Mitsubishi Electric - S-N150FN Class 2 Heat Resistant Magnetic Contactor (AC Operated, 140A Carrying, 140A AC-3 at 220V)

Mitsubishi Electric - S-N150FN Class 2 Heat Resistant Magnetic Contactor (AC Operated, 140A Carrying, 140A AC-3 at 220V)

Mitsubishi Electric MS-T/N series S-N150FN class 2 heat-resistant magnetic contactor for distribution boards and panelboards of dedicated emergency power receiving equipment.

Key features

  • Retains conduction and insulation function at high temperature during a fire so that power to fire fighting equipment continues, switching and carrying the heat-resistant rated current for 30 minutes under the one seventh fire temperature curve
  • Heat-resistant carrying current 140A, heat-resistant rated current 140A at 220V, 140A at 440V, 140A at 550V under AC-3 class and 140A at 220V, 140A at 440V under AC-1 class, 3a main contacts
  • AC operated coil, durability and outline dimensions the same as the standard product
  • Reversing type S-2XN150FN is available
  • Type approval number 2MC-99138
  • Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981

Specifications

Type Class 2 heat-resistant magnetic contactor for emergency power switchboards
Frame N150
Operation AC operated
Main Contact 3a
Heat Resistant Carrying Current 140A
Heat Resistant Rated Current AC-3 Class 140A at 220V, 140A at 440V, 140A at 550V
Heat Resistant Rated Current AC-1 Class 140A at 220V, 140A at 440V
DC Rated Current at DC48V 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class)
DC Rated Current at DC110V 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class)
DC Rated Current at DC220V 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class)
Durability Same as the standard product
Type Approval Number 2MC-99138
S-N150FN AC24V S-N150FN class 2 heat-resistant contactor, AC24V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC24V | Coil Rating: 24V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC24V S-2XN150FN class 2 heat-resistant contactor, AC24V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC24V | Coil Rating: 24V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC48V S-N150FN class 2 heat-resistant contactor, AC48V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC48V S-2XN150FN class 2 heat-resistant contactor, AC48V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC100V S-N150FN class 2 heat-resistant contactor, AC100V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC100V S-2XN150FN class 2 heat-resistant contactor, AC100V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC200V S-N150FN class 2 heat-resistant contactor, AC200V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC200V S-2XN150FN class 2 heat-resistant contactor, AC200V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC300V S-N150FN class 2 heat-resistant contactor, AC300V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC300V S-2XN150FN class 2 heat-resistant contactor, AC300V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC400V S-N150FN class 2 heat-resistant contactor, AC400V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC400V S-2XN150FN class 2 heat-resistant contactor, AC400V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC500V S-N150FN class 2 heat-resistant contactor, AC500V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC500V S-2XN150FN class 2 heat-resistant contactor, AC500V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
Magnetic ContactorsMitsubishi Electric
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - S-N150FN Class 2 Heat Resistant Magnetic Contactor (AC Operated, 140A Carrying, 140A AC-3 at 220V)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (14)

S-N150FN AC24V, S-2XN150FN AC24V, S-N150FN AC48V, S-2XN150FN AC48V, S-N150FN AC100V, S-2XN150FN AC100V, S-N150FN AC200V, S-2XN150FN AC200V, S-N150FN AC300V, S-2XN150FN AC300V + 4 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S-N150FN AC24VS-N150FN class 2 heat-resistant contactor, AC24V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC24V | Coil Rating: 24V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC24VS-2XN150FN class 2 heat-resistant contactor, AC24V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC24V | Coil Rating: 24V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC48VS-N150FN class 2 heat-resistant contactor, AC48V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC48VS-2XN150FN class 2 heat-resistant contactor, AC48V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC100VS-N150FN class 2 heat-resistant contactor, AC100V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC100VS-2XN150FN class 2 heat-resistant contactor, AC100V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC200VS-N150FN class 2 heat-resistant contactor, AC200V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC200VS-2XN150FN class 2 heat-resistant contactor, AC200V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC300VS-N150FN class 2 heat-resistant contactor, AC300V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC300VS-2XN150FN class 2 heat-resistant contactor, AC300V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC400VS-N150FN class 2 heat-resistant contactor, AC400V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC400VS-2XN150FN class 2 heat-resistant contactor, AC400V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-N150FN AC500VS-N150FN class 2 heat-resistant contactor, AC500V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XN150FN AC500VS-2XN150FN class 2 heat-resistant contactor, AC500V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: N150 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Heat Resistant Carrying Current: 140A | Heat Resistant Rated Current AC-3 Class: 140A at 220V, 140A at 440V, 140A at 550V | Heat Resistant Rated Current AC-1 Class: 140A at 220V, 140A at 440V | DC Rated Current at DC48V: 100A 2-pole series, 130A 3-pole series (DC2 and DC4 class), 120A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC110V: 80A 2-pole series, 120A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | DC Rated Current at DC220V: 60A 2-pole series, 80A 3-pole series (DC2 and DC4 class), 100A 2-pole series, 140A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-99138 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
