformer) | Protection: IP50
KH-2204LER-1 Operation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: 110 VAC (transformer) | Protection: IP50
KH-2204LER-2 Operation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: 220 VAC (transformer) | Protection: IP50
KH-2204LER-3 Operation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: 230 VAC (transformer) | Protection: IP50
KH-2204ER-TL Operation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: Full voltage | Protection: IP50
KH-2204LER-TL Operation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: Full voltage | Protection: IP50
Push Button SwitchesKOINO
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOINO KH-2204EB / KH-2204ER Ø22 Illuminated Mushroom Push Button Switches

Brand KOINO·Push Button Switches

Available part numbers (16)

KH-2204EB-1, KH-2204EB-2, KH-2204EB-3, KH-2204LEB-1, KH-2204LEB-2, KH-2204LEB-3, KH-2204EB-TL, KH-2204LEB-TL, KH-2204ER-1, KH-2204ER-2 + 6 more — see full table ↓

How to order

Send the KOINO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KH-2204EB-1Operation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: 110 VAC (transformer) | Protection: IP56
KH-2204EB-2Operation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: 220 VAC (transformer) | Protection: IP56
KH-2204EB-3Operation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: 230 VAC (transformer) | Protection: IP56
KH-2204LEB-1Operation: Mushroom momentary push button | Light Source: LED | Voltage: 110 VAC (transformer) | Protection: IP56
KH-2204LEB-2Operation: Mushroom momentary push button | Light Source: LED | Voltage: 220 VAC (transformer) | Protection: IP56
KH-2204LEB-3Operation: Mushroom momentary push button | Light Source: LED | Voltage: 230 VAC (transformer) | Protection: IP56
KH-2204EB-TLOperation: Mushroom momentary push button | Light Source: Filament lamp | Voltage: Full voltage | Protection: IP56
KH-2204LEB-TLOperation: Mushroom momentary push button | Light Source: LED | Voltage: Full voltage | Protection: IP56
KH-2204ER-1Operation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: 110 VAC (transformer) | Protection: IP50
KH-2204ER-2Operation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: 220 VAC (transformer) | Protection: IP50
KH-2204ER-3Operation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: 230 VAC (transformer) | Protection: IP50
KH-2204LER-1Operation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: 110 VAC (transformer) | Protection: IP50
KH-2204LER-2Operation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: 220 VAC (transformer) | Protection: IP50
KH-2204LER-3Operation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: 230 VAC (transformer) | Protection: IP50
KH-2204ER-TLOperation: Mushroom push-lock, turn-release | Light Source: Filament lamp | Voltage: Full voltage | Protection: IP50
KH-2204LER-TLOperation: Mushroom push-lock, turn-release | Light Source: LED | Voltage: Full voltage | Protection: IP50
