KOINO KPB16 Ø16 K Series Non-Illuminated Push Button Switches

KOINO KPB16 Ø16 K Series Non-Illuminated Push Button Switches

Ø16 mm modular (separable contact block) non-illuminated push button switches in round, square and rectangular shapes, momentary or alternate action.

Key features

  • KC, UL/cUL, CE and CCC certified
  • Silver-alloy contacts suitable from general machinery to low-current circuits
  • Tested to elevator safety standard KS C IEC 60947-5-1 (Annex K: KPB16SM-R1/R2)
  • Max. ambient temperature rating 50 °C

Specifications

Mounting Hole Ø16 mm
Contact Rating 250 VAC 3 A (resistive)
Contacts Up to 2c
Contact Resistance 30 mΩ max. (initial)
Insulation Resistance 100 MΩ min. (500 VDC)
Dielectric Strength 1,000 VAC 50/60 Hz for 1 min
Operating Temperature -15 to +55 °C (no icing)
Electrical Life 100,000 operations min.
Protection IP40
Button Colour Red, Green, Yellow, Orange, White, Blue (R/G/Y/O/W/B)
Material Body: Nylon glass, Contact block: PBT, Ring: Nylon glass, Button: PC
Certification KC, UL/cUL (UL508), CE, CCC
KPB16M Shape: Round, head Ø18 mm (standard) | Operation: Momentary push button
KPB16AT Shape: Round, head Ø18 mm (standard) | Operation: Push-lock, push-release
KPB160M Shape: Round, head Ø25 mm (flush) | Operation: Momentary push button
KPB160AT Shape: Round, head Ø25 mm (flush) | Operation: Push-lock, push-release
KPB161M Shape: Round, head Ø25 mm (projecting) | Operation: Momentary push button
KPB161AT Shape: Round, head Ø25 mm (projecting) | Operation: Push-lock, push-release
KPB16SM Shape: Square | Operation: Momentary push button
KPB16SAT Shape: Square | Operation: Push-lock, push-release
KPB16RM Shape: Rectangular | Operation: Momentary push button
KPB16RAT Shape: Rectangular | Operation: Push-lock, push-release
Push Button SwitchesKOINO
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOINO KPB16 Ø16 K Series Non-Illuminated Push Button Switches

Brand KOINO·Push Button Switches

Available part numbers (10)

KPB16M, KPB16AT, KPB160M, KPB160AT, KPB161M, KPB161AT, KPB16SM, KPB16SAT, KPB16RM, KPB16RAT

How to order

Send the KOINO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KPB16MShape: Round, head Ø18 mm (standard) | Operation: Momentary push button
KPB16ATShape: Round, head Ø18 mm (standard) | Operation: Push-lock, push-release
KPB160MShape: Round, head Ø25 mm (flush) | Operation: Momentary push button
KPB160ATShape: Round, head Ø25 mm (flush) | Operation: Push-lock, push-release
KPB161MShape: Round, head Ø25 mm (projecting) | Operation: Momentary push button
KPB161ATShape: Round, head Ø25 mm (projecting) | Operation: Push-lock, push-release
KPB16SMShape: Square | Operation: Momentary push button
KPB16SATShape: Square | Operation: Push-lock, push-release
KPB16RMShape: Rectangular | Operation: Momentary push button
KPB16RATShape: Rectangular | Operation: Push-lock, push-release
