KOINO KH-3040 Ø30 Guarded Push Button Switch

Ø30 mm push button switch with a protective guard ring around the button.

Key features

KC and CCC certified
Ring protects the button
Contact arrangements of 2a+2b or more made to order

Specifications

Insulation Resistance	100 MΩ min. (500 VDC)
Rated Insulation Voltage	600 V AC or DC
Contact Resistance	30 mΩ max. (initial)
Dielectric Strength	1,500 VAC 50/60 Hz for 1 min
Operating Temperature	-25 to +50 °C (no icing)
Humidity	45-85% RH
Protection	IP40
Contact	1a+1b
Mounting Hole	Ø30 mm
Contact Rating	250 VAC 6 A (resistive)
Thermal Current	10 A max.
Mechanical Life	250,000 operations (1,800 ops/h)

KH-3040

Operation: Momentary push button
