Kyongbo Electric Watt/Watt-hour Transducer TAP / TVP-W

Kyongbo Electric Watt/Watt-hour Transducer TAP / TVP-W

Combined transducer giving a DC analog output proportional to active power plus a pulse output proportional to active energy.

Key features

  • Combined analog power output and energy pulse output
  • Order-made input, output, aux. power and frequency available
  • VT ratio, CT ratio and pulse ratio specified at order (max. 3600 pulses)

Specifications

Accuracy 0.2% of span (power); 0.2% at rated V and I (energy)
Ripple 0.5% P-P of span
Response Time 0.4 s (0-99%)
Pulse Time approx. 100 ms
Pulse Rate 1P/1kWh, 10P/1kWh, 100P/1kWh, 1P/10kWh, 1P/100kWh
Burden Voltage 0.5 VA/phase, current 1.0 VA/phase
Auxiliary Power AC 110 / 220 V
Frequency 50 or 60 Hz
TAP-1W1C Circuit: 1P2W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 700 g | Case: TL
TAP-1W2C Circuit: 1P2W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 700 g | Case: TL
TAP-2W1C Circuit: 1P3W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-2W2C Circuit: 1P3W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-3W1C Circuit: 3P3W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-3W2C Circuit: 3P3W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-4W1C Circuit: 3P4W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
TAP-4W2C Circuit: 3P4W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
TVP-1W1C Circuit: 1P2W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 730 g | Case: TL
TVP-1W2C Circuit: 1P2W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 730 g | Case: TL
TVP-2W1C Circuit: 1P3W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-2W2C Circuit: 1P3W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-3W1C Circuit: 3P3W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-3W2C Circuit: 3P3W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-4W1C Circuit: 3P4W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
TVP-4W2C Circuit: 3P4W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
Power TransducersKyongbo Electric
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Kyongbo Electric Watt/Watt-hour Transducer TAP / TVP-W

Brand Kyongbo Electric·Power Transducers

Available part numbers (16)

TAP-1W1C, TAP-1W2C, TAP-2W1C, TAP-2W2C, TAP-3W1C, TAP-3W2C, TAP-4W1C, TAP-4W2C, TVP-1W1C, TVP-1W2C + 6 more — see full table ↓

How to order

Send the Kyongbo Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TAP-1W1CCircuit: 1P2W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 700 g | Case: TL
TAP-1W2CCircuit: 1P2W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 700 g | Case: TL
TAP-2W1CCircuit: 1P3W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-2W2CCircuit: 1P3W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-3W1CCircuit: 3P3W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-3W2CCircuit: 3P3W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TAP-4W1CCircuit: 3P4W | Analog Output: DC 0-1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
TAP-4W2CCircuit: 3P4W | Analog Output: DC 4-20 mA | Load: < 500 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
TVP-1W1CCircuit: 1P2W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 730 g | Case: TL
TVP-1W2CCircuit: 1P2W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 730 g | Case: TL
TVP-2W1CCircuit: 1P3W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-2W2CCircuit: 1P3W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-3W1CCircuit: 3P3W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-3W2CCircuit: 3P3W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 890 g | Case: TL
TVP-4W1CCircuit: 3P4W | Analog Output: DC 0-1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
TVP-4W2CCircuit: 3P4W | Analog Output: DC 1-5 V | Load: > 1 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Pulse Output: Relay contact AC 110 V 1 A PF 1.0 | Weight: approx. 1040 g | Case: TL
