• LS Electric EBE50Fb-K Beyond X Residential MCB/RCBO (E-type RCBO (Hydraulic-Magnetic), 50AF RCBO, 2.5kA @ 220V AC / 1.5kA @ 380V AC, 15, 30mA, 3~50A)
1 1

LS Electric EBE50Fb-K Beyond X Residential MCB/RCBO (E-type RCBO (Hydraulic-Magnetic), 50AF RCBO, 2.5kA @ 220V AC / 1.5kA @ 380V AC, 15, 30mA, 3~50A)

LS Electric EBE50Fb-K Beyond X Residential MCB/RCBO (E-type RCBO (Hydraulic-Magnetic), 50AF RCBO, 2.5kA @ 220V AC / 1.5kA @ 380V AC, 15, 30mA, 3~50A)

LS ELECTRIC Beyond X Residential MCB/RCBO EBE50Fb-K family. | Application: Residential distribution panel (RCBO). | Frame: 50AF | Type: E-type RCBO (Hydraulic-Magnetic) | Trip method: Hydraulic-Magnetic + RCD | Trip curve: C (5~10×In) / D (10~20×In) | Breaking capacity Icn: 2.5kA @ 220V AC / 1.5kA @ 380V AC | Ics: 100% Icn | Sensitivity (I△n): 15, 30mA | Rated current (In): 3A, 6A, 10A, 16A, 20A, 32A, 40A, 50A | Pole: 2P / 3P | Mounting: Screw or DIN-Rail | Uimp: 4kV | Standard: KS C 4621 / IEC 61009 | 16 variants — see RFQ table for specific MPN.

Miniature Circuit BreakersLS Electric
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric EBE50Fb-K Beyond X Residential MCB/RCBO (E-type RCBO (Hydraulic-Magnetic), 50AF RCBO, 2.5kA @ 220V AC / 1.5kA @ 380V AC, 15, 30mA, 3~50A)

Brand LS Electric·Miniature Circuit Breakers

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
